Sorting belt paddle ejector

DIMTER

Condition: refurbished (used), DKV III continuous press with braking unit Completely overhauled Optional with original hydraulic motors or with servo motors Options: - Chain threading Rsdev T Aqyjpfx Alaocf - Co-rotating cut-off saw Function: For pressing the dovetail joint without stopping (in a continuous process). The upper and lower plate chains generate the feed force. Downstream braking plates transmit the required longitudinal pressing force to the wood through friction. Advantages: - High performance despite a relatively slow feed rate - Absolutely no vertical displacement of the dovetail joints Technology: Heavy-duty plate chain 2", pneumatically adjustable Braking elements are floating Press force measurement via contact manometer Height adjustment electrically Maximum press force adjustable and dependent on feed rate and wood cross-section, 4500 daN at 32 m/min 2200 daN at 70 m/min Feed rate adjustable 10-70 m/min Drive power Adjustment of infeed unit 1 kW Adjustment of brake 1 kW Hydraulic motors 45 kW Technical data: Wood width 90 - 180 mm Wood thickness 20 - 80 mm Ratio thickness - width 6 : 10 Wood cross-section with 15/16.5 mm tenon max. 90 cm²

Condition: repair required (used), functionality: unexamined, Dovetail grooving system for wood packages dimter HK 400 Dovetail grooving system Rcjdpovi Hw Nsfx Alajf Input lengths: 800–6,000 mm Grooving height: 285 mm, optional 300 mm Color: Blue Consisting of: Pos. 01 Packaging unit Pos. 02 Package roller conveyor Pos. 03 Central milling cutter Pos. 04 Package roller conveyor Pos. 05 Package singulation unit Pos. 06 Chain transverse conveyor Pos. 07 Infeed roller conveyor Pos. 08 Cycle press Pos. 09 Feed unit Pos. 10 Crosscut saw Including control cabinets and operator panels The system requires repair and is sold in its current condition. It has already been dismantled and is stored in Achern. All technical documentation is available. We are available at any time to answer questions about the system and provide technical information. We will provide consulting support for the repair and reassembly.

Condition: ready for operation (used), Year of construction: 2019, operating hours: 42,874 h, working width: 300 mm, cutting length (max.): 6,300 mm, workpiece width (max.): 120 mm, cutting speed: 300,000 mm/min, Optimizing Cross-Cut Saw manufactured in 2019. This WEINIG / DIMTER OptiCut 450 features a maximum board length of 6,300 mm and a wood thickness capacity ranging from 12 mm to 120 mm. It includes a powerful saw motor with 7.5 kW and a feed speed of up to 300 m/min. If you are looking to get high-quality cutting capabilities, consider the WEINIG / DIMTER OptiCut 450 machine we have for sale. Contact us for further details. • Working Height: 900 mm • Feed Direction: Left-hand feed • Blade Diameter: 500 mm • Blade Bore: 30 mm • Input Length, Min.: 500 mm • Input Length, Max.: 6,300 mm • Wood Width, Min.: 30 mm • Wood Width, Max.: 310 mm • Wood Thickness, Min.: 12 mm • Wood Thickness, Max.: 120 mm • Maximum Rectangular Wood Section: 310 × 12 mm • Maximum Rectangular Wood Section: 190 × 120 mm • Minimum Fixed Length After Sawing: 150 mm • Minimum Fixed Length at End of Board: 180 mm • Maximum Board Curvature: 10 mm/m • Length Tolerance: ±3 mm • Cutting Thickness Accuracy: ±0.8–1.5 mm • Feed Speed, Continuously Adjustable: Max. 300 m/min • Cutting Cycle Time, Including Braking and Acceleration: 0.6–1.0 sec. • Saw Motor Power: 7.5 kW (10 HP) • Feed Motor Power: 5.0 kW (7 HP) • Vario Conveyor Motor Power: 2.5 kW (3.4 HP) • Electrical Connection: Approx. 18 kW • Operating Voltage: 400 V / 50 Hz • Control Voltage: 230 VAC / 24 VDC • Nominal Current: 30 A • Fuses: 35 A • Compressed Air Consumption: Approx. 1,200 Nl/min • Operating Pressure: Approx. 8 bar • Extraction Air Velocity: Approx. 30 m/sec. • Extraction Air Volume: Approx. 1,800 m³/h Rodpfx Alezwu Hwsascf • Sorting Conveyor Width: 250 mm • Usable Conveyor Width: 210 mm • Maximum Workpiece Width: 300 mm • Exit Conveyor Length: 7.5 m • Automatic Width Measurement: Laser distance sensors • Width Measurement Accuracy: Max. ±2 mm • Number of Active Products: Max. 16 • Minimum Wood Thickness for Measurement: 12 mm • Scrap Pit Width: 250 mm • Maximum Scrap Length: Approx. 120 mm • Heavy-Duty Ejector: For workpieces over 20 kg • Ejector Plate Height: 80 mm • Writing Length: Workpiece length − 10 mm • Control Panel: OptiCom Pro 18.5" • Display Type: Industrial TFT touchscreen • Display Resolution: 1366 × 768 pixels • Front Protection: IP65 • Board Infeed Capacity: Up to 6.3 m • Marking Station: 2 marking positions • Marking Bench Length: 5 m • Electrical System: 400 V / 50 Hz • UPS: 24 V supply • Operating Hours: 42,874 h

Condition: used, Year of construction: 2010, functionality: fully functional, machine/vehicle number: 467334, Manufacture year 2010 Machine specifications: - Push infeed, max. length 6300 mm - Automatic length measuring and chalk reader - Cutting width 40 – 420 mm - Cutting height 15 – 170 mm Rcsdpfx Asypvdijlajf - Min. cross section 20 x 10 mm - Max. cross section 270 x 170 / 410 x 30 mm - Motor 13.5 kW - Total electrical load approx. 22 kW -Operating pressure approx. 8 bar - Saw blade diameter 630 mm / bore 30 mm Consisting of: 1. Cross chain infeed system 8 pc. chain transport with 3 latch rows 2. Push infeed system with liftable pusher Infeed length 6300 mm, length detecting and chalk reader 3. OptiCom Direct controller 4. Opticut cross cut saw unit S90 XL With side pusher and waste gate 5. Outfeed transport belt

Condition: used, Year of construction: 2007, Lamination press Manufacturer: Dimter Type: PROFIPRESS L2500 Year of manufacture: 2007 Technical data Wood dimensions to be processed Wood width, panels: 30 - 150 mm Wood thickness: 11 - 60 mm Wood inlet length: 800 - 2500 mm Panel widths, variable: max. 1300 mm Specific pressing pressure for cross-sections of 2500 x 60 mm: up to 1.6 N/mm2 The pressing surface per press cycle must not be smaller than 100 cm2 Filling width of the press per cycle: min. 650 mm / max. 1300 mm Max. filling area of the press per cycle: 3.25 m2 (The max. usable press width depends on the widths of the individual lamellas.) Wood type Softwood/hardwood Press without options Electrical connection, press: 7 kW Electrical connection, 40 kW generator: 56 kW Operating voltage: approx. 400 Volt / 50 Hz (C/s) Rcsdpfx Aszuzwqjlaof Collection table extended to 3700 x 1300 mm, with stainless steel wood support Motor-driven multi-function slider Lamination press Profipress L 2500 Press bed area approx. 2500 x 1300 mm Sturdy base frame with lower press table made of stainless steel as a grounding electrode Quick-change stop guide sets for panel thicknesses of 19 - 40 mm, which can be hydraulically adjusted to the current filling width Hydraulic special pressure elements ensure uniform pressure distribution over the entire joint length and compensate for tolerances In multi-lane operation, filling widths may vary by a maximum of 15 mm Upper pressure plate with hydraulic drive generates high vertical pressing pressure for minimal displacement Integrated hydraulic unit for generating pressing force and driving the hydraulic motors Control cabinet and control panel Protective cladding Additional individual pressure elements from above Automatic gluing station with precision gluing head Infeed for different widths Camera Washing and rinsing device for gluing head Modem incl. software for online connection Note: The technical data and descriptions are copies of the order confirmation from that time. The information is provided for informational purposes only and is non-binding.

Condition: ready for operation (used), Year of construction: 2018, Optimizing Cross-Cut Saw manufactured in 2018. This WEINIG DIMTER Opticut S90 features a saw blade diameter of 500 mm and a maximum cutting height of 120 mm. It accommodates input lengths from 400 to 6,300 mm and widths from 20 to 300 mm. If you are looking to get high-quality cutting capabilities, consider the WEINIG DIMTER Opticut S90 machine we have for sale. Contact us for further details. • Saw blade • Diameter: 500 mm • Bore: 30 mm • Adjustable saw blade speed: 40–100% via frequency converter • Workpiece capacity • Input length (min/max): 400–6,300 mm • Width (min/max): 20–300 mm • Thickness (min/max): 10–120 mm • Maximum cutting height: 120 mm • Minimum cross-section: 20 x 10 mm • Maximum cross-section 1: 215 x 120 mm • Maximum cross-section 2: 300 x 40 mm • Permissible timber curvature: max 2 mm/m or 8 mm over entire length • Table inclination: 10° • Motion and accuracy • Positioning speed (reverse stroke): max approx. 180 m/min • Positioning speed (forward stroke): max approx. 60 m/min • Positioning accuracy: +/- 0.1 mm • Motors and power • Pusher motor power: 5.1 kW • Saw motor power: 7.5 kW • Total electrical load: approx. 15 kW • Control and interface • Control unit: OptiCom Pro with 18.5" touch screen • Screen resolution: 1366 x 768 pixels • Protection class (front): IP65 • Interface: USB port and Ethernet network connection Redpfx Aezuhdwjlajcf • Data format: CSV (ASCII) for import/export • Utilities and environment • Voltage: 400 V / 50 Hz • Operating pressure: 6–8 bar (min.) • Air consumption: approx. 250 NL/min • Extraction connection: diameter 125 mm • Required extraction performance: speed approx. 30 m/s; volume approx. 1,300 m³/h • Noise level (idling): ≤ 85 dBA

Condition: ready for operation (used), Year of construction: 1997, travel distance X-axis: 3,000 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 142 mm, controller manufacturer: SIEMENS, controller model: WS 400-20, CNC processing center manufactured in 1997. This WEINIG / DIMTER Unicontrol 10 features a maximum workpiece length of 3,600 mm and a maximum workpiece height of 100 mm. It includes a powerful cross-cut saw with a spindle speed of up to 3,000 rpm and a tenoning spindle motor power of 15 kW. If you are looking to get high-quality CNC processing capabilities, consider the WEINIG / DIMTER Unicontrol 10 machine we have for sale. Contact us for further details. • Max. workpiece height: 100 mm • Min. workpiece height: 40 mm • Min. workpiece width: 40 mm • Max. workpiece width: 140 mm • Max. workpiece length with CNC stop: 3,500–3,600 mm • X-axis stroke: 3,000–3,500 mm (version dependent) • Cross-cut saw motor power: 3.7 kW • Cross-cut saw spindle speed: 2,800–3,000 rpm • Cross-cut saw max. tool diameter: 400 mm • Cross-cut saw spindle diameter: 40 mm • Tenoning/slotting spindle quantity: 2 pcs • Tenoning spindle diameter: 50 mm • Tenoning spindle clamping length: 400–640 mm • Tenoning spindle max. tool diameter: 400 mm • Tenoning spindle motor power 1: 11 kW • Tenoning spindle motor power 2: 15 kW • Tenoning spindle speed: 2,900–3,250 rpm • Profiling spindle quantity (vertical): 2–3 pcs • Profiling spindle diameter: 50 mm • Profiling spindle clamping length: 320–400 mm Rcodpfx Aezug Nrolasf • Profiling spindle max. tool diameter (flight circle): 232 mm • Profiling spindle motor power: 11 kW (each) • Profiling spindle speed: 6,000 rpm • Horizontal profiling unit (top) motor power: 3 kW • Horizontal profiling unit spindle diameter: 40 mm • Horizontal profiling unit max. tool diameter: 130 mm • Horizontal profiling unit speed: 5,850 rpm

Condition: used, Weinig OptiCut C700 under-table cross-cut saw for the safe and precise cutting of solid timber, particularly hard and heavy timbers with large cross-sections. The machine features a pneumatically guided saw unit, two-hand control and a hold-down device, and is ideally suited for sawmills, timber construction and industrial solid timber processing. Technical data: - Saw blade diameter: 550 mm - Cutting width: 750 mm Rjdpfx Ajzrywdjlaocf - Cutting depth: 175 mm - Motor: 5.5 kW

Condition: used, Dimter OptiCut 700 automatic optimising cross-cut saw (sliding saw) for cutting very wide timber to size according to defects (marked with fluorescent chalk) and length. Rcjdszryvaepfx Alajf Technical data: - Cutting height: max. 120 mm - Feed length: max. 5,500 mm - Cutting width: max. 700 mm - Saw blade diameter: max. 700 mm

Condition: excellent (used), Year of construction: 2005, Weinig Dimter OptiCut S 90 optimizer with 2 ejectors – after technical review – German production – year of manufacture 2005 TECHNICAL PARAMETERS: max. length of cut material 4500 mm max. width 360mm max. height 160mm automatic length measurement optimization in 4 quality classes total power 13 kW Rcsdpfoi Apgmox Alaof blade motor power 7. 5 kW pneumatic side and top pressure disc diameter max. 500mm OptiCom Assist control receiving conveyor 5600 mm two ejectors total length 13 m component marking printer cutting accuracy +/- 0.5 mm transport dimensions (length / width / height) 600 / 240 / 190 cm weight ~ 1800 kg
