Gear Hobbing Machine - Vertical
WMW HECKERT ZFWVG 250x2000/3

Name: WMW HECKERT ZFWVG 250x2000/3
Brand: WMW HECKERT
Availability: InStock

Condition

Used

Location

Germany

Gear Hobbing Machine - Vertical WMW HECKERT ZFWVG 250x2000/3

Show map

Machine data

Machine type:: Gear Hobbing Machine - Vertical

Manufacturer:: WMW HECKERT

Model:: ZFWVG 250x2000/3

Condition:: used

Price & Location

Location:: , Germany

Call

Details about the offer

Listing ID:: A188-73076

Reference number:: 1087-0400814

Update:: 06.01.2026

Description

Technical details:

center height over bed: 260 mm
workpiece dia. over bed: 500 mm
workpiece dia. over support: 250 mm
hobbing length: 2000 mm
number of teeth: 2 - 50
feed:: 0,023 - 5,17 / mm/min
module max. : 8 / 12
Fpjdpfx Aev U T Dysgmeb
spindle bore diameter: 102 mm
workpiece rpm : 18 - 224 U/min
tailstock quill adjustment: 100 mm
total power requirement: 9,5 kW
weight of the machine ca.: 5,2 t
dimension machine xH: 3,6 x 2,1 x 2,0 m
