Cylindrical grinding machine

Karstens

Condition: excellent (used), Year of construction: 1980, Karstens K11 1000 This Karstens K11 comes from a university environment and was only used very sparingly. All cables and hoses in the wet area have been replaced. It has extremely low operating hours. As we specialize in Karstens cylindrical grinding machines, we can offer you full service (electrical and mechanical) for the machine after purchase. Technical Data: Centre distance: 1000 mm Centre height: 180 mm Workpiece weight: 70 kg (between centers, cantilevered), 250 kg (between centers) Grinding wheel diameter: 400 mm Workpiece spindle: Morse Taper 4, infinitely variable speed 30–450 rpm, swiveling range 0–90° Tailstock: Morse Taper 4, quill stroke 45 mm Tailstock rest beside Z-axis table Quill force: 200–600 N Table swivel: 12.5 degrees Travel of infeed spindle: 80 mm Rapid traverse: 50 mm Dkedpfx Aeh Rit Eodgji Coarse adjustment air cushion: 280 mm External grinding spindle motor: 4 kW Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 0.55 kW Machine weight: net 3,500 kg Infeed drive by DC motor Air cushion-supported rapid adjustment of the grinding spindle headstock for fast and safe positioning at the grinding station. Separate drives for spindles for external and internal grinding. Fully automatic operation cycle, feed movement controlled via rotary switch: Rapid advance, rapid retraction, grinding mode, feed stop, mym-feed adjustment. Automatic longitudinal grinding cycle Central coolant supply for all grinding stations Workpiece headstock with infinitely adjustable drive for rotating and lockable spindle. Infeed control for longitudinal grinding and plunge grinding, settings for retraction, feed amounts, feeds, spark-out times, idle strokes. Digital readout for X-axis by Heidenhain Paper band filter unit can be offered on request. Comparable to Weiss/ EMAG/ GP-cylindrical grinders/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat

Condition: new, We offer you spare parts of all kinds for your conventional or CNC Karstens / EMAG WEISS / GP cylindrical grinding machine—covering your tailstock, workpiece headstock, grinding spindle headstock, ball screw spindles, glass scales, grinding wheel flanges, drive motors, axis drives (BOSCH SIEMENS), ECKELMANN controls, bellows, bearings, K11/K21 infeed controls (new and used), as well as Z-axis reversing blocks for exchange. We service machines from year of manufacture 1955 onwards: ASA-ASE-K10-K11-K12-K13-K16-K19-K21-K22-K23-K24-K25-K26-K27-K28- K29-K33-K35-K37-K50-K51-K52-K53-K57-W11-W21-GP cylindrical grinding machines—all assemblies based on Karstens design. Djdpjup Aiksfx Adgski Comparable/ EMAG-WEISS/ GP cylindrical grinding machines/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat.

Condition: new, We offer all types of spare parts for your conventional or CNC Karstens/GP cylindrical grinding machine, including components for your tailstock, workpiece spindle head, grinding spindle head, ball screws, glass scales, grinding wheel flanges, drive motors, axis drives (BOSCH SIEMENS), bellows, bearings, K11/K21 infeed control systems—new and used—as well as reversing blocks for the Z axis on an exchange basis. Also suitable for similar Weiss/EMAG/GP cylindrical grinding machines, Studer, Kellenberger, Schaudt, Tschudin, Tacchella, Dannobat, Bahmüller, Fortuna. Dkodpfxoraibve Adgei

Condition: refurbished (used), Year of construction: 2026, Karstens K11 1000 Full Equipment Dsdpfoh Riwdex Adgeki The cylindrical grinding machine has been completely overhauled by PS-Karstens. The machine has been tested and is in very good condition. Since we specialize in Karstens cylindrical grinding machines, we can offer you comprehensive service (both electrical and mechanical) for the machine after purchase. Technical Data: Centre distance: 1000 mm Centre height: 180 mm Workpiece weight: 100 kg (unsupported), 250 kg (between centers) Grinding wheel diameter: 400 mm Workpiece spindle: MT 4, steplessly adjustable speed 30–450 rpm, swiveling range 0 - 90° Tailstock: MT4, quill stroke 45 mm, fine adjustment for the quill Quill force: 200-600 N, hydraulically operated via foot pedal Table swivel angle: 10 degrees Infeed spindle travel: 80 mm Rapid traverse travel: 50 mm Coarse adjustment with air cushion: 280 mm External grinding spindle motor: 4 kW Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 0.55 kW Machine weight: net 3,800 kg Infeed drive by DC motor Air cushion assisted rapid adjustment of the grinding spindle headstock for fast and safe positioning of the grinding position. Separate drive for spindles for external and internal grinding. Fully automatic operation cycle, infeed motion via star dial switch: Rapid approach, rapid return, grinding mode, infeed stop, micron infeed. Automatic longitudinal grinding cycle Central coolant supply to all grinding positions Workpiece headstock with steplessly adjustable drive for live and lockable spindle operations. Infeed control for longitudinal and plunge grinding, input for retraction, infeed amounts, feeds, spark-out times, empty strokes Digital readouts for grinding spindle B-axis, workpiece spindle, X and Z axes from HEIDENHAIN Paper band filter unit approx. 250 L Similar to Weiss / EMAG / GP cylindrical grinders / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat / Bahmüller / Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Center height: 181 mm Center distance: 650 mm Maximum grindable workpiece diameter: 360 mm Max. load (overhung): 1000 N / 100 kg Max. load (between centers): 3000 N / 300 kg Z-axis Table swivel angle: 10° Table drive hydraulic: 0–4 m/min X-axis Cross slide travel: 80 mm Rapid traverse (hydraulic): 50 mm Coarse positioning—air cushion: 280 mm Infeed drive via DC motor Rapid feed rate: 48 mm/min/Ø Infeed process: Plunge / Longitudinal grinding 4 pre-selectable feed rates: mm/min/Ø 0.01–48 4 pre-selectable infeed increments: mm/ 0.001–0.1 Spark-out during end stop grinding: s 0–99 / 0–99 strokes Jog infeed: mm/Ø 0.001 Grinding spindle headstock—universal, swiveling: degrees 0–180 Grinding wheel (external): D x width x bore mm 500x100x127 or 203.2 Grinding wheel (face, option): D mm 250x32x76.2 Grinding wheel (internal, option): D mm (2–250) Drive power (external, face): kW 5.5 (7.5) Drive power (internal): kW 2.2 Peripheral speed (external): m/s 35 (50) Grinding wheel wear (external): mm/Ø 160 Wheel guard width: mm 100 Grinding spindle diameter: mm 60 Internal spindle mount: mm 80 (100) Workpiece headstock: Infinitely variable drive, MK 4: 1/min 30–270/ 50–450 Workpiece spindle lockable Spindle mount: mm MK 4/24 Spindle nose for flange mounting: MK 4 mm cylindrical Ø63H6 x 6 Workpiece headstock swivels on the rotary part: degrees 0–90 Tailstock: Dsdpfx Aotqf Sqsdgeki Quill mount / quill diameter: mm MK 4/750 Quill stroke mm: 45 Quill force N: 100–800 / 250–1400, adjustable Quill actuation: manual (foot switch) Quill fine adjustment: ±40μm Connections: Total power requirement of the machine: kW 6.5–10 Grinding spindle headstock: kW 5.5 (7.5) Workpiece headstock: kW 0.55 (1.1) Coolant cleaning: kW 0.75–2.2 Guideway lubrication pump: kW 0.1 Hydraulic pump: kW 1.5 Hydraulic tank: liters 80 Pneumatics: bar 6 Similar to Weiss/ EMAG/ GP cylindrical grinding machines/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat/ Bahmüller/ Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 650 Premium Retrofit Cylindrical Grinding Machine Dkedeiv Audjpfx Adgoi Manufacturer: Karstens Technical specifications: Centre distance: 750 mm Centre height: 180 mm / (250 mm optional) Workpiece weight: 100 kg (between centres) – 250 kg (supported between centres) Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MT 4, stepless speed adjustment 30–450 rpm, swivel range 0–90° Tailstock: MT 4, quill stroke 45 mm, quill offset adjustment Quill force: 200–600 N manual, (up to 2500 N adjustable as option) Table swivel adjustment: 12.5 degrees Cross slide travel: 80 mm Rapid traverse distance: 50 mm Coarse adjustment with air cushion: 280 mm External grinding spindle motor: 4 kW / (5.5 kW optional) Stepless speed setting of the grinding wheel via potentiometer Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 1.1 kW Hydraulic motor: 1.5 kW Lubrication motor: 0.1 kW Hydraulic tank: 80 litres Machine weight: Net 3,500 kg Feed drive via DC motor Air-cushioned rapid adjustment of the grinding spindle head for fast and precise positioning. Separate drive for external and internal grinding spindles. Fully automatic operation, feed movement controlled via handwheel switch: rapid feed, rapid return, grinding operation, feed stop, mym-feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding zones Workpiece headstock with steplessly adjustable drive, with live and lockable spindle. Digital feed control with Siemens panel and Siemens PLC for plunge and traverse grinding, input for retraction, infeed values, feed rates, spark-out times, idle strokes, compatible with traditional Karstens infeed control, with colour Siemens touch panel. Scale in X and Z axis by HEIDENHAIN. Comparable with Weiss / EMAG / GP cylindrical grinders / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat / Bahmüller / Fortuna.

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 1000 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Technical Data: Centre distance: 1100 mm Centre height: 180 mm / (250 mm optional) Dkodpfxeh Rimmj Adgji Workpiece weight: 100 kg between centres, 300 kg with support Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MT 4, infinitely variable speed from 30-450 rpm, swivel range 0 - 90° Tailstock: MT4, quill stroke 45 mm Quill force: 200-600 N manual, (up to 2500 N adjustable = optional) Table swivel: 10 degrees Infeed spindle travel: 80 mm Rapid traverse: 50 mm Coarse adjustment with air cushion: 280 mm External grinding spindle motor: 4 kW / (5.5 kW = option) Infinitely variable speed adjustment of grinding wheel via potentiometer Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 1.1 kW Hydraulic motor: 1.5 kW Lubrication motor: 0.1 kW Hydraulic tank: 80 litres Net machine weight: 3800 kg Infeed drive via DC motor Air cushion-supported rapid adjustable grinding spindle stock for fast and safe positioning to grinding location. Separate drive for spindles for external and internal grinding. Fully automatic operating sequence, infeed movement via rotary dial switch: Rapid approach, rapid return, grinding operation, infeed stop, mym-infeed. Automatic longitudinal grinding cycle Central coolant supply for all grinding zones Workpiece headstock with infinitely variable drive for both live and lockable spindle operation. New digital infeed control with Siemens panel and Siemens PLC for longitudinal grinding and plunge grinding, inputs for retraction, infeed amounts, feed rates, spark-out times, dwell strokes; compatible with the old Karstens infeed control; with colour Siemens touch panel. Similar to Weiss/ EMAG/ GP cylindrical grinders/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat/ Bahmüller / Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 1000 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Technical specifications: Centre distance: 1100 mm Centre height: 180 mm (250 mm optional) Workpiece weight: 100 kg between centres (unsupported), 300 kg between centres Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MT 4, infinitely variable speed control 30–450 rpm, swivelling range 0–90° Tailstock: MT4, quill stroke 45 mm Quill force: 200–600 N manually, (up to 2500 N adjustable, option) Table swivel: 10° Cross slide travel: 80 mm Rapid traverse: 50 mm Coarse adjustment (air cushion): 280 mm External grinding spindle motor: 4 kW (5.5 kW optional) Infinitely variable grinding wheel speed adjustment via potentiometer Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 1.1 kW Hydraulic motor: 1.5 kW Lubrication motor: 0.1 kW Hydraulic tank: 80 litres Net machine weight: 3,800 kg Infeed drive via DC motor Air cushion-supported rapid adjustment of the grinding spindle head for fast and safe positioning to the grinding position. Dksdoiv Au Eepfx Adgsi Separate drive for the spindles for external and internal grinding. Fully automatic operation, infeed movements controlled via rotary selector switch: rapid advance, rapid return, grinding mode, infeed stop, micrometre infeed. Automatic longitudinal grinding cycle Central coolant supply to all grinding points Workpiece headstock with infinitely variable drive for rotating and lockable spindle. New digital infeed control with Siemens panel and Siemens PLC for traverse and plunge grinding; input for retraction, infeed amounts, feed rates, spark-out times, idle strokes; compatible with the original Karstens infeed control; with coloured Siemens touchscreen; HEIDENHAIN scales in X and Z axes. Comparable to Weiss/EMAG/GP cylindrical grinding machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat /Bahmüller/Fortuna

Condition: refurbished (used), Year of construction: 2026, Karstens K11 650 The cylindrical grinding machine has been completely overhauled by PS-Karstens. The machine has been tested and is in very good condition. As specialists in Karstens cylindrical grinding machines, we can provide you with complete service (electrical and mechanical) for the machine after purchase. Technical Data: Centre distance: 650 mm Centre height: 180 mm Workpiece weight: 100 kg (between centers), 250 kg (supported) Grinding wheel diameter: 400 mm Dkedpfjh Rixxsx Adgji Workpiece spindle: Morse taper 4, infinitely variable speed 30–450 rpm, swiveling range 0–90° Tailstock: MT4, quill stroke 45 mm, micrometer adjustment Quill force: 200–600 N, hydraulically operated via foot pedal Table swiveling: 10 degrees Feed spindle adjustment range: 80 mm Rapid traverse: 50 mm Rough adjustment with air cushion: 280 mm External grinding spindle motor: 4 kW Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 0.55 kW Machine weight: net 3,800 kg Feed drive by DC motor Air-cushion-assisted rapid adjustment of the grinding spindle stock for fast and precise positioning of the grinding position. Separate drives for external and internal grinding spindles. Fully automatic operating sequence, feed movement controlled via cam switch: Rapid approach, rapid return, grinding mode, feed stop, micron feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding positions Workpiece spindle head with infinitely variable drive for live and locked spindle operation. Feed control for both plunge and traverse grinding, input for retraction, feed amount, feed rates, dwell times, and idle strokes Paper band filter system approx. 250 L Comparable to Weiss/EMAG/GP cylindrical grinding machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat /Bahmüller/Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Centre height: 181 mm Centre distance: 1000 mm Maximum grindable workpiece diameter: 360 mm Max load cantilevered: 1000 N (100 kg) Max load between centres: 3000 N (300 kg) Z-axis: Table swivel angle: 10° Table drive, hydraulic: 0–4 m/min X-axis: Cross slide travel: 80 mm Rapid traverse (hydraulic): 50 mm Coarse adjustment – air cushion: 280 mm Infeed drive by DC motor Rapid infeed speed: 48 mm/min/Ø Infeed cycle: Plunge grinding / Longitudinal grinding 4 preselectable speeds: mm/min/Ø: 0.01–48 4 preselectable infeed increments: mm: 0.001–0.1 Automatic shut-off during stop-grinding: 0–99 s or 0–99 strokes Stepwise infeed: mm/Ø: 0.001 Grinding headstock universal, swivelling: 0–180° Grinding wheel (OD): D x width x bore: 500 x 100 x 127 mm or 203.2 mm Grinding wheel (face, option) D: 250 x 32 x 76.2 mm Grinding wheel (ID, option) D: 2–250 mm Drive power, external/face: 5.5 (7.5) kW Drive power, internal: 2.2 kW Peripheral speed, external: 35 (50) m/s Dkjdpjtqf Rzofx Adgji Grinding wheel wear (OD): mm/Ø: 160 Guard width: 100 mm Grinding spindle diameter: 60 mm Internal spindle mounting: 80 (100) mm Workpiece headstock: Infinitely variable drive: MK 4, 1/min: 30–270 / 50–450 Workpiece spindle lockable Spindle mounting: MK 4/24 mm Spindle nose for flange attachment: MK 4, cylindrical Ø63H6 x 6 mm Headstock swivels on rotating part: 0–90° Tailstock: Quill mounting / Quill diameter: MK 4, 750 mm Quill stroke: 45 mm Quill force, N: 100–800 / 250–1400 adjustable Quill operation: manual (foot switch) Quill fine adjustment: ±40 μm Connections: Total machine connected load: 6.5–10 kW Grinding headstock: 5.5 (7.5) kW Workpiece headstock: 0.55 (1.1) kW Coolant filtration: 0.75–2.2 kW Lubrication pump – guideways: 0.1 kW Hydraulic pump: 1.5 kW Hydraulic tank: 80 l Pneumatics: 6 bar Comparable to: Weiss / EMAG / GP cylindrical grinders / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat
