CNC lathe

Haas SL-30

Condition: used, Year of construction: 2007, Technical details: turning diameter over bed: 762 mm turning length: 850 mm facing movement (x-axis): 287 mm longitudinal traverse (z-axis): 864 mm control: CNC Haas spindle passage: 76 mm revolution per minute: max. 3400 steples U/min tailstock taper ISO: Ø 290 tailstock quill stroke: ja mm tool turret - number of stations: 12 Nlodpfx Ajvvt Emofxjh electrics - voltage/frequency: 360/ 400 V - 50-60 Hz V/Hz Weight approx.: 6,3 t transport measurements machine: ca. 3,4 x 2,1 x 2,4 m Equipment: 3-jaw power chuck KITAKAWA Ø 250 mm (without jaws) 4200 rpm. Operable via 2-position foot switch. Tool turret with powered tools available. Electric coolant system provided. Tool measuring system available. I.D. *

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 3078451, turning diameter over cross slide: 368 mm, turning length: 750 mm, spindle bore: 102 mm, spindle speed (max.): 2,400 rpm, travel distance X-axis: 287 mm, travel distance Z-axis: 864 mm, spindle motor power: 30 W, total height: 1,900 mm, total length: 3,800 mm, total width: 2,000 mm, Working length 750 mm Swing over bed 760 mm Swing over cross slide 368 mm Spindle speeds 2.400 rpm Njdpexmu Rnsfx Afxolh Spindle bore 117/102 mm Number of tools 12 pcs X-axis travel 287 mm Z-axis travel 864 mm Main motor power 30 Kw

Condition: excellent (used), Year of construction: 2007, operating hours: 8,800 h, functionality: fully functional, Equipment: documentation/manual, The used HAAS SL 30 THE CNC lathe is a fast, medium-sized slant bed CNC lathe equipped with a tailstock, hydraulic 3-jaw power chuck, and a 12-position automatic turret. The configuration is completed with tool presetting, chip conveyor, programmable tailstock body, 250mm BB hydraulic 3-jaw chuck, and fixed tool holders. Main features: Maximum workpiece diameter: 350 mm Maximum workpiece length: 826 mm Njdpfx Aoxiu D Tofxelh Maximum bar capacity: 76 mm Spindle speed: 3,400 rpm Spindle power: 30 HP Year of manufacture: 2007, with only 8,800 spindle hours. Machine compliant with "CE" standards.

Year of construction: 2007, condition: ready for operation (used), General Data Measurements width 2000 mm Measurements depth 3300 mm Measurements height 2000 mm Control Unit Brand HAAS Main Drive Spindle speed range 3400 Spindle bore 76 mm Number of axis 2 Movement X-Axis Movement 287 mm Z-Axis Movement 864 mm Turret Number of turrets 1 Tools Nodpfoxc Rfajx Afxelh Number of station 12 Media Chip conveyor Yes This HAAS SL-30HE was manufactured in 2007. A robust horizontal turning machine featuring a turning diameter over bed of 762mm and a length of 860mm. It includes a VDI tool turret with 12 positions and a chip conveyor. Ideal for precise and efficient turning operations. Contact us for more information about this machine. Application Types Turning

Year of construction: 2005, condition: used, For sale Haas lathe model Sl30 Nodpfxswir R Hj Afxelh The machine is functional, interested parties are welcome to inspect it live.

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, turning diameter over cross slide: 762 mm, turning length: 863 mm, turning diameter: 431 mm, spindle speed (max.): 3,400 rpm, overall weight: 7,250 kg, chuck outer diameter: 254 mm, Haas SL-30 THE Year 2008 Control Haas Chuck 10” Turning Length 863 mm Turning Ø 431mm Ø above the bed 762 mm Nlsdpswbd Hqofx Afxoh Turret 12 station Speed 3400 rpm Length x width x height 4500 x 2300 x 2000 Weight 7250 kg

Condition: used, Year of construction: 2008, turning diameter 432 mm turning length 864 mm control HAAS bar diameter 76 mm 3-jaw-chuck diameter 254 mm travel -z axis 864 mm travel -x axis 287 mm spindle speed: 3400 1/min spindle bore 88 mm swing over bed 762 mm swing diameter over bed slide 432 mm turret head 12 Pos. VDI 40 drive capacity - spindle motor 22 kW voltage 400 V weight of the machine ca. 7.250 t dimensions of the machine ca. 3,90 x 2,00 x 1,90 m - serial-no.: 3082298 - Machine Run Time: ---- h - control: HAAS - tool measuring arm - chip conveyor - collant equipment Nodoupmhwepfx Afxelh

Condition: excellent (used), Year of construction: 2006, operating hours: 6,650 h, functionality: fully functional, Equipment: documentation/manual, The used HAAS SL 30 THE CNC lathe is a fast, medium-sized, slant-bed numerically controlled lathe equipped with a tailstock, C-axis spindle, and a 12-position powered turret with VDI 40 tooling interface. The configuration also includes a tool presetter, chip conveyor, programmable tailstock body, hydraulic 3-jaw chuck 250mm BB, and fixed toolholders. Main features: Nljdpfx Afexdvarexsh Maximum workpiece diameter: 350 mm Maximum workpiece length: 826 mm Maximum bar diameter: 76 mm Spindle speed: 3,400 rpm Spindle power: 30 HP Year of manufacture: 2006, with only 6,650 spindle hours, CE compliant machine.

Year of construction: 2008, condition: ready for operation (used), Control Unit Brand HAAS Main Drive Spindle speed range 3400 rpm Media Chip conveyor Yes Additional Equipment Nsdpfx Aexc Rfyefxelh Toolsetter VDI40 x 12 Part Catcher / Hainbuch SK80 / KID 80 Barfeeder This HAAS SL-30 was manufactured in 2008. A robust horizontal turning machine featuring a 22 kW, 3400 rpm gearbox, and a 102 mm bore. It includes a Hainbuch SK80, chip conveyor, tool setter, part catcher, and a KID 80 bar feeder. If you are looking to get high-quality turning capabilities, consider the HAAS SL-30 machine we have for sale. Contact us for more information. Application Types Turning

Year of construction: 2008, condition: ready for operation (used), General Data Measurements depth 3900 mm Measurements width 2000 mm Nodoxc Rd Nopfx Afxjlh Measurements height 1900 mm Control Unit Brand HAAS Main Drive Spindle speed range 3400 Spindle bore 103 mm Number of axis 2 Workpiece Workpiece drm over bed 762 mm Additional Equipment 2-step gearbox 3 jaw chuck + collet chuck Barfeed magazine Samsys This HAAS SL-30TBHE was manufactured in 2008. A robust horizontal turning machine featuring a spindle speed of 3400 1/MIN, 22 kW motor power, and a swing over bed of 762 mm. It includes a 12-position turret, hydraulic tailstock, and both 3 jaw and collet chucks. Dimensions are 3900x2000x1900 mm. Consider the opportunity to buy this HAAS SL-30TBHE horizontal turning machine. Contact us for more information. Application Types Turning
