Press brake

TRUMPF TrumaBend V170

Year of construction: 1997, operating hours: 47,122 h, condition: ready for operation (used), Control Unit Brand DELEM Bodpexd H Tcsfx Abmjww Model DA-65 Additional Equipment Hydraulic clamping system This 6-axis TRUMPF Trumabend V170 press brake was manufactured in 1997. It features a bending force of 1700 kN and a maximum bending length of 4060 mm. The distance between uprights is 3680 mm, and it includes a hydraulic clamping system. Consider the opportunity to buy this TRUMPF Trumabend V170 press brake. Contact us for more information about this machine. Application Types Bending

Condition: good (used), functionality: fully functional, Year of construction: 1997, operating hours: 47,122 h, machine/vehicle number: 887034, control type: CNC control, degree of automation: automatic, actuation type: electric, bending force (max.): 170 t, working width: 4,000 mm, input voltage: 400 V, input current: 42 A, input frequency: 50 Hz, Equipment: documentation/manual, european tool clamping system, The machine is fully operational. Functionality can be checked. If you have any questions, please contact us. Bodpfexm Rlnsx Abmoww

Condition: excellent (used), Year of construction: 1997, pressure 170 t chamfer lenght 4080 mm distance between columns 3680 mm column arm 410 mm dayligth 385 mm stroke 215 mm ajustment speed 200 mm/sec working feed 1-10 mm/sec return speed 135 mm/sec table width 200 mm table height 1050 mm Number of working hours 25.430 h oil volume 350 l total power requirement 29 KVA weight of the machine ca. 16.450 kg. range L-W-H 4620 x 2210 x 2885 mm Machine in good condition Regularly serviced by the manufacturer CNC backgauge with 8 axes (!!) - in checked conditions - machinevideo - ?v=yEaRj0XJAC4 Equipment: - CNC electro-hydraulic press brake/die bending press - DELEM CNC control - swiveling front left * High-resolution graphic screen * Clear, concise menus in the operator's language * Large tool and product library * Graphic 2D programming * Automatic bend sequence calculation and collision detection * Emergency stop button at front - CNC axis adjustment: * Y1 - Y2 - X1 - X2 - R1 - R2 - Z1 - Z2 axis + CNC crowning - X axis - adjustment speed: 500 mm/sec. Bwedpjxcp Rbjfx Abmow * Max. stop range: 860 mm - R axis - Adjustment speed: 300 mm/sec. * Max. travel: 250 mm - Z axis - Adjustment speed: 1000 mm/sec. * Max. travel: 3260 mm - CNC electric motor table crowning - CNC electro-pneumatic die shift (I axis) - WILA / TRUMPF upper tool clamping - hydraulic - WILA / TRUMPF lower tool clamping - hydraulic - 2x front, robust support arms - movable - 1x freely movable 2-hand/foot control - 1x freely movable foot switch - Side safety device (swivel doors) - Rear safety device (sliding doors) - Original operating instructions

Condition: ready for operation (used), Year of construction: 1997, Press force: 1700kN, bending length: 4000mm, stroke: 215mm, installation height: 365mm, passage width: 3680mm, throat depth: 410mm, feed speed: 200mm/s, bending speed: 1-10mm/s, retraction rate: 135mm/s, working height: 1050mm, control: Delem. Including spare parts and accessories. Documentation available. Bwedpotqfqijfx Abmjw

Condition: ready for operation (used), Year of construction: 2003, operating hours: 57,202 h, General Data Measurements width 2210 mm Measurements depth 5000 mm Measurements height 3100 mm Bedpfx Aboxd H R Ijmjww Machine weight 18000 kg Control Unit Brand TRUMPF Main Drive Pressing force 1700 kN Bending length 4080 mm Stroke 365 mm Number of axis 8 This 8-axis TRUMPF TrumaBend V170 press brake was manufactured in 2003. It features a pressing force of 1700 kN, a stroke of 365 mm, and a maximum bending length of 4080 mm. The distance between columns is 3680 mm. If you are looking to get high-quality bending capabilities, consider the TRUMPF TrumaBend V170 machine we have for sale. Contact us for further details regarding this machine. Application Types Bending
