INGERSOLL Gantry 800

Condition: excellent (used), Year of construction: 2011, OPS Ingersoll Gantry Eagle 800 Year of manufacture: 2011 Operating hours: 1703 Eagle Powertec control X, Y, Z travel: 550 x 850 x 450 mm Clamping plate: 760 x 1000 mm Max. workpiece weight: 2000 kg EROWA interface Submersible working tank C-axis Chiller Fire extinguishing system Remote control 20-station electrode changer 60 amp generator Codpfjxiwz Uex Abwehc Incl. dielectric fluid (+/- 700 liters) Incl. probe Incl. probe on machine bed Incl. magnet 400 x 200 mm Incl. cabinet with accessories Incl. documentation Machine is powered up for inspection

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 575650, travel distance X-axis: 550 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 450 mm, TECHNICAL DETAILS Design: Lift tank Internal dimensions (W x D x H): 800 x 1100 x 480 mm Dielectric height programmable/automatic: max. 450 mm WORKING HEAD On ram clamping system UPC/H8000/Dynafix: 150 kg Min. distance electrode clamping system to worktable: 135 mm Max. distance electrode clamping system to worktable: 585 mm INTEGRATED C-AXIS Adjustable rotation speed: 1 - 20 rpm Measuring resolution: 0.001 degrees Load capacity with manual electrode change: 50 kg Load capacity with automatic electrode change: 15 kg Holding torque/clamping force: 120 Nm Max. moment of inertia of electrode: 0.4 kgm² WORKTABLE Support surface (W x D): 760 x 1000 mm Load capacity: 2,000 kg TRAVEL PATHS X / Y / Z (inside work tank): 550 x 850 x 450 mm Y (for electrode change and loading position): 1180 mm CONTROL PC-NC dialog: 2 x 32 bit Drive type: digital AC servo motors Max. travel speed X, Y, Z: 5,000 mm/min High speed jump max.: 18,000 mm/min MACHINE DETAILS Main voltage: 400 V / 50 Hz Control voltage: 24 VDC Maximum fuse: 32 A Power consumption: 19 kVA Machine weight: 6,400 kg Main dimensions (W x H x D) including generator: 2760 x 2730 x 2940 mm Footprint with generator: 9 m² Generator weight: 640 kg Csdpfxew T Thms Abwshc Operating hours: 3,221 h

Condition: used, Year of construction: 2004, machine/vehicle number: 575259, travel distance X-axis: 550 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 450 mm, For sale is a high-quality sinker EDM machine from the renowned manufacturer OPS Ingersoll. This machine is ideal for precise EDM operations in tool and mold making, and comes equipped with an extensive range of features. 🔍 General Information: Manufacturer: OPS Ingersoll Model: Gantry 800 Machine No.: 575259 Year of manufacture: 2004 Origin: Made in Germany Condition: Used, well-maintained, and fully operational ⚙️ Technical Specifications: Travel distances (X/Y/Z): 550 x 850 x 450 mm Worktable size: approx. 800 x 1000 mm Max. head load: 200 kg Max. clearance: 585 mm Max. traversing speed: 12,000 mm/min 💡 Equipment & Features: 30-position tool changer, EROWA Mitsubishi 64-bit CNC control (separate control panel) Programming software: MultiProg Control technology: Multipulse PRO Chuck: ER-016841 Integrated CO₂ fire extinguishing system Cartridge filter unit Dielectric cooling system by Weinreich Industriekühlung Extensive accessories and connection cables available ⚡ Electrical Data (as per type plate): Supply: 400 V / 3~ / 50 Hz Control voltage: 24 V AC / DC Power consumption: 17 A Fusing: 25 A Chjdpfxjw Ig A He Abwoc Wiring diagram no.: 107258 Errors, typos and prior sale excepted.

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 1,010 mm, travel distance Y-axis: 1,510 mm, travel distance Z-axis: 700 mm, workpiece weight (max.): 2,000 kg, OPS Ingersoll Gantry 800 Eagle Year of manufacture: 2014, overhauled in 2024 Control: Eagle powertec 3036 Generator: Eagle Powertec PT 60 Travel paths: 1010x1510x700mm Clamping table: 760x1000mm Load capacity: 2000kg Codpew Hdbfsfx Abwehc Max. dielectric height: 450mm 30-position EROWA tool changer Integrated C-axis 0.001° Max. head load: 200kg High Speed Jump max. 18m/min interval on Z axis Multi Prog Powertes - technology programming Powertec handheld unit Manual eroding with Powertec Dielectric cooler
