CNC Window tenoning + profiling centre

Weinig Unicontrol 6

Condition: used, Year of construction: 1999, Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm Control Weinig PC-Nexus # 7015 Weinig Unicontrol 6 with NC spindles ----- Machine available for inspection while still in operation until September 2026 Summary of technical data (please inquire about any additional accessories included) Item 1: Cross-cut saw ----- > Electronic cross-cut saw, horizontally continuously adjustable > Number of tools: 1 unit > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser alignment light for identifying the cut position > NC length stop mounted on the slotting table included; positioning of the cross-cut saw integrated into the control system. > Length 3500 mm Item 2: Tenoning and slotting spindle ----- > Number of tools: variable, infinitely adjustable via NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely adjustable 254 mm via NC axis > Spindle speed: 3500 rpm > Spindle diameter: 50 mm > Max. tool diameter: 320 mm > Motor power: 11 kW Fjdezdk Hyspfx Aptspi Item 3: 1st profiling spindle (climb-cut and conventional-cut capable) ----- > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool cutting circle: 232 mm > Motor power: 7.5 kW Item 4: 2nd profiling spindle ----- > Position: vertical right > Number of tools: variable, infinitely adjustable via NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely adjustable 254 mm via NC axis > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool cutting circle: 232 mm > Motor power: 11 kW Item 5: Horizontal profile milling unit (top) ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Speed: 5,850 rpm > Max. tool cutting circle: 130 mm > Axial adjustment range: 2 positions > Radial adjustment range: 2 positions Item 6: 3. Profiling spindle (hardware groove spindle) ----- > Position: vertical, right > Tool clamping length: 160 mm > Axial adjustment range: 3 positions > Radial adjustment range: 2 positions > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Max. tool cutting circle: 210 mm > Motor power: 3.0 kW Additional features ----- > Network-ready (online capability) > Rebating unit for tear-free rebating > Double-part processing package > Return conveyor system for one-man operation: slat conveyor > Screen-based control system > Angled window processing unit > Electronic angle display for angled windows > Industrial PC, PC control/NEXUS > Excluding machining tools ----- Price of the above-mentioned machine available on request! ----- Optional extra: EUR 6,500.00 Note regarding used tools: We currently have used "Gold" series tools in stock (Stock No. #2790) Window tools (Gold series) for IV78 Wood and IV78 Wood/Aluminum Previously used on a Weinig Unicontrol 10; a jointing cutter is additionally required for use on a Unicontrol 6. Tool set for fixed-stroke or CNC spindle machines (80 mm and 95 mm stroke), (Tool set prepared for IV92 where technically feasible) Wood-aluminum tool set ...

Condition: used, Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm 1 used Weinig Unicontrol 6 window system ----- Manufacturer's description: For the production of individual parts, elements, and small series. Spindle arrangement: One cross-cutting saw, one single-sided tenoning and slotting spindle, one right-hand profiling spindle, one tenoning and slotting spindle, and profiling spindle suitable for holding multiple tools stacked on top of each other, with pneumatic spindle movement. Slotting table with motorized table movement and automatic transfer to the continuous, chainless rubber roller feed of the profiling unit. Feed height adjustment manually. Workpiece clamping via 2 pneumatic clamping cylinders. Length stop with scale and magnifying glass for frame or sash external dimensions. Tool positions (longitudinal and transverse machining) controlled via selector switch on the control panel. Technical Specifications ----- Crosscut Saw ----- Number of Tools: 1 Spindle Speed: 2,800 rpm Spindle Diameter: 40 mm Max. Tool Diameter: 350 mm Motor: 3 kW Mortise and Slot Spindle ----- Number of Tools: 3/4 pcs. for wood thicknesses IV 68 - IV 92 Spindle Speed: 3,500 rpm Spindle Diameter: 50 mm Tool Clamping Length: 320 mm Max. Tool Diameter: 320 mm Motor: 11 kW Profile Spindle ----- Number of Tools: 3/4 pcs. for wood thicknesses IV 68 - IV 92 Spindle Speed: 6,000 rpm Spindle Diameter: 50 mm Tool clamping length 320 mm Max. tool diameter 232 mm Motor 11 kW Special equipment: Synchronous spindle ----- Pneumatically timed forward/backward for tear-free rerouting of window sashes, frames, and doors. Spindle diameter 50 mm, 4 kW Fodpfjx Tu N Hjx Aptepi Tool clamping length 120 mm, zero tool diameter 112-140 mm Max. tool diameter 232 mm, spindle speed 6000 rpm Motor boost for synchronous spindle from 4 kW to 7.5 kW Screen control for 99 window types. One type can contain up to 8 different parts, each with 2 end profiles and 2 longitudinal profiles. Production options: single parts, double parts, frame-by-frame, series, rerouting. Data entry via keyboard with integrated operator guidance and error diagnostics. 1 Grooving spindle from above ----- Motor power: 2.2 kW Speed: 6000 rpm Spindle diameter: 40 mm, with 10 x 4 mm key Clamping length: 13 mm Clamping length: 40 mm Axial stroke, 2 positions Radial stroke, 2 positions Max. tool diameter: 130 mm Grooving spindle motor boost from 2.2 to 3 kW 1 Fitting milling unit, right: ----- For milling fitting grooves in the circumferential milling pass or for grooving in the longitudinal profile. Pneumatic horizontal movement with selector switch on the control panel. Motor power: 2.2 kW Speed: 6000 rpm Spindle diameter: 40 mm Clamping height: 125 mm Tool cutting radius: min. 140 mm, max. 180 mm Home position below table level: 10 mm Special design of the fittings milling machine: Clamping length 150 mm Axial stroke 80 mm, 3 positions 3 tools Radial cycle, 2 positions Motor booster for the hinge milling spindle from 2.2 to 3 kW Hinge milling spindle for 230 mm tool diameters in and above the table Electric height adjustment of the feed with selector switch on the co...

Condition: reconditioned (used), Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm control Weinig, PC-Nexus # 2764 Weinig Unicontrol 6 with NC spindles ----- Machine will be cleaned and completely checked before delivery Technical data summary (please enquire about any additional accessories included) Item 1: Cross-cut saw ----- > Electronic cross-cut saw, infinitely adjustable horizontally > Number of tools: 1 piece > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3.0 kW > Laser aiming light for detecting the saw section > NC length stop, mounted on slot table included Positioning of the cross-cut saw integrated in the control system. > Length 3500 mm Item 2: tenoning spindle ----- > Number of tools: variable, infinitely variable adjustment NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely variable adjustment 254 mm NC axis > Spindle speed: 3500 rpm > Spindle diameter: 50 mm > Max. tool diameter: 320 mm Fsdjvu Hfqjpfx Aptjpi > Motor power: 11 kW Item 3: 1st profiling spindle (synchronous spindle and counter-rotation) > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Max. tool flight circle: 232 mm > Motor power: 7.5 kW Item 4: 2nd profiling spindle ----- > Position: vertical right > Number of tools: variable, infinitely variable adjustment NC axis > Tool clamping length: 320 mm > Vertical spindle stroke: variable, infinitely variable adjustment 254 mm NC axis > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Tool flight circle max.: 232 mm > Motor power: 11 kW 2 feed rollers opposite the spindle, axially pneumatically controlled, 2 positions Rung guide consisting of: Guide ruler in the stop (area of ??synchronous spindle), Rung support bar from above in the area of ??profile milling unit vertical right and profiling spindle. Pos. 5: Profile milling unit horizontal top ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Speed ??5,850 rpm > Tool flight circle max. 130 mm > Axial adjustment range 30 mm, 8 positions using pneumatic turret > Radial adjustment range 125 mm, 8 positions using pneumatic turret Pos. 6: 3rd profiling spindle (fitting spindle) ----- > Position: vertical right > Tool clamping length: 160 mm > Axial adjustment range 115 mm, 8 positions using pneumatic turret > Radial adjustment range 100 mm, 8 positions using pneumatic turret > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Max. tool flight circle: 210 mm > Motor power: 3.0 kW Other features ----- > online-capable > rebating device for tear-free rebating > double parts package > return conveyor for 1-man operation: tilting belt > screen control > inclined window device > electronic angle display for inclined windows > industrial PC, PC control/NEXUS > Weinig type production program > without processing tools No original images available yet. Images show identical machines from our archive. ----- Price of the above-mentioned machine upon request! ----- Optional with additional charge: EUR 6.500,00 Note on used tools: We currently ha...

Condition: ready for operation (used), Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 40/50 mm # 2809 Weinig Unicontrol 6 ----- Machine will be checked in our factory before delivery! Technical Data Summary (Please inquire about any additional accessories included) Item 1: Cut-off saw ----- > Number of tools: 1 pc. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Maximum tool diameter: 400 mm > Motor power: 3.0 kW > Laser guide light for identifying the saw cut CNC-controlled length stop ----- > Length: 3,600 mm > Electronic length stop including positioned cut-off saw Item 2: Tenoning spindle ----- > Number of tools: 3 (stroke 2 x 100 mm) or 4 (Stroke 3 x 80 mm) > Tool clamping length: 320 mm > Pneumatic vertical spindle stroke: 240 mm for wood thicknesses 68 - 92 mm > Spindle speed: 3000 rpm > Maximum tool swing diameter: 320 mm > Spindle diameter: 50 mm Fedpfx Apextvgkstspi > Maximum tool diameter: 360 mm > Motor power: 11 kW Item 3: 1. Profiling spindle (co-rotation and conventional) ----- > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Maximum tool swing diameter: 232 mm > Motor power: 7.5 kW Item 4: 2. Profiling spindle ----- > Position: Vertical right > Number of tools: 3 (stroke 2 x 100 mm) or 4 (stroke 3 x 80 mm) > Tool clamping length: 320 mm > Pneumatic vertical spindle stroke: 240 mm for wood thicknesses 68 - 92 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Maximum tool swing diameter: 232 mm > Motor power: 11 kW 2 axially indexed feed rollers opposite the profiling spindle, for the production of narrow, short parts (e.g., glass-dividing muntins) Munch guide consisting of: Munch support strip from above in the area of ??the vertical right-han d profile milling unit and profiling spindle. Item 5: Horizontal top profile milling unit ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Spindle speed: 5,850 rpm > Maximum tool swing diameter: 130 mm > Axial travel: 52 mm, indexed in 2 positions > Radial travel: 125 mm, indexed in 2 positions Item 6: 3rd profiling spindle (fitting spindle) ----- > Position: Vertical right > Tool clamping length: 160 mm > Axial travel: 90 mm, indexed in 3 positions > Radial travel: 100 mm, indexed in 2 positions > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Maximum tool swing diameter: 210 mm > Motor power: 3.0 kW Further features ----- > Electric feed height adjustment including mechanical digital display and manual feed bar clamping > Rebating device for tear-out-free rebating > Double part package > Return conveyor for 1-person operation: swivel conveyor > Screen control > Angled window device > Electronic angle display for angled windows > Industrial PC with Windows PC control/NEXUS Extraction nozzle diameter: ----- Crosscut saw 80 mm Tenoning spindle 140 mm Profile spindle 1 140 mm Profile spindle 2 140 mm Grooving device from above 80 mm Hardware spindle 120 mm -----...

Condition: used, Used control cabinet from a Weinig Unicontrol 6, suitable as a source of spare parts or for building a new control cabinet. Fjdpfx Apjt Na Drotspi Contents include, among others: - Brake unit Hilger & Kern - Transformer Rathgeber type ET 1000.

Condition: reconditioned (used), Tenoning spindle 1 St. Number of milling agregates 5 St. Spindle diameter 50 mm Control Weinig, PC-Nexus # 2774 Weinig Unicontrol 6 with NC spindles Machine will be cleaned and completely checked before delivery ----- Technical data summary (please enquire about any additional accessories included) Item 1: Cross-cut saw ----- > Number of tools: 1 pc. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Max. tool diameter: 400 mm > Motor power: 3 kW > Radial adjustment path pneumatically controlled to 8 positions, e.g. for edge rounding from above > Laser aiming light for detecting the saw section Item 2: Rounding unit horizontal below ----- > Position: horizontal below > Motor power: 1.5 kW > Spindle diameter: 20 mm > Clamping length 25 mm > Spindle speed: 9,000 rpm > Max. tool flight circle: 130 mm > Axial adjustment path mechanically coupled with Crosscut saw > Adjustment path radial pneumatically controlled on/off Length stop NC controlled ----- > Length 3500 mm > Electronic length stop Item 3: Tenon and slot spindle ----- > Number of tools: variable, stepless adjustment, NC > Tool clamping length: 320 mm > Vertical spindle stroke: variable 254 mm, stepless adjustment, NC-controlled > Spindle speed: 3500 rpm > Tool flight circle max. 320 mm > Spindle diameter: 50 mm > Tool diameter max.: 320 mm > Motor power: 11 kW Item 4: 1. Profiling spindle (same and opposite rotation) ----- > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm Fpedpfx Apevu Hghstoi > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Tool flight circle max.: 232 mm > Motor power: 7.5 kW Item 5: 2nd profiling spindle ----- > Position: vertical right > Number of tools: variable, stepless adjustment, NC > Tool clamping length: 320 mm > Vertical spindle stroke: variable 254 mm, stepless adjustment, NC-controlled > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Tool flight circle max.: 232 mm > Motor power: 11 kW 2 feed rollers axially pneumatic opposite the spindle controlled, 2 positions Rung guide consisting of: Guide ruler in the stop (area of ??the synchronous spindle), Rung support bar from above in the area of ??the profile milling unit vertically on the right and profiling spindle. Pos. 6: Profile milling unit horizontal top ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Speed ??9,000 rpm > Tool flight circle max. 130 mm > Axial adjustment range 30 mm, 8 positions > Radial adjustment range 125 mm, 8 positions Pos. 7: 3rd profiling spindle (fitting spindle) ----- > Position: vertical right > Tool clamping length: 160 mm > Axial adjustment range 115 mm, 8 positions > Radial adjustment range 110 mm, 8-way turret > Spindle speed: 5850 rpm > Spindle diameter: 40 mm > Tool flight circle max.: 210 mm > Motor power: 3.0 kW Item 8: Profile milling unit/grooving unit from below ----- > Motor power: 3.0 kW > Tool clamping length: 125 mm > Axial adjustment range 100 mm, 8 positions > Radial adjustment range 1...

Condition: excellent (used), WEINIG Window Production Line, Unicontrol 6, S/N 035-823, year 1997 Crosscut saw, pneumatically indexed (3 kW) with laser alignment light Slotting spindle 50 x 320 mm for 4 tools at 80 mm each – 11 kW motor Parallel spindle 50 x 120 mm – 7.5 kW motor Longitudinal profiling spindle 50 x 320 mm for 4 tools at 80 mm each – 11 kW motor Fitting spindle, pneumatically indexed, 40 x 160 mm – 3 kW motor Saw/grooving spindle, horizontal top, pneumatically indexed – 3 kW motor Feed speed adjustable from 6–12 m/min – 1.1 kW motor Screen control for 99 window types Support bar for muntin production, pneumatically indexed Studio window setup with digital angle display Length stop up to approx. 3,500 mm Corner jointing unit with support rail Return conveyor to operator side Machine complete with operating manuals, circuit diagrams, spare parts lists LEITZ tool set, IV-78 THE SYSTEM IS IN VERY GOOD TECHNICAL AND COSMETIC CONDITION Fpjdpfx Aey Dud Eoptei Delivery: EXW Delivery time: Prompt by arrangement Inspection: By appointment Payment: Upon notification that the goods are ready for dispatch Subject to prior sale and errors excepted.
