CNC boring mill machine

TOS VARNSDORF WHN 13 CNC

Condition: good (used), Year of construction: 2013, Ref. -No.: 10636 Manufacturer: TOS VARNSDORF Type: WHN 13 CNC Year of construction: 2013 Type of control: CNC-Steuerung Control: Heidenhain 530 Storage location: Halberstadt Country of origin: Czech Republic X-Travel: 3500 mm Rodezc D E Ispfx Anpjw Y-Travel: 2000 mm Z-Travel: 1250 mm W-Axis: 800 mm B-Axis: 360 ° Table Load: 15.000 kg Tool Taper: SK 50 Turning Speeds: 1400 RPM Spindle Speed: 2000 RPM Table size: 1800 x 2200 mm Further information: - The control system was converted to a HEIDENHAIN 530i in 2013. - All drives were upgraded to digital. Thrust bearing replacement on the tower also renewed in 2013. - Accessories: - 3D probe - Heidenhain, large spindle support - 1x Heidenhain axis module (completely overhauled), - 1 new axis module is installed in the machine. - Newly packaged spare parts, covers from the machine. - All bearings have been replaced on the machine in recent years. - Tools and milling cutter heads are available. The machine is first-hand. The machine is still powered up and in production. The machine can be viewed by appointment.

Condition: used, Year of construction: 2001, Technical details: x-travel: 2500 mm y-travel: 1000 mm z-travel: 750 mm table surface area: 3220 x 1000 mm Workpiece weight approx.: 3000 kg spindle taper ISO: 50 milling spindle turning speeds: 20 - 5000 U/min feed speeds: 1- 30000 mm/min rapid traverse: 30 m/min total power requirement: 40 kW dimensions of the machine ca.: 6,9 x 4,1 x 3,7 m weight of the machine ca.: 21 t Rsdpfjvptmwox Anpjw with CNC HEIDENHAIN TNC 426 30-pockets autom. toolchanger RENISHAW measuring probe coolant attachment with TSC and chip conveyor diverse toolholders *

Condition: good (used), Year of construction: 2003, feed length X-axis: 3,500 mm, feed length Y-axis: 2,500 mm, feed length Z-axis: 1,250 mm, total length: 7,200 mm, total height: 5,300 mm, table width: 1,800 mm, total width: 6,800 mm, table length: 2,200 mm, workpiece weight (max.): 12,000 kg, Table type boring mill TOS VARNSDORF - WHN13CNC MACH-ID 9629 Make: TOS VARNSDORF Type: WHN13CNC Control: HeidenHain TNC430 Year: 2003 1e owner machine ca 16.000 Spil hours Chip conveyor Under power  Redpjy T E Itjfx Anpsw X - Travel: 3500mm Y - Travel: 2500mm Z - Travel: 1250mm W - Travel: 800mm Table Length: 2200mm Table Width: 1800mm Table load: 12000 Speeds / ranges: 2800Rpm Power: 37kW Spindle Taper: 50ISO/Bt/Mk Feed rate X-Axis: 10000mm/min. Feed rate Y-Axis: 10000mm/min. Feed rate Z-Axis: 10000mm/min. Feed rate W-Axis: 10000mm/min. Number of controlled axis:5 Length: 7200mm Width: 6800mm Height: 5300mm Weight: 36850kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2018, Heidenhain iTNC 640 CNC control Table dimensions: 1800 x 2200 mm Max. workpiece weight: 25,000 kg X-axis travel: 3,500 mm Y-axis travel: 2,500 mm Z-axis travel: 1,600 mm Spindle/cone diameter: 130 mm Speed range: 3,000 RPM Spindle power: 46 kW Max. torque at 100% duty cycle: 1,000 Nm Machine weight: 38,000 kg Power-on hours: 16,631 Spindle hours: 4,430 Accessories: – Controlled B-axis – 40-position tool changer / chain-type magazine – Belt filter system with high-pressure pump – Chip conveyor Rsdpfx Anjw Hbnvspsw – Heidenhain TS 460 workpiece probe – Automatic milling head type HUI 50 – Movable operator cabin Yp = 1,600 mm, Zp = 600 mm – Centralized lubrication system – Pfannenberg oil cooler – Documentation

Condition: used, Year of construction: 2017, pipe diameter (max.): 80 mm, mandrel length: 4,500 mm, Mandrel bending machine S8004 ----- For the production of dimensionally accurate pipe geometries with bending radii of up to 1.5XD → maximum bending performance pipe 76 x 4 mm (400 N/mm²) → maximum bending performance pipe 60 x 60 x 3 mm (400 N/mm²) → maximum bending performance pipe 76 x 2.9 mm (stainless steel) → total connected load 7 kW → pipe length 4.5 mtr Robust and durable steel construction in a force-locking connection - no construction susceptible to torsion due to, for example, the split construction of the bending head and mandrel carrier. Maintenance-free electromechanical drive of the bending axis. The touch display of the control enables simple and intuitive programming and use of the system. After the pipe has been pushed on, it is fixed in the carriage by the chuck. This enables the pipe to be positioned precisely and thus the creation of dimensionally accurate geometries. The standard also includes checking the pipe geometry before the bending process: If the bending process is started in the wrong position, the machine does not give permission for this. This prevents incorrect operation. Optional additional features provide more convenience and increase the output and thus the efficiency of the system. Data is exchanged from the optional pipe calculation program TBS-3D (PC version) via USB stick or via FTP access from the computer to the machine control system. USB or LAN connectors (RJ45) are available as standard. Existing pipe geometries can be converted quickly and easily, for example, using the STEP format. Standard equipment: → Electromechanical drive of the bending axis 4 kW → Speed 2.9 rpm (=17°/sec.) → Bending direction left → Bending angle resolution 0.1° → Max. bending radius 200 mm → Bending shaft diameter 50 mm → Electronic length measurement ±0.1mm → Electronic twist measurement ±0.1° → Manual stop system (overtravel stops in length) → Manual locking system (15° in twist) → Three-jaw chuck for locking the pipe in the carriage → External control panel PLC control: → Touchscreen 10.1" → ETH 10/100, X2X Link, USB → Foot switch operation → Data transfer via network (W)LAN or USB → Material database Rsdpfottah Rsx Anpsw Unique graphic programming: Simple geometries can be calculated directly on the machine. The control calculates the feed values directly after entering the length and angle and the bending angles. Hydraulics: → Hydraulic power 3 kW → Hydraulic pipe clamping with adjustable clamping pressure → Programmable early mandrel retraction Options (can be ordered as additional equipment): → Variable bending speed using frequency converters or servo motors → Automatic tool retraction (manual or controlled) → Pneumatic chuck → Automatic mandrel lubrication → Pneumatic stop system (length + twist) → Mobile version (rollers) → Radius extension Pictures show new machine

Condition: good (used), travel distance X-axis: 3,500 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 800 mm, table load: 12,000 kg, total height: 3,900 mm, total length: 7,200 mm, total width: 5,200 mm, table length: 1,800 mm, table width: 1,600 mm, feed rate X-axis: 8,000 m/min, feed rate Y-axis: 8,000 m/min, feed rate Z-axis: 8,000 m/min, rotational speed (max.): 2,000 rpm, Table type boring mill TOS VARNSDORF - WHN 13 CNC MACH-ID 9612 Make: TOS VARNSDORF Type: WHN 13 CNC Control: Heidenhain TNC415 X - Travel: 3500mm Y - Travel: 2000mm Z - Travel: 800mm W - Travel: 1000mm Table Length: 1800mm Table Width: 1600mm Table load: 12 Speeds / ranges:2000Rpm Power: 37kW Spindle Taper: ISO50ISO/Bt/Mk Feed rate X-Axis:8000mm/min. Feed rate Y-Axis:8000mm/min. Feed rate Z-Axis:8000mm/min. Feed rate W-Axis:8000mm/min. Length: 7200mm Width: 5200mm Height: 3900mm Weight: 34500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details! Rjdpfxoy H Dahs Anpow

Condition: ready for operation (used), travel distance X-axis: 3,500 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,250 mm, table load: 12,000 kg, spindle diameter: 130 mm, spindle speed (min.): 10 rpm, spindle speed (max.): 2,500 rpm, table length: 2,200 mm, table width: 1,800 mm, feed length X-axis: 3,500 mm, feed length Z-axis: 1,250 mm, Spindle diameter: 130 mm X-axis travel: 3,500 mm Y-axis travel: 2,500 mm Z-axis travel: 1,250 mm B-axis (table): 360º W-axis travel (quill): 800 mm Table size: 2,200 x 1,800 mm Max. table load: 12,000 kg CNC: Heidenhain 424 M Spindle speed (2 ranges): 10 - 2,500 rpm Coolant tank: Yes Rjdpfxey Hgvrs Anpew Tool holder: BT 50 Weight: 42,000 kg Dimensions: 6,460 x 6,960 x 4,400

Condition: refurbished (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 6,800 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,200 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, 5-axis gantry machining center CYPORT CP 6830 Travels X/Y/Z: 6,800 / 3,000 / 1,200 mm Gantry passage Y/Z: 3,276 / 1,405 mm Rapid Traverse X/Y/Z 30/30/30m/min 2-axis-NC-swivel head M-Series of German manufacturer Cytec: Swivel range A-axis : +/-110° Rsdpfoigrikjx Anpjw Swivel range C-axis +/- 360° Powerful milling spindle of German manufacturer Cytec: Tool taper: HSK-A100 Speed: 8,000 rpm Power: 50/64 kW (100%/40% DC) Torque: 240/300 Nm (100%/40% DC) Control: HEIDENHAIN TNC 530 (Heidenhain TNC 640 / 7 possible) 5-axis path control DXF-converter CAD-Viewer KinematicsOPT Energy efficiency certificate Remote Service Tool magazine: Number of pockets: 39 pcs. HSK-A63 max. tool diameter: 125/175 mm max. tool length: 300 mm max. tool weight: 15 kg Coolant system Manufacturer: KNOLL Tank volume: 1,600 L external coolant supply: 20 bar internal coolant supply: 50 bar Paper band filter, Spray gun Chip conveyor Coolant-airblast-changeover Work piece measuring system: Touch probe BLUM TC 60 - radio controlled Working area coverage Safety light sensors Documentation CE-certification Made in Germany

Condition: used, Year of construction: 2007, x-travel 900 mm y-travel 300 mm z-travel 1000 mm control Siemens Sinumerik 840D max. workpiece diameter 1600 mm max. module 20 mm tip circle diameter 350 mm Milling arbour diameter 375 mm Total closing value 80 kVa weight of the machine ca. 33,5 t dimensions of the machine ca. 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 - Workpiece table 0 to 8 Rsdpsw Rrb Hsfx Anpjw Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler - Technical documentation

Condition: good (used), total width: 3,500 mm, total length: 19,000 mm, total height: 2,100 mm, workpiece weight (max.): 6,000 kg, grinding diameter: 850 mm, grinding length: 6,000 mm, center height: 425 mm, Cylindrical grinder Schmaltz - RM 82/6000 MACH-ID 9492 Make: Schmaltz Type: RM 82/6000 Centre height: 425mm Grinding Ø: 850mm Grinding length: 6000mm Grinding stone dimensions:1100 x 80 x 560mm Grinding stone speeds: 700Rpm Table inclasement: -5 to +5° Tailstock: 160 x 100Mk Length: 19000mm Width: 3500mm Height: 2100mm Weight: 31000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details! Rodsy Dr Eajpfx Anpjw
