CNC window machining center

WEINIG UNICONTROL 10

Condition: used, Tenoning spindle 1 St Number of milling agregates 4 St. Spindle diameter 50 mm Control Weinig, PC-Nexus Weinig Unicontrol 10 CNC - Spindles radially and axially CNC-controlled ----- The machine was factory overhauled by Weinig in 2024. The control system was also upgraded to a Siemens S 7 677 C, with a new membrane panel "Touch". With the following machining units: Crosscut saw ----- with laser alignment light, motor power 3 kW, spindle diameter 40 mm, spindle speed 3,000 Axially adjustable via NC axis Radial pneumatic adjustment to 8 positions for edge rounding from above Unit from below for edge rounding ----- Axially adjustable with crosscut saw Tenon and slotting spindle ----- Motor power 15 kW Spindle diameter 50 mm Spindle speed 2,925 rpm Tool travel radius min. 380, max. 400 mm Tool clamping length 640 mm Axially adjustable CNC axis Axially adjustable travel 580 mm Adjustment speed 100 mm/sec. 1. Profile spindle (up- and down-rotation) ----- Motor power 11 kW Spindle diameter 50 mm Spindle speed 6,000 rpm Tool clamping length 400 mm with counter bearing Axially and radially adjustable via CNC axis 2. Profile spindle ----- Motor power 11 kW Spindle diameter 50 mm Spindle speed 6,000 rpm Tool clamping length 400 mm with counter bearing Axially and radially adjustable via CNC axis Profile milling unit horizontally mounted on top ----- Motor power 3 kW Spindle diameter 40 mm Spindle speed 9,000 rpm Pneumatically adjustable to 8 axial and radial positions Profile milling unit vertically mounted on the right side Machine end ----- Motor power 3 kW Spindle diameter 40 mm Spindle speed 5,850 rpm Pneumatic adjustment to 8 axial and radial positions Additional accessories ----- CNC-controlled length stop, mounted on the slotting table for lengths up to 3,500 mm, including a positioned cross-cutting saw integrated into the control system. Studio window device, pivots 60° on both sides Double-part package with automatic separation and transfer Synchronization device with automatic window rebating Rebating carriage for rebating small sash widths Fsdpfx Afow Im H Sopogh Air conditioning unit in the control cabinet PC control NEXUS Automatic turning system Slat conveyor, including conveyor belt for returning the workpieces to the operator (Technical specifications according to the manufacturer - without guarantee).

Condition: used, Year of construction: 2000, Storage location: Nattheim Fgsdpfx Afovwdmwjpjh

Condition: used, Year of construction: 2001, functionality: unexamined, spindle stroke: 40 mm, Weinig Unicontrol 10 window production line Fgsdpfxju A Ixfj Afpeh

Year of construction: 1998, condition: ready for operation (used), An angular system for Weinig window and door production is available. Max. tool outside diameter: 320mm, max. tool flight circle: 232mm, slotted spindle length: 640mm, profiling and synchronized spindle length: 285mm-320mm, control: Siemens WS400. Including complete tooling and style window. Documentation available. Fedpfxstq U A Ij Afpogh

Condition: used, Year of construction: 1991, CNC Machining Center weinig UNICONTROL 10 Location Gorzów Wlkp. Conditions of delivery OWN RECEIVING Cost of delivery to be negotiated Startup type to be negotiated Description Comments Longitudinal saw: 2800 rpm min., 3 kW, power take-off and slot spindle: 5 x 100 mm, 11 kW, 2.800 rpm. min., 1 spindle profiling: 6000 rpm. min., 11 kW, 2. Spindle profiling: 6000 rpm. min, 11 kW. "Angle windows, machining center WEINIG UNICONTROL 10 Number of spindle spindles: 1 Number of spindles molding: 2 Length of the spindle spindle mm: 300 Xrwk8iolx Fodedm Umlopfx Afpegh Length of profiled spindle mm: 295 Separate shaft grooves: yes Continuous stroke mm: 100 Spindle diameter mm: 50 Cutting tool cutting wheel mm: 232 Cutting wheel for perforation mm tool: 360 Length of material max mm: 2,600 Equipped for profiling: yes Automatic kontherholz: yes Glaucoma: Yes Workpiece rotation: Roller transport Main engine power kW: 11 Max feed rate m / min: 8 Control: Spindle ON / OFF only Working condition: dismantled / stored "

Condition: excellent (used), Year of construction: 1996, functionality: fully functional, Weinig Unicontrol 10 Year of manufacture: 1996 Technical condition: Very good Description: The Weinig Unicontrol 10 is a CNC automatic machine designed for planing and profiling wooden elements, particularly used in the production of windows and doors. It combines the functions of four-sided planing and precise profiling. Main features: ✅ Automatic adjustment of spindles and guides using a CNC system ✅ Very high machining precision – ideal for serial production ✅ Fast machine setup thanks to profile setting memory ✅ Robust and durable frame construction ✅ Suitable for working with various types of wood – both soft and hard Fgsdpjwbikbofx Afpjh Included in the set: Weinig Univar 6, year of manufacture: 1996, in very good condition.

Condition: ready for operation (used), Year of construction: 1993, functionality: fully functional, WEINIG, Type UNICONTROL 10/3, Machine No. 032-1136, Year 1993 Technical Specifications: Crosscut saw with 4-station turret, laser alignment light Vertical stroke 125 mm Speed 2800 rpm Spindle ø 40 mm Tool ø 350 mm Clamping length 40 mm Horizontal stroke 160 mm Motor 4 kW Fjdpfx Ajwk U Rlefpogh Extraction ø 80 mm UNITEC slotting spindle 50 x 300 mm 3 tools Vertical stroke 2 x 100 mm Speed 3500 rpm Spindle ø 50 mm Tool ø 300-320 mm Clamping length 300 mm Motor 11 KW Extraction ø 140 mm UNIVAR milling spindle 50 x 285 mm (co-rotating spindle) 3 tools Vertical stroke 2 x 95 mm Speed 6000 rpm Spindle ø 50 mm Tool ø 232 mm Clamping length 285 mm Horizontal stroke 80 mm Motor 11 KW Extraction ø 140 mm UNIVAR milling spindle 50 x 285 mm 3 tools Vertical stroke 2 x 95 mm Speed 6000 rpm Spindle diameter 50 mm Tool diameter 232 mm Clamping length 285 mm Horizontal stroke 80 mm Motor 11 KW Extraction diameter 140 mm Design: Working width min. 30 mm / Working height min. 30 mm Working height max. (with stroke) 100 mm / Working height max. (without stroke) 120 mm Feed speed 1.1 KW / continuously variable 6-12 m/min. LEITZ Dufix IV-68 EURO window tool set Digital display for studio windows Mechanical length stop Screen control Double parts package Return roller conveyor Machine is technically and visually in good working condition NET PRICE: EUR 7,400 + VAT Delivery: EXW Delivery time: shortly upon request Inspection: upon request Subject to errors and prior sale.

Condition: used, Angular system Weinig Unicontrol 10 (UC 10) for the production of windows, elements and doors. Frame by frame, in series or individual part production with 2 tapping and slotted spindles incl. Oertli tool set * Aggregates: 1. Crosscut saw, NC axis, 3 kW, ø 40 mm, 2,800 rpm 2. First tapping and slotting spindle, NC axis, ø 50 mm, 15 kW, Clamping length: 640 mm (8 x 80) mm 3. Second tapping and slotting spindle, NC axis, ø 50 mm, 11 kW, clamping length: 400 mm 4. Profiling spindle 1, NC axis, ø 50 mm, 11 kW, clamping length: 4 x 80 mm 5. Profiling unit, horizontal from above, 3 kW 6. Profiling spindle 2, NC axis, ø 50 mm, 11 kW, clamping length: 4 x 80 mm 7. Profiling spindle 3, NC axis, ø 50 mm, 11 kW, clamping length: 400 mm 8. Profiling unit, vertical right, 3 kW 9. Profiling unit, vertical right from above, 3 kW 10. Profile milling unit, horizontal from below, NC axis 3 kW * Double part package * Milling package with milling carriage * Automatic turning system * PC control NEXUS * CNC controlled length stop * Studio window facility * Aggregate for edge rounding from below with a crosscut saw * Rung support bar * Incl. suction pipe system * Incl. tool set Oertli * Further technical data and tool drawings on request. Fgsdpfev Ag Tdsx Afpjh

Condition: used, Combined tenon, slot and rebate angle machine Weinig UC 10, for the flexible production of various windows, elements and doors without changing tools. Frame-wise, serially or individual parts production, including tool set Oertli Wood/Alu IV 77 & 67 and Wood IV 77 & 67. · Aggregates: 1. Cross-cut saw: NC controlled, ø 40 mm, 3 kW 2. Tap and slot spindle: clamping length: 640 mm, ø 50 mm, stroke: 8 x 80 mm, 11 kW 3. Profiling spindle 1: clamping length: 320 mm, ø 50 mm, stroke: 4 x 80 mm, 11 kW 4. Profile milling unit, horizontal from above, 3 kW, ø 40 mm, clamping length: 40 mm 5. Profiling spindle 2: clamping length: 320 mm, ø 50 mm, stroke: 4 x 80 mm, 11 kW 6. Profile milling unit, vertical right, 3 kW, ø 40 mm, clamping length: 160 mm 7. Profile milling unit, horizontal from below, 3 kW, ø 40 mm, clamping length: 125 mm · Studio window setup · CNC controlled length stop · Slat conveyor including conveyor belt for automatic return transport to the operator · NC-axis: feed height adjustment · Milling package · Incl. tool set Oertli Wood/Alu IV 77 & 67 as well as Wood IV 77 & 67. Fedpfx Aevmqtcsfpegh

Condition: used, Used control cabinet of a Weinig type Unicontrol 10 as a spare parts carrier or for building a new control cabinet. Contents include: * Siemens Simatic S5 * Siemens EMG 45 Fjdpferrk I Hsx Afpjgh
