Wide-belt sander

Weber - Kronach OFZ II

Condition: used, Year of construction: 2008, machine/vehicle number: 0-411-49-1873, Technical data: - Manufacturer: Bütfering - Type: Optimat SGO 211/RC - Number of grinding units: 2 - Year of manufacture: 2008 Rcedpfxsyh Hwue Ankjd - Working width: 1.100 mm - Grinding belt width: 1.120 mm - Grinding belt length: 1.900 mm - Workpiece thickness: 3-160 mm - Feed speed: 2,5-13 m/min. - Table height adjustment Standard equipment: - Automatic workpiece thickness adjustment - Stepless feed speed via requency converter. - 125 grinding programs can be stored - Wear-free braking system 1. Grinding unit (R) - Calibration roller - Profiled steel contact roller - Diameter 160 mm - Drive motor: 15 kW 2nd grinding unit (C) - Combination unit with roller and grinding shoe - Rubberized contact roller 65 Shore - Contact roller diameter 160 mm - Electronic link pressure bar with segment width 35 mm. - Belt speed: 12 and 21 m/s - Tolerance compensation up to 1 mm - Suitable for veneered surfaces and solid wood. - Drive motor: 11 kW - Total connected load: approx. 28 kW - Operating voltage: 400 V / 50 Hz. - Compressed air consumption at 6 bar, 20 L/min. - Belt blow-off device per pressure surge 440 L/min. - Extraction volume: approx. 2,880 m3/h/ at 20 m/s - Extraction connection: Dedusting: 1 x Ø 160 mm (grinding unit, roller) 1 x Ø 160 mm (grinding unit, shoe) Dimensions: - Length: 1,700 mm - Width: 1,850 mm - Height: 2,100 mm - Location: not in stock - Available from April 2026

Condition: like new (used), Working width 1350 mm The machine is in excellent, new condition as shown in the pictures. Rcjdpfx Aouuitgonkod

Condition: excellent (used), Year of construction: 2008, Working width: 1100 mm Workpiece thickness: 3 – 160 mm Abrasive belt dimensions: 1,120 x 1,900 mm Variable feed speed: 2.6 - 13 m/min Feed motor output: 1.10 kW, 400 V, 50 Hz Extraction port diameter: 2 x 160 mm Compressed air supply: 6 bar Dimensions (L x W x H): 1705 x 1545 x 1905 mm 1st unit: Steel contact roller, diameter 160 mm Motor output: 15 kW, 400 V, 50 Hz 2nd unit: Combination unit with rubber-coated contact roller (Sh 65), rigid sanding shoe Motor output: 11 kW, 400 V, 50 Hz Abrasive belt cleaning via compressed air 3rd unit: Cleaning brush Multi-function display Multi-function lever (conveyor belt, workpiece thickness adjustment) Electronic belt oscillation Pneumatic conveyor carpet oscillation Motorized workpiece thickness adjustment with LED display in 0.1 mm increments Units with emergency braking system Emergency stop button at infeed & outfeed Motor protection switch Roller table extension at infeed with 2 loose rollers Automatic star/delta start Complete documentation Rcodpfxjychqzj Ankod Note for used machines: • Specifications and prior sale subject to change. • Stated prices are ex works – loaded free of charge! • The machine has been cleaned and functionally tested. • All machines are sold as seen, without any warranty or guarantee. Buyers are welcome to inspect the machine on site. • Special agreements are only possible in written form. (We only respond to inquiries providing your address and telephone number!)

Condition: good (used), Year of construction: 1995, Multi-purpose surface sander, paint sander, modular unit, finishing unit, sanding unit, sanding station, belt sander -Max. sanding belt width: 1350 mm -Abrasive belt: oscillating -Drive: 11 kW -Speed: Frequency controlled Rcsdpfx Ansgnnbvjked -Sanding belt dimensions: 2620 x 1350 mm -Max. workpiece clearance height: 140 mm -Sanding belt unit: height-adjustable (conveyor belt fixed height) -Machine dimensions: 2210/2320/H2310 mm -Machine weight: 4500 kg

Condition: used, Year of construction: 2002, Grinding width: 1350 mm Grinding belt width: 1370 mm Grinding belt length: 1900 mm Workpiece thickness: 3 - 150 mm Feed speed: 2.5 - 13 m/min (infinitely adjustable) Drives: Grinding unit: 15 kW Total connected load: 17 kW Weight: approx. 2400 kg Dimensions: 2000 x 1850 x 2100 mm Storage location: Nattheim Rcedpfeytrfksx Ankjd

Condition: used, Year of construction: 2000, Working width .- mm Rsdpevwfl Ujfx Ankjcd With 1 sanding unit consisting of:- combination unit with electronic shoe for lacquer sanding- lacquer sanding- dust brush- roller table at infeed 270 mm- program control electronic f. 50 programswith brand-new feed carpetusedmake Bütferingtype Classic 111 Cyear of construction 2000machineNo. 63608Working width 1100 mmPassage height 160 mmCE type-testedGS wood dust testedBelt dimensions 1120 mm x 1900 mmFeed speed 4 8 m/min.1 piece combi unit 3.7/7.5 15 kW , 3 belt speeds with autom. steel rollerdiameter 130 mmbelt speed approx. 4,5 9 18 m/selectronic link shoesegment pitch 50 mmfor lacquer sanding workpiece controlledstorage location 97447 Gerolzhofen, free loaded, unpackeddelivery as seen,without guarantee and warranty
