Double-sided high speed press

HAULICK & ROOS RVD 125-910 NS

Year of construction: 2008, condition: used, pressure 315 t stroke 40-200 mm no. of strokes 20-100 Hub/min ram - range of adjustment 120 mm ram surface 2000x1100 mm table surface area 2000x1200 mm hole in the table 1700x250 mm 500 mm column travel -side 820x650 mm Bsdpferdi Dlox Af Helr total power requirement 45 kW weight of the machine ca. 44 t

Year of construction: 1981, condition: used, pressure 63 t stroke 6-60 mm no. of strokes 90-550 Hub/min Bjdpfx Afelp U R Is Helr 300 mm table surface area 780x600 mm ram surface 807x460 mm tool hole in ram Ø 40 mm ram - range of adjustment 80 mm total power requirement 15 kW weight of the machine ca. 8 t dimensions of the machine ca. BxTxH 2900x2000x3000 m

Condition: used, Year of construction: 1996, pressure 63 t distance between columns 965 mm Bedpovut Rgjfx Af Holr stroke 4 - 60 mm no. of strokes 30 - 800 Hub/min dayligth (stroke and adjustment up) 380 mm column travel -side 355 mm table surface area 960 x 640 mm hole in the table 850 x 140 mm table height over floor 1150 mm ram surface 960 x 460 mm power requirement 32,5 kW weight of the machine ca. 13,00 t required space 3,3 x 1,7 x 2,9 m ram adjustment 80 mm permitted for automatic mode according to the CE Regulations with infinitely variable drive, pneumatic clutch, semi-automatic stroke adjustment, motoric ram adjustment, mechanical pincer feed type GF 160 can be offered without or with putting into operation in given condition

Condition: used, Year of construction: 1981, machine/vehicle number: 104680, Press capacity: 45 ton Ram stroke adjustable: 10 - 40 mm Slide adjustment: 50 mm Shut height (stroke down, adjustment up): 220 - 300 mm Free frontal opening L-R: 560 mm Table surface area : 550 x 450 mm Slide area: 550 x 360 mm Bledsuqcwdjpfx Af Her Hole in table: 450 x 100 mm Number of strokes: 100 - 500 s.p.m. Required power: 7,5 kW Weight of machine approx.: 6,2 ton

Condition: used, Year of construction: 1985, Technical details: Punching capacity: 40 kN air pressure - required: 8 bar ram stroke - adjustable min/max: 6 - 50 mm ram adjustment: 50 mm no. of strokes: 70 - 400 Hub/min Table dimensions: LxB: 480 x 445 mm hole in table: LxB: 250 x 112 mm slowing-down time: 80 ms bei 450 U/min. clamping surface ram: LxB: 420 x 345 mm ram hole: Ø 40 x 230 mm voltage: 380 V control voltage: 220 V frequency: 50 Hz Bljdpeu Icwgsfx Af Hsr total power requirement: ca. 19 kVA (ca. 7,5 KW) weight of switch cabinet: 0,3 t machine weight ab.: 4000 kg 40t punching press without roll feed/conveyor belt system Operation via control panel / two-hand operation Operation: manual / automatic *

Condition: used, Year of construction: 1980, machine/vehicle number: 130861, Press capacity: 50 ton Ram stroke: 54 mm Slide adjustment: 80 mm Shut height (stroke down, adjustment up): 303 mm Bljdpsuqc Hlofx Af Hsr Table surface area : 810 x 550 mm Number of strokes: 65 - 400 s.p.m. Weight of machine approx.: 7,5 ton Main Motor: 11 kW Extended machine accessories IMCO Press force measurement Automation Grip Feeder, Type ZR18ZT1Max. Sheet width 180 mmFeeding length 150 mm
