Used Biesse Stream A for sale (68,171)

Condition: excellent (used), FULL LINE of Double-side Sizing-Milling & Edge Banding, max working width mm 3000, with automatic handling. Composed of the following machines: X03001A) Double Loader "RBO" Mod. Winner C 3200 with central motorised roller conveyor X03001B) 1st Double-side Sizing & Edge Banding "BIESSE" Mod. Stream SB 1 - 7.5 X03001C) Turning station (90°) lengthwise to crosswise "RBO" Mod. GPK 1 Nsdpfxji Rbg Ts Aiqswk X03001D) 2nd Double-side Sizing & Edge Banding "BIESSE" Mod. Stream SB 2 - 11 X03001E) Turning station (90°) crosswise to lengthwise "RBO" Mod. GPK 2 X03001F) Double Stacker "RBO" Mod. Winner S 3200 with central motorised roller conveyor

Condition: excellent (used), FULL LINE of 4 Side Sizing-Milling & Edge Banding (also SOFTFORMING), through-feed drilling and splitting of panels. Complete with fast automatic handling. Composed of the following machines: Nwjdpfxottgy Ho Aiqjk A) Loader (Bridge-Frame) "RBO (BIESSE)" Mod. Winner C (1) B) 1st Double-side Sizing & Edge Bander "BIESSE" Mod. Stream SB1 11.0 Softforming C) 1st 90° Turning device (Lengthwise to Crosswise) "RBO (BIESSE)" Mod. GPK-1 D) 2nd Double-side Sizing & Edge Bander "BIESSE" Mod. Stream SB 2 9.5 E) 2nd 90° Turning device "RBO (BIESSE)" Mod. GPK-2 (straight or Crosswise to Lengthwise) F) Multi-Borer with CN "BIESSE" Mod. Techno FDT CN (with 2 horizontal working units, 6 vertical bottom working units and 3 vertical top working units) G) Multi-Borer with CN "BIESSE" Mod. Techno FDT CN (with 2 horizontal working units, 6 vertical bottom working units and 3 vertical top working units) H) 3rd 90° Turning device "RBO (BIESSE)" Mod. GPK-3 (straight or Crosswise to Lengthwise) I) Splitting Saw (Splitter) Lengthwise "GM (for BIESSE)" Mod. Split 4-84 LT L) Stacker (Bridge-Frame) "RBO (BIESSE)" Mod. Winner SC (2)

Condition: excellent (used), Universal DOUBLE-SIDE SIZING & EDGE BANDING MACHINE (for both 1st and 2nd pass) Edges (tape) thickness in rolls (min/max) mm 0,3 - 3 Panels thickness (min/max) mm 10 - 60 Working width (min/max) mm 240 - 2700 Numerical Control /Software SINITRA Adjustable feeding speed (m/min ) 10 - 40 Distance (center-axes) of the Disappearing Dogs (mm) 500 SIZING PART (for each side): Anti-chipping Milling Unit AS 10 (1 x Kw 5,2 ca.) N°2 Hogging Units (1 Top + 1 Bottom) DT 10 (2 x Kw 5,8 ca.)+ Spraying unit (Anti-sticking liquid) EDGE-BANDING PART (for each side): Glueing Unit (Hot Melt + Quick Melt Unit) SP30 (High Melt + Edge control EC40) Band Pressure zone (N.C. adjustment) . Edge coils supporting unit (No. 6 reels) Snipping (end-cutting) unit IT 90-S (2 x Kw 0,3 ca.) 28 m/min (0° - 25°) Rough Trimming unit RS 10 (2 x Kw 0,75) Fine Trimming unit (Multi-profile, by N.C.) RF 30 (2 x Kw 0,37) 0°-25° Multi Function Unit (Profile contour Trimming unit) AR 30 (Kw 0,35 x 2) LEFT: 2 x Milling grooving units FB 32 (2 x Kw 5 ca.) 0° - 90° RIGHT: Milling grooving unit FB 30 (1 x Kw 5 ca.) 0° - 90° Profile Scraping unit RB 10 Glue scraping unit RC 10 + Spraying Unit (for polishing liquid) Nwodpfeywk Eljx Aiqsk Buffing unit SZ 30 (2 x Kw 0,37) + Hot Air Heater (to reactivate the color of plastic tape) PH 10 OPTION: D.O.M. Unloader with load-bearing column and mobile arm (with vacuum suction cups), for unloading and stacking edged panels

Condition: excellent (used), Year of construction: 2015, machine/vehicle number: 1000004052, functionality: fully functional, Equipment: type plate available, For sale edgebanding machine Biesse Stream B1 8.5 with return table Edgebanding machine in continuous use - edgebanding in PUR and AIR FORCE technology feed rate 1-25 mb/min wrapping methods - AIR FORCE - PUR - EVA maximum height of the elements being glued - 40 mm maximum width of the elements on the return table - 1300 mm line composition - 2 milling heads height 44mm - EVA / PUR overlay unit - AIR FORCE - drills - pre-profile cutters - rounders - groove saw - profile cyclers - flat cyclines - polishers magazine for 12 rolls of edge banding in case of questions please contact us. Nwodpfxou Suh Ss Aiqek

Condition: ready for operation (used), Year of construction: 2008, machine/vehicle number: 77503, functionality: fully functional, workpiece height (max.): 60 mm, feed rate X-axis: 25 m/min, overall weight: 6,510 kg, controller manufacturer: SINTRA, TECHNICAL DETAILS Panel height: 60 mm Solid wood: 20 mm PVC / ABS: 3 mm Max. feed speed: 25 m/min MACHINE DETAILS Control: Sintra Weight: 6,510 kg EQUIPMENT - Sanding unit - Coil holder magazine with 2 positions and automatic edge change via CNC - Adhesive unit for EVA hot-melt glue with preheating device and glue pot - Preparation for adhesive unit for PUR glue - Pressure group for straight profiles with electronically adjustable pressure rollers via CNC Nwjdpeydidrefx Aiqsk - End trimming unit with 2 motors and automatic tilt adjustment - Filler unit with 2 vertically aligned motors - Edge smoothing unit with 2 swivelling motors - Multifunctional 4-motor corner rounding unit (smoother + corner rounder) with numerical control in automatic adaptation - Anti-stick unit - Adjustable edge scraper unit - Glue-saving unit - Oscillating brush unit - Electronically adjustable working height - Motorized rubber belt with increased pressure - Motorized and electronically adjustable panel guide - Side roller conveyor with idler rollers for panel support

Condition: used, Double edgebanding machine BIESSE STREAM SB2 10.5 usable as 1st and 2nd machine in a edgebanding line Nodpfx Aiju Rim Hjqjwk Numerical Control with Sintra Software Machine suitable for 1st + 2nd pass of the panel Opening of the mobile shoulder motorized by C.N. mm 3000 Panel height 60 mm Pvc/Abs mm 3 Continuously variable feed speed from C.N. (up to 40 m/min) Working height electronically adjustable by C.N. (up to 60 mm) Opening of the moving shoulder electronically adjustable by C.N. Motorized rubber belt with higher pressure Track with bearings with hidden pins - distance between PINS mm 500 Automatic system for supporting large panels Anti-adhesive group Part to be squared composed of (for each side): * Automatic timed anti-splinter group * Double shredder group * Two-motor grinding group Border part composed of (for each side): * Gluing unit for EVA hot melt glue with pre-melter * Edge pressure group on straight profiles with electronically adjustable pressure rollers by C.N. * 6-position reel magazine with automatic edge change by C.N. * End trimming unit with 2 motors with automatic inclination * Overlapping trimming group with 2 motors * Edge trimming group with 2 tilting motors electronically adjustable by C.N. * Multifunction rounding unit with 4 motors (cornering tool + rounding tool) with numerical control adjustment automatically * Toupie Group (with 2 motors on the fixed left side \ with 1 0-90° tilting motor on the mobile right side) * Electronically controlled edge scraper group by C.N. * Glue scraper group * Oscillating brush group * Phon group

Condition: used, Numerical Control with NC 410 Software Machine suitable for 1st pass of the panel Motorized mobile shoulder opening by C.N. 1500mm Panel height 60 mm PVC/Abs mm 3 Continuously variable feed speed Working height adjustable electronically by C.N. Motorized rubberized belt with superior pressure Squaring part composed of (for each side): * Double shredder group * Automatic timed anti-splinter unit Beading part composed of (for each side): * Gluing group for EVA hot melt glue with pre-melter * Edge pressure group on straight profiles with adjustable pressure rollers Njdpfx Aierxzb Uoqewk * 2-position reel magazine with automatic edge change * Overlapping trimming group with 2 motors * Gleaning unit with 2 tilting motors * Moulder group tiltable 0-90 ° * Edge scraper assembly * Glue scraper unit * Belt sander assembly * Brush group

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, workpiece height (max.): 60 mm, workpiece width (max.): 1,300 mm, workpiece length (max.): 3,200 mm, edge thickness (max.): 3 mm, Equipment: CE marking, TECHNICAL DETAILS Max. feed speed: 24 m/min Maximum panel thickness: 60 mm Minimum panel height: 10 mm Maximum panel height: 60 mm Minimum panel length: 320 mm Maximum panel length: 3,200 mm Minimum panel width: 150 mm Maximum panel width: 1,300 mm Minimum edge thickness: 0.3 mm Maximum edge thickness: 3 mm Number of working units: 8 UNITS Trimming Unit 1 Function: Sizing Model: RT30 Motor Power: 3.5 kW Max. speed: 9,000 rpm Edge Processing Unit 1 Function: End Trimming Model: IT90-S Number of motors: 2 Max. processing speed: 28 m/min Motor power: 0.65 kW Max. speed: 12,000 rpm Edge Processing Unit 2 Function: Edge Milling Model: RF10 Number of motors: 2 Motor power: 1 kW Max. speed: 12,000 rpm Edge Processing Unit 3 Function: Multifunction Model: AR30 Number of motors: 2 Max. processing speed: 18 m/min Motor power: 0.65 kW Max. speed: 12,000 rpm Edge Processing Unit 4 Function: Profile Scraper Model: RB40 Edge Processing Unit 5 Function: Glue Scraper Model: RC20 Edge Processing Unit 6 Function: Brushing Model: SZ30 Number of motors: 2 Motor power: 0.37 kW Max. speed: 1,400 rpm MACHINE DETAILS Installed total power: 25 kW Dimensions Nodpfx Aexw T Tpsiqjwk Conveyor length: 12,300 mm Width: 1,300 mm Length: 12,300 mm EQUIPMENT Jointing cutters Multifunction unit Top pressure Pressure via rubberised belts Panel support guide NC positioning Angled panel infeed system Automatic engagement by time Edge preheating lamps Coil magazine Hot-melt glue pot Hot-melt glue pre-fuser Edge pressure roller conveyor Spray unit SINTRA machine programming software Panel discharge via roller transfer conveyor Panel feed via motorised carpet belt Return system for left-side edge bander CE marking

Condition: ready for operation (used), Year of construction: 2011, machine/vehicle number: 36956, functionality: fully functional, workpiece height (max.): 60 mm, edge thickness (max.): 3 mm, total length: 9,800 mm, overall weight: 600 kg, plate height: 1,060 mm, TECHNICAL DETAILS Workpiece height: 60 mm Edge thickness: up to 3 mm Nwjdpex A Tzqofx Aiqjk Minimum panel width: 55 mm Minimum panel length: 100 mm Panel height: 1,060 mm Tool interface: ISO 30 MACHINE DETAILS Dimensions & weight Total length: 9,800 mm Weight: 600 kg Input frequency: 50 Hz EQUIPMENT Return system Operates with PUR adhesive Spray system Pre-milling unit RT 20 Gluing unit SP 20 6-position edge magazine End trimming unit IT 90-S Rough milling unit RS 10 Fine trimming unit RF 40 Note: Further information regarding equipment can be found on the attached machine data sheet.

Condition: used, machine/vehicle number: 008562, X axis working area: 2465 mm Y axis working area: 1260 mm Working Table: Flat table Main Electrospindle power: 13.2 KW Number of controlled axes: 3 axes Nedpfx Aiezvwiljqewk Total number of drilling spindles: 10 Total number of tool changer positions: 16

Condition: used, machine/vehicle number: 008564, X axis working area: 2465 mm Y axis working area: 1260 mm Working Table: Flat table Main Electrospindle power: 13.2 KW Number of controlled axes: 3 axes Total number of drilling spindles: 10 Nwodpfxezvwh Is Aiqek Total number of tool changer positions: 16

Condition: used, Year of construction: 2018, total height: 2,200 mm, total length: 5,350 mm, total width: 1,200 mm, Colour: White Weight: 3.500 kg Price: On request - Year: 2018 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 1000022855 - Number of units [pcs]: 8 - └ 1st unit type: - - Tools available: Yes - └ 3rd unit type: - - Tools available: Yes - └ 4th unit type: - - Tools available: Yes Nodpfx Aezw El Roiqjwk - └ 5th unit type: - - Tools available: Yes - └ 6th unit type: - - Tools available: Yes - └ 7th unit type: - - Tools available: Yes - └ 8th unit type: - - Tools available: Yes - Min. edge band thickness [mm]: 0.4 - Max. edge band thickness [mm]: 3 - Edge band height [mm]: 64 - Min. panel thickness [mm]: 10 - Max. panel thickness [mm]: 60 - Min. panel width [mm]: 85 - Max. panel width [mm]: 3200 - Min. panel length [mm]: 140 - Max. panel length [mm]: 3200 - Min. feed speed [m/min]: 12 - Max. feed speed [m/min]: 18 - Max. spindle speed [rpm]: 12000 - Voltage [V]: 400 - Current consumption [A]: 20 - Fuse [A]: 32 - Power [kW]: 11.0 - Transport dimensions: 5350mm x 1200mm x 2200mm (l x w x h) - Transport weight [kg]: 3500kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, machine/vehicle number: 008270, X axis working area: 4320 mm Y axis working area: 1500 mm Working Table: Pod and Rail Main Electrospindle power: 13 KW Number of controlled axes: 5 axes Nedpfezw Dxcjx Aiqewk Total number of drilling spindles: 23 Total number of tool changer positions: 22

Condition: used, Year of construction: 2017, The BIESSE ROVER A 1643 EDGE is a comprehensively equipped CNC machining center with a 5-axis machining head and an integrated edge banding unit. Working area, X-axis: 4,320 mm Swing machining in X: 1,620 mm Working area, Y-axis: approx. 1,580-1,660 mm Travel, Z-axis: 180 mm Edge banding Working area, X-axis: 3,300 mm Working area, Y-axis: 1,540 mm Maximum loading width in Y: 1,900 mm, expandable to up to 2,100 mm 5-axis unit 5-axis machining head C-axis: continuous 360° rotation B-axis: continuous 360° rotation B-axis speed: 18 rpm C-axis speed: 18 rpm Maximum spindle speed: 24,000 rpm Power 11 kW in S1 operation 13 kW in S6 operation Additional features Maximum undercut angle: -10° Collision monitoring for the 5-axis unit Prepared for the use of attachments on the 5-axis unit Work table and clamping system ATS work table 8 support rails 32 adjustable consoles 32 pneumatic vacuum cups Vacuum cups adjustable in 15 steps Pneumatic system divided into 2 working zones along the X-axis Vacuum system Vacuum pump capacity: 250 m³/h Additional equipment 6 lifting bars for easier loading and unloading 28 sensors for detecting lowered stops Stops and positioning 8 rear stops 8 center stops 4 side stops (2 left + 2 right) 2 additional side stops 4 removable center stops (2 left + 2 right) 2 additional center stops Pneumatic positioning and lowering of the stops Drilling unit BH 24L drilling head Nwedpfx Aszuwyzjiqek 13 independent vertical spindles 5 independent horizontal spindles Grooving saw, 120 mm Maximum groove depth: 25 mm Programmable spindle speed up to 6,000 rpm Tool changer 16-position rotary magazine Mounted on the X-axis carriage For tools and attachments Capacities Maximum tool/attachment weight: 7.5 kg Maximum total load of the magazine: 55 kg Edge banding unit GU60A edge banding unit For workpieces up to 60 mm thick Edge banding speed up to 20 m/min Double pressure roller system Glue pot with hot melt system Edge heating lamp, 600 W CNC-controlled edge feeding system Automatic edge trimming Sensor for closed geometric shapes Accessories for edge machining Edge magazine 2-roller edge magazine mounted on the X-axis carriage Maximum roller diameter: 800 mm Maximum edge height: 65 mm Additional units Rounding tool 85 mm, HSK F63 Saw unit HSK F63 for cuts and grooves Maximum saw blade diameter: 215 mm Maximum saw speed: 8,400 rpm Maximum cutting depth with a 215 mm saw blade: 68 mm Post-processing Combined glue joint and edge trimming blade units Tool sets for different edge thicknesses Software bSolid basic module 2D CAD environment Import of DXF, CIX and BPP files 3D machine simulation Tool management Management of 5-axis machining through positioning Assistant-supported program creation

Condition: ready for operation (used), Year of construction: 2014, operating hours: 1,618 h, travel distance Z-axis: 430 mm, number of axes: 5, number of slots in tool magazine: 16, table length: 4,300 mm, table width: 2,205 mm, spindle motor power: 13,000 W, spindle speed (max.): 20,000 rpm, swivel angle B-axis (min.): -99 °, swivel angle B-axis (max.): 100 °, swivel angle C-axis (max.): 360 °, This 5-axis BIESSE Rover A FT 2243 including WINSTORE 3D K1 was manufactured in 2014. It operates on a 400 V power supply. With approximately 1,700 hours of axis movement, this CNC wood machining centre is designed for precision and efficiency. If you are looking to get high-quality wood machining capabilities, consider the BIESSE Rover A FT 2243 machine we have for sale. Contact us for further details. Technical Data • Working Table Dimensions: 4,300 × 2,205 mm • Maximum X-Axis Speed: 80 m/min • Maximum Y-Axis Speed: 60 m/min • Maximum Z-Axis Speed: 20 m/min • Z-Axis Travel (3-/4-Axis Version): 325 mm • Z-Axis Travel (5-Axis Version): 430 mm • Maximum Workpiece Clearance in Z: 170 mm • Maximum Workpiece Clearance with Sweeping Arm: 120 mm • X-/Y-Axis Drive: Rack and Pinion • Z-Axis Drive: Ball Screw • Axis Guides: Linear Guides with Recirculating Ball Bearing Blocks • Vacuum Pump Capacity: 300 m³/h at 50 Hz • Vacuum System: 20 Independent CNC-Controlled Zones • Working Fields: 2 • Clamping Areas: 2 in X • Pneumatic Stops: 16 • Grid Table Pitch: 30 mm • Vacuum Module Dimensions: 132 × 146 mm • Vacuum Module Height: 29 mm • Vacuum Module Rotation Increment: 15° • Air Cushion Table Blower: Yes • Maximum Single Panel Thickness: 50 mm • Minimum Single Panel Thickness: 9 mm • Maximum Multiple-Panel Loading Thickness: 20 mm • Maximum Multiple-Panel Unloading Thickness: 60 mm • Protective Board Thickness: 8–25 mm • Maximum Panel Weight: 200 kg • Minimum Loadable Panel Size in Y: 800 mm • Unloading Conveyor Length: 4,800 mm • Maximum Unloadable Panel Length: 4,300 mm 5-Axis Machining Unit • Number of Axes: 5 Interpolating Axes • Tool Interface: HSK F63 • Cooling: Liquid-Cooled • Power S1: 11 kW / 15 HP at 12,000 rpm • Power S6: 13 kW / 17.4 HP at 12,000 rpm • Maximum Spindle Speed: 20,000 rpm • C-Axis Rotation: 360° Continuous • C-Axis Speed: 12.4 rpm • B-Axis Positioning Range: ±100° • B-Axis Speed: 12.4 rpm • Spindle Bearings: Ceramic • Drive Motor: Brushless, Digitally Controlled • Gearbox: Harmonic Reduction Gear • Lubrication: Lifetime Lubrication Drilling Head • Type: BH 26 2L • Maximum Number of Tools: 26 • Vertical Drilling Spindles: 16 • Vertical Spindle Arrangement: 8 in X / 8 in Y • Vertical Spindle Pitch: 32 mm • Horizontal Drilling Spindles: 4 with Double Output • Horizontal Spindle Axis Distance: 32 mm • Grooving Saws: 2 • Grooving Saw Directions: X / Y • Grooving Saw Diameter: 120 mm • Maximum Grooving Depth: 25 mm • Motor Power: 1.7 kW at 2,800 rpm / 3 kW at 6,000 rpm • Maximum Drilling Speed: 6,000 rpm Tool Magazine • Type: Turret Tool Magazine • Capacity: 16 Tools • Tool Position Spacing: 114 mm • Maximum Tool Diameter with Full Magazine: 110 mm • Maximum Individual Tool Weight: 7.5 kg • Maximum Total Tool Weight: 55 kg Automatic Loading / Unloading • Loading Direction: Front • Material Flow: Right to Left • Loading / Unloading System: Type B • Suction Cups: 5 Nwodpfx Aiszuygqjqok • Automatic Loading Capacity: Up to 3 Panels • Sweeping Arm: Yes • Automatic Table Cleaning: Yes • Loading Table: Automatic X/Y Alignment • Unloading Conveyor: Motorized • Conveyor Control: CNC-Controlled • Conveyor End Detection: Photocell WINSTORE 3D • System: WINSTORE 3D K1 • System Length: 16,000 mm • Beam Length: 8,000 mm • Additional Modules: 3,000 / 6,000 / 8,000 mm • Maximum Suction Frame Length: 5,200 mm • Cross Conveyors: Belt Type, 5,200 mm • Panel Handling: Raw and Thin Panels • Panel Weight Detection: Load Cell

Condition: good (used), Year of construction: 2015, functionality: fully functional, TS07 Control System · 7” LCD Touch Screen graphical display Edge trimming unit RT02, 1 set of diameter trimming cutters, H=65 mm for edge trimming unit RT02 Gluing unit SP03 End trimming unit IT03 Fine trimming unit RF02 Njdpfx Aiozuavlsqjwk Edge rounding unit AR02 Edge scraper RB02 Glue scraper unit RC02 Cleaning unit LPT02 Anti-adhesive unit ADZ02 AX-1, NC axis on the stop AX-1, motorized, controlled pressure beam AX-1, NC axis for pressure rollers for the gluing unit AX-4, NC axis for the fine trimming unit AX-2 NC axis on the edge rounding unit AR02 AX-4 NC axis on the edge scraper RB02

Condition: used, Technical specifications: - X = 3,060 mm - Y = 1,320 mm - Z = 150 mm - Central automatic lubrication system - 6 ATS workpiece supports - 18 bearing consoles Nwsdpszutqvofx Aiqok - Vacuum system with division into 2 working areas in the X-direction - Pneumatic system for console adjustment - 2 independent working areas in the X-direction - 4 workpiece supports - 12 clamping devices for clamping narrow workpieces - Conveyor belt for removing chips and cutting waste - Vacuum pump, 90 m³/h - 12 kW electric spindle with ISO 30 tool holder, air-cooled - The machine is additionally equipped with an integrated rotary unit that is integrated into the machine control system and functions as a 5th axis for drilling operations at different angles. - Tool changer with 10 tool positions - Manual laser barcode scanner Drilling unit BH 21L - 7 + 7 vertical drilling spindles - 6 horizontal drilling spindles (4 in the X-direction, 2 in the Y-direction) - 1 grooving unit (saw blade) in the X-direction

Condition: ready for operation (used), Year of construction: 2016, overall weight: 1,870 kg, Edgebander manufactured in 2016. This BIESSE Akron 1440 A features a pre-milling unit, multifunction milling units, flat trimming, and a corner rounding unit. It also includes automatic glue application, motorized adjustment of units, and a touchscreen control for ease of use. It comes with the complete panel return system. If you are looking to get high-quality edgebanding capabilities, consider the BIESSE Akron 1440 A machine we have for sale. Contact us for further details. Technical Data: • Model: BIESSE Akron 1440 A • Year: 2016 • Working hours: approx. 4,200 h • Power: 13 kW • Power supply: 380 V, 50 Hz, 3 / N / PE • Full-load current: 24 A • Air pressure requirement: 7 bar • Weight: approx. 1,870 kgWorking Capacity: • Feed speed: 8 / 12 / 15 / 18 m/min • Workpiece thickness: 10–60 mm • Edge thickness: coil 0.4–3 mm, strip up to 12 mm Nodpszug Smofx Aiqswk • Edge height: 14–64 mm • Minimum panel length: 140 mm • Minimum panel width: 50 mmInstalled Units / Equipment: • Automatic glue application unit • Pre-milling unit • Multifunction milling units R1 + R2 • Flat trimming unit • Corner rounding unit (Rondomat) • Radius profile scrapers • Flat scrapers • Polishing brushes • Cleaning liquid application unit • Motorized adjustment of units • Touchscreen control • IntelliSet system • FAST setting technology • ECO modeAdditional Information:The transport chain / output conveyor for finished panels is included with the machine.Availability:The machine is currently in daily production and can be inspected under power. Inspection and testing are possible by prior appointment.Available for collection from the beginning of September 2026.

Condition: ready for operation (used), Year of construction: 2020, travel distance X-axis: 3,765 mm, travel distance Y-axis: 1,560 mm, travel distance Z-axis: 378 mm, number of axes: 3, spindle motor power: 13,200 W, spindle speed (max.): 24,000 rpm, This 5-axis BIESSE Rover PLAST A FT 1536 was manufactured in 2020, featuring a robust electro-welded base and high-precision movement systems. It boasts a main electrospindle power of 13.2 kW, a programmable rotation speed up to 24,000 RPM, and an 8-position revolver tool magazine. Ideal for intricate woodworking, it includes a 21.5" LCD monitor and Industry 4.0 integration. Consider the opportunity to buy this BIESSE Rover PLAST A FT 1536 CNC Wood Machining Centre. Contact us for more information. • Maximum piece clearance: 170 mm • Axis speeds: X 85 m/min, Y 60 m/min, Z 20 m/min • Base: Electro-welded closed-circuit structure with high-thickness steel plates • Axis drives: X with two independent brushless motors and helical rack & pinion; Z with preloaded ballscrew, ISO5 precision • Work table: Phenolic laminate with 30 mm grid vacuum system; vacuum steps every 150 mm; M8 threaded inserts for templates/fixtures • Main electrospindle: 13.2 kW (17.7 HP), HSK F63, air-cooled, 1,000–24,000 rpm • Tool magazine: 8-position revolver on Y-carriage; max tool diameter 110 mm; max tool weight 7.5 kg (32 kg total magazine) • Tool measurement: Digital presetter for tool length measurement up to 130 mm diameter • Control system: BH660 PC-based with Windows Real Time (WRT); CPU Intel Core i5 or better; 8 GB RAM; 128 GB SSD or better; 21.5" LCD monitor • Power supply: 380/400/415 V, 50/60 Hz • Automatic lubrication system for moving parts • Software: bSolid 3D CAD-CAM for design, simulation, and process management • Connectivity: Industry 4.0 integration via TCP/IP and OPC-UA Additional equipment • Vacuum pump: 250 m³/h, dry-running • Air conditioner for the electrical cabinet • Safety guarding: 2 m high protection nets and front vertical photocells Njdpfxszug N Se Aiqewk

Condition: ready for operation (used), Year of construction: 2021, total width: 5,851 mm, travel distance X-axis: 3,140 mm, travel distance Y-axis: 1,260 mm, travel distance Z-axis: 245 mm, overall weight: 3,000 kg, controller manufacturer: BIESSE, controller model: HH660 PC-based control, spindle motor power: 13,200 W, product length (max.): 7,116 mm, spindle speed (max.): 24,000 rpm, number of axes: 4, This 4-axis BIESSE Rover A 1232 was manufactured in 2021. It features a working area of 3140 mm in the X-axis, 1260 mm in the Y-axis, and a Z-axis travel of 245 mm. The machine is equipped with an electrospindle power of 13.2 kW and a maximum tool diameter of 113 mm. If you are looking to get high-quality CNC routing capabilities, consider the BIESSE Rover A 1232 machine we have for sale. Contact us for further details. • Power supply voltage 400 VAC • Full load current 31.7 A • Number of power supply phases 3 • Installed power 18.66 kW • Frequency 50 Hz • Short circuit protection rating 10 kA RMS Sym • Working area X 3140 mm • Working area Y 1260 mm • Working area Z 245 mm • Max panel thickness: depends on vacuum module height (H74 / H29) and tooling • Workpiece support length 1200 mm Nsdpfxezugwps Aiqjwk • Vacuum pump capacity 90 m³/h • Vacuum pump capacity 108 m³/h at 60 Hz • Vacuum system dry pump • Electrospindle power 13.2 kW • Electrospindle speed 12000 to 15000 rpm S1 • Electrospindle speed 12000 to 24000 rpm programmable • Tool holder HSK F63 • Rotation clockwise and counterclockwise • Two separate magazines installed: • 8-position tool magazine (rear / Y-axis area) • 13-position tool magazine (main X-axis unit) • Maximum tool diameter 113 mm • Maximum tool length 110 mm • Maximum tool weight 7.5 kg • Maximum total magazine weight 32 kg • Vacuum system:Configurable vacuum pump system. Available configurations include:– 2 × 90 m³/h– 2 × 100 m³/h– 1 × 250 m³/h

Condition: used, machine/vehicle number: 008560, X axis working area: 3140 mm Y axis working area: 1260 mm Working Table: Pod and Rail Nwedpfxszvwtqj Aiqok Main Electrospindle power: 13.2 KW Number of controlled axes: 3 axes Number of controlled axes: 3 axes Total number of drilling spindles: 16 Total number of tool changer positions: 13

Condition: used, machine/vehicle number: 008694, X axis working area: 4320 mm Y axis working area: 1287 mm Working Table: Pod and Rail Main Electrospindle power: 11 KW Nwjdpfx Aozqz Nxeiqsk Number of controlled axes: 5 axes Total number of drilling spindles: 16 Total number of tool changer positions: 31

Condition: used, Year of construction: 2008, input voltage: 400 V, input frequency: 50 Hz, number of slots in tool magazine: 8, Equipment: CE marking, Biesse Rover ROVER A 3.40 FT K2 CNC machining centre Nodpfx Ajzqdqljiqewk Description Working fields: X = 3685 mm; Y = 1290 mm; Z = 160 mm The composition includes: Automatic lubrication system FT Work Table 4 front stops + 4 back stops equipped with pneumatic system and sensors. 4 side stops equipped with pneumatic system and sensors. Vacuum tank Vacuum system for 2 300 m3/h pumps 300 m3/h rotary claw vacuum pump 12 kW (16.1 HP) Electrospindle with ISO 30 adaptor, air cooled Blowing unit Flange for the assembly of aggregates on the electrospindle Prearrangement for operating device with 360° interpolation and gear transmission. Boring head BH 21 L Revolving tool changer with 18 places Prearrangement for the assembly of the automatic unloading device for nested-based machined panels Controls on remote keyboard Numerical Control XP600 User-friendly interface BIESSEWORKS - Advanced programming system BIESSE NEST Module Air conditioner for electric cabinet Inverter Safety devices with 2 mats and low fencing CE (Despite our great care all changes, mistakes in technical data, prices and all information is subject to (typing) errors. No guarantee on printed data! Availability subject to prior sales). (Trotz größter Sorgfalt bleiben Änderungen, Irrtümer bei technischen Daten, Preisen und allen Angaben (Tipp-)Fehler vorbehalten. Keine Gewähr auf gedruckte Daten! Verfügbarkeit vorbehaltlich Zwischenverkauf). Prices excl. advertisement cost MachineSeeker / Preise exkl. Inserierungskosten MaschinenSucher Best woodworkingmachines from the Netherlands Holland Die besten holzbearbeitungsmaschinen aus die Niederlande De beste gebruikte machines uit Nederland

Condition: used, Biesse Akron 1440 A - Manual setting - 2017. £16750 + VAT (Ex-Works). Manual setting edgebander with multi profile cutters for thin tape and 2mm tape. Can also apply 8mm Lippings. PLC Control unit. EVA Glue, Pre-Melting unit. Nedpozm U Rnefx Aiqswk Pressure zone. End Trimming Saws. Top & Bottom Profile trimming. 2 x Motor Corner Rounding. Profile scraping. Glue line scraper Buffing. Machine still powered and comes with extraction manifold.

Condition: used, machine/vehicle number: 008272, Position 1: 5 Axis CNC Routers BIESSE + KUKA-ROVER A + KR210 R3100 Nsdpfxsx A Tfvj Aiqswk Position 2: Robot BIESSE + KUKA-ROVER A + KR210 R3100
