Other Weinig

Weinig

Condition: like new (used), Year of construction: 2010, planing height: 200 mm, Weinig Powermat 2000 XL four-sided planer: - German manufacture - DTR CE - automatically controlled - PowerLock heads - year of production 2010 - for wet wood Ljdpfxoun Natj Amtohi TECHNICAL PARAMETERS: - planer width: 300 mm - planing height: 200 mm - PowerLock heads - control from the touch panel - electronically adjustable heads - pneumatically pressed heads 1 bottom head: 18.5 kW 2 right head: 15 kW 3 left head: 15 kW 4 top head 22 kW with side cutter: 1.5 kW 5 Overhead: 18.5 kW 6 Lower head: 20 kW - heads with automatic jointing system - spindles speed: 8000 rpm - inverter-controlled feed speed: 6 - 60 m/min - six steel drawing top rollers - three rubber trailing top rollers - top feed rollers with support - six rollers in the drawing table, of which 2 milled in front of the first head - automatic central lubrication - spigot diameter: 4 x 160 and 2 x 140 mm

Condition: excellent (used), Year of construction: 1995, Weinig Profimat 23E four side planer - German production - year of production 1995 - right and left spindles with a face milling cutter ensuring parallelism and a right angle of 900 Lhjdpfoibq Niox Amtji - element width measurement - electronic width adjustment TECHNICAL PARAMETERS: planing width 230 mm planing height 120 mm electronic planing width control 1 lower spindle 4 kW 2 right spindle 4 kW 3 left spindle 4.2 kW (face milling) 4 spindle right 4.2 kW (face milling) 5 upper spindle 7.5 kW element width measurement electric height adjustment of the feed rollers electric height adjustment of the upper spindle spindle diameter 40 mm six top steel rollers yen top roller, rubber one roll in the table top pulling pneumatic pressure feed on cardan shafts pre-table length 2470 mm diameter of nozzles 140 mm Machine dimensions 456x240x220 weight 4000 kg

Condition: excellent (used), Raimann KS 310 BV edger multisaw - year of manufacture 1995 - German production - DTR - two movable discs TECHNICAL PARAMETERS: - track width 340 mm - cutting height max 120 mm - engine power 30 kW - disc diameters 250/360 mm - Possibility to put on a shoe - electric height adjustment - feed continuously adjustable 11-38 m / min - power of the feed motor 1.5 kW - two movable discs - three lasers - max element width 1000 mm - minimum element length 600 mm with a shoe 400 mm - four upper pressure rollers Lodpfxjir Eubs Amtehi - spindle diameter 65 mm - sleeve diameter 80 mm - spigot diameter 250 mm Dimensions 230x220x230 weight 2500 kg

Condition: excellent (used), Year of construction: 2005, Weinig Dimter OptiCut S 90 optimizer with 2 ejectors – after technical review – German production – year of manufacture 2005 TECHNICAL PARAMETERS: max. length of cut material 4500 mm max. width 360mm max. height 160mm Lsdpfx Aji Apgmemtohi automatic length measurement optimization in 4 quality classes total power 13 kW blade motor power 7. 5 kW pneumatic side and top pressure disc diameter max. 500mm OptiCom Assist control receiving conveyor 5600 mm two ejectors total length 13 m component marking printer cutting accuracy +/- 0.5 mm transport dimensions (length / width / height) 600 / 240 / 190 cm weight ~ 1800 kg

Condition: good (used), Year of construction: 2008, Raimann FlexiRip 4200 rip saw - German production, user manual - year of production 2008 - automatic material collection Lhjdohzg Agepfx Amtei TECHNICAL PARAMETERS: cutting length max. 4200 mm cutting width max. 600 mm cutting height max. 130 mm feed continuously adjustable up to 80 m / min main engine power 11 kW disc diameter max. / min. 600 mm / 400 mm 100 dimensions can be programmed line laser two-stage blade feed touch panel control stub diameter 2 x 160 mm dimensions of the machine (length / width / height) 620/160/220 cm weight 2250 kg

Condition: ready for operation (used), Year of construction: 1990, functionality: fully functional, operating hours: 4,452 h, cutting height (max.): 120 mm, cutting depth: 340 mm, main saw diameter: 380 mm, Raimann KR 310 E 340/120 multi-saw with movable disc - manufactured in Germany - year of manufacture 1990 - DTR - number of hours 4452 h TECHNICAL PARAMETERS: - track width 340 mm - cutting height max 120 mm - cutting height with movable disc 85 mm - engine power 30 kW - minimum length of the element 700 mm - width of table 740 mm - feed regulated on inverter 6-48 m/min - three rows of pawls Lhedpfx Ajrhig Esmtei - possibility to mount a bush - sleeve diameter 80 mm - length of fixed sleeve 190 mm - electrical adjustment of cutting height - electrical adjustment of shaft height - four top pressure rollers - automatic central lubrication - laser - ruler - spigot diameter 250 mm Overall dimensions of the machine 250x200x220 cm weight 2000 kg

Condition: excellent (used), Year of construction: 2004, Weinig Dimter Opticut 200 Classic optimizer - after the technical review - year of production 2004 - declaration of conformity, DTR - German production TECHNICAL PARAMETERS: min./max. entry length of the element 800/3500 mm min./max. entry width of the element 80/200 mm min./max. element input thickness 12/80 mm type of wood hard / soft dash cutting wood classification max. feed speed 120 m / min acceleration 5 m / s saw blade diameter fi 500 mm saw hole diameter 30 mm saw spindle speed 4600 U / min duration of 1 cycle 0.7 - 1.2 sec a powered conveyor at the entrance and a marking station with side tables for two markers conveyor belt total power 15 kW length measurement - fluorescence camera for 3 qualities receiving station - conveyor belt Lhsdpjgz Tbdofx Amtji full optimization total length 8300 mm stub diameter 80 and 120 mm OptiCom Direct control power supply 400 V / 50 Hz

Condition: good (used), Year of construction: 2002, Weinig Unimat 23 EL four side planer - machine in stock Lhjdpjhhyr Asfx Amtei - German production - year of production 2002 - DTR TECHNICAL SPECIFICATIONS: - planing width 230 mm - planing height 170 mm - feed adjustable on the inverter 6-26 m / min - spindle diameter 40 mm 1 lower spindle 7.5 kW 2 right spindle 7.5 kW 3 left spindle 7.5 kW 4 upper spindle 7.5 kW 5 lower spindle 7.5 kW 6 upper spindle 7.5 kW - 4 kW feed motor power - feed on cardan shafts - pneumatic pressure - five top steel rollers - four upper rubber rollers - electric height adjustment - diameter of the stub pipe 140 mm - central lubrication - length of the top 1980 mm Machine dimensions: - length 520 cm - width 210 cm - height 210 cm - weight 4000 kg

Condition: excellent (used), RAIMANN KD31 double-shaft multi-saw - after the technical review - German production - year of production 1988 TECHNICAL PARAMETERS: cutting width 340 mm cutting height 200 mm material width max. 800 mm engine power 2 x 55 kW feed speed smoothly regulated on the inverter disc diameter max. 350 mm lower shaft 400 mm upper shaft spindle diameter 65 mm sleeve diameter 80 mm four rows of pawls four upper pressure rollers electric height adjustment the ability to work independently with each spindle ruler central lubrication caterpillar with nails table top height from the base 930 mm spigot diameter 200 mm transport dimensions (length / width / height) 320/200/240 cm Lsdpjg Db U Aofx Amtohi weight ~ 5000 kg

Condition: like new (used), Weinig Hydromat H22N four-side planer - German production - DTR Lsdpfepvi Skex Amtshi - year of production 1992 - two rollers in the tabletop, milled before the first head - for wet wood TECHNICAL PARAMETERS: - planing width 220 mm - planing height 140 mm - spindle diameter 50 mm 1 lower head 7.5 kW 2 legal head 7.5 kW 3 left head 11 kW 4 upper head 7.5 kW 5 lower head 11 kW hydraulic feed pump motor power 15 kW feed speed smoothly adjustable up to 60 m/min feed on cardan shafts electric height adjustment pneumatic pressure five pulling rollers in the countertop eight steel upper pulling rollers one upper rubber pulling roller rests on horizontal spindles jointer on the lower spindles Transport dimensions 500x200x160 cm weight 4 tons
