CNC lathes

Ernault & somua Ø 2000 x 7500 mm CNC

Condition: used, Technical details: faceplate diameter: 5000 mm swing diameter: 6100 mm turning height: 2400 mm ram stroke each side: 1490 mm ram head dimension: 340 x 340 mm max. workpiece weight: 100.000 kg total power requirement: 100 kW weight of the machine ca.: 155 t faceplate turning speed range: 0,4 - 50 U/min Ndsdpfew Rz U Asx Ac Hof with 2 x 2 axes CNC SIEMENS 840 D *

Year of construction: 1998, condition: good (used), CHIRON FZ 18L 1998year Sinumerik 810 with 4 Axis Nikken Travels X 2000 mm Y 400 mm Z 425 mm table2280 x 450 mm spindle max 8000 Toolchanger ATC: 20 pos tools SK 40 weight 6,70 T manual books dimensions lenght 3,9m width 2,45m height 2,8m free loaded on truck EXW 01360 LOYETTES Nedohpq U Uopfx Ac Hjdf

Condition: refurbished (used), Year of construction: 1974, functionality: fully functional, machine/vehicle number: 1276, CNC Hot Radial Forging GFM SX-13 New in 1974 / 2022 New control system PLC SIEMENS S7 Machine number: 1276 No. of Hammers: 4 Forging force each hummer: 160 Ton Hammer stroke / min: 700/min Hammer lenght: 240 mm Diameter setting range: 80 mm Maximum forging diameter: Structural steel, round-cross section: Ø 130 mm square cross section: Ø 115 mm Ndodpfoq U R T Nox Ac Hef Smallest dimensions forged: Ø 25 mm Manipulator A max. displacement: 6820 mm Manipulator B max. displacement: 7150 mm Maximum workpiece length: 6000 mm Rapid speed manipulator: 400mm/sec Total connected power: 300 kW 380 V, 50 Hz Machine dimensions: Forging height over floor: 615 mm Total height pf the machinr over floor: 1665 mm Total machine lenght: 32670 mm Total foundation lenght: 33400 mm Tot. machine width (without auxliary equipments): approx 3885 mm Total foundation width: 16000 mm Total weight of the machine: 84.000 Kg

Condition: used, Year of construction: 1998, swing diameter 2000 mm table diameter 1800 mm turning height 1500 mm Control Siemens Sinumerik 840 C table turning speeds 0-280 U/min feed range 0-18000 mm/min workpiece weight max. 12000 kg total power requirement 177 kVA Feed drives: - Crossbeam support, vertical and horizontal mm/min - Crossbeam support, rapid traverse 18000 mm/min - Crossbeam adjustment speed 425 mm/min Milling drive: - Milling drive power 30 kW - Number of gear stages 2 stages - Stage jump 3.17 - Speed range of the 1st gear stage 10 - 224 - 950 rpm - Speed range of the 2nd gear stage 32 - 72 - rpm Tool system, cutting force: - Tool system 250.2 - Milling spindle holder according to 69871-A SK 50 - Cutting force on turning tool 50 kN Equipment/accessories: - Tool measuring probe - Various turning tool holders - Various clamping jaws - Various clamping devices - Various SK 50 mountings - Grinding spindle - Powered tools - Tool changer/head changer Ndsdpfjxap Eyex Ac Hef - Hydraulic unit - Chip conveyor - Technical documentation

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, turning height: 1,020 mm, workpiece weight (max.): 10,000 kg, turning diameter: 1,560 mm, faceplate diameter: 1,480 mm, rotational speed (max.): 250 rpm, Titan VT 1700 Vertical Lathe with: - table diameter 1480 mm - maximum turning diameter 1560 mm - maximum load allowed in the spindle 10000 kg - maximum turning height 1020 mm - 12-position tool magazine - Fagor 8055 CNC Nedewi Ufmjpfx Ac Hjdf - Rotomors 4-jaw hydraulic chuck - chip conveyor - year 2016 Free extension in 12/24 months

Condition: used, Year of construction: 1981, machine/vehicle number: 78.977, Equipment: documentation/manual, Year of manufacture: 1981 / Year of conversion: 1996/1997 Control: Siemens 840 C Siemens control for X/Y/Z/W/U/B/V axes Spindle diameter: 200 mm Main motor: Siemens: 68 kW Spindle speed: Step 1: 3 - 202 rpm Step 2: 180 - 808 rpm X travel: 12,000 mm Y travel: 4,500 mm Ndsdpfx Aoqc Umgsc Hef Z travel: 2,400 mm (support sleeve □ 520 mm / travel 1,200 mm + W axis 1,200 mm) Adapter: SK60 (SK50) Face slide: yes Milling head: 2 pieces Prepared for CNC rotary table (4th axis) Without rotary table and plate field (sold separately) Full documentation Self-weight: approx. 140 tons Video available!

Condition: used, Technical details: faceplate diameter: 1000 mm swing diameter: 1600 mm turning height: 1200 mm main drive: 75 kW faceplate speeds from - to: 7 - 800 U/min milling motor: 25 kW milling head speed: 7 - 3000 U/min milling spindle - taper: ISO 50 cross rail adjustment - vertical: 800 mm ram head dimension: 240 x 240 mm weight of the machine ca.: 40 to Njdpfxjvb Dcas Ac Hsdf dimensions of the machine ca.: 9 x 7,8 x 6,0 m Machine general overhould in 2004 and equiped with Siemens 840 D control - tool changer rack magazine - C-axis, live tooling, - Transmit function electronical Y-axis - angular milling head - complete splash housing - coolant device, chip conveyor *

Condition: ready for operation (used), Broadbent Heavy Duty Lathe 1041mm x 10,000mm Year approx. 1973. Swing over bed 1041mm (41”) Swing bin gap1575mm (62”) Distance between centres 9300mm (30’ 6”) Ndjdpfxov I T Ewe Ac Hjf Spindle bore 115m (4 ½”) Spindle speeds (18) 3.3 – 360 rpm Spindle motor 30 HP or 40 HP (To be confirmed) Tailstock 6 MT Imperial Metric screw-cutting with change gears. 36” Faceplate with 4 adjustable jaws, 54” Faceplate, Taper turning attachment, Power feed to top slide, 2 x 18” 3 point steadies, 24”/28” Steady.

Condition: used, TECHNICAL DETAILS - Number of axes : 2 - Table dimensions : 2500 [mm] - Table rotation speed : 1.25 - 160 [rpm] - Max. turning diameter : 2800 [mm] - Maximum workpiece height : 2300 [mm] MACHINE HOURS - Number of working hours : 15557 [h] EQUIPMENT Nodpfx Acswbkd Ne Hodf - CNC : FANUC Series 16i-T

Condition: ready for operation (used), controller model: Num, empty load weight: 35,000 kg, total length: 11,000 mm, total width: 2,950 mm, total height: 2,000 mm, swing diameter over cross slide: 6,500 mm, Robuuste draaibank met 4 geharde lineaire geleidingen Maximaal werkstukgewicht: 20 ton bestemd voor staalfabrieken, walsgieterijen, smederijen voor het maken van producten zoals turbinerotoren, grote assen en staafproductie Swing over bed: 1400 mm Ndedswaiu Rjpfx Ac Hof Swing over cross-slide: 1100 mm Power on the spindle: 81 kW Chuck: 900 mm
