Swiss Type Turning Machine

Star SA-12

Condition: ready for operation (used), Year of construction: 2000, This Star SA-12 swiss type turning machine was manufactured in 2000. It features a workpiece conveyor SA12/16, 15° indexing of the main spindle, a 3-spindle cross-boring unit ER11, and a red signal light. Additionally, it includes an FMB minimag 3200 "A" and a Minimag feed channel. Consider the opportunity to buy this Star SA-12 swiss type turning machine. Contact us for more information. Bjdpsxrhd Eofx Af Hjdk Application Types Turning

Condition: excellent (used), Star SA-12 Swiss-Type Lathe Technical Specifications Rapid feed (X, Y, Z, ZB): 370 mm Maximum turning feed (X, Y, Z, ZB): 270 mm Smallest input unit (X, Y, Z, ZB): 120 mm Machining Capacity Maximum turning diameter: 13 mm Maximum headstock stroke: 140 mm Maximum drilling capacity: 7 mm Maximum tapping capacity: 7 mm Maximum thread cutting capacity: M6 x P1.0 Main Spindle Spindle speed: 500 – 12,000 rpm Drive: Spindle drive Main spindle motor: 2.2 / 3.7 kW Main spindle indexing angle: 1° or 15° Main spindle bore: 20 mm Tool slide Type: Linear slide Number of tools: 6 tools Number of driven tools: 3 tools (collet: ER 11) Driven tools Spindle speed: 1970 / 2330 rpm Max. drilling capacity: 4 mm Max. milling capacity: 4 mm Pick-up spindle Max. clamping diameter: 13 mm Max. part length for forward ejection: 85 mm Max. unclamping length: 30 mm Spindle speed: 500 – 8000 rpm Pick-up spindle motor: 0.5 kW Tool selection: 4 tools Max. drilling capacity: 4 mm Max. tapping capacity: M3 x P0.5 Power supply Voltage: 3-phase 200/220 V Frequency: 50/60 Hz Power: Average: 6.0 KVA SCOPE OF OFFER Among other things: (list not exhaustive): STAR SA-12 Swiss-Type Lathe Control: Fanuc Series 18i-T Fire Extinguishing System Coolant Tank Transformer LNS Bar Loader Exact scope of supply as per photo gallery Bsdpfjwi Ty Aex Af Hedk No liability is assumed for the accuracy, completeness, or timeliness of the information.

Condition: good (used), Year of construction: 1998, Star SA 12 Swiss-type lathe, year 1998, Fanuc control, bar capacity up to 15 mm, main spindle / sub-spindle with C-axis, 15° indexing, spindle speed main/sub-spindle 10,000/6,000 rpm, LNS bar feeder, horizontal tool carrier with 6 stations, 2 cross attachments for driven tools, 4 drilling stations. Bodpfx Afsxm Tnlo Hedk

Condition: used, Year of construction: 2003, operating hours: 43,000 h, machine/vehicle number: IntNr231372, STAR SA 12 CNC sliding headstock lathe, year of manufacture 2003 CNC control: FANUC 18i-T Operating hours: 43,000 Technical Specifications - Number of axes: 5 - Number of spindles: 2 MAIN SPINDLE - Maximum bar diameter: 12 mm - Z-axis travel distance: 100 mm - Spindle speed: 8,000 rpm - Spindle drive power: 2.2 kW - Number of tool stations: 13 SUB SPINDLE Bsdpfx Asxdy Tief Hjdk - Maximum bar diameter: 12 mm - Spindle speed: 8,000 rpm - Number of tool stations: 4 Includes FMB Minimag bar feeder. The machine can be inspected under power by prior appointment. Technical specifications and details are subject to change and error. Prior sale reserved!

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, turning diameter: 16 mm, rotational speed (max.): 12,000 rpm, bar passage: 12 mm, TECHNICAL DETAILS Turning diameter: 16 mm Bar capacity: 12 mm Control: Fanuc Series 18 i-T Main spindle speed range: 500 – 12,000 rpm Drilling capacity (stationary): 7 mm Thread cutting capacity (stationary): M6 × P1.0 Thread cutting capacity (driven tool): M3 × P0.5 Spindle stroke with stationary guide bushing: 135 mm Spindle stroke with gripper unit and stationary guide bushing: 120 mm Spindle stroke with rotary guide bushing: 100 mm Spindle stroke with gripper unit and rotary guide bushing: 90 mm Tool size: 10 mm × 95 mm – 125 mm / 6 tools Sub spindle Max. clamping diameter: 16 mm Speed range: 500 – 8,000 rpm Drilling capacity: 4 mm Thread cutting capacity: M3 × P0.5 EQUIPMENT - Bar feeder FMB Turbo 2-16 / 3200A - Chip conveyor Bdodpfewur Shjx Af Hjk
