Vertical Turning Machine

EMAG VL 5i

Condition: used, TECHNICAL DETAILS - Number of axes : 2 - Number of turrets : 1 - Max. turning diameter : 220 [mm] - Maximum workpiece height : 175 [mm] - X/Z stroke : 660/300 [mm] MAIN SPINDLE - Spindle speeds : 4500 [rpm] - Spindle power : 27 [kW] - C axis indexing precision : 0.001 [°] TURRET - Tool type : VDI40 - Number of positions : 12 POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 36 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3120/2266 [mm] - Machine height : 3200 [mm] - Machine weight : 7000 [kg] MACHINE HOURS - Number of hours under power : 74809 [h] - Number of spindle hours : 30521 [h] EQUIPMENT - CNC : Fanuc 32i-A - Interface : Ethernet / RS232 / USB / PCMCIA - Coolant tank - Chips conveyor - Parts conveying strip - Chuck 3 jaws Psdsxc N I Tjpfx Agkjgn

Condition: used, Year of construction: 2017, Milling machines Travel distance X: 800 mm Travel distance Y :950 mm Travel distance Z: 1020 mm HSC-machines Number of axis: 5 milling machine / machining center Control: Siemens Sinumerik spindle chuck: HSK 100 spindle revolutions: 6000 rpm Speed range to: 6000 U/min table size X: 770 mm table size Y: 770 mm max. workpiece weight: 800 kg tool changer: 60 - time input Power : 32 kW Torque: 340 Nm Rapid traverse: 40 m/min feed rate: 40 mm/min Pedpfeyzw Sasx Agkjgn spindle cooling chip conveyor control Siemens 5-axis CNC universal machining center Designed for high-precision milling of various materials Extremely rigid construction for heavy-duty cutting Equipped with Siemens Sinumerik control HSK100 spindle, ideal for hard metal machining High process reliability and efficiency Suitable for automotive, mechanical engineering and mold making industries

Condition: used, Year of construction: 2011, functionality: fully functional, machine/vehicle number: 102821, Technical characteristics: Work Area - Maximum diameter of the clamping plate: 250 mm - Maximum turning diameter: 270 mm - Maximum machining diameter: 220 mm - Maximum workpiece length: 175 mm - X-axis travel: 660 mm / Rapid traverse in X: 60 m/min - Z-axis travel: 300 mm / Rapid traverse in Z: 30 m/min - Standard closed automation (number of loading nests by workpiece diameter: 14/(80...200), 18/(30...160), 30/(30...85)) Main Spindle - Spindle interface to DIN 55026: Size 6 - Maximum speed: 4,500 rpm - Power at 100% / 40% duty cycle: 18 / 27 kW - Torque at 100% / 40% duty cycle: 202 / 303 Nm Tool Turret with Driven Tools - Toolholders, cylindrical shank DIN 69880: 12x VDI40 - Number of stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6,000 rpm - Maximum torque at 10% duty cycle: 37 Nm, 25%: 26 Nm, 100%: 14 Nm Pedpfxexxikgo Agkogn Electrical Equipment - Operating voltage: 400 V - Connected load: 36 kW / 80 A Dimensions - Dimensions (L x W x H): 3,120 mm (4,185 mm with chip conveyor) x 2,266 mm x 3,200 mm - Weight: 7,500 kg Main Features and Capabilities: - Vertical design for optimal chip removal and easy access for loading/unloading - CNC control: GE Fanuc Series 32i Model A - High precision with X, Z, and Y axis positioning accuracy ±0.001 mm (Heidenhain linear scales) - Powerful main spindle with wide speed range - Integrated automation for part loading/unloading - Driven tools available for both milling and drilling operations - Workpiece detection sensor with compressed air gauge through spindle: SMW Autoblock Linear Position Sensor LPS-X - In-process gauging: Marposs T25 - Chip conveyor included - Documentation: Complete, both electronic and paper versions Machine status: IN OPERATION

Condition: repair required (used), Year of construction: 2011, functionality: not functional, machine/vehicle number: 102920, Technical Characteristics: Work Area - Maximum diameter of clamping plate: 250 mm - Maximum turning diameter: 270 mm - Maximum machining diameter: 220 mm - Maximum workpiece length: 175 mm - X-axis travel: 660 mm / Rapid traverse in X: 60 m/min - Z-axis travel: 300 mm / Rapid traverse in Z: 30 m/min - Standard enclosed automation (number of loading stations by workpiece diameter: 14/(80...200 mm), 18/(30...160 mm), 30/(30...85 mm)) Main Spindle - Spindle according to DIN 55026: Size 6 - Max. speed: 4,500 rpm - Power at 100% / 40% duty cycle: 18 / 27 kW - Torque at 100% / 40% duty cycle: 202 / 303 Nm Pgjdpfxoxxiwyj Agksn Turret with Driven Tools - Tool holders per DIN 69880: 12 x VDI40 - Number of positions: 12 - Max. tool length (including holder): 190 mm - Max. speed: 6,000 rpm - Max. torque at 10% duty cycle: 37 Nm, at 25%: 26 Nm, at 100%: 14 Nm Electrical Equipment - Operating voltage: 400 V - Connected load: 36 kW / 80 A Dimensions - Total dimensions: Length: 3,120 mm (4,185 mm with chip conveyor), Width: 2,266 mm, Height: 3,200 mm - Weight: 7,500 kg Main Features and Capabilities: - Vertical design: Enables optimal chip evacuation as well as easy loading and unloading - Control: Siemens 840D - High precision: Positioning accuracy in X, Z, and Y axes ±0.001 mm, Heidenhain linear scales - Main spindle: High power and broad speed range - Automated loading/unloading: Automated workpiece loading and removal via integrated system - Driven (live) tools: Supports live tooling for extended machining range, including drilling and milling - Part detection sensor with compressed air gauge through spindle: SMW Autoblock Linear Position Sensor LPS-X - In-process control: Marposs T25 - Chip conveyor - Coolant chiller: Texa TCW55PMSBXMF000, max. 30 bar input - Coolant filtration with paper belt filter: Micron filter EVO500Pro+KMT150, 550 liters, 80 l/min - Documentation: Digital & hard copy manuals available Machine Status: NOT WORKING - Lifetool motor - Slideways & carriages (X & Z axes) - Hydraulic pressure compensation block

Condition: refurbished (used), Year of construction: 2014, functionality: fully functional, total width: 2,500 mm, total length: 4,500 mm, total height: 3,200 mm, Offered is a double spindle pick up turning machine VSC 250 DUO. There are 2 nearly identical machines available. Each machine is equipped with 2 independent working spindles and 2 EMAG turrets. The machine can produce 2 identical workpieces with the same machining operation, as well as one workpiece in two successive machining operations. The VSC 250 DUO will receive a general overhaul before delivery and gets a control upgrade to Siemens Sinumerik ONE. Podpfx Aer Nc Ufegksgn The machine can be equipped with other periphery (chip conveyor, coolant system, external automation, etc.), depending on requirements. COTROL Siemens Sinumerik One TECHNICAL DATA workpiece diameter: max. 250 mm workpiece height: max. 150 mm chuck diameter: 250/315 mm swing diameter: 350 mm X-stroke: 745 mm Z-stroke: 300 mm TOOL CARRIER working area 1 1x EMAG disc turrets, 12x VDI 50 without driven tools working area 2 1x EMAG disc turret, 12x VDI 50 with driven tools Price, delivery time and equipment of the machine on request.

Year of construction: 2011, condition: ready for operation (used), An Emag vertical CNC lathe is available. Clamping chuck diameter: 250mm, max. circulation diameter: 270mm, max. machining diameter: 250mm, max. machining length: 175mm, speed: 4500rpm, tool positions: 12, tool holder: VDI 40, travel X/Z: 660mm/300mm, rapid traverse X/Z: 60m/30m/min. Machine dimensions X/Y/Z: approx. 4300mm/1600mm/3300mm, weight: approx. 7500kg, control: Fanuc Series 32i-Model A, operating hours: 64137h. Including automatic loading and unloading with pick-up spindle and integrated part diverter and workpiece storage. Documentation available. On-site inspection is possible. Pgsdpfx Agowtg E Tskon

Condition: ready for operation (used), Year of construction: 2015, operating hours: 15,050 h, functionality: fully functional, travel distance X-axis: 660 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 200 mm, spindle speed (max.): 7,500 rpm, turning diameter: 220 mm, turning height: 175 mm, TECHNICAL DETAILS Turning diameter: 220 mm Pgedpfowynigex Agken Swing diameter: 270 mm Turning height: 175 mm Control & axis travel Control: SIEMENS 840 D SL X-axis: 660 mm Y-axis: 300 mm Z-axis: 200 mm Spindle & tool change Max. speed: 7,500 rpm Tool changer: 12-station MACHINE DETAILS Total power requirement: 24 kW Machine weight: approx. 5.2 t Space requirement: approx. 2.5 x 1.6 x 2.3 m

Condition: ready for operation (used), Year of construction: 2017, operating hours: 15,208 h, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 880 mm, overall weight: 12,000 kg, spindle speed (max.): 15,000 rpm, spindle motor power: 21,000 W, number of axes: 4, This 4-axis DMG MORI NHX 5000 was manufactured in 2017. It features a maximum spindle speed of 15,000 rpm and a travel of 730 mm in both the X and Y axes, with a Z-axis travel of 880 mm. The machine includes a robust pallet size of 500 x 500 mm and a tool capacity of 40 tools. If you are looking to get high-quality machining capabilities, consider the DMG MORI NHX 5000 horizontal machining centre we have for sale. Contact us for further details. • Spindle torque: 111 Nm (continuous 85 Nm) • Tool capacity: 40 tools (optional magazine 60 tools) • Rapid traverse (X/Y/Z): 60 m/min • Acceleration (X/Y/Z): 1G • Pallet size: 500 x 500 mm • Number of pallets: 2 • Automatic rotary pallet changer: 2 stations • NC table B axis: direct drive, indexing 0.001°, max speed 100 rpm • Maximum pallet load: standard 500 kg (optional 700 kg) • Direct position measuring system; Linear scale standard • Control system: CELOS Siemens 840D sl with 21.5" ERGOline multi-touch display • Electronic handwheel: Siemens • Coolant through spindle preparation up to 70 bar • Renishaw probe OMP60 • Tool breakage detection system • Machine status signal lamp • Water-glycol spindle cooling unit • Application Tuning Cycle (ATC) • Machine bed: 3-point support • Power connection: L1 L2 L3 N PE • Connected load: 46 kVA Pgsdpfx Agsyt Hwzjksn • Maximum input current: 67 A • Fuse protection: 125 A • Short circuit current: 1.25 kA • Maximum supply voltage: 4.0 kV • Supply voltage: 400 V ±10 % • Frequency: 50 Hz • Control voltage: AC 230 V / DC 24 V • Operating time: 27,715 h • Spindle hours: 15,208 h Additional equipment • Knoll KF110/700 • Knoll Flow Monitor • High-pressure coolant system • 2x clamping towers (250 x 250 x 650 mm) TRIAG incl. accessories • 95x tool holders HSK63 (various clamping devices) Technical Specification Taper Size BT 40

Condition: used, Year of construction: 2016, functionality: fully functional, machine/vehicle number: 103979, We offer for sale CNC vertical lathe EMAG, VL5i F., year of production 2016, used, preserved, functional. Still in production. Must see. EXW price incl. loading. More information on request. Pgsdpouyh Tdjfx Agkon

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, travel distance X-axis: 660 mm, travel distance Z-axis: 300 mm, TECHNICAL DETAILS X-axis travel: 660 mm Z-axis travel: 300 mm Chuck diameter: 250 mm Pjdpfx Agsxy Hp Nskjgn Swing diameter: 270 mm

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, Working area Grinding length: 250 mm Centre height: 100 mm Workpiece weight: 30 kg Z-axis: 350 mm Pgsdpfx Ajvz Snkjgksn Table adjustment: 8 ° degrees X-axis: 190 mm Grinding spindle Grinding wheel diameter max.: 500 mm Grinding wheel width max.: 80 mm Grinding wheel bore: 127 (203) Grinding wheel motor power: 5.5 kW Peripheral speed: 50 m/s Grinding wheel protection cover: D500 x 80mm Workpiece spindle Speed: 1 - 2,000 rpm Workpiece spindle mount: MK4 Tailstock Tailstock quill mount: MK3 Tailstock quill stroke length: 30 mm Cylinder fine adjustment range: ± 0.04 Equipment Paper belt filter system Rinse gun Mechanical fume extraction

Condition: used, functionality: fully functional, We are offering a complete EMAG line consisting of 6 machines (VL3, VL5, and VL5i – see nameplates) including central chip conveyor and coolant supply. The machines are in operational condition and can be inspected under power at our facility in 47225 Kedzierzyn-Kozle, Poland. We are happy to sell internationally, but please note that special packaging will be required for overseas shipment. Disassembly and export packaging suitable for shipping overseas are the buyer’s responsibility. The listed price is for a single machine without chip conveyor and coolant supply. If you purchase the entire line, the price is EUR 120,000, including chip conveyor and coolant supply. Podsu U D E Njpfx Agkjgn

Condition: ready for operation (used), Year of construction: 2015, operating hours: 15,050 h, functionality: fully functional, travel distance X-axis: 660 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 200 mm, spindle speed (max.): 7,500 rpm, turning diameter: 220 mm, turning height: 175 mm, TECHNICAL DETAILS Turning diameter: 220 mm Swing diameter: 270 mm Turning height: 175 mm Control & axis travel Control: SIEMENS 840 D SL X-axis: 660 mm Y-axis: 300 mm Z-axis: 200 mm Pjdpfx Ajxf Apvsgksgn Spindle & tool change Max. speed: 7,500 rpm Tool changer: 12-station MACHINE DETAILS Total power requirement: 24 kW Machine weight: approx. 5.2 t Space requirement: approx. 2.5 x 1.6 x 2.3 m

Condition: excellent (used), Year of construction: 2019, operating hours: 403 h, functionality: fully functional, turning length: 1,200 mm, spindle bore: 120 mm, controller model: Siemens 840 Dsl, Equipment: documentation/manual, Technical data: Turning length 1200 mm Chuck diameter 350 mm Working stroke X top/bottom 200 mm Working stroke Y. axis 210 mm (+130/-80) Working stroke Z. axis 1200 mm Maximum travel speed W/X/Y/Z meters/minute 45/40/40/46 Ball screw diameter W/X/Y/Z mm 40/40/40/40 Profile rail guide, B/X/Y/Z mm 45/45/45/55 Tool flight circle 700 mm Maximum center distance 1200 mm Main spindle/counter spindle Spindle bearing diameter 120 mm/160 mm Spindle passage 65/105 mm Spindle bore diameter 80/120 mm Spindle flange/spindle head DIN 55026 A6 / A8 Drive power 100% ED 22 KW/67.4 Drive power, 40% ED 24 KW/80 Nominal speed 1400 rpm Maximum speed 5,700 rpm Torque 100% ED 150 nm/585 Torque 40% ED 191 nm/795 C-axis resolution 0.001 degrees Both turrets: Tool holder: VDI 40 Maximum speed rpm 6000 torque drive 12,000 speed drive Maximum drive power kW: 28.5 torque drive 23.5 speed drive Maximum torque (25% ED) Nm: 85 torque drive 56 speed drive Pjdpjvw Upcjfx Agkogn Dimensions: 4500 x 2500 x 2500 Weight approx. 16000 kg Control: Siemens 840 Dsl
