Used 7 Multi-Spindle Lathes for sale (41,146)

Condition: repair required (used), Year of construction: 2001, CNC-controlled wood lathe Processes 3 components simultaneously No controller Control cabinet without computer, the attractiveness of the offer without control should be considered. Nwjdpfsf Ezgqex Ag Dof Control system can be supplied for the customer at an additional cost Technical specification Maximum working length: 1200 mm Maximum square: 100×100 mm 3 components machined simultaneously Programmable template Fagor control Designed for high productivity.

Condition: used, Year of construction: 1989, Technical details: number of spindles: 6 spindle passage: 20 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Gildemeister Type: GS20-6 Yob: 1989 six-spindle automatic lathe 8 main spindles for bars up to D=20mm All cross units are equipped with a tool holder (from Gildemeister or IMG Attachments) All longitudinal units are equipped, either fixed or rotating (without collets) Njdox Hggwopfx Ag Dewf An independent feed is installed at position 1 A gear set for one speed is installed A gear set for one cycle time is installed The scope of delivery regarding the tooling equipment could be different like pictures. Please, contact us for getting more information and pictures on mail(at) or *

Condition: used, Year of construction: 1989, Technical details: number of spindles: 6 spindle passage: 20 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Gildemeister Type: GS20-6 Yob: 1989 six-spindle automatic lathe Nwedpjx Hgkcjfx Ag Dsf 8 main spindles for bars up to D=20mm All cross units are equipped with a tool holder (from Gildemeister or IMG Attachments) All longitudinal units are equipped, either fixed or rotating (without collets) A gear set for one speed is installed A gear set for one cycle time is installed The scope of delivery regarding the tooling equipment could be different like pictures. Please, contact us for getting more information and pictures on mail(at) or *

Condition: used, Year of construction: 1999, Technical details: number of spindles: 6 spindle passage: 20 mm Njdpfx Aex Sx Nhsg Dowf Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: SF20 S Dnt Yob: 1999 Six-spindle automatic lathe with 6 main spindles max. nominal diameter: D=20mm Spindle drum hirth coupled, CNC cross slide in positions 4, CNC cross slide in positions 5, pick up in position 6, sorting chute, 1x independent feed, thread cutting couplings, workpiece belt, Coolant tank with hinged belt chip conveyor Ruez, Oil/steel operation, PLC Siemens S7, Siemens CNC control, Siemens Simodrive 611, The scope of delivery regarding the tooling equipment could be different like pictures. Interface for: IEMCA PRA bar loading magazine (optional: IEMCA PRA40/31/ built in 1997 rear loader) *

Condition: used, Year of construction: 1987, Technical details: Nsdpsmf Aw Aofx Ag Djwf number of spindles: 8

Condition: good (used), Multi-spindle head, drill beam, multi-spindle drill head, articulated multi-spindle head, row drilling machine, dowel drill head, dowel drilling machine, drilling gearbox Njdjb A R Rgjpfx Ag Djwf -Number: max. 7x drill bits -Recording: M8 -right/left: rotating alternately -Drill bit spacing: 32 mm -Drill bit spacing: 15 mm -Dimensions: 190/80/H110 mm -Weight: 8 kg

Condition: good (used), Multi-spindle head, drill beam, multi-spindle drill head, articulated multi-spindle head, row drilling machine, dowel drill head, dowel drilling machine, drilling gearbox -Number: max. 7x drill bits -Recording: M8 -right/left: rotating alternately -Drill bit spacing: 32 mm Nwsdpfx Ageb A R Rrj Def -Number: 2 drill heads available -Price: per piece -Dimensions: 240/70/H80 mm -Weight: 6 kg

Condition: good (used), Multi-spindle head, drill beam, multi-spindle drill head, articulated multi-spindle head, row drilling machine, dowel drill head, dowel drilling machine, drilling gearbox -Number: max. 7x drill bits -Recording: M8 -right/left: rotating alternately -Drill bit spacing: 32 mm -Number: 2 drill heads available Price: per piece -Dimensions: 245/70/H90 mm Nodpfxsb A R R Ie Ag Dswf -Weight: 8 kg

Condition: good (used), Year of construction: 2004, machine/vehicle number: 2420701, CNC multi-spindle automatic lathe, make Index, type MS52C2-1, year 2004, serial no. 160024, - robot cell, - 7 clamping devices, - 3 rigid tool holders simple, - 3 rigid tool holder multiple, - 4 powered tool holders, - Suction Büchel Handlings and assembly robot cell Stäubli Unimation incl. basket translator with basket stack for raw and finished parts, two shuttles on top of each other for supply/removal baskets, Integrated measuring station Commissioning 2021 Connected load 24 kW, control, make Index, type C200-4D (Siemens 840 D basis), Nwedpfslmkucsx Ag Dsf - 2 steering positions, - 6 spindles, - travel X/Y 300 x 500 mm, - bar diameter max. 52 mm, - - spindle speed max. 5000 rpm, -12 tool carriers, coolant system, - Industrial robot, make Stäubli, - programming panel, - extraction device, - settling device, - Accesories

Condition: used, Year of construction: 2016, Article: CNC-controlled multi-spindle automatic lathe Manufacturer: Tornos Type: MultiSwiss 8x26 Yob: 2016 full cross slide configuration, counter spindle, part-pre-drawing device, 2 x driven tools, 3 x Y-axis, Nedpeldk R Refx Ag Djwf 1 rigid backworking, 1 x driven backworking, 2x 80 bar high pressure pumps optional: setting robot, manufacturer HandlingTech. The scope of delivery regarding the tooling equipment could be different like pictures. Please, contact us for getting more informations and pictures on or *

Condition: used, Year of construction: 2019, Article: CNC-controlled multi-spindle automatic lathe Manufacturer: Tornos Type: MultiSwiss 8x26 Yob: 2019 full cross slide configuration, counter spindle, part-pre-drawing device, 2 x driven tools, 1 rigid backworking, 1 x driven backworking, 2x 80 bar high pressure pumps optional: setting robot make HandlingTech. The scope of delivery regarding the tooling equipment could be different like pictures. Please, contact us for getting more informations and pictures on or * Nodpfoldk R Hsx Ag Djwf

Condition: used, Year of construction: 1995, Technical details: number of spindles: 6 Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: SFH130 Yob: 1995 six-spindle automatic lathe 6 main spindles as a chucker automatic lathe control Siemens S7-200 PLC Dnt drive loading and disloading in position 6 additional cooling pump with magnetic spark plug filter Please, contact us for getting more information and pictures on mail(at) or * Nodpfx Agew Hbz As Dswf

Condition: used, Year of construction: 1999, Technical details: number of spindles: 6 Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: SG18 Yob: 1999 six-spindle automatic lathe 6 main spindles as a chucker automatic lathe control Siemens S7-200 PLC loading and disloading in position 6 spindle brake Njdpjw Hb Trofx Ag Djwf Please, contact us for getting more information and pictures on mail(at) or *

Condition: repair required (used), Year of construction: 1989, 6 spindles Thread cutting Nwsdpfxsv R Uqtj Ag Def Cross drilling Thread rolling Milling attachment Many accessories Feed motor (curves) defective! with IEMCA PRA 40/32 P bar loader

Condition: good (used), Multi-spindle lathe (6 spindles) max. bar diameter 16 mm Njdpfx Agep Dux Ts Dewf guide tubes 4,000 mm chip conveyor

Condition: used, Year of construction: 1998, number of spindles 6 spindle passage 27 mm turning length 59 mm hexagon material 24 mm square material 18 mm cross slide travel 36 mm longitudinal slide travel 85 mm spindle turning speed range 366 - 5020 U/min max. torque 95 Nm control INDEX total power requirement 20 kW - 6 cross slides Njdpfx Aevh Naqjg Dswf - 6 longitudinal slides - polygon device - thread cutting device - hydr. tapping device - workpiece removal belt - bar loading magazine PIETRO CUCCHI, model AN-BN Accessories: various tool holders, various collets, chip conveyor, coolant

Year of construction: 2018, operating hours: 7,879 h, condition: reconditioned (used), functionality: fully functional, machine/vehicle number: 8110000014B, A rebuild of the machine took place in 2021: - Change of bar feeder from Chucci to Iemca Next 25-33 - Change of control from Fanuc 30i-B to Fanuc 611 SL IV (Slim Line) - Addition of valve block for hydraulic control of cooling lubricant supply (equipped with 28 controllable valves for high pressure) - an electronic parts shuttle for unloading the workpieces was installed - converted to a tool breakage monitoring system Artis / CTM program TECHNICAL DETAILS bar capacity: 36 mm number of main spindles: 6 number of cross slides X-Y axes: 6 C axes: 6 angular resolution: 0,002 ° Rotational speed: 7500 rpm rapid traverse: 40 m/min spindle positioning: 0,1° Nedpfxomduh Eo Ag Dowf Drive unit tool speed: max. 13800 rpm MACHINE DETAILS working area: 21,9 sqm (with loader) net weight machine: 15 t chip conveyor: included LUBRICANT DETAILS oil tank volume: 1.800 l total oil volume: 2.000 l 6,3 bar: 140 l/min 45 bar: 100 l/min 80 bar: 50 l/min BAR FEEDER DETAILS Model: Iemca Next 42/33 bar length: max. 3300 mm bar length: min. 2400 mm Loading capacity as area loader: 450 mm bar diameter: 4 - 36 mm Guide channels: 6 fixed + 6 movable (with spindle reduction tubes and bushings)

Condition: not inspected (used), Year of construction: 2006, functionality: unexamined, rotational speed (max.): 2,970 rpm, workpiece length (max.): 2,500 mm, workpiece width (max.): 1,000 mm, Equipment: CE marking, TECHNICAL DETAILS Max. panel width: 1,000 mm Max. panel length: 2,500 mm Min. panel length: 250 mm Min. panel width: 100 mm Number of vertical lower groups: 5 Nedpfsyzy T Tex Ag Djwf Number of vertical upper groups: 1 Lateral horizontal groups: yes Number of pressure elements: 5 Number of horizontal lateral groups: 2 Motor power: 1.5 kW Speed: 2,970 rpm MACHINE DETAILS System control: TOPDRILL Machine programming software: WOODWOP Total installed power: 35 kW EQUIPMENT Lateral horizontal groups CNC positioning of the groups CNC positioning of the Z-axis Safety standards with CE marking Safety light barriers Automatic chip extraction The machine is sold and delivered in its actual and legal condition ("as seen and approved") based on photo documentation and technical/commercial reference documents of a descriptive nature. The buyer has the right to inspect the goods before collection and assumes responsibility for installation, securing, and operation of the machine at the destination. External reference: 6157

Condition: used, Year of construction: 2017, Mfd. 2017 Configuration: 2-Synchron (Dual Counter-Spindle) Production Hours: 20,000 Overview Well-equipped and maintained INDEX Werke MS22-6 configured for high-precision production, including medical components. This machine features a robust Siemens control platform, dual counter-spindles, and extensive automation for efficient, lights-out capable operation. Control & Technology • Siemens 840D SL CNC control • Dual NCU (Numerical Control Units) • TRANSMIT / TRACYL functions • ARTIS tool monitoring system • 2 additional electronic shaft preparations Configuration & Equipment • 6 main spindles • 2 SCARA counter-spindles • 2 parts catchers with conveyor belt • Bar scrap recuperator • INDEX bar guide system • IEMCA PRA bar loader • Bar feeder interface • Fire protection system Capacity & Performance • Max. bar diameter: 22 mm • Spindle speed: 10,000 rpm • Spindle power: 8.7 / 15 kW • Torque: 10 / 18 Nm Njdpfx Agsy Abc Es Dewf Axes & Travels • Total slides: 10 • Main slides travel (X/Z): 62 / 85 mm • Counter-operation slides: 2 • Counter slide travel (X): 62 mm Additional Specifications • Number of counter-spindles: 2 • Counter-spindle speed: 10,000 rpm • Machine dimensions (L x W x H): 3330 x 1830 x 2860 mm • Weight: 5,700 kg • Connected load: 75 kVA Applications • High-precision medical components • Complex turned parts requiring multi-operation efficiency • Ideal for high-volume production environments

Condition: used, Year of construction: 1980, Wickman 1" SN: 17069 Mfd. 1980 6 Spindles 1" Capacity Motor and Controls Stock Stand and Reel Chip Conveyor Nwjdpfxjyzkfyo Ag Dof Universal Threading Configured as pictured Recently Reconditioned

Condition: excellent (used), Year of construction: 2024, Mfd. 2024 Chip Blaster High Pressure pump 8 Port Programmable High Pressure Manifold 1000 PSI 12 Port Coolant Manifold with Shut Off Valves Parts Catcher Sub Spindle & Back Working Attachment Spindle Drive Motor: 5.00 Nm (Nominal Torque) Max. Speed: 5000 RPM Feed Motors (X & Z): 2.1 Nm3000 RPM (X Has Break) Travel Z: 7.874″ Stroke Rapid Feed Rate: (Z) : 1000 IPM Travel X: 4.375″ Stroke Rapid Feed Rate (X): 200 IPM Cross Slides Motors: 2.1 Nm, 3000 RPM ( 4th X Motor Has Break) 1st Travel: 2.625″ Stroke 2nd Travel: 2.000″ Stroke 3rd Travel: 7.400″ Stroke Njdpfsyzkbhex Ag Djwf 4th Travel X: 1.750″ Stroke 4th Travel Z: 4.062″ Stroke Rapid Speed: 200 IPM Specs to be verified by purchaser

Condition: good (used), Year of construction: 1980, Davenport Model B 3/4" Mfd. in 1980s Pickoff / Back Finish Threading Stock Reel and Stand Chip Conveyor Noise Tamer Sound Enclosure Refurbished and Ready to Run Several similar machines available Nwedpfx Agoh I Euae Def

Condition: good (used), Year of construction: 2016, machine/vehicle number: 30339, Wickman 6-57 CNC Multi-Spindle Screw Machine SN: 30339 Mfd. 2016 Siemens CNC control Motors and controls Stock stand and stock reel with enclosure (2) 2-Axis CNC Slides in Pos. 4 and 5 Nwedouzlltepfx Ag Def Single Axis CNC Turret Single Axis CNC Auxiliary slides pos. 4th + 5th Turbo Chip Conveyor Machine configured as follows Pos. 1: Mechanical cross slide, Turret open Pos. 2: Mechanical cross slide, Turret open Pos. 3: Mechanical cross slide, Turret open Pos. 4: 2-Axis CNC Slide, Auxiliary single Axis Pos. 5: 2-Axis CNC Slide, Auxiliary single Axis Pos. 6: Mechanical cross slide, programable pick-up turret is single axis CNC With (6) Collet tubes Sold as-is where-is condition from current location. Buyer is responsible for shipping and rigging.

Condition: good (used), Year of construction: 2006, INDEX MS52C CNC Multi-Spindle Mfd. 2006 Control: Siemens 840D 6 Spindles 52mm Capacity Equipped as pictured Under power Knoll System Chip Conveyor Riedel Chiller 3.6 meter (12ft) IEMCA SIR Bar Feed SIR MS52/F Nwjdpfxst Rkzws Ag Def Type 38 XL Mfd. 2005

Condition: used, Year of construction: 2024, INDEX MS22-8 Mfd. 2024 2 NCU (4) Y-Axis SL Control Cutting hours: 1,000 Turnkey Available Located in Europe 4-Meter IEMCA SIR MS22-8/43/P Rack loader 50 Hz D9-13-19-25 Bar length 4300 mm with drilling unit and minimum quantity lubrication unit additional end-of-bar sensor Bar stock 500mm (D12-D24) Bar stock 340 mm (D5-D11). Additional storage chain for 22 bars with Profinet interface. 1 11007253 (21711) 1 set (8 pieces) bar stock pushers, external clamping for bar stock diameters D7-D10 mm, internal clamping for bar stock diameters D13-D18 mm, consisting of: 8 bar stock pushers D12 8 rotating sleeves D12 1 10287026 Nwodpfsxnrtcsx Ag Dsf (21712) 1 set (8 pieces) bar stock pushers, external clamping for bar stock diameters D11-D16 mm, internal clamping for bar stock diameters D19-D24 mm, consisting of: 8 bar stock pushers D18 8 rotating sleeves D18 1 10536056 (21713) 1 set (8 pieces) bar stock pushers for bar diameters D17 mm-D22 mm, consisting of: 8 bar stock pushers D23 8 rotating sleeves D23 1 10414481 (21702) 1 set (8 pcs.) of internal clamping sleeves D12mm for bar diameters D13 mm - D18 mm Drill diameter D8 mm. 1 10472413 (21704) 1 set (8 pcs.) of external stops D12 mm for bar diameters D13 mm - D18 mm pre-machined. 1 10264327 (21703) 1 set (8 pcs.) of internal clamping sleeves D18mm for bar diameters D19 mm - D24 mm Drill diameter D15mm. 1 10058206 (21705) 1 set (8 pcs.) of external stops D18 mm for bar diameter D19 mm - D24 mm pre-machined. 1 12123486 Drill for drilling unit consisting of: 1 indexable insert drill D 15 mm 10 indexable inserts for steel 2 solid carbide drills D 8 mm
