Krauss Maffei 160-750 (2019) + Robot, Medical clean

KraussMaffei 160-750

Condition: excellent (used), Year of construction: 2007, operating hours: 25,215 h, functionality: fully functional, clamping force: 1,600 kN, screw diameter: 45 mm, clearance between the columns: 520 mm, displacement volume: 318 cm³, ejector force: 22,000 N, ejector stroke: 150 mm, plate length: 845 mm, plate width: 820 mm, installation height: 2,100 mm, total length: 5,100 mm, total width: 1,600 mm, total height: 2,100 mm, overall weight: 6,600 kg, type of input current: three-phase, input frequency: 50 Hz, input voltage: 400 V, clear span: 950 mm, Equipment: documentation/manual, warehouse no.: 503472 manufacturer: KRAUSS MAFFEI Hedpfxjxhg Eme Afpofn type: KM 160-750 CX controller: MC5 year of construction: 2007 operation hours: 25215 h clamping force: 1600 kN distance between tie-bars h x v: 520 x 520 mm size of mould plates h x v: 820 x 845 mm min. mould height: 300 mm max. open daylight: 950 mm opening stroke: 650 mm screw diameter: 45 mm swept volume: 318 ccm injection pressure: 2336 bar equipment included screen text german screen text english CEE-socket 16A core pulling hydraulically 2x machine incl. belt conveyor machine incl. Handling machine incl. safety fencing machine with material hopper Anti vibration mounts interface EUROMAP 67 wear-resistant injection unit mould heating 6x measures of machine l x w x h: 5.1m x 1.6m x 2.1m total weight: 6600KG technical data robot-system handling type: Linear manufacture: Krauss Maffei controller: LRX S100-1321 year of construction: 2008 X axis: 550 mm Y axis: 1200 mm Z axis: 2500 mm total weight: 280 kg

Condition: used, Year of construction: 2008, clamping force: 160 kN, displacement volume: 251 cm³, injection pressure: 2,500 bar, overall weight: 8,200 kg, load hours: 37,200 h, screw conveyor diameter: 40 mm, terms of delivery: FCA Pegnitz delivery time: on request terms of payment: 100% prior to delivery Hfedpfx Aowd Udlefpen

Condition: new, Year of construction: 2025, Injection Moulding Machine – Krauss Maffei KM 160-750 CX Year of manufacture: 2025 Fully hydraulic clamping system. MC 6 control system based on an industrial computer with real-time Ethernet technology, equipped with an integrated 21.5" operator panel with colour touchscreen display. Plasticising Unit Complete plasticising unit for thermoplastics, screw diameter 50 mm, with check valve and open nozzle Nozzle radius: 10 mm Nozzle orifice: 4 mm Technical data (standard version) Clamping Unit Clamping force: 1,600 kN Opening force: 86 kN Platen dimensions (H x V): 820 x 845 mm Tie bar spacing (H x V): 520 x 520 mm Opening stroke: 650 mm Minimum mould height: 300 mm Maximum daylight: 950 mm Ejector stroke: 150 mm Ejector force front/rear: 23 / 10 kN Injection Unit Hfodpfxjxdd N Ue Afpsn Screw diameter: 50 mm L/D ratio: 20.2 Injection pressure: 1,892 bar Shot volume: 393 cm³ Shot weight (PS): 357 g Injection speed: 90 mm/s Injection rate (standard): 177 cm³/s Screw speed (standard): 265 rpm Electro-hydraulic System Pump motor power: 22 kW Installed heater power: 15.5 kW Dry cycle time according to Euromap 6: 2.1 s Oil tank capacity: 400 l Linear Robot – Krauss-Maffei LRX 100 Payload < 10 kg (gripper + drives + parts) Part removal on operator-offside Axes: X-axis (from mould): 620 mm, servomotor Y-axis (vertical, with brake): 1,200 mm, servomotor Z-axis (crosswise): 1,500 mm, servomotor Dimensions and Weight Net weight (with control cabinet): 6.10 t Machine dimensions (L x W x H): 4.93 x 1.62 x 2.04 m

Condition: new, Year of construction: 2023, functionality: fully functional, machine/vehicle number: 61036683, clamping force: 1,600 kN, screw diameter: 50 mm, displacement volume: 393 cm³, injection pressure: 1.892 bar, injection weight: 358 g, mold height (min.): 200 mm, ejector force: 33,000 N, ejector stroke: 100 mm, opening stroke: 950 mm, installation height: 500 mm, total length: 5,650 mm, total width: 1,820 mm, total height: 1,950 mm, overall weight: 9,700 kg, heating capacity: 15.5 kW (21.07 HP), drive type: Vollelektrisch, clear span: 570 mm, tool weight: 600,000 g, Injection molding machines direct from the manufacturer! As the manufacturer KraussMaffei, we offer you our tested and flexible stock machines here: The basic injection molding machine, precisionMolding, offers the perfect entry-level solution for all-electric injection molding, enabling you to react quickly and innovatively to market requirements. It combines high performance, simple operation and short delivery times. It can be used in a wide range of applications, e.g. in the packaging industry, the electrical and electronics industry, medical technology and the automotive industry. Your benefits: - Optimized price-performance ratio for a wide range of applications - High energy efficiency thanks to all-electric machine concept - Realization of demanding delivery times thanks to basic machine concept with a wide range of options TECHNICAL DATA: KM 160 / 750 PA G01 (order 38670011) (machine no.: 61036683, new, year of manufacture 2013) CONTROL  MC P1 with 15" TFT color screen with multi-touch functions CLAMPING UNIT  Clamping force kN 1600  Mold opening force, max kN 120  Clear width (h x v) mm 570 x 520  Clamping platen (h x v) mm 770 x 720  Tool installation height min. - max. mm 200 - 500  Opening width mm 950  Mold opening stroke max. mm 450  Ejector drive electric  Ejector stroke mm 100  Ejector force forwards/backwards kN 33 / 33  Ejector speed forwards/backwards mm/s 300 / 300  Max. Mold weight kg 1200 Hfjdpfx Ajugfupofpon SPRING UNIT  Screw diameter / type mm 50 / standard  Effective Ls/D ratio 20.2  Injection pressure bar 1892  Stroke volume cm³ 393  Shot weight at max. stroke for PS g 358  Injection speed mm/s 200  Injection flow rate cm³/s 393  Screw drive/speed 1/min 267  Plasticizing flow (standard screw)4) g/s 36.5  Nozzle contact force kN 42 ELECTRICAL PARAMETERS  Connected load kW 31.2  Installed heat output kW 15.5  Power supply V / Hz 400 / 50 3 phases with neutral conductor WEIGHT AND DIMENSIONS  Net weight with switch cabinet t 9.7  Length x width x height m 5.65 x 1.82 x 1.95 ADDITIONAL EQUIPMENT  Open nozzle  Air valve 1 - compartment (BWAP)  Pneum. Control hot runner valve gate 1 - compartment  Euromap interface handling E18  Automatic central lubrication  Adaptive Process Control (APC)  Injection compression molding circuit  Graphic analysis package  Swivel device Injection unit The machine is located in our factory in Parsdorf and is available at short notice. Further additional options can be offered on request. We look forward to your inquiry.

Year of construction: 2005, condition: ready for operation (used), Flange diameter: 160mm, clamping force: 1600kN, tie bar distance: 520mm/520mm, min. mold diameter: 350mm, min. mold installation height: 300mm, opening stroke: 650mm, platen distance: 950mm, ejector stroke: 150mm. Screw diameter: 45mm, injection pressure: 2336bar, stroke volume: 318cm³, nozzle radius: 15mm, injection volume: 134cm³, injection weight: 289g. Machine dimensions X/Y/Z: approx. 4900mm/1600mm/2200mm, weight: approx. 7400kg, operating hours: approx. 71187h. The machine has an unknown defect. Documentation available. An on-site inspection is possible. Hfsdeuabq Tspfx Afpjn

Condition: new, Year of construction: 2023, functionality: fully functional, machine/vehicle number: 61036940, clamping force: 1,600 kN, screw diameter: 50 mm, displacement volume: 393 cm³, injection pressure: 1.892 bar, injection weight: 358 g, mold height (min.): 200 mm, ejector force: 33,000 N, ejector stroke: 100 mm, opening stroke: 950 mm, installation height: 500 mm, total length: 5,650 mm, total width: 1,820 mm, total height: 1,950 mm, overall weight: 9,700 kg, heating capacity: 15.5 kW (21.07 HP), drive type: Vollelektrisch, clear span: 570 mm, tool weight: 600,000 g, Injection molding machines direct from the manufacturer! As the manufacturer KraussMaffei, we offer you our tested and flexible stock machines here: The basic injection molding machine, precisionMolding, offers the perfect entry-level solution for all-electric injection molding, enabling you to react quickly and innovatively to market requirements. It combines high performance, simple operation and short delivery times. It can be used in a wide range of applications, e.g. in the packaging industry, the electrical and electronics industry, medical technology and the automotive industry. Your benefits: - Optimized price-performance ratio for a wide range of applications - High energy efficiency thanks to all-electric machine concept - Realization of demanding delivery times thanks to basic machine concept with a wide range of options TECHNICAL DATA: KM 160 / 750 PA G01 (order 38670011) Hfedpfx Aeugfw Defpjn (machine no.: 61036683, new, year of manufacture 2013) CONTROL  MC P1 with 15" TFT color screen with multi-touch functions CLAMPING UNIT  Clamping force kN 1600  Mold opening force, max kN 120  Clear width (h x v) mm 570 x 520  Clamping platen (h x v) mm 770 x 720  Tool installation height min. - max. mm 200 - 500  Opening width mm 950  Mold opening stroke max. mm 450  Ejector drive electric  Ejector stroke mm 100  Ejector force forwards/backwards kN 33 / 33  Ejector speed forwards/backwards mm/s 300 / 300  Max. Mold weight kg 1200 SPRING UNIT  Screw diameter / type mm 50 / standard  Effective Ls/D ratio 20.2  Injection pressure bar 1892  Stroke volume cm³ 393  Shot weight at max. stroke for PS g 358  Injection speed mm/s 200  Injection flow rate cm³/s 393  Screw drive/speed 1/min 267  Plasticizing flow (standard screw)4) g/s 36.5  Nozzle contact force kN 42 ELECTRICAL PARAMETERS  Connected load kW 31.2  Installed heat output kW 15.5  Power supply V / Hz 400 / 50 3 phases with neutral conductor WEIGHT AND DIMENSIONS  Net weight with switch cabinet t 9.7  Length x width x height m 5.65 x 1.82 x 1.95 ADDITIONAL EQUIPMENT  Low-wear plasticizing  BluePower fully insulated plasticizing cylinder  Open nozzle  Air valve 1 - fold (BWAP)  Pneum. Control hot runner valve gate 1 - compartment  Electrical interface pneum. Cascade 4-fold  Euromap interface handling E18 + E67  Euromap interface (central computer) E67, E77  Water battery 4 - compartment  Electrical preparation for hydraulic auxiliary unit  Automatic central lubrication  Adaptive Process Control (APC)  Injection compression molding circuit  Graphic analysis package  Swivel device for injection unit The machine is located in our factory in Parsdorf and is available at short notice. Further additional options can be offered on request. We look forward to your inquiry.
