Gear Grinding Machine

GLEASON-PFAUTER Phoenix 600 G

Condition: used, Year of construction: 1980, max. wheel diameter 2500 mm gear width 1200 mm max. module 32 min. module 3 total power requirement 25 kW weight of the machine ca. 60 t dimensions of the machine ca. m Gear , min. / max. 180 / 2,500 mm Module 3 - 32 Helix angle, max. 10 - 35 ° Gear width for straight gears 1,200 mm Stroke length, approx. 100 - 1,200 mm No. of strokes 80 - 350 /min Stroke position adjustable 300 mm Stroke speed 4 - 40 mm Itodpfjt Hwqqsx Ad Dep Max. weight of workpiece, approx. 18,000 kg Min. / max. no. of teeth 16 / 576 Table size x bore 1,400 x 500 mm Grinding wheel Ø, approx. 500 mm Grinding wheel peripheral speed 34 m/s Total electrical load, approx. 45 kW - 380 V - 50 Hz Weight of machine, approx. 60,000 kg Accessories / Special Features: * Hydrostatic guides in grinding slide, table and in all other guideways. * Completely covered working area with sliding doors. * Automatic grinding process for various cycles, with settings for roughing, finishing, fine finishing and automatic dressing cycle after preset number of teeth. * Profile correction is possible via appropriate dressing, as well as additional movement of grinding slide (depth and width crowning). * Approx. 50 change gears. * Grinding slideTilt display device. * Large coolant device with band filter and oil mist exhaust. * Separate switch cabinet. * Separate hydraulic unit. * Separate oil cooling unit. Condition : Very good. Machine can soon be inspected in our showrooms. It is not under power at present. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. The machine comes directly from a first class gear factory, where it was grinding Quality 5 - 6. Grinding diagrams are available. This type and quality of machine is rarely available. Thank you for your interest. We always have a good selection of gear machines available. Please let us know what you need.

Condition: used, Year of construction: 2001, tip circle diameter 1000 mm root circle diameter 50 mm max. module 18 mm min. module 1 mm max. wheel diameter 1000 mm gear width 630 mm Profile height max. 41 mm helical angle (left/right) max. 45 ° table diameter 720 mm Itedpfx Aewp S Thjd Djp max. table load 1500 kg grinding wheel diam. min/max. 180 / 400 mm grinding wheel width 60 (45/30) mm grinding spindle speed 0 - 3100 U/min total connected load 30 kVa

Condition: used, Year of construction: 2008, tip circle diameter 650/800 mm workpiece length - max. 1100 mm Ijdpfx Adow Rrbys Detp max. module 20 (25) mm min. module 0,5 mm control Siemens Sinumerik 840 D total connected load 62 kVA helical angle -45 / + 120 ° weight of the machine ca. 10 t

Condition: as good as new (ex-display), Year of construction: 2025, Centre height: 181 mm Centre distance: 1000 mm Maximum grindable workpiece diameter: 360 mm Max load cantilevered: 1000 N (100 kg) Max load between centres: 3000 N (300 kg) Z-axis: Table swivel angle: 10° Table drive, hydraulic: 0–4 m/min X-axis: Cross slide travel: 80 mm Rapid traverse (hydraulic): 50 mm Coarse adjustment – air cushion: 280 mm Infeed drive by DC motor Rapid infeed speed: 48 mm/min/Ø Infeed cycle: Plunge grinding / Longitudinal grinding 4 preselectable speeds: mm/min/Ø: 0.01–48 4 preselectable infeed increments: mm: 0.001–0.1 Automatic shut-off during stop-grinding: 0–99 s or 0–99 strokes Stepwise infeed: mm/Ø: 0.001 Grinding headstock universal, swivelling: 0–180° Grinding wheel (OD): D x width x bore: 500 x 100 x 127 mm or 203.2 mm Grinding wheel (face, option) D: 250 x 32 x 76.2 mm Grinding wheel (ID, option) D: 2–250 mm Drive power, external/face: 5.5 (7.5) kW Drive power, internal: 2.2 kW Peripheral speed, external: 35 (50) m/s Grinding wheel wear (OD): mm/Ø: 160 Guard width: 100 mm Grinding spindle diameter: 60 mm Internal spindle mounting: 80 (100) mm Workpiece headstock: Infinitely variable drive: MK 4, 1/min: 30–270 / 50–450 Workpiece spindle lockable Spindle mounting: MK 4/24 mm Spindle nose for flange attachment: MK 4, cylindrical Ø63H6 x 6 mm Headstock swivels on rotating part: 0–90° Tailstock: Quill mounting / Quill diameter: MK 4, 750 mm Iodpfxstqf Rze Ad Djtp Quill stroke: 45 mm Quill force, N: 100–800 / 250–1400 adjustable Quill operation: manual (foot switch) Quill fine adjustment: ±40 μm Connections: Total machine connected load: 6.5–10 kW Grinding headstock: 5.5 (7.5) kW Workpiece headstock: 0.55 (1.1) kW Coolant filtration: 0.75–2.2 kW Lubrication pump – guideways: 0.1 kW Hydraulic pump: 1.5 kW Hydraulic tank: 80 l Pneumatics: 6 bar Comparable to: Weiss / EMAG / GP cylindrical grinders / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 4304, rotary table diameter: 600 mm, grinding height: 450 mm, overall weight: 14,500 kg, Machine is equipped with 3 spindles, surface grinding, external grinding, bore grinding Iedpfx Adevt A Rte Dotp Turret head B-axis with 1° division Belt filter system included

Year of construction: 1987, condition: ready for operation (used), Workpiece diameter: 10-350mm, max. grinding length: 660mm, clamping length: 1055mm, max. module: 25mm, swivel angle: +/-60°, grinding wheel dimensions: 300-500x100mm, with Faudi cooling lubricant belt filter and Elbaron oil mist separator. No longer fit for operation and can only be used as a basis for a complete overhaul. Ijdpfergah Hox Ad Dstp

Condition: good (used), Year of construction: 2007, Height of points 150 mm Distance between points 1000 mm Grinding wheel dimensions (h x id x w) Ø400xØ127x50mm Internal head 4 pcs Center height 150mm Max. workpiece weight 80Kg X-axis travel (transverse) 350mm X axis speed 10 meters per minute Z axis travel (longitudinal) 1000mm Z-axis speed 12 meters per minute Z-axis resolution 0.00004" B-axis turning range 210° B-axis resolution 0.00004 B-axis resolution 0.0001° B-axis resolution 0.0001 Drive capacity 10 HP Grinding wheel diameter 400mm Max. width Grinding wheel width 63mm Spindle Speed Range 0-1000 RPM Itodpfxerakimj Ad Dop Spindle turning range 0° - 90° Tailstock stroke 30mm Tailstock stroke 30mm Equipped with Fanuc 21i-TB CNC Control Dimensions 3350x 2130x 2130 Weight 4535Kg Accessories: Steady rests, magnetic chuck, 3-jaw chuck, balancer, sensitron 6, coolant with paper and magnetic filter, fume extractor, etc.
