Lead and feed shaft lathe

Trencin TRENS SU 500 Leit und Zugspindel Drehmaschine

Condition: new, Year of construction: 2025, CORMAK 400 metal lathes is a new, improved version of the popular metal processing lathes. Among other things, the tool holder cover, spindle bearing system, new digital readout have been improved. They are suitable for production plants, workshops and tool shops. They are perfect for unit and small lot production. NEW, IMPROVED MODEL !!! high-quality and reinforced spindle bearing system new guards system compliant with CE standards the latest model of digital axis reading reinforced and modernized lathe base with drawers for tools and an extendable chip tray Characteristics of the machine REINFORCED, RIBBED SURFACE OF THE LATHE'S BED PROVIDES MAXIMUM REDUCTION OF VIBRATION, ADDITIONALLY PRECISE GRINDED, HARDENED BED DIGITAL READOUT OF THE AXIS IN STANDARD EQUIPMENT LARGE SPINDLE BORE PROVIDES OPTIMUM PERFORMANCE 52 mm THE APPROPRIATE BED WIDTH ENSURES STABLE AND PRECISE WORKING CONDITIONS MACHINE EQUIPPED WITH HIGH-QUALITY AND HARDENED SPINDLE BEARING SYSTEM EFFICIENT MACHINING THANKS TO TWO AUTOMATIC FEEDS AND EQUIPMENT WITH A ROLLER AND A DRAFT BOLT HARDENED WHEELS IN THE SPINDLE GEAR ADJUSTABLE CLUTCH OVERLOADS ON THE PULL SHAFT POSSIBILITY TO MACHINE THE FULL RANGE OF THREADS WITHOUT REPLACING THE WHEELS IN THE GUITAR FEED CHOICE LOCK: THROUGH SCREW OR SHAFT THE REMOVABLE BRIDGE ENABLES THE WORKING OF ELEMENTS WITH AN INCREASED DIAMETER RETRACTABLE CHIP DRAWER AND TOOL DRAWERS FOR BETTER AND EFFICIENT WORK Technical data MAXIMUM TURNING DIAMETER 400 mm MAXIMUM TURNING DIAMETER OVER THE BED 250 mm MAXIMUM TURNING DIAMETER IN THE SELECTION OF THE BRIDGE 520 mm TURNING LENGTH IN DEAD CENTRES 1000 mm Nedpfx Asiz Tczoh Djli BED WIDTH 218 mm SPINDLE END CAMLOCK D5 SPINDLE CONE MK6 SPINDLE BORE 52 mm SPINDLE ROTATION RANGE 65-1810 rpm SPINDLE SPEED NUMBER 16 ranges RANGE OF LONGITUDINAL FEED (40) 0,053 - 1,291 mm RANGE OF TRANSVERSE FEED (40) 0,011-0,276 mm THE MAXIMUM DIMENSION OF THE TOOL 20 mm x 20 mm METRIC THREAD 0,4-7 mm INCH THREAD 4-60 T.P.I. MODULAR THREAD (22) 0,4-3 mm THREAD D. P. (28) 8-84 D. P. TAILSTOCK QUILL DIAMETER 50 mm TAILSTOCK QUILL STROKE 110 mm TAILSTOCK TAPER MT4 ENGINE POWER 2,2 kW PUMP POWER 0,1 kW WEIGHT 640 kg DIMENSIONS 2000x820x1650 mm EQUIPMENT digital readout steady rest follow rest 200 mm 3-jaw chuck 200 mm 4-jaw chuck face plate 280 mm dead center MK4 x 2 reduction sleeve MK6/MK4 keys Factory new machine, under warranty For more information you can visit our web page.

Condition: as good as new (ex-display), functionality: fully functional, turning diameter over cross slide: 330 mm, spindle bore: 78 mm, turning diameter over bed slide: 520 mm, center height: 260 mm, turning length: 1,500 mm, quill stroke: 127 mm, quill diameter: 68 mm, total length: 2,670 mm, total width: 810 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 20 rpm, bed width: 300 mm, overall weight: 2,135 kg, quill mount: MK 4, Equipment: rotational speed infinitely variable, Center height: 260 mm Center distance: 1500 mm Njdoctutmepfx Ah Doli Spindle bore: 78 mm Spindle nose according to DIN 55029 Camlock D8 Spindle speed range: 20-2000 rpm Drive power: 7.5 kW Weight approx. 2135 kg Features include infinitely variable speed control Hardened and precision-ground Z-axis guideways Turcite coatings (on mating surface) of the tool and cross slides Manual central lubrication with one pump for longitudinal and cross slides Complete coolant system with rear splash guard and splash guard on the slide Chuck guard Switch rod with 3 adjustable cams Machine light Fixed center point Set of machine mounting plates

Condition: new, The V-Turn 410/1500, part of the Conventional Horizontal Lathes category and under the Engine Lathes group, is a precision lathe designed for both precision machining and robust production tasks. This bestselling model from KNUTH features an inverter and a powerful 5.5 kW motor, offering spindle speeds up to 3,000 1/min, making it highly effective for processing workpieces with small diameters while maintaining exceptional quality. The constant cutting speed function during face turning automatically adjusts spindle speed based on the diameter, ensuring turning results that rival those of CNC machines. Built with a heavy ribbed machine bed and a solid cast-iron frame, the V-Turn 410/1500 provides stability and strength for heavier machining applications. Additional features include a micrometer stop, turret stop, and integrated central lubrication for low maintenance. With extensive standard equipment, this machine is ready for various turning operations. To enhance your productivity with a top-notch Engine Lathe, order online today or request a quote. Nledjuxddcjpfx Ah Dei

Condition: new, turning diameter over bed 410 mm turning diameter over slide rest 240 mm turning length 1000 mm Nlodpfx Ahsm Rlb Nj Dji turning diameter in the gap 530 mm turning speeds 65 - 1810 U/min centre height 205 mm spindle bore 52 mm tailstock quill taper MT 4 total power requirement 2,2 kW weight of the machine ca. 0,9 t dimensions of the machine ca. 1,9 x 0,8 x 1,3 m Center lathe with: 3-axis digital measuring system fully assembled electromagnetic main spindle brake auto. Feed in longitudinal and transverse direction safety relay Micrometer end stop coolant device 3-jaw lathe chuck with 1 set of turning and drilling jaws German operating instructions.

Condition: new, TC 165 x 750V Illustration shows MIOTAL® TC 180 x 1000 Center distance: 750 mm Center height: 165 mm Swing diameter over bed: Ø 330 mm Bed width: 190 mm Cross slide travel: 160 mm Top slide travel: 90 mm Spindle connection: DIN 55029 (Camlock) D 1 - 4 Spindle bore: Ø 40 mm Max. Chuck diameter: Ø 200 mm Spindle speed, infinitely variable: 30 - 2000 1/min Mechanical feed stages: 3 Motor power: 2.2 kW Longitudinal feeds Z: (40) 0.044 - 1.96 mm/rev Face feeds X: (40) 0.022 - 0.98 mm/rev Metric thread: (32) 0.4 - 7.0 mm Thread inch: (32) 4 - 56 Gg/inch Thread module: (32) 0.4 - 7.0 Diametral thread: (32) 7.5 - 112 Quill diameter tailstock: Ø 40 mm Inner taper of quill tailstock: MK 3 Quill stroke: 100 mm Lateral adjustment: ± 10 mm Weight, approx.: 650 kg Features: - Acceptance protocol according to DIN - Precise, hardened and ground guides - Robust headstock with recirculating oil lubrication, precision bearing-mounted spindle, hardened and ground gears for long-lasting quality - Electromagnetic spindle brake (TC), frequency converter with electric braking device (V models) - Torsion-resistant machine beds made of MEEHANITE quality casting, stress-free annealed and multi-ribbed for extremely smooth running - Electrical equipment from SIEMENS/SCHNEIDER - Overload protection for feed gearbox - Pulse button for main spindle - CE / IEC as well as German documentation and German service Basic equipment (standard accessories): - Machine stand with splash guard rear panel - 3-jaw lathe chuck - 4-fold steel holder - Foot pedal with mech. brake device - Coolant device - Chuck guard and spindle cover in accordance with European safety standards CE - 1 Fixed center point for main spindle - 1 Fixed center point MK3 - 1 Test report - Safety devices and electrical equipment according to CE - Reducing sleeve for main spindle Operating tool Available options for this lathe: Nljdpeir Igwjfx Ah Dei - 3-axis digital readout - Quick-change holder system Multifix also available as a gearbox version

Condition: good (used), Year of construction: 1988, Weiler lathe Type Condor B 2-axis digital readout Center height 165 mm Center distance 750 mm Rotation over bed 330 mm Rotation over cross slide 185 mm Spindle bore 40 mm Connected load 3 kw Speed 22-2800 rpm Tailstock MK 3 Nledpfx Ahjvgmbvo Dei Coolant pump (not connected) work light Automatic longitudinal and planar feed spindle brake - Folding jaw chuck guard - splash guard Weight approx. 1040 kg 3 jaw lathe chuck Multifix B Rotating center point

Condition: used, turning diameter 210 mm turning length 1000 mm swing diameter over bed slide 435 mm centre height 210 mm greates pass round over bed 435 mm spindle head DIN 55027 / DIN ISO 702-3 spindle bore 52 mm turning speeds 44 - 2.000 U/min transmission ratio 12 feed per revolution 0,036 - 2 U/mm diameter of quill 65 mm quill stroke 120 mm taper bore DIN 228 MK4 total power requirement 5,5 kW Nledpjxqrdyefx Ah Doi From a training workshop Features: -Lead screw and feed screw cover -Brake for main spindle -Toolmaker precision according to DIN 8605 -High drive power and high torque on the main spindle -Large thread cutting range -Convenient operation -Digital position display (HEIDENHAIN ND 7013) -LED machine light -Coolant device

Condition: used, turning length 800 mm turning diameter 280 mm turning diameter over slide rest 150 mm Nlodpexacg Rofx Ah Dei spindle bore 42.0 mm tailstock quill taper MT 3 MK bed width 208 mm turning speeds 42 - 2022 U/min spindle taper DIN 55027/5 quill stroke 90.0 mm voltage 380 V total power requirement 3.0 kW weight of the machine ca. 750 kg range L-W-H 1800 x 800 x 1250 mm Due to its design (type, performance, feed rates, etc.) it can be used successfully in training workshops, but also for toolmaking and repair shops. Equipment: - robust conventional lead/spindle lathe - WMW 3-jaw chuck Ø 150 mm - faceplate 280 mm - MULTIFIX quick-change holder, with insert - movable tailstock - chuck key - machine base with storage area - pole-changing drive motor - operating instructions

Condition: used, Technical details: turning diameter over bed: 320 mm turning length: 800 mm centre distance: 800 mm centre height: 150 mm spindle bore of work spindle: 30 mm range of revolution per miute: 35 - 1500 / 16 step U/min range of feed in x - axis: 0,04 - 2,4 / 30 step m/min tailstock quill adjustment:: 125 mm tailstock taper MT: MK2 Nedpfx Aou Ixy Djh Doli dimension machine xH: 1,7 x 0,8 x 1,5 m Equipment and other features: -3-jaw chuck Röhm 160mm -chuck guard -protection system WxH: 510x400mm -Multifix tool clamp (4 pieces) -Tip in tailstock -Upper slide swivels +/- 45°, maximum travel = 100mm -Cross slide travel = 300mm feed Pump for coolant device (without feed) *

Condition: good (used), Centre height: 195 mm Distance between centres: 1250 mm Max. swing diameter over bed/cross slide: 400/265 mm Spindle mount/bore: Camlock D1-6"/54 mm Tailstock quill taper: MT 5 Spindle speeds steplessly adjustable in 3 ranges: 0 - 2500 rpm Longitudinal feeds: 0.018 - 1.2 mm/rev Cross feeds: 1/2 of longitudinal feeds 51 metric thread pitches: 0.2 - 14 mm 56 imperial (inch) threads: 2 - 56 TPI 20 module threads: 0.2 - 3.5 module Nlodpfxexlg Dwo Ah Dsi 20 diametral pitch threads: 8 - 56 DP Electrical connection: 400 V, 7.5 kW Weight: 1500 kg Space requirement: 2500 x 1300 x 1300 mm
