Injection moulding machines

ARBURG 470 C 1500-400 Golden Editions

Condition: used, Year of construction: 2021, clamping force: 120 kN, displacement volume: 36 cm³, injection pressure: 2,200 bar, overall weight: 5,400 kg, load hours: 3,500 h, screw conveyor diameter: 22 mm, terms of delivery: EXW (ex Works) delivery time: on request terms of payment: 100% prior to delivery Fodpfx Aaexwy Utjmjfw

Condition: good (used), Year of construction: 2001, Ref. no.: 18404 Hersteller: ARBURG Type: 420C-1300-350 Year of construction: 2001 Clamping unit Clamping force: 130 ton Opening stroke: 500 mm Distance between tie bars: 420 x420 mm Mould height min.: 250 mm Opening width: 750 mm Platen size (h x v): 605 x 605 mm Injection unit Screw diameter: 45 mm Ffsdpfewm I A Tex Aamsw Injection volume: 230 cm³ Shot weight: 210 g Injection pressure: 1670 bar Measurements and weight Dimensions: 4,68 x 1,3 x 2,2 m Machine weight: 4080 kg Additional information & extras Core pull: 1 pcs

Condition: good (used), Year of construction: 2001, operating hours: 56,380 h, machine/vehicle number: 184172, Used injection molding machine Fsdovimd Nepfx Aamefw The machine has a complete history with all important repair work and components replacement hoses etc. Manufacturer: Arburg Type: 420C 1300-350 Year of construction: 2001 Machine no. 184172 Control system: Selogica Operating hours: 56380 h constant maintenance by manufacturer clamping unit Clamping force: 1300 kN/ 130 tons Distance between tie bars: 420 x 420 mm Mold mounting platens: 570 x 570 mm Ejector stroke: 175 mm / 40 kN Opening stroke: 500 mm Tool installation height: 250 mm Distance between platens: 750 mm max. Injection unit Injection volume: 145 ccm Injection weight: 127 g Cgu3U8W0U Screw diameter: 35 mm Injection pressure: 2500 bar Extras Hydraulic core pull - Available immediately from our warehouse in Hanover, free on delivery or free to your door against freight reimbursement - Functionally tested (guaranteed function until first commissioning)

Condition: excellent (used), Year of construction: 2019, Clamping force: 500 kN Opening force: 40 kN Opening stroke: 250 mm Screw diameter: 15 mm Includes 2 pcs. WITTMANN temperature control units Includes spare screw 15 mm Includes complete documentation Ffodexrymlopfx Aamsw The machine is in very good condition and immediately available from stock!

Condition: excellent (used), Year of construction: 2014, Equipment: documentation/manual, Arburg 470C 1500 400 (2014) Golden edition Clamping force: 150 t Screw diameter: 45 mm (wear resistant) Distance between tie bars V: 470 mm Distance between tie bars H: 470 mm Type: Horizontal Drive: Hydraulic Ffsdpjx Elqrefx Aamow Air blow 2 units Euromap 67 for robot 2 pumps machine Injection pressure incrased 10% (2500bar) HOURS: 54914

Condition: excellent (used), Year of construction: 2014, Arburg 420C 1000-290 (2014) e2 Clamping force (max): 1000 kN Opening force | stroke: 250 kN | 500 mm Mould height (fixed | variable, min): 250 mm Platen daylight (fixed | variable, max): 750 mm Distance between tie bars (w × h): 420 × 420 mm Mould mounting platens (w × h, max): 570 × 570 mm Weight of movable mould half (max): 600 kg Ejector force | stroke: 40 kN | 175 mm Dry cycle time (EUROMAP 2): 1,8 – 29,4 s Screw diameter: 40 mm Effective screw length (L/D): 17,5 Screw stroke (max): 150 mm Calculated stroke volume: 188 cm³ Shot weight (PS): 172 g Material throughput (PS): 24,5 kg/h Material throughput (PA6.6): 12,5 kg/h Injection pressure (max): 1530 bar Holding pressure (max): 1530 bar Injection flow (max): 182 cm³/s Screw circumferential speed (max): 62 m/min Screw torque (max): 430 Nm Nozzle contact force | retraction stroke: 60 kN | 240 mm Fsdpfx Ajxdl H Ioamsfw Heating capacity | zones: 7,7 kW | 5 zones

Condition: used, Year of construction: 2017, Arburg 470S 1100 290 injection moulding machine, year 2017 2-component machine The machine has been idle for quite some time. It is from 2017 and has only around 21,600 operating hours. The machine has a clamping force of 1100 kN; the lower unit is a 290 with a 35 mm screw, and the upper unit is a 100 with a 30 mm screw. Only ABS and TPE have been processed so far. The machine is equipped with an integrated hot runner system and 3 core pulls, along with additional options. Fjdpfjw D R N Rjx Aamofw Included is a Kuka handling unit, which is operated via the Selogica control of the machine, as well as the complete safety enclosure. The two material loaders and the large conveyor belt are not included in the sale.

Condition: excellent (used), Year of construction: 2015, Clamping unit: 50 tons Oppening stroke (max. kN/mm) : 30 / 250 Ffodpfx Aox H Nu Reamjw Mould height (fixed/variable) min.-max. mm: ---/172/272 Platen daylight (fixed/variable) max. mm: ---/422-522 Shuttle table stroke: 650 mm Screw diameter: 20 mm Injection volume: 31 cm3 Shot weight: 29 g Injection pressure: 2500 bar Working hours: 7600 hours 1 x hydraulic core 1 x pneumatic core 6 x hot runners

Condition: good (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 184686, clamping force: 1,000 kN, screw diameter: 25 mm, clearance between the columns: 420 mm, displacement volume: 54 cm³, injection weight: 45 g, For sale is an injection moulding machine from the brand Arburg, model 420 C 1000-150/60. The machine is in excellent technical condition and has been very well maintained. The machine is offered without peripherals. The rotary table, material feed, temperature control units, and other accessories are not included. Technical data: Year of manufacture: 2001 Clamping force: Clearance between tie bars: 420 x 420 mm Opening stroke: 500 mm Mould installation height: 250 mm Mould mounting plate: 570 x 570 mm Ejector stroke: 175 mm Fedex E U Elopfx Aamjfw Screw diameter: 25 mm Theoretical shot volume: 54 cm³ Shot weight: 45 g/PS Transport and loading can be organised on request, at an additional cost, Europe-wide. All prices are subject to VAT. Inspection by appointment is possible. Please contact us—our team is happy to assist you. Trade-in or exchange possible! Machinery purchase / sale BUYING / SELLING PRODUCTION & METALWORKING MACHINES AND MORE Are you looking for a high-quality yet affordable metalworking machine for your production? Or are you looking to sell yours? For further information or contact options, please visit our website.

Condition: refurbished (used), functionality: fully functional, clamping force: 350 kN, Awaiting refurbishment at our headquarters in Northamptonshire is this Arburg 221KS 350/100 U injection moulding machine. Fitted with a Selogica controller. This is a universal machine from Arburg which allows for the clamp unit to be pivoted vertically, ideally suited to insert moulding. These small machines are sought after for the many moulding options they can suit, from a very compact machine. Occasional vertical moulding requirement? These machines are ideal. In standard horizontal configuration, they operate the same as any traditional machine. Any machines awaiting refurbishment with us can be reserved with a 10% deposit and we then prioritise the refurbishment and aim to have the machine available for inspection within 8 weeks from order. Refurbished machines from STV Machinery undergo a comprehensive test procedure during which every function of the machine is tested and if necessary repaired. A production run of at least 5000 fault free cycles prior to sign off ensures trouble free operation once delivered. Machines are ultra clean and cosmetically as good as we can get them. We guarantee our refurbs are delivered fault free and leak free. Prices shown are ex-works, but we can quickly provide DAP (Delivered at Place) Incoterm pricing on request. We can take out the hassle and additional costs of purchasing machinery within the UK and EU. Contact us with a potential delivery address and we’ll do the rest. Ffsdpfx Aaswqnggomew Please note that the video shown is of a near identical machine previously refurbished by STV Machinery. It’s a good example of what can be expected once this machine is fully refurbished by our team. *The video shown in this listing is of a previously refurbished Arburg 221 which is similar to the Arburg 221KS machine we are currently refurbishing. Please contact the team if you would like to see the machine in person.
