Four-blade panel saw KALLFASS

KALLFASS

Condition: ready for operation (used), Year of construction: 1982, functionality: unexamined, length of welding knife: 560 mm, passage height: 230 mm, passage width: 430 mm, Equipment: documentation/manual, KALLFASS Compact Shrink Wrapper KC 5040/450 - Used unit, year of manufacture 1982 Description: Easy-to-use L-sealer combined with a shrink tunnel. Exceptionally robust design for industrial use. Sealing frame dimensions: 500 x 400 mm. Proven impulse sealing technology with PTFE-coated sealing wire for absolutely odorless operation. Performance up to approx. 20 cycles/min. Sealing frame can be closed manually with minimal effort. Equipped with a closure mechanism featuring an automatic pressure system for precise compliance with set sealing times and reliable separation, even for thicker films. Product transfer conveyor for automatic feed of sealed packages into the shrink tunnel. Suitable for all standard centerfold shrink films from approx. 12 - 80 µm, e.g. polyethylene or polyolefin films. Standard basic equipment: • Film roll holder for setting film reels • Feed table complete with film separator bar and separator sheet • Air support plate for automatic opening of the centerfold film • Film hold-down plates on the sealing frame • Base heating for the sealing wires to increase packing performance • Automatic product transfer conveyor into the shrink tunnel, height adjustable for seal placement at half product height • 1 transition roller at the tunnel entrance • Adjustable rod-chain transport through the shrink tunnel • Silicone-coated conveyor rods, rod spacing 25 mm, rod diameter 12 mm • Energy-saving 2-stage heating • Highly effective thermal insulation on the tunnel hood for energy saving • Infinitely adjustable tunnel blower power • Temperature control via electronic thermostat • Adjustable tunnel passage height • Adjustable working height Ppjdpfx Aljy H Evdo Sjr • Machine mounted on castors for mobile use Included additional equipment: • Automatic product transport into the shrink tunnel • 300 mm cooling station with ball-bearing aluminium rollers at tunnel exit • Special cooling fan at top of tunnel exit Technical specifications: Sealing frame dimensions: 500 x 400 mm Film: Centerfold film, approx. 12 - 80 µm Max. outer diameter of film rolls: 300 mm Film core diameter approx.: 76 mm Max. film roll width: 550 mm Adjustable working height: 870 - 970 mm Tunnel passage width: 450 mm Adjustable tunnel passage height: 100 - 400 mm Heated tunnel hood length: 900 mm Product transport: Rod-chain conveyor Variable conveyor speed: 2.5 - 12 m/min Drive: AC gear motor 0.25 kW Temperature control: Electronic thermostat Heater blower output: Infinitely adjustable Electrical connection: 400 V 3-phase, 50 Hz, with protective earth Installed heating power, 2-stage switchable: 4.5 + 1.5 kW (continuous operation consumption approx. 40%) Nominal power: 8.5 kW Nominal current: 12.3 A Control cabinet and operator side: Left, in working direction Paint finish: Kallfass green, similar to RAL 6011 Dimensions: L = 2,500 mm x W = 1,050 mm

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, Modular gripping chain feeding system Kallfass MGZ 400 manual unit - Used machine, year of manufacture: 2002 Ppedpoy H Ep Djfx Al Sjr - On wheels, lockable with spindle feet Chain gripper feeder with centrally positioned, interchangeable pushers and side guides in modular design. The pusher pitch is approx. 460 mm, with a maximum pusher height of 145 mm. The usable width is 500 mm. The drive is frequency-controlled and equipped with an overload clutch. The pusher spacing is adjustable. The chain gripper feeder is mobile. Total length is approx. 4,800 mm, providing space for 4 working or loading stations. Total length: 4800 mm Total width: 800 mm Working height: approx. 860-1000 mm Side guides adjustable, height 70 mm.

Condition: used, functionality: fully functional, Kallfass shrink wrapping machine – indestructible and fully operational Psdpfsxz Trysx Al Sspr

Condition: excellent (used), Dimensions of the entrance opening 400x200 Ppsdpfstrtztex Al Sor Dimensions Length 2995 mm Width 1250 mm Height 1550 mm

Condition: used, Year of construction: 2010, functionality: fully functional, Manufacturer: KALLFASS Model: UNIVERSA 500, year 2010 Model: Shrink Tunnel COMPACT 650 SO, year 2010 SPECIFICATIONS KALLFASS UNIVERSA 500 - fully-automatic side sealer Transverse seal bar, length: 500 mm Product clearance height: up to 200 mm Power supply: 208 - 480 volt Film, center-folded film: 12 - 80 μm Transport speed: 10 - 35 meter / minute Packaging capacity, max.: 85 cycles / minute Technical Data Compact 650 SO Tunnel clearance in width: 650 mm Tunnel clearance in height, adjustable: 100 - 400 mm Length of the heated tunnel hood: 1100 mm Air-flow regulation with patented ring nozzle system: standard Maintenance free plastic-mesh-belt: standard Pedpjxnzlhofx Al Sepr Transport speed infinitely variable, frequency controlled: approx. 10 – 35 m/min. Capacity of the tunnel blower infinitely variable, frequency controlled: standard Energy saving 2-stage heating with special insulation in tunnel hood: standard Temperature control by means of electronic thermostat: switching precision +/- 0.2° C Wear resistant and contactless temperature control: standard safety device according to EC regulation machines EN 60204: limit temperature control: standard Working height, adjustable: 800 - 900 mm Power supply: 400 Volts, 50 Hz, with protective earth conductor Heating capacity, installed, 2-stage switchable: 9.0 + 4.5 kW Rated capacity: 14.5 kVA Nominal current at 400 V: 21.0 amps Total connected load: max. 37.0 amps (incl. add. three phase power supply) Position of control cabinet and operating side: left hand side in working direction

Condition: excellent (used), Year of construction: 2020, Complete sawmill for pallet lumber consisting of: 1. Log yard Häwa, with root reducer and Valon Kone debarker VK 90. Calibrated factory log input measurement system by Jörg. Sorting with 28 bins. Log length 2.0 - 5.0 m. Log diameter from 20 - 90 cm. 2. Sawmill: Möhringer band saw, running bandsaw with Flexi Drive carriage. Slab scanning unit. Round timber intake with step-by-step singulation. Laser measurement by Bidac. Kallfass cross-cut unit. Resaw: EWD Optimes with chipper canter and double arbor saw NKU. Brodbaek edger system. Stacking system for main products, empty pallet handling for both main and side products. Kuka robot for packing side products and main products, four dimensions possible. Complete mechanization, electric and electronic control cabinets, etc. Waste disposal. Detailed plans or video can be provided upon request. Ppsdpjx T Azwsfx Al Sor

Condition: refurbished (used), Year of construction: 2010, functionality: fully functional, Manufacturer: Kallfass GmbH Type: Compact Shrink Wrapper KC 5040/450 Universal Year of manufacture: 2010 Ppsdpfxsyyxr Ej Al Sor Technical data: Sealing frame dimensions: 500 x 400 mm Film roll width: max. 550 mm Working height: 870 - 970 mm Power supply: 380 V three-phase Easy-to-operate L-sealing machine combined with a shrink tunnel. Especially robust design for industrial use. Sealing frame dimensions 500 x 400 mm. Proven impulse sealing technology with Teflon-coated sealing wire for completely odor-free operation. Equipped with a closing mechanism as a pressure-automation system to ensure precise adherence to the set sealing time and to enable reliable sealing even of thick films. Inspection and demonstrations are possible at our premises by appointment. Functional guarantee, no warranty.

Condition: refurbished (used), Year of construction: 2014, functionality: fully functional, Fully automatic flow pack machine for packaging products – regardless of their length – in a full wrap and without film overlap. Product infeed is via a conveyor belt while simultaneously wrapping into a center-folded film using a forming shoulder. Product separation is controlled by a photoelectric sensor. The infeed conveyor can be easily adjusted for different product widths. Longitudinal sealing is achieved by a continuous side sealing device. The height position of the forming shoulder and sealing units is manually adjustable. Ppjdpfjyybuijx Al Ssr Wearing parts and defective components have been replaced. The machine has been technically inspected by Kallfass and is fully functional. Technical data: Cross sealing bar: 850 mm Film: center-folded film, approx. 12 - 80µm Film roll outer diameter: max. 400 mm Film roll width: max. 900 mm Min. product length: 120 mm Pass-through height: 300 mm Working height: 780 - 930 mm Power supply: 400 Volt three-phase, 50 Hz with protective conductor Rated output: 3.5 kVA Rated current: 5.1 A Inspection and demonstrations are possible in our facilities by appointment. Functionality guarantee, no warranty.

Condition: refurbished (used), Year of construction: 2016, functionality: fully functional, Used machine Manufacturer: Kallfass GmbH Model: Fully Automatic Side Sealing Machine Universa 500 Year of manufacture: 2016 Dimensions: approx. 2150 x 1800 x 1550 mm (L x W x H) Weight: approx. 1050 kg Transverse sealing bar: 500 mm Film: semi-tubular film, approx. 12 - 80 µm Max. film roll outer diameter: 400 mm Max. film roll width: 600 mm Min. product length: 80 mm Passage height: 200 mm Working height: 780 - 930 mm Power connection: 400 V three-phase, 50 Hz with protective earth Psdpsyw Rn Tofx Al Sepr Rated power: 3.5 kVA Rated current: 5.1 A Fully automatic tubular bag machine for packaging products—regardless of their length—in full wrap and without film overlap. Product feed is via a conveyor belt with simultaneous wrapping in a semi-tubular film using a forming shoulder. Product indexing is controlled by a photoelectric sensor. The infeed conveyor can be easily adjusted for different product widths. Longitudinal sealing is achieved by a continuous side sealing unit. The height of the forming shoulder and the sealing units can be adjusted manually. Manufacturer: Kallfass GmbH Model: Shrink Tunnel Compact 650 S Year of manufacture: 2016 Dimensions: approx. 1850 x 1400 x 1450 mm (L x W x H) Weight: approx. net 580 kg / gross 630 kg Technical Data: Tunnel passage width: 650 mm Tunnel passage height: 200 mm fixed Length of heated tunnel hood: 1200 mm Working height: 800 - 900 mm Power connection: 400 V three-phase Energy consumption: approx. 6 kWh Rated current at 400 V: 21.0 A in standalone operation Compact and cost-effective shrink tunnel featuring a patented ring nozzle heating system with highly effective air volume control. Equipped with a steplessly adjustable plastic modular belt. This tunnel is particularly suitable for shrinking small to medium-sized products at medium output rates. Offer validity: 30 days, subject to prior sale Function guarantee, no warranty

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, Manufacturer: Kallfass GmbH Model: Shrink Tunnel Universal 950 HV Year of manufacture: 2007 Dimensions: approx. 2540 x 1655 x 1600 mm (L x W x H) Weight: approx. net 750 kg / gross 820 kg Technical data: Tunnel passage width: 900 mm Tunnel passage height: 500 mm Pedjyw Rm Aopfx Al Sepr Length of heated tunnel hood: 1700 mm Length of additional insulation hood: 2200 mm Tunnel discharge, extended: approx. 600 mm Working height: 800 - 900 mm Power supply: 400 V three-phase Rated power: 39 kW Rated current at 400 V: 56 A in single operation Universally applicable, high-performance shrink tunnel with laterally adjustable air flaps and outlet openings, adjustable from the outside at the bottom, for precise control of hot air flow, ensuring optimal shrink results even with products of challenging shapes. The recirculation system, the tunnel hood with an additional dual-chamber system, and significantly increased overall insulation provide energy-efficient operation. Equipped with rod chain conveyor, infinitely variable speed control. Functional guarantee, no warranty. Offer valid for 30 days, subject to prior sale. Please note that all machines are delivered without power cables.
