Used Ipsen Oven for sale (18)

Year of construction: 2002, Condition: as good as new (ex-display), Functionality: fully functional, Maximum operating temperature 7Drnlqvwm Zone 2.. 925ºC Zone 1..700ºC Dimensions of shaker shot Width..510mm Length 3410mm Height 130mm Useful hearth area 1.23m2 Throughout (approximate value, depending from bulk density, shape and dimensions of parts) - Carbonitriding/Carburising case depth 0.1 - 0.2 mm; 550 HV.. - Hardening... 225kg/h Heating Connected load 156kW Idling consumption, 850 °C 50kW Number of radiation tubes Zone 1... 8 Zone 2....6 Removal space above smoke.. Atmosphere circulating Number of fans 2 Total connected load of the furnace apron kVA25

Condition: good (used), Functionality: fully functional, Ipsen Industries International GmbH Vacuum furnace, VFC 124 Model: VFC124 Year of construction: 1979 Technical data: Heating: electric Protective gas: N2 Gas absolute pressure min.: 13x10-5mbar Gas absolute pressure max.: 1500mbar Working temperature min.: 500°C Working temperature max.: 1320°C Compressed air consumption Vn: 0.1m3/batch Cooling gas consumption Vn: 0.6m3/batch Quenching type: Gas cooling Type of thermal insulation: Insulating wool Cqp8Ckwq08 Max. load weight: 60kg Type of loading and unloading: by hand Chamber dimensions: 300x380x200mm (WxLxH) Total electrical data: Rated voltage: 380V AC Nominal current: 56A Frequency: 50Hz Power: 37kVA Electrical data heating: Rated voltage: 30V AC Rated current: 416/588A Frequency: 50Hz Power: 25kW

Condition: good (used), Vacuum Furnace, Abar Ipsen, Used Machine Manufacturer: Abar Ipsen Type: Vacuum Furnace Uszxlhgkhl Maximum Temperature: 1200°C Vacuum: 5×10-3 mbar Insertable Object Size: 700 x 1250 x 670 mm Electrical Supply: 3 x 200 A Accessories: Vacuum furnace Transformer for heating Stokes 412 large vacuum pump System for the water circuit (pump and distributors) Gas booster for the furnace Control cabinet Diffusion vacuum pump Missing components: High Vacuum Pump: Edwards EH1200IND 50HZ HYD Oil-sealed Vacuum Pump: Edwards RV8 Cooling Circuit Large Heat Exchanger The vacuum furnace we offer is the ideal solution for any industrial process requiring extremely precise heat treatment at temperatures up to 1200°C, without the risk of oxidation or contamination from ambient air. The vacuum environment ensures that materials are heat-treated in perfect purity under tightly controlled temperatures. Key Features and Benefits: Excellent Heat Treatment Solution: Ideal for hardening, annealing steel, alloys, and other metals where clean, oxidation-free surfaces are critical. Vacuum Environment: Prevents oxidation, which is particularly important for materials sensitive to contaminants and air. Metal Evaporation and Coating: Suitable for thin-film deposition, perfect for optical and semiconductor manufacturing applications. Compaction and Sintering: Capable of turning metal powders and ceramics into high-quality solid materials. Hermetic Brazing: Enables soldering of electronic and metal components in a perfectly airtight environment, ensuring maximum bond strength and reliability. This vacuum furnace, capable of reaching 1200°C, is the best choice for those seeking high-quality industrial heat treatment solutions without compromise. Its low-pressure operation improves manufacturing process efficiency, minimizes potential errors, and guarantees premium results across various applications.

Condition: used, Year of construction: 1983, machine/vehicle number: 20136, Complete multi-purpose camera stove line consisting of: Voyw78Co - Hardening furnace with automated oil and air quenching - Atmospheric single chamber tempering furnace - washer - Unloading / loading device Working temperature 750 °C - 1050 °C

Year of construction: 1986, Condition: ready for operation (used), A furnace system consisting of an (1) Ipsen pusher-type furnace with shaking trough, a (2) WMV Apparatebau cleaning system and a (3) Kohnle tempering furnace is available. 1) Year of construction: 1986, working temperature range: 850°C-890°C, heating: electric, quenching: oil including oil cooling (via air), defects: Furnace lining and muffle. 2) Year of construction: 2011, drum diameter: 500mm, processes: spinning/washing/rinsing/drying, including transfer unit. 3) Year of construction: 1986, working temperature range: 400°C-500°C, heating: electric. Including large package of spare parts, especially for the Ipsen oven. Y3Vmp3O0

Year of construction: 1986, Condition: ready for operation (used), Vacuum Furnace, Vacuum Oven, Abar Ipsen, Used Machine Manufacturer: Abar Ipsen Model: Vacuum Furnace Year: 1986 C93Ew2A Maximum Temperature: 1200°C Vacuum: 5×10-3 mbar Load Dimensions: 700 x 1250 x 670 mm Electrical Supply: 3 x 200 A Accessories: Vacuum furnace Transformer for heating Stokes 412 large vacuum pump System for the water circuit (pump and distributors) Gas booster for the furnace Control cabinet Diffusion vacuum pump High Vacuum Pump: Edwards EH1200IND 50HZ HYD Oil-sealed Vacuum Pump: Edwards RV8 Cooling Circuit Large Heat Exchanger The vacuum furnace we offer is an ideal solution for any industrial process requiring highly precise heat treatment at temperatures up to 1200°C, without the risk of oxidation or contamination from ambient air. The vacuum environment allows materials to be heat-treated in perfect cleanliness and under precisely controlled temperatures. Key Features and Benefits: Superior Heat Treatment Solution: Ideal for hardening and annealing steel, alloys, and other metals where clean, oxidation-free surfaces are critical. Vacuum Environment: The vacuum prevents oxidation, which is especially important for materials sensitive to contamination and exposure to air. Metal Evaporation and Coating: Suitable for creating thin film layers, perfect for optical and semiconductor manufacturing applications. Shrinkage and Sintering: Capable of transforming metal powders and ceramics into high-quality, solid materials. Hermetic Brazing: Enables brazing of electronic and metal components in a perfectly sealed environment, ensuring maximum bonding strength and reliability. This vacuum furnace, capable of reaching 1200°C, is the best choice for those seeking a top-tier, industrial heat treatment solution without compromise. Thanks to its low-pressure operation, it enhances production efficiency, minimizes the potential for errors, and ensures premium results across all applications.

Condition: good (used), Functionality: fully functional, Complete hardening shop, consisting of various ovens, protective gas generators, cleaning system and air compressors with accessories Components/equipment: Cqqdvex930 Safed electric curing oven T 40/36-T/GM 40/Prop 25, BJ1987 Ipsen electric curing oven TOPF-2-EM, BJ1987 Ipsen electric curing oven WPS-2-E Ipsen electric curing oven DAC-2-ER, BJ1987 Ipsen protective gas generator G-1500-E, FY1979 Ipsen protective gas generator G-750-E, FY1989 Safed cleaning system TR5/21V, TR5/21 Ipsen electric vacuum furnace VFC-124, FY1979 Machine and container construction MB 030602-1,350, FY2008 Rapid scale 5-100kg

Condition: good (used), Year of construction: 1982, operating hours: 3,500 h, Useful dimensions 6600*600 H500 Load 300 Kg Diffusion pump (vacuum 10-5) Quenching under ^pressure 6 bars Ci8Bqbs9

Condition: excellent (used), 1 CHAMBER FURNACE IPSEN TQF5 1984 2 CHAMBER FURNACE IPSEN TQF5 1982 3 CHAMBER FURNACE IPSEN TQF5 1982 Joilrh2Rq 4 IPSEN DA(C)6 PREHEATING FURNACE 1989 5 PREHEATING FURNACE IPSEN DA6 1982 6 PREHEATING FURNACE IPSEN DA6 1982 7 PREHEATING FURNACE IPSEN DAC 1984 8 PREHEATING FURNACE IPSEN DAC6 1989 9 TEMPERING FURNACE IPSEN DL6 1982 10 TEMPERING FURNACE IPSEN DL6 1982 11 TEMPERING FURNACE IPSEN DL6 1984 12 ANLASSOFEN SOLO 13 ENDOGAS GENERATOR IPSEN G750-E 1982 14 ENDOGAS GENERATOR IPSEN G750-E 1980 15 ENDOGAS GENERATOR IPSEN G1500-E 1973

Year of construction: 1986, Condition: used, Functionality: unexamined, machine/vehicle number: 43563, Heating: Gas Fuel gas: Propane Gas overpressure: 10-50 mbar Dqukvr Working temperature: 150-450 °C

Condition: used, Vacuum soldering furnace, make Ipsen Type: VVFC-48x14 – Shaft furnace with forced gas cooling Dqqqxv Useable dimensions (Dia. x H): ø 1200 x 350 mm Working temperature: 500 ÷ 1320°C Connected load: 148 kVA Charge: max. 600 kg Vacuum: 10-4 mbar

Year of construction: 1988, Condition: as good as new (ex-display), machine/vehicle number: 1116/87, MANUFACTURER: ELTERMA/IPSEN MODEL: VDFC-413 DESCRIPTION: Vacuum tempering furnace YEAR OF PRODUCTION: 1988 Fzdr8Bg STATUS: New unused, need revamping of the obsolete parts ( Cabinets ) Max Load Dimensions: 610x900x500mm Max Load Weight: 500 kg Working temperature: 150-750⁰C Approximate warm-up time of the vacuum chamber at 550 ° C for 30 minutes

Condition: good (used), Year of construction: 1979, Functionality: fully functional, Ipsen Industries International GmbH Protective gas generator, G 750 E Model: G750E Year of construction: 1979 Electrical data: Rated voltage: 380V AC Frequency: 50Hz Dppbon

Year of construction: 1988, Condition: used, machine/vehicle number: 59.011, - Heating type: Electrically heated - Quenching type: Gas cooling nitrogen (N2) - Working temperature range: 150 - 750 °C - Charge dimensions: W x L x H = 600 x 900 x 600 mm - Max. permissible load weight: 600 kg gross - Type of loading: by hand - Type of unloading: by hand - Heating time with max. batch weight from RT to 550 °C: approx. 120 min. Do20Vt - Cooling time with max. batch weight from 550 °C to 150 °C: approx. 120 min. - Space required for installation: 3000 x 3000 mm - Height of the system: 2600 mm

Year of construction: 1989, Condition: excellent (used), ipsen tq 11 line CHIMNEY STOVE RTQPF-11-GRM Cnct732Nv

Year of construction: 1988, Condition: used, Functionality: unexamined, machine/vehicle number: 26535, Heating: gas Jwhrmalhe Fuel gas: propane Gas overpressure: 80-100 mbar Working temperature: 150-750 °C Heating output: 550 °C (300 kg/h steel) Max. permissible load weight: 350 kg gross Type of loading: automatic with loading device Type of unloading: manually via loading device Max. batch dimensions: 610x910x460 mm

Condition: ready for operation (used), Year of construction: 1985, Functionality: fully functional, machine/vehicle number: 30596, Heat treatment furnace that allows hardening and tempering under vacuum. D7Tgxek

Condition: good (used), Year of construction: 1987, Functionality: fully functional, Ipsen Industries International GmbH Protective gas generator, G 1500 E Model: G1500E Year of construction: 1987 Dppbnp Technical data: Heating: electric Reaction gas: Propane Gas overpressure min.: 10 mbar Gas overpressure max.: 50 mbar Working temperature min.: 980°C Working temperature max.: 1020°C Total electrical data: Rated voltage: 380V AC, 3-phase Rated current: 60A Frequency: 50Hz Power: 22kVA Electrical data heating: Rated voltage: 380V AC Rated current: 52A Frequency: 50Hz Power: 20kW
