Used Panhans Bsb 600 for sale (4)

Condition: new, Year of construction: 2025, machine/vehicle number: C890, PANHANS band saw Type BSB 600 Stand in modern steel construction, table top thick-walled, high ribbed cast iron massive grey cast iron band saw frames technology: - upper and lower PANHANS band saw blade guide APA II - finely planed cast iron table - swivelling table top up to 20 - dynamically balanced band saw blades with vulcanized rubber bandages - fence ruler can be used to the left of the saw blade Pedpobzmb Hefx Ag Segu - Fence profile can be folded down - blade tension indicator - mechanical height adjustment by hand wheel with locking pinion - automatic motor brake with main switch and motor protection switch technical data: - max. cutting height 380 mm - max. cutting width 570 mm - table size (BT) 590 x 810 mm - table height 905 mm - wheel-Ø 600 mm - engine power 2,2 kW - wheel speed 820 rpm - max. saw band length 4710 mm - suction nozzle-Ø 2 x 100 mm - machine weight 272 kg - machine size (LBH) 1120 x 750 x 2125 mm Location: ex stock Bitburg Top exhibition price Freely loaded

Condition: new, Year of construction: 2024, New machine Year of manufacture 2024 Equipment and technical data: · Wheel diameter: 600 mm · Belt speed: 1550 m/min · Cutting height: 400 mm · Cutting width: 580 mm · Blade length max.: 4735 mm · Saw blade width min. / max.: 15 mm / 30 mm · Optional with special covering saw blade width min. / max.: 8 mm / 25 mm · Table size: 810 x 590 mm · Table height: 920 mm · Extraction nozzle: 2 x Ø 100 mm · Motor power: 2.2 kW / 3 HP · Voltage: 400 V / 50 Hz · Color: RAL 7035 light gray and RAL 5000 violet blue · Net weight: approx. 275 kg TECHNICAL DESCRIPTION · Solid German mechanical engineering · Machine stand in an attractive, modern, torsion-free double-chamber welded steel construction Pgodpsw Nabljfx Ag Seu · Upper and lower doors secured by limit switches · Upper and lower precision band saw blade guide APA 2, size. 2 · Finely planed gray cast iron table · Swiveling table top up to 45° · Dynamically balanced band saw wheels with vulcanized rubber bandages · Stop ruler can be used to the left of the saw blade, stop profile can be folded over · Blade tension indicator · 1 saw blade 4735 x 25 x 0.6 mm, tooth width 9 mm, No. 3780.250D · Mechanical height adjustment of the saw blade guard using a handwheel with locking pinion · From 2.2 kW - rotary cam switch with direct start and emergency stop button · From 3.0 kW - rotary cam switch with star-delta start and emergency stop button · Mechanical motor brake with main switch and motor protection relay · CE-compliant Incl. transport pallet Incl. pre-freight to 65239 Hochheim Availability: short term Storage location: Flörsheim

Condition: new, Year of construction: 2024, New machine Year of manufacture 2024 Equipment and technical data: · Wheel diameter: 600 mm · Belt speed: 1550 m/min · Cutting height: 400 mm · Cutting width: 580 mm · Blade length max.: 4735 mm · Saw blade width min. / max.: 15 mm / 30 mm · Optional with special covering saw blade width min. / max.: 8 mm / 25 mm · Table size: 810 x 590 mm · Table height: 920 mm · Extraction nozzle: 2 x Ø 100 mm · Motor power: 2.2 kW / 3 HP · Voltage: 400 V / 50 Hz · Color: RAL 7035 light gray and RAL 5000 violet blue · Net weight: approx. 275 kg TECHNICAL DESCRIPTION · Solid German mechanical engineering · Machine stand in an attractive, modern, torsion-free double-chamber welded steel construction · Upper and lower doors secured by limit switches · Upper and lower precision band saw blade guide APA 2, size. 2 · Finely planed gray cast iron table · Swiveling table top up to 45° · Dynamically balanced band saw wheels with vulcanized rubber bandages Pgodpfew Nabrex Ag Seu · Stop ruler can be used to the left of the saw blade, stop profile can be folded over · Blade tension indicator · 1 saw blade 4735 x 25 x 0.6 mm, tooth width 9 mm, No. 3780.250D · Mechanical height adjustment of the saw blade guard using a handwheel with locking pinion · From 2.2 kW - rotary cam switch with direct start and emergency stop button · From 3.0 kW - rotary cam switch with star-delta start and emergency stop button · Mechanical motor brake with main switch and motor protection relay · CE-compliant Incl. transport pallet Incl. pre-freight to 65239 Hochheim Availability: short term Storage location: Flörsheim

Condition: new, Year of construction: 2025, New machine Year of manufacture 2025 Equipment and technical data: · Wheel diameter: 600 mm · Belt speed: 1550 m/min · Cutting height: 400 mm · Cutting width: 580 mm · Blade length max.: 4735 mm · Saw blade width min. / max.: 15 mm / 30 mm · Optional with special covering saw blade width min. / max.: 8 mm / 25 mm · Table size: 810 x 590 mm · Table height: 920 mm · Extraction nozzle: 2 x Ø 100 mm · Motor power: 2.2 kW / 3 HP · Voltage: 400 V / 50 Hz · Color: RAL 7035 light gray and RAL 5000 violet blue · Net weight: approx. 275 kg Pgjdpsvymg Eofx Ag Sou TECHNICAL DESCRIPTION · Solid German mechanical engineering · Machine stand in an attractive, modern, torsion-free double-chamber welded steel construction · Upper and lower doors secured by limit switches · Upper and lower precision band saw blade guide APA 2, size. 2 · Finely planed gray cast iron table · Swiveling table top up to 45° · Dynamically balanced band saw wheels with vulcanized rubber bandages · Stop ruler can be used to the left of the saw blade, stop profile can be folded over · Blade tension indicator · 1 saw blade 4735 x 25 x 0.6 mm, tooth width 9 mm, No. 3780.250D · Mechanical height adjustment of the saw blade guard using a handwheel with locking pinion · From 2.2 kW - rotary cam switch with direct start and emergency stop button · From 3.0 kW - rotary cam switch with star-delta start and emergency stop button · Mechanical motor brake with main switch and motor protection relay · CE-compliant Availability: short term Storage location: Flörsheim
