VTL SC 17 CC Vertical Turret Lathe

UMARO SC 17 CC

Condition: good (used), Year of construction: 2004, Table diameter: 1220 mm Fjdpfx Agexg Nmksmoft Max. turning diameter: 1500 mm Table speed range: 4.5 to 100 rpm Feed range: 0.127 mm to 6.35 mm per revolution Maximum height under crossrail: 900/1200 mm Slide travel (X-axis): 1000 mm Main drive motor: 41 kW Tool changer: 30 positions Accessories: - 8 clamping jaws - 30 tool holders with full enclosure - Oil mist extraction

Condition: excellent (used), Year of construction: 1986, workpiece weight (max.): 5,000 kg, turning diameter over cross slide: 1,700 mm, turning diameter: 1,620 mm, faceplate diameter: 1,620 mm, feed rate Y-axis: 1,380 m/min, rotational speed (max.): 150 rpm, rotational speed (min.): 3 rpm, workpiece diameter (max.): 1,700 mm, overall weight: 18,500 kg, faceplate torque: 22,500 Nm, Equipment: documentation/manual, VTL - SK16 - good condition Ffedpfow Ulx Tsx Agmst

Condition: used, Year of construction: 1970, functionality: fully functional, turning height: 4,000 mm, workpiece weight (max.): 100,000 kg, turning diameter: 17,000 mm, Universal 5-axis machine (turning & milling) Froriep 40KE 500/600-400 Spheromill Technical Data Year of manufacture: 1970 – modernised in 1984 and 2006 Control: Siemens 840D Milling length (X-axis): 8,500 mm Maximum working height (Z-axis): 4,000 mm Max. swing diameter: 17,000 mm Table diameter: 5,000 mm Ram adjustment: -15° to +90° Table speed: up to 40 rpm (100 kW drive) Maximum table load: 100 t Accessories & Equipment Ffodpfx Agjxbbfnjmet Milling head: 800 rpm / 60 kW Universal milling head: 630 rpm Facing slide up to Ø 1,000 mm Grinding attachment 90° angle head (630 rpm) Small 90° angle head (450 rpm)

Condition: used, WEBSTER & BENNETT EV 36” HIGH SPEED VERTICAL BORER MAKE WEBSTER & BENNETT, MADE IN ENGLAND MODEL EV 36” TABLE DIA 915 mm SWING 1168 mm HEIGHT UNDER RAIL 533 - 1016 mm SPEED 13.5 - 300 rpm FEED RATE 0.005-0.250 inch/min MAIN SPEED 40 HP PLUS HIGH SPEED TAABLE EV SERIES MACHINE Fjdpfxsxp Na Nj Agmoft ELEVATING RAIL SAFETY GAURDING SET OF JAWS FULLY FUNCTIONAL GOOD SLIDES
