Machining center

Weeke BHX 500

Condition: used, machine/vehicle number: 005910, X axis working area: 2500 mm Y axis working area: 1300 mm Godpfowuckhox Aptjbp Main Electrospindle power: 6 KW Number of controlled axes: 3 axes Total number of drilling spindles: 84

Condition: excellent (used), FLEXIBLE C.N.C. WORKING CENTER 3 axes (X-Y-Z) Movable panel (workpiece), static working head - Horizontal position of the panel (workpiece) Numerical Control PC 85 (Software woodWOP) Safety cabin (enclosure) of the working head Separate electric and command cabinet - Total installed power (Kw) 20 (ca.) No. 2 Workpieces fixing clamps (for the panels introduction in the working area) In-feeding working table (panel support) Out-feeding table (with motorized belts) Minimum workpieces dimensions (X - Y - Z) mm 200 x 100 x 8 (2 x 4 mm) Maximum workpiece dimensions (X -Y- Z) mm 3000 x 1000 (option mm 1300) x 80 (2 x 40 mm) Two panels simultaneously processables (in Z axe) WORKING GROUPS (TOP): 2V32, 2H8X/Y2, N2 X-Y90,F2-ETP-6 KW No. 1 Vertical electro-spindle ETP-25 (power Kw 6) No. 1 Circular Grooving Saw (90° on X-Y axe) dia. mm 125 No. 32 Vertical drilling spindles (power Kw 2.7) No. 10 Horizontal drilling spindles (8 in X + 2 in Y) WORKING GROUPS (BOTTOM) Gbjdpoziapbsfx Aptjp No. 1 Vertical electro-spindle ETP-25 (power Kw 6) No. 1 Circular Grooving Saw (90° on X-Y axe) dia. mm 125 No. 32 Vertical drilling spindles (power Kw 2.7) No. 10 Horizontal drilling spindles (8 in X + 2 in Y)

Condition: used, Year of construction: 2007, functionality: fully functional, For sale: vertical CNC machining center Weeke Optimat BHX 500, year 2007, designed for drilling, milling, and slotting panel materials in the furniture industry. The machine allows fast and precise processing of components and is suitable for both series and custom furniture production. Technical specifications: Model: Weeke Optimat BHX 500 Year: 2007 Machine type: 3-axis continuous CNC machining center CNC control: WoodWOP (Homag / Weeke) Maximum workpiece length: approx. 3050 mm Maximum workpiece width: approx. 1200 mm Maximum workpiece thickness: 80 mm Minimum workpiece length: approx. 200 mm Minimum workpiece width: approx. 70 mm Equipment: Drilling head with multiple vertical and horizontal spindles 96 drilling spindles (48 top, 48 bottom) 36 vertical tools 12 horizontal tools Slotting saw Milling cutter (top and bottom) 125 mm saw, rotatable 90° Automatic clamping workpiece transport Applications: Gbedpfjywgb Nex Aptop Drilling for dowels and fittings Milling and slotting Processing of particleboard, MDF, HDF, plywood, and solid wood Advantages: Ability to process two pieces simultaneously, significantly increasing productivity Quick setup and workpiece change High precision in drilling and milling Ideal for manufacturing case furniture, kitchens, cabinets, and interior fittings Condition: Machine is regularly maintained and operational Test run possible upon inspection Delivery: June 2026

Condition: excellent (used), FLEXIBLE C.N.C. WORKING CENTER 3 axes (X-Y-Z) Movable panel (workpiece), static working head - Horizontal position of the panel (workpiece) Safety cabin (enclosure) of the working head Numerical Control PowerControl PC86 power Touch (Software woodWOP) Separate electric and command cabinet No. 2 Workpieces fixing clamps (for the panels introduction in the working area) WEEKE Prepositioning Unit - to position workpieces in machine with clamp grippers faster. In-feeding working table (panel support) and Out-feeding table (with motorized belts) Minimum workpieces dimensions (X - Y - Z) mm 200 x 70 x 8 (2 x 4 mm) Maximum workpiece dimensions (X -Y- Z) mm 3000 x 1000 (option mm 1300) x 80 (2 x 40 mm) Two panels simultaneously processables (in Z axe) Separate electric and command cabinet WORKING GROUPS (TOP): 2V42, 2H8X/2Y, N2 X-Y90,F2-ETP-6 KW No. 1 Vertical electro-spindle ETP-6 (power Kw 6) Gbsdpsyyvttsfx Aptsp No. 1 Circular Grooving Saw (90° on X-Y axe) dia. mm 125 No. 42 Vertical drilling spindles (power Kw 2.3) No. 10 Horizontal drilling spindles (8 in X + 2 in Y) WORKING GROUPS (BOTTOM) 2V42, 2H8X/2Y, N2 X-Y90,F2-ETP-6 KW No. 1 Vertical electro-spindle ETP-6 (power Kw 6) No. 1 Circular Grooving Saw (90° on X-Y axe) dia. mm 125 No. 42 Vertical drilling spindles (power Kw 2.3) No. 10 Horizontal drilling spindles (8 in X + 2 in Y)

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, TECHNICAL DETAILS Workpiece length: min. 250 – max. 2500 mm Workpiece width: min. 70 – max. 1000 mm Workpiece thickness: min. 4 mm – max. 80 mm Workpiece stacking: max. 2 pieces Vertical Drilling Unit 2V21 HIGH SPEED 7500 Feed stroke (Z-axis): 60 mm Drilling depth: max. 38 mm Direction of rotation: clockwise/counterclockwise Speed: 1,500 – 7,500 rpm, frequency-controlled Drive: 2 x 2.7 kW Drill chuck: d = 10 mm Total length of drill bit: 70 mm Maximum drill bit diameter: 35 mm Spindle distance: 32 mm Spindle type: individually controllable Horizontal Drilling Unit 2H4X/1Y 4 drilling spindles each in X-direction 1 drilling spindle each in Y-direction Drilling depth: max. 38 mm Drilling height (Z-axis): 38 mm from top edge of workpiece Direction of rotation: clockwise/counterclockwise Speed: 1,500 – 7,500 rpm, frequency-controlled Drill chuck: d = 10 mm Total length of drill bit: 70 mm Maximum drill bit diameter: 20 mm Spindle type: individually controllable Grooving Saw Unit N2 X-Y 90° Cutting depth: 30 mm Machining cross-section: max. 70 mm² Speed: 1,500 – 7,500 rpm, frequency-controlled Tool diameter: 125 mm Saw blade thickness: max. 5 mm Milling Unit F2-ETP-6 KW Tool holder: for shaft diameter d = 25 mm Maximum tool diameter: 60 mm Tool clamping length: min. 65 mm / max. 95 mm Maximum tool weight: 2.5 kg Tool change: manual, ETP 25 hydro quick-clamping system Direction of rotation: clockwise/counterclockwise Speed: 6,000 – 18,000 rpm, steplessly programmable Drive: frequency-controlled three-phase motor Max. output at tool: up to 5/6 kW in continuous / intermittent operation (S1/S6-50%) EQUIPMENT Material infeed "IgeL-ROBOT" Lower machining support Upper machining support Vertical drilling unit 2V21 HIGH SPEED 7500 Horizontal drilling unit 2H4X/2Y Gedpeyg E R Hefx Aptjbp Grooving saw unit N2 X-Y 90° Milling unit F2-ETP-6 KW Barcode reader Manufacturer: Datalogic

Condition: ready for operation (used), Year of construction: 2010, machine/vehicle number: 0-250-12-2554, functionality: fully functional, workpiece length (max.): 1,000 mm, workpiece width (max.): 3,000 mm, workpiece height (max.): 80 mm, controller model: PC 85, TECHNICAL DETAILS Workpiece width min.: 250 mm Workpiece width max.: 3,000 mm Workpiece length min.: 100 mm Workpiece length max.: 1,000 mm Workpiece height min.: 8 mm Workpiece height max.: 80 mm Upper vertical working unit ETP-6 vertical spindle power: 6 kW Grooving cutter diameter: 125 mm Vertical drilling spindles: 32 (power 2.7 kW) Horizontal drilling spindles: 10 (8 in X + 2 in Y) Lower vertical working unit ETP-6 vertical spindle power: 6 kW Grooving cutter diameter: 125 mm Vertical drilling spindles: 32 (power 2.7 kW) Gbsdpfx Aeydnu Noptop Horizontal drilling spindles: 10 (8 in X + 2 in Y) MACHINE DETAILS Control: PC 85 Software: woodWOP 6 EQUIPMENT Safety enclosure for tool set 2 clamping chucks for securing and moving the workpiece during machining Loading bench with air cushion table Powered roller conveyor for panel discharge Capability for simultaneous processing of two panels

Condition: excellent (used), Year of construction: 2009, Weeke BHX 500 – Operator Side Right Weeke Machining Center, each with one machining support above and below Infeed table with automatic workpiece feeding and positioning WORKPIECE DIMENSIONS Min. workpiece length: 200 mm Max. workpiece length: 2,500 mm Min. workpiece width: 70 mm Max. workpiece width: 1,000 mm Min. workpiece thickness: 8 mm (2*4 mm) Max. workpiece thickness: 80 mm Max. workpiece stacking: 2 pieces Machine configuration: 2V21 HIGH SPEED 7500 Vertical drilling unit arranged in both upper and lower machining supports, each with 21 drilling spindles (individually controllable with variable speed range). 2H4X/1Y Gbodox S Hzlspfx Aptep Horizontal drilling unit arranged in both upper and lower machining supports, each with 10 spindles individually selectable via program. Each with 8 drilling spindles: in X-direction Each with 2 drilling spindles: in Y-direction N2 X-Y 90° Grooving saw unit arranged in both upper and lower machining supports for machining operations in the X-Y direction, swiveling 90°. Cutting depth: 30 mm ADDITIONAL NOTE ON GROOVING SAW BLADE The saw blade width can be 8.4 mm. The cutting cross-section must not exceed 70 mm². F2-ETP-6 KW Milling unit arranged in both upper and lower machining supports, suitable for receiving shank tools. Manual tool change. Tool clamping: manual, Hydro quick-clamping system ETP 25 Rotation direction: right/left Speed: 6,000 – 18,000 rpm, stepless programmable Machining up to 3,000 mm Infeed table with automatic workpiece feeding and positioning Workpiece discharge area with cross belt conveyor and lifting arms – Workpiece length measurement in the machine – Movable operator terminal – Barcode software incl. scanner
