Sliding table saw

Altendorf F45

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, cutting width (max.): 1,300 mm, saw blade diameter: 500 mm, Equipment: scorer, TECHNICAL DETAILS Double roller carriage length: 3,000 mm Cutting width: 1,300 mm Drive power: 5.5 kW Saw blade diameter: 500 mm Table extension: 840 mm Knsdpfxexnx Hco Afpec EQUIPMENT 2-axis scoring unit Mitre/fence angle stop

Year of construction: 2008, condition: ready for operation (used), This Altendorf F45 ELMO IV was manufactured in 2008. A robust panel saw featuring a double roller sliding table with a length of 3400 mm and a cutting width of 1300 mm, CNC controlled. It includes a powerful 5.5 kW VARIO drive and can handle a max saw blade diameter of 500 mm. Ideal for precise and versatile cutting tasks. Contact us for more information about this machine. Kodpfx Aoxp Spaefpjnc Application Types Sawing (Wood)

Condition: used, Year of construction: 1993, sliding table length: 2800 mm cutting width at the fence: 1250 mm cutting width at the cross cut: 2800 mm cutting depth: 145 mm scoring unit: ja height adjustment sawblade: elektrisch tilting adjustment sawblade: elektrisch adjustment fence: manuell readout sawblade tilting: Digital read out sawblade height: - Kodpfx Aexp Raksfpjnc read out fence: Scala read out crosscut stop: Scala sawblade diameter: 450mm number of speeds: 4 motor power: 5,5kW motor brake: ja - automatisch suction connection: 80mm und 120mm machine length: 3000mm machine width: 2200mm weight: 1000kg

Condition: used, Year of construction: 2018, Used machine Year of manufacture 2018 Basic equipment Electric height and tilt adjustment 0-46° with automatic cutting height correction when tilting Control at eye level, pivoting Double sliding table, table length 3,000 mm Parallel stop, manually adjustable via scale, including manual fine adjustment Cutting width 1,000 mm Angle stop with fixed 90° position, manually adjustable via scale up to 3,200 mm Max. sawblade projection 150 mm Max. sawblade diameter 450 mm Drive power 4 kW (5.5 HP) at 4,000 rpm AKE tool clamping system for the main sawblade Working height 91 cm Kjdpjxppv Rsfx Afpsnc Productivity package Motor 5.5 kW (7.5 HP) with VARIO F45 - Continuously variable speed control from 2000 - 6000 rpm - Precise speed adjustment to the material increases cutting quality and sawblade service life. Extended cutting height for one-sided tilting This option is equipped with a large extraction hood for a max. sawblade diameter of 550 mm and a max. sawblade projection of 204 mm for one-sided tilting. In combination with a scoring unit, the max. sawblade diameter is 500 mm or 179 mm cutting height. Only in conjunction with a minimum drive power of 5.5 kW (7.5 HP). Two-sided tilting! RAPIDO Plus 3-Axis Scoring Unit With electric height and lateral adjustment, programmable scoring blade height with quick lowering and quick raising, drive motor 0.75 kW (1 HP), 8200 rpm. Retrofitting only possible on machines prepared for a scoring unit. LED Lighting With particularly energy-efficient LED technology, the danger area of the scoring unit is clearly marked. Sliding Table with a Carriage Length of 3000 mm Basic Equipment Sliding Table with a Carriage Length of 3000 mm The Altendorf sliding table is famous for its smooth and precise operation. It can be infinitely locked in any position. The large double rollers, precision-machined from hardened steel, hold the upper carriage in connection with the lower carriage with absolute precision in the respective hard-chrome-plated guide rods. This running quality is maintained even after decades of use and contamination. The carriage is designed as an extremely torsion-resistant and dimensionally rigid multi-cavity system. The table surface is precisely planed and anodized. A hard-chrome-plated round bar, which is positively embedded in the upper carriage, serves as a mount for the cross slide and as an interface for various accessories. The entire unit is low-maintenance and requires no lubrication. DIGIT-L Angle Miter Stop, Cutting to Lengths up to 3500 mm This ALTENDORF-patented stop with integrated length compensation facilitates precise cutting of angles and miters in one function. In both positions, the swivel angle is continuously adjustable by 49° and is digitally displayed. The play-free and robust stop flaps can be easily moved and adjusted as individual flaps over the entire range up to a maximum of 3500 mm. For cutting to lengths up to approx. 1700 mm, the roller-supported, stable telescopic

Condition: excellent (used), Year of construction: 1993, functionality: fully functional, machine/vehicle number: 93-09-128, saw blade diameter: 350 mm, power: 5.5 kW (7.48 HP), sliding table length: 2,800 mm, Panel saw Altendorf F 45, year 1993, with 2800 mm sliding table, max. blade 350 mm, main motor 5.5 kW, scorer motor 0.75 kW, with width extension and length extension. Knjdpfx Aoxp Rk Nsfpsc

Condition: excellent (used), CATALOGUE NUMBER 7731 - Maximum main saw blade diameter without scorer: 400 mm - Maximum main saw blade diameter with scorer: 350 mm - Cutting height with 400 mm blade: 110 mm Kodpfjxa Elpsx Afponc - Electrically adjustable saw blade height and angle - Electric angle display - Arbor diameter: 30 mm - Scorer blade diameter: 120 mm - Electrically adjustable scorer height and lateral position - With sliding table - Sliding table cutting length: 2900 mm - Pressure beam: 1480 mm - Sliding table guidance on steel bars - Cutting width with rip fence: 1350 mm - With side carriage - Main motor: 5.5 kW - Scorer motor: 0.75 kW - Electric brake - 4 spindle speeds: 3000/4000/5000/6000 rpm - Electronic speed display - Extraction port diameter: 90/120 mm - Table dimensions with extension and widening: 2060 x 1410 mm - Blade guard - Machine dimensions (LxWxH): 3150 x 3650 x 1550 mm - Weight: 1155 kg ADVANTAGES – German manufacture – Electric adjustment of the saw and scorer – With scorer – Pressure beam – Unpainted – Used saw in very good condition Net price: PLN 33,900 Net price: EUR 7,980 (at the exchange rate of 4.25 EUR) (Prices may fluctuate with significant currency changes)

Condition: excellent (used), Year of construction: 1986, Used, good condition Make: Altendorf Knedpswhgd Ssfx Afpoc Type F45 Year of manufacture: 1986 Machine No. 86-4-143 GS-tested Motor: 5.5 kW Carriage length: approx. 2500 mm Cutting width: approx. 800 mm Pivotable up to 45° Saw blade diameter: 450 mm Parallelogram guard Miter stop Extraction connection: D 80 and 120 mm Space required: approx. 2500 mm x 1600 mm x 1500 mm Weight: approx. 1000 kg Storage location: 54634 Bitburg, Germany, free on load, unpacked Sold in the current condition as seen, without warranty or guarantee

Condition: reconditioned (used), Year of construction: 2020, functionality: fully functional, cutting length (max.): 3,400 mm, cutting width at rip fence: 1,300 mm, saw blade diameter: 450 mm, table length: 840 mm, power: 5 kW (6.80 HP), Equipment: lighting, rotational speed infinitely variable, scorer, Used machine GM010.0303 Ksdow Im I Aopfx Afponc Year of manufacture: 2020 F45 ElmoDrive Machine height: 910 mm Eye-level operation Dual-sided tilting (+/- 46°) Max. blade diameter: 450 mm Motor 5.0 kW (7.5 HP) VARIO 2-axis scoring unit incl. park position LED lighting Table extension 840 mm Double roller carriage with carriage length 3400 mm DIGIT L angle-mitre fence CNC parallel fence 1300 mm Laser-cut kerf indicator

Condition: used, Year of construction: 2006, Carriage length: 3000 mm Cutting width at rip fence: 1000 mm Cutting width at cross-cut fence: 3200 mm Cutting depth: 154 mm Scorer: yes Saw blade height adjustment: electric / position control Saw blade tilt adjustment: electric / position control Rip fence adjustment: electric / position control Cross-cut fence adjustment: manual Saw blade angle display: digital readout Cutting height display: digital readout Rip fence display: digital readout Cross-cut scale display: scale Cross-cut scale with miter function: yes Saw blade diameter: 450 mm Speeds: variable Motor power: 5.5 kW Extraction connection: 80 and 120 mm Knjdpoxp Radofx Afpjc Machine length: 3200 mm Machine width: 2200 mm Weight: 1200 kg

Condition: new, Year of construction: 2025, functionality: fully functional, cutting length (max.): 3,105 mm, cutting width (max.): 1,300 mm, cutting width at rip fence: 1,300 mm, cutting height with scoring (max.): 150 mm, saw blade diameter: 450 mm, height adjustment type: electric, table height: 910 mm, rotational speed (min.): 3,000 rpm, rotational speed (max.): 5,000 rpm, type of input current: three-phase, input voltage: 400 V, warranty duration: 12 months, power: 7.5 kW (10.20 HP), Altendorf F45 Pro Drive The machine is new and configured as follows: Working height: 910 mm Sliding table length: 3200 mm Control panel at eye level for comfortable operation Cutting height: 150 mm with a 450 mm saw blade Main motor: 7.5 kW with three rotation speeds; features the AKE saw blade changing system 2-axis scoring unit with a safety LED light in the scoring area, enhancing operator awareness when the scoring unit is active Main motor and scoring unit ON/OFF buttons on the sliding table for convenient machine startup Mitre crosscut fence, extendable to 3500 mm, with angle correction Knjdpfx Asxaudhofpjc Cutting width: 1300 mm with CNC, programmable via the screen Gobjxaudhskr A Tq Djkc Motorized rise, fall, and tilt adjustment (0–46°) for the main saw blade, with automatic cutting height correction when the blade is tilted The Altendorf F45 has long been recognized as the flagship of sliding table saws, consistently setting the highest quality standards for this type of machine.
