Eccentric Press - Single Column

WEINGARTEN NR 80

Year of construction: 2003, condition: used, pressure 100 t Gksdpera Rr Ejfx Adksd stroke 10-130 mm no. of strokes 30-90 Hub/min throat 330 mm ram - range of adjustment 100 mm table surface area 950x660 mm ram surface 540x440 mm hole in the table Ø 230 mm table height 1000 mm tool hole in ram Ø 50 mm total power requirement 7,5 kW weight of the machine ca. 7 t

Year of construction: 1978, condition: used, pressure 100 t throat 380 mm stroke 400 mm Gkodpolp U Dpofx Adksd power capacity 22 kW dayligth 600 mm ram surface 600x500 mm table surface area 720x600 mm weight of the machine ca. 9 t

Year of construction: 1982, condition: used, pressure 150 t throat 350 mm stroke 20-120 mm no. of strokes 40-60 Hub/min ram - range of adjustment 85 mm table surface area 1050x690 mm Godpfx Adolp U Iwjkjkd ram surface 650x320 mm hole in the table 325x200 mm table height 850 mm tool hole in ram Ø 50 mm weight of the machine ca. 8,6 t dimensions of the machine ca. 2500x2500x2900 mm

Year of construction: 1966, condition: used, pressure 100 t throat 410 mm stroke 8-112 mm no. of strokes doubel-strokes per min. 55 / 82 ram - range of adjustment 80 mm table surface area 950 x 700 mm ram surface 700x450 mm hole in the table Ø 280 mm table height 850 mm tool hole in ram Ø 50 mm Gedslp U D Espfx Adkokd weight of the machine ca. 7,0 t dimensions of the machine ca. 1400x2200x2800 mm

Condition: used, Single-column eccentric press WEINGARTEN type EV 63 Machine. No. 738 / 61 Year of construction 1962 Pressure capacity 63 ton. throat 260 mm Table surface 630 x 530 mm Table opening Ø 210 mm ram surface 315 x 260 mm Plunger stroke adjustable 8-100 mm Plunger adjustment 63 mm Installation height max 450 mm Gsdpok S Htxefx Adkskd Stroke rate 115 strokes / min. Compressed air requirement min. 4.5 bar Motor power 4 kW Mains connection 380 Volt, 50 Hz Table height above floor approx. 750 to 900 mm - Electric lift release via foot switch or two-hand operation - Overload protection by breaker plate - Clutch/brake combination with WEINGARTEN friction threaded clutch with TDC overrun protection - Front crankshaft support bearing - Press table height-adjustable via 2 threaded spindles - Manual central grease lubrication - Control cabinet adjacent - UVV for manual insertion work Space requirement L x W x H 1750 x 1600 x 2430 mm Weight 4.5 tons good condition

Year of construction: 1977, condition: used, pressure 100 t throat 410 mm stroke 8-112 mm no. of strokes 55/82 Hub/min ram - range of adjustment 80 mm table surface area 950x700 mm ram surface 700x450 mm hole in the table Ø 280 mm table height 800 mm Gkodpfx Aolp U Daodked total power requirement 11 kW weight of the machine ca. 7,5 t dimensions of the machine ca. BxTxH 1600x2200x3000 m

Year of construction: 1970, condition: used, pressure 100 t throat 415 mm stroke 8-140 mm no. of strokes 48 Hub/min ram - range of adjustment 80 mm table surface area 920x670 mm ram surface 700x450 mm table height 800 mm Gkjdpfxolp U Spo Adkjd tool hole in ram Ø 50 mm weight of the machine ca. 8 t dimensions of the machine ca. BxTxH 1500x2000x2800 mm

Condition: used, Year of construction: 1991, Pressure capacity 1,500 kN Adjustable stroke 20 - 132 mm ram adjustment max. 90 mm Stroke rate 50 / 75 1/min. Further data and pictures on request Gkedpsrm Nqmofx Adked used, the press is currently completely disassembled not functional and must be mechanically and electrically overhauled

Condition: used, Year of construction: 1976, pressure 100 t throat 315 mm Gksdpfxeugnpie Adked stroke 8 - 112 mm table surface area 725 x 570 mm ram surface 410 x 315 mm ram adjustment 80 mm no. of strokes 55 / 82 Hub/min tool shank hole (depth x diameter) 85 x 50 mm dayligth 355 mm total power requirement 7,5 kW weight of the machine ca. 6 t dimensions of machine L x W x H 2,00 x 1,00 x 2,87 m

Year of construction: 1987, condition: used, pressure 40 t throat 270 mm stroke 4-100 mm no. of strokes 130 Hub/min ram - range of adjustment 80 mm table surface area 670x540 mm ram surface 460x300 mm hole in the table Ø 100 mm table height 850 mm tool hole in ram Ø 50 mm weight of the machine ca. 6 t dimensions of the machine ca. BxTxH 1500x2300x3300 mm Gkedjp Syctjpfx Adked
