Heavy-duty lathe

Weisser Heilbronn GIGANT CNC

Condition: used, Technical details: turning diameter over bed: 1040 mm turning diameter over support: 720 mm centre distance: 5400 mm center height over bed: 540 mm control: Siemens 828D CNC mit shop turn turning dia. in gap: 1300 mm length of gap: 640 mm spindle bore: 152 mm revolution per minute: 3,5...1000/ 4 steps U/min feed:: x-Achse: 37,24 (m/min) m/min feed:: z-Achse: 21,91 (m/min) m/min force of feed longitudinal: x-Achse: 6,44 (KN) N feed force Z - max.: 17,2 (KN) N tailstock taper MT: MK 6 tailstock quill stroke: 300 mm total power requirement: ca. 30 kW weight of the machine ca.: 14,1 t space requirement approx.:: L:7,7xB:1,7xH:2,0 m CNC Lathe with shop turn Rjdpou Ix Rpefx Agijck Geometric overhaul is in procedure. Equipment: - headstock Morse 6, travel of spindle sleeve 300mm - thread cutting possible (metric thread, inch threads, module threads) - multi quick steel holder swiveable 360° - 3-jaw lathe chuck Ø=630mm - chuck protection - 2 steady rests (Lynettes) (1x fixed + 1x fixed open) - 4 pcs tips for tailstocks - 5 x multi quick change steel holder for chisel - 1 x drill chuck 16mm + 2x drills with MK-cone sleeves 68,5mm & 24,75mm - 1 lot self constructed clamping means Accessories: - face chuck Ø=800mm (adaptation necessary) - CNC turning with shop turn - your benefits at first glance: - flexible programing via graphic interactive (without DIN/ISO knowledge) or text programming with contour definition and cycle support - user friendly operation through practical set up -and measuring operations, clearly arranged tool managment and 3D-Simulation - increase of productivity via supporting PC-Software for work preparation without machine assignment *

Year of construction: 1998, condition: good (used), Make: UNION Type: Ti 1800 Year: 1998 Specifications Metric US Standard Table Length 2000 mm Table Width 1800 mm Table load 16000 Movement V-axis 1250 mm Rotation B-Axis 360.000 ° Rotation speed B-Axis 1,35 Omw/min. Movement speed V-axis 4000 mm/min. Dimensions (Estimate) Rsdpjkwcdbjfx Agisck Length 3400 mm Width 2000 mm Height 920 mm Weight 6500 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 1982, Technical details: faceplate diameter: 2600 mm turning diameter over support: 2500 mm turning length: 450 mm centre distance: 1600 mm turning diameter over bed: 2900 mm spindle bore: 100 mm revolution per minute: gear steps U/min feed range: Überdrehen 0,12-31,5 Plandrehen 0,12-45 mm/min bed guideways length: 2900 mm max. workpiece weight between centres: 400.000 kgs total power requirement: 45 kW weight of the machine ca.: alle Komponenten zusammen: ca. 29,0 t machine dimensions LxWxH: 5.2 x 5,0 x 3,1 m 3-way measuring system with digital display RSF electronics Control panel Cooling unit for Rittal electric cabinet Rjdpfswtctysx Agisck *

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, SFM Sunfirm CNC lathe in good working condition. Specifications: Swing diameter over bed: 1520 mm Swing diameter over cross slide: 1100 mm Swing diameter in gap: 1800 mm Distance between centers: 3000 mm Spindle speed: 6–500 rpm in 4 steps Rjdpfxow Uqf So Agiock Z-axis travel: 3300 mm Bed width: 850 mm Control: FAGOR 8055 8-position turret Motor power: 30/37 kW Accessories: 4-jaw chuck 1400 mm Chip conveyor 8-position turret Steady rest

Year of construction: 1971, condition: ready for operation (used), A heavy face lathe Ravensburg is available. Center height: 600mm, faceplate diameter: 800mm, turning diameter over bed/cross slide: 900mm/1200mm, max. turning length: 600mm, max. workpiece weight: 350kg, weight: approx. 6100kg. An on-site inspection is possible. Redpfx Aexq Eynogisck

Condition: used, Year of construction: 2007, table length 3000 mm table width 2000 mm table load 25 t longitudinal adjustment 1500 mm rapid traverse 6 m/min total power requirement 12 kW Rjdsw Rrbtepfx Agisck weight of the machine ca. 18,5 t dimensions of the machine ca. 5 x 2,3 x 1,2 m Table has hydrostatic guideways and SPS (Siemens) control.

Condition: excellent (used), Year of construction: 2001, AN VERY RARE OPORTUNETEY TO BUY AN EXCELLENT MACHINE WITH HUGE AMOUT OF TOOLINGS, DRAWERS, CLAMPING EQUIPMENT... CNC BORING MILL WOTAN RAPID 1 RETRIFITTED 2001 WITH HUGE AMOUNT OF OVER 450 TOOLING VERY LOW HOURS WORKING TIME DATA: CONTROL ON: 8001 H MACHINE POWER ON: 13692H PROGRAM RUN: 4650 H SPINDLE S1 TIME: 4690 H AXIS TIME: 4568H HYDRAULIC ON TIME: 12702 H WE OFFER AN STUNNING EXCELLENT CONDITION WOTAN CNC RAPID 1 WITH HUGE AMOUNT OF TOOLINGS, FOR A SPECIAL STAINLESS WORK. MACHINE HAVE HEIDENHAIN 530 CONTROLS TECHNICAL DETAILS: SPINDLE SPEED : 6,3-1600 U/Min SPINDLE MOVE : Y AXIS : 1250 mm DRILLING SPINDLE MOVE: Z AXIS: 600 mm Rsdpfx Asvkkf Hogijck W : 1000 mm X : 2000 mm B: 360.000 DEGREE SPINDLE DIAMETER: 105mm TOOL HOLDER: ISO 50 WITHOUT TOOL CHANGER CLAMPING: HIDRAULIC MAX TABLE LOAD: 6000 KG TABLE: 1120 X 1400 NUT -BILD 7 ; 22H7 INDEXING 4 X 90 DEGREE TOTAL WEIGHT: 16000 KG DIMENSION OF MACHINE: LENGHT 4800 X BREIT 4665 X HEIGHT 4200

Condition: used, Year of construction: 1995, functionality: fully functional, Technical data Control system Siemens Sinumerik 840 Dsl Main dimensions and travels Face plate diameter 3,600 mm Rotation diameter (max.) 4,200 mm Workpiece height (max.) 4,800 mm Total height of the machine 8,700 mm Maximum workpiece weight 80,000 kg. Table base Y Horizontal table displacement 2,000 mm Cross beam Vertical adjustment of the cross beam in 100 mm steps 2,800 mm Crossbeam support (right) Horizontal adjustment of support - 1,800 to + 2,200 mm Vertical adjustment of the chisel slide 1,500 mm Cross-section of the chisel slide 240x240 mm Tool positions 20 pcs. Without vertical support (left) Lateral support (right) Vertical adjustment of support 2,800 mm Horizontal displacement of the chisel slide 1,000 mm Cross-section of the chisel slide 240x240 mm Turning diameter max./min. 4500/2500 mm Tool changer Main drive: Power of the main motor 105 kW Speed range of the faceplate 0.4-90 rpm Maximum torque on the faceplate Drilling and routing drive Vertical support: Power of the drive motor 22.5 kW Maximum torque 900 Nm Side support drilling and milling drive: Power of the drive motor 22.5 kW Maximum torque 900 Nm Connection values of the machine Machine connection voltage 380 Volt / 50Hz Control voltage 220V AC / 24V DC Total connected load 150 kVA Required back-up fuse 400 A Equipment and accessories: Operator platform Chip conveyor Cooling lubricant system Rsdpfx Agju R Imloijck Tool changer Tool measuring probe RENISHAW

Condition: ready for operation (used), Year of construction: 1992, Immediately available ex-location: CNC lathe Gildemeister Type CT 60 Year of manufacture: 1992 CNC control: EPL 2 Turning diameter: 360 mm Turning length: 1000 mm Swing diameter over bed: 600 mm Swing diameter over cross slide: 360 mm Travel X axis: 1100 mm Travel Z axis: 380 mm Chuck: 250 mm Spindle bore: 108 mm Spindle speeds: 16 – 3150 rpm Drive: 30 kW Turret: 12 positions Driven tools Rapid traverse: 10 m/min Tailstock: MK 5 Quill stroke: 180 mm Accessories: jaws Chip conveyor Weight: 6.5 t Price: EUR 5,500 – plus VAT, ex-location Rsdpfx Agex Ihk Tjijck
