Other Weinig

Weinig

Condition: used, Number of boring spindles 5 St. Working width 230 mm Working height 120 mm Lhsdpsx Ecguefx Amtei

Condition: excellent (used), CATALOGUE NUMBER 6946 TECHNICAL DATA - Max. working width: 210mm - Max. working thickness: 120mm - Number of spindles: 2 pcs - Spindle diameter: 50mm From above: - 3 infeed feed rollers, rubber, smooth, including 2 double rollers - 2 outfeed feed rollers, rubber, including 1 double roller - Cutterheads on supports - Cutterhead up/down adjustment - Electric adjustment of top cutterhead height - Electric setting of planing thickness - Spindles equipped with brake - Main motor: 2×5.5kW - Stepless feed speed adjustment - Feed motor: 3kW - Feed via Kardana shafts - Extraction nozzle diameter: 2x160mm - Dimensions (L/W/H): 2350x1780x1950mm - Weight: 1882kg – Made in Germany – Jointers for sharpening knives on the cutterhead – 2 Hydro cutterheads included – Not repainted – Very good condition, used planer Net price: 33,900 PLN Net price: 8,070 EUR Lhodpszcdz Asfx Amtei Net price calculated at 4.2 PLN/EUR (price may change with significant exchange rate fluctuations)

Condition: excellent (used), Catalog number 7994 TECHNICAL DATA - max. width of the workpiece 230mm - max. height of the workpiece 130mm 7 spindles: 1) horizontal lower 230mm 4kW 2) vertical right 130mm 3) vertical left 130mm (2 and 3 spindles) 11kW 4) horizontal upper 230mm 5.5kW 5) horizontal upper 230mm 5.5kW 4 and 5 spindles are electrically adjustable up/down 6) horizontal lower 230mm 4kW 7) universal 230mm, adjustable at an angle of 360° 5.5kW - all spindles adjustable up/down, left/right - spindle diameter 40mm - 4 infeed rollers from above, geared, pulling - 4 outfeed rollers from above, pulling, rubber, smooth, including 3 double rollers - metal roller from below, pulling - feed on cardan shafts - rollers pneumatically pressed - stepless speed adjustment of the feed rate on an inverter - feed motor 3kW - working pressure 6-10 bar - electric adjustment of the planing thickness - central lubrication of the table - length of the infeed table 1960mm - diameter of the dust extraction nozzles 3x120mm, 4x140mm - dimensions L/W/H 5360x1800x1660mm - weight approx. 4000kg ADVANTAGES – German production, WEINIG brand – with 7 heads – DTR documentation – universal spindle Lhjdpoy T Nu Dsfx Amtji – used planer, very good condition Net price: 75900 PLN Net price: 18070 EUR, depending on the exchange rate of 4.2 EUR (Prices may vary due to significant fluctuations)

Condition: excellent (used), Year of construction: 1995, MULTI-BLADE SAW RAIMANN KS 310BV, 1995, MOTOR 30KW, 2 VARIABLE SAWS Ledpfx Amsznxdhstshi

Condition: good (used), Year of construction: 2010, functionality: fully functional, milling height: 180 mm, WEINIG NKT Dovetail Grooving Line – Double Unit DP20 An industrial dovetail grooving and gluing machine – developed for maximum precision and efficiency. Technical specifications: Wood input length: min. 130 mm | max. 1000 mm Wood output length: min. 3700 mm | max. 7400 mm (half lengths possible!) Wood cross-section: min. 20 x 40 mm | max. 80 x 180 mm Cutter diameter: 370 mm Dovetail design: Vertical / Horizontal, 10/11 dovetails, 3.8 mm pitch Glue application: 2-sided, PVAC white glue Connection power: 80 kW Note: The machine is currently disassembled and is in our warehouse. An inspection is possible by appointment. Scope of supply: WEINIG NKT Double Unit DP20 including control unit Integrated gluing station for 2-sided application Operating manual & documentation Hydromat 17B (7 spindles) General information Manufacturer: Weinig AG Model: Hydromat 17B // 7 spindles (various tools) Type: High-performance profiling milling machine / planing and rabbeting machine Year of manufacture: 1989 Operating voltage: 380 V / 50 Hz Bottom-Right-Left-Right-Left-Top-Bottom table, fixed Lhodeznum Sspfx Amtoi Description Heavy-duty, high-performance planing and rabbeting machine made of vibration-damping and torsion-resistant cast iron components in a modular system. Designed for precise and economical woodworking with high continuous output. Mechanical feed, adjustable in the range of 5 – 35 m/min, feed motor 5.5 kW (7.5 HP). Surfacing table 2 m long, quick adjustment available. Chip removal for surfacing and jointing spindles, adjustment range 10 mm each. Technical data • Feed speed: 5 – 35 m/min, mechanical • Feed motor: 5.5 kW / 7.5 HP • Operating voltage: 380 V / 50 Hz • Table length: 2000 mm • Adjustment range of chip removal: 10 mm (surfacing and jointing side) • Machine design: Without counter bearing, in high-performance design

Condition: used, Year of construction: 1998, functionality: fully functional, working width: 230 mm, spindle diameter: 50 mm, planing width: 150 mm, overall weight: 9,200 kg, table length: 2,000 mm, number of spindles: 9, 4-sided moulder with 9 spindles, configured as follows: lower horizontal spindle, right spindle moulder, left spindle moulder, right spindle moulder, left spindle moulder, upper horizontal spindle, upper horizontal spindle, lower horizontal spindle, universal spindle. Lhedpfx Amey A Tugstoi

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, feed rate X-axis: 12 m/min, feed rate Y-axis: 120 m/min, feed rate Z-axis: 120 m/min, working width: 230 mm, planing height: 120 mm, spindle diameter: 50 mm, planing width: 230 mm, working height: 120 mm, overall weight: 16,000 kg, power of feed motor: 37,000 W, spindle speed (max.): 6,000 rpm, spindle speed (min.): 3,000 rpm, height adjustment type: electric, planer shaft diameter: 50 mm, type of input current: three-phase, number of spindles: 10, power: 574 kW (780.42 HP), input frequency: 50 Hz, Equipment: cabin, motor brake, rotational speed infinitely variable, Weinig Powermat 2500 Ledpjx Svm Rsfx Amtshi 10 Spindles, Working width: 230 mm, Working height: 120 mm, Spindle diameter: 50 mm, Feed: 37 kW / 12–120 m/min, Spindle configuration: 1- Bottom (22 kW) – with hydraulic clamping and fully automatic straight jointer 2- Right (11 kW) 3- Left (11 kW) 4- Top (37 kW) – with fully automatic straight jointer 5- Bottom (18.5 kW) – with hydraulic clamping and fully automatic straight jointer 6- Top (18.5 kW) – with hydraulic clamping and fully automatic straight jointer 7- Top (53 kW) – with hydraulic clamping, speed 3,000–6,000 rpm 8- Bottom (53 kW) – with hydraulic clamping, speed 3,000–6,000 rpm 9- Top (53 kW) – with hydraulic clamping, speed 3,000–6,000 rpm 10- Bottom (53 kW) – with hydraulic clamping, speed 3,000–6,000 rpm Short infeed table, 1.3 meters (4 rollers), with 2 powered rollers above the table and 2 powered rollers in the table (both table rollers can be lifted). Table height adjustment with electronic digital readout. Incl. 2 heavy-duty side pressure rollers, 140 mm diameter, pneumatically actuated. Base supports, height 320 mm, for a table height of 1190 mm. Marathon POWER Coating for machine table, fences, and guide rails (excluding infeed table and special table surfaces). Special coating to protect table plates, fences, and guide rails from excessive wear. Recommended for processing abrasive materials (e.g., tropical woods, MDF, chipboard, plastics, metals). Automatic lubricant pump for table resin removal. Powered rollers in the machine table, hardened. Heavy-duty steel pressure rollers from above, diameter 120 mm, located in the area of the right and left spindle.

Condition: excellent (used), working width: 240 mm, planing height: 160 mm, spindle diameter: 50 mm, planing width: 240 mm, working height: 160 mm, total width: 240 mm, spindle speed (max.): 7,000 rpm, spindle speed (min.): 7,000 rpm, Weinig Unimat 1000 with grooved table Working width: 240 mm, working height: 160 mm, 5 spindles Spindle diameter: 50 mm Spindle arrangement: 1-Bottom (7.5 kW) 7000 RPM 2-Right (7.5 kW) 7000 RPM 3-Left (7.5 kW) 7000 RPM Ledpfxozbz Uks Amtjhi 4-Top (7.5 kW) 7000 RPM 5-Bottom (5.5 kW) 7000 RPM Feed rate: 4 kW / 6-36 m/min, one driven roller in the table at the outlet.

Condition: excellent (used), Year of construction: 2008, operating hours: 8,000 h, Four-sided planer Weinig Model Powermat 400 LE - machine with ribbed table Year of manufacture: 2008 Operating hours: 8000 Maximum working width: 230 mm Maximum working height: 120 mm The machine is equipped with 5 spindles featuring the Powerlock system Spindle configuration: - bottom 5.5 kW - left and right – 7.5 kW each - top – 7.5 kW - bottom – 7.5 kW Spindle speed: 6000 rpm Feed speed steplessly adjustable via inverter: 5 – 30 m/min Electronic spindle positioning – Memory system The machine is in very good technical condition, complete with cutter heads. Lsdpjwybrnofx Amtehi

Condition: good (used), Year of construction: 1981, For inquiries: Zoltán Utasi Plus 36 30 205 7380 pindle configuration: Bottom Lhsdpfxjy Nmv Dj Amtei Right Left Top Bottom Spindle speed: 6000 rpm Working width: 170 mm Working height: 120 mm Jointing table length: 2 m Equipped with Waxilit pump Infinitely variable feed speed: 7–18 m/min Side pressure roller Motorized pressure beam adjustment Equipped with 5 cutter heads (3 pcs L180 mm, 2 pcs L130 mm) Machine documentation available
