Vertical Turret Lathe - Single Column

DÖRRIES VCE 2000/180 MC

Condition: ready for operation (used), Schiess 80 DF Type: 80 DF 700/900-550/280 Originele CNC-machine van Schiess (geen ombouw van conventioneel naar CNC) Volledig hydrostatische machine Gelaste kolom Siemens-motor Uitgerust met een controlelift om de bovenkant van het werkstuk te bekijken Machine met zeer hoge tolerantie Tafeldiameter: 7000 mm Maximale diameter van het werkstuk: 9000 mm Maximale belasting: 315 ton Snelheid: 0,25 25 tpm Maximaal rotatiekoppel: 63.000 kgm Maximale snijkracht met uitgeschoven ram tot 900 mm: 12.500 kg Gereedschapskop kan -40° tot +40° kantelen Vermogen: 125 kW Kjdpfx Aov Rwdpeayodw gewicht van de tafel: 71 ton Ramsectie: 380 x 380 mm Horizontale verplaatsing van de ram vanaf het midden van de tafel: 5640 mm Verticale slag van de ram: 2800 mm Maximale hoogte onder dwarsbalk: 5547 mm Horizontale verplaatsing van de dwarsbalk: 4700 mm Uitgerust met 3-positie automatische gereedschapswisselaar Totaalgewicht van de machine: 260 ton! Unieke eigenschap er zijn 3 mogelijke configuraties van de hoofdkolom: 1 - voor maximale zwenking 9000 mm (zoals momenteel ingesteld) 2 - voor max. zwenkbereik 10.500 mm 3 - voor maximale swing 13 100 mm Dit kan worden bereikt door de hoofdkolom opnieuw op het fundament te positioneren.

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, Vertical Turret Lathe - Double Column with 5 controlled axes - Brand: CKD Blansko / SKD / YOM: 2008 Overhaul and renewals were carried out on the machine in 2019 (completion January 2020), further work was carried out/followed ... The machine can be inspected by appointment under power. TECHNICAL SPECIFICATIONS: Workspace: - Faceplate diameter: 4.000 mm - Swing diameter max.: 5.000 mm - Workpiece height max.: 2.500 mm - Faceplate load max.: 50 tons C-axis: - Speed of the C-axis: 0,01 - 2 rpm - Torque on the faceplate max.: 35.000 Nm Machine: - Total power requirement: 160 kVA - Machine weight: approx. 74 tons Kdjdpfx Aaeww H Ivjyow EQUIPMENT: - Control: SIEMENS SINUMERIK 840D - Automatic tool changer - Pick-up magazine: 1 Angular head - Angular milling head - Oil coolant equipment - Coolant system with paper filter - AC drive for rotary tools - AC drives for X/Z/C/U/W-axis - Full enclosure - Chip conveyor - Slat-band chain conveyor - Documentation - CE marking There is no guarantee for correctness and completeness of the technical details and accessories. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request.

Condition: ready for operation (used), empty load weight: 22,000 kg, Type FTC75 Distance between centers: 8000 mm Swing over bed: 1500 mm Swing over cross-slide: 1100 mm Kdedowkw Umjpfx Aayjw Diametre of main spindle bore: 130 mm Number of speeds: 3,6 > 720 rpm Total power needed: 29,5 kW / 40 hp Max weight between centers: 11 ton

Condition: good (used), turning diameter: 5,000 mm, travel distance Z-axis: 2,000 mm, turning length: 2,500 mm, The machine is in good technical condition, fully functional, modernized in 2008. It is equipped with a Siemens Sinumerik 802 D control system, a maximum turning diameter of 5000 mm and a clamping plate diameter of 2500 mm. The workpiece weight is 40 tons and the height is 2000 mm. Ksdpjv Dkykjfx Aayodw

Condition: excellent (used), TECHNICAL CHARACTERISTICS Capacity: Chuck diameter: 3.000 mm Ksdper Ddu Dofx Aayjdw Maximum turning diameter: 3.110 mm Maximum piece weight: 20 Tn Revolutions: 1,5-39,5 Rpm Main motor power: 45 Kw Movable crossbeam: 1.200 mm Height under crossbeam: 1.800 mm Vertical lathe with two arms: Right carriage pentagonal turret 5 positions with automatic rotation X travel: 1,500 mm Z travel: 965 mm Left slide with RAM Travel X: 1.500 mm Travel Z: 1,200 mm Remarks: Independent control panel 2 x CNC Fagor 8055 for the control of the 2 slides from the same screen. Grinding head (optional) Year of manufacture/reconstruction: 1975/2001

Condition: good (used), Webster & Bennett CNC Ram Type VTL Year 1986/2005 Table 1500mm dia. 10 Station Automatic Tool Changer Max Turning Dia 54” Fanuc Oi-TC Control Fully Enclosed Guards Automatic Tool changer Tooling Kdodjtv Nm Djpfx Aaysw Table Jaws Swarf Conveyer

Year of construction: 1998, condition: good (used), CHIRON FZ 18L 1998year Sinumerik 810 with 4 Axis Nikken Travels X 2000 mm Y 400 mm Z 425 mm table2280 x 450 mm spindle max 8000 Toolchanger ATC: 20 pos tools SK 40 weight 6,70 T manual books dimensions lenght 3,9m width 2,45m height 2,8m Ksdpfxohpq U Ue Aaysdw free loaded on truck EXW 01360 LOYETTES

Condition: refurbished (used), Year of construction: 1974, functionality: fully functional, machine/vehicle number: 1276, CNC Hot Radial Forging GFM SX-13 New in 1974 / 2022 New control system PLC SIEMENS S7 Machine number: 1276 No. of Hammers: 4 Ksdpfxoq U R T No Aayodw Forging force each hummer: 160 Ton Hammer stroke / min: 700/min Hammer lenght: 240 mm Diameter setting range: 80 mm Maximum forging diameter: Structural steel, round-cross section: Ø 130 mm square cross section: Ø 115 mm Smallest dimensions forged: Ø 25 mm Manipulator A max. displacement: 6820 mm Manipulator B max. displacement: 7150 mm Maximum workpiece length: 6000 mm Rapid speed manipulator: 400mm/sec Total connected power: 300 kW 380 V, 50 Hz Machine dimensions: Forging height over floor: 615 mm Total height pf the machinr over floor: 1665 mm Total machine lenght: 32670 mm Total foundation lenght: 33400 mm Tot. machine width (without auxliary equipments): approx 3885 mm Total foundation width: 16000 mm Total weight of the machine: 84.000 Kg

Condition: good (used), Year of construction: 1998, table diameter 1800 mm turning diameter 2060 mm swing diameter 2000 mm work height max. 1557 mm Kdedpfxjw H Dkms Aayjw power capacity - milling spindle 30 kW workpiece weight 12 t table drive 100 kW gear box 2 Stufen grinding spindle drive 30 kW milling spindle SK50 with Grinding device

Condition: used, Year of construction: 1981, machine/vehicle number: 78.977, Equipment: documentation/manual, Year of manufacture: 1981 / Year of conversion: 1996/1997 Kdsdpoqc Umgofx Aayow Control: Siemens 840 C Siemens control for X/Y/Z/W/U/B/V axes Spindle diameter: 200 mm Main motor: Siemens: 68 kW Spindle speed: Step 1: 3 - 202 rpm Step 2: 180 - 808 rpm X travel: 12,000 mm Y travel: 4,500 mm Z travel: 2,400 mm (support sleeve □ 520 mm / travel 1,200 mm + W axis 1,200 mm) Adapter: SK60 (SK50) Face slide: yes Milling head: 2 pieces Prepared for CNC rotary table (4th axis) Without rotary table and plate field (sold separately) Full documentation Self-weight: approx. 140 tons Video available!
