Used Deep Hole Drilling Machine Imsa Mf 1200 for sale (69,772)

Condition: like new (used), The machine is completely overhauled and therefore as good as new! Technical specifications Drilling method : single-lip drilling Number of spindles 1 Drilling range in steel D= 1-6 mm Drilling depth 420 mm Max. workpiece length 420 mm Manufacturer: TBT / SFT Lredpfx Aksfgwlbjyen New electrics and new controls!

Condition: excellent (used), Year of construction: 2008, The deep hole drilling machine is in very good condition! Deep hole drilling machine type TBM 120-2000 Drilling system BTA Min. drilling diameter D 35 mm Max. solid drilling D 130 mm Max. counterboring D 170 mm Main spindle block with two-stage gearbox -Drive Ax AC motor 37 kW with brake for spindle locking 1200-1500 rpm -Drill spindle block with two-stage gearbox 50-500 rpm, 450-1200 rpm, electrically switchable. Optional rotating / stationary tool. Main spindle box (tailstock) with two-stage gear electr. switchable Tailstock with counter-rotation Optionally with or without counter-rotation Hydraulic jaw chuck. Main and drill spindle speed continuously adjustable Machine bed as welded construction Guideways in linear roller design size 65 -Drill carriage movement via ball screw, Lrodpfjq A S Ekex Akyjn gear and servo motor 3 kW Rapid traverse max. 3000 mm/min Maximum feed rate: 1000 mm/in. Hydraulically attachable drill bushing holder 2 x attachable steady rests 2 x roller pre-centering devices D20-100 mm 2 x Boza drilling range D 8-200 mm with chip chute and suction pump Scraper conveyor -1-axis CNC control PS 100 SFT for controlling and monitoring the drilling cycle Torque monitoring of the drilling spindle and feed rate in % painting: blue/gray, RAL 5015/7035

Condition: like new (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 106882-11, total length: 4,400 mm, total width: 1,700 mm, total height: 2,700 mm, overall weight: 7,000 kg, The drilling process of the deep hole drilling machine utilizes the single-lip drilling method. Lrodpfxowh Rp Ee Akysn Drilling Unit Information: - Drilling depth: 200 mm - Min./max. drilling diameter: 1–12 mm based on ST 60 - Number of spindles: 2 - Spindle distance: 200 mm - Spindle drive: 2 x 2.4/4.2 kW - Infinitely variable spindle speed: 1,000–20,000 rpm - Infinitely variable feed rate: 10–25,000 mm/min - Rapid traverse: 25,000 mm/min - Slide travel (nominal): 650 mm - Slide width: 460 mm - X-axis slide travel: 200 mm, rapid traverse: 25,000 mm/min - Y-axis slide travel: 200 mm, rapid traverse: 25,000 mm/min Fluid Information: - Coolant supply: deep hole drilling oil - Tank capacity: 500 liters - 1x automatic filter, filter performance: 50 l/min - 1x monitoring filter - 2x ELB drilling oil supply lines - 1x flow divider - 1x air cooler with recirculation pump - 1x electrostatic oil mist extraction unit - 1x scraper belt chip conveyor - 1x hydraulic unit and pneumatic unit/equipment - 1x sump pump - 3x submersible pumps - 1x radial piston pump with remote adjustment: Delivery rate: 1–38 l/min Pump drive: 7.5 kW Spindle Unit: - Motorized spindles with frequency-controlled, infinitely variable speed regulation - Spindle head with connection for tool holder - 2 x tool holders for collet sleeves according to VDI 3208 SE10x60, permanently bolted to the spindle head of the motorized spindle Drill Bushing Carrier: - The drill bushing carrier is positionable via the NC axis - Cast iron design, mounted on linear guideways - W-axis drive via AC servomotor and ball screw with indirect, absolute position measurement system Workpiece Slide: - The workpiece slide is designed as a cross-slide for vertical and horizontal positioning of the workpiece, for mounting clamping plates or special fixtures - Base unit in cast iron design with linear roller guideways - X and Y axes driven by AC servomotors and ball screws - Direct, absolute position measurement systems. Table plate with clamping or alignment grooves Clamping Table with NC rotary indexing device for positioning: - With rotary and swivel axes - Hydraulic clamping in rotary and swivel axes Technical Data: - Swivel range: 270º - Rotary range: 360º - Center height: 25 ± 0.02 - Spindle distance: 200 ± 0.005 - Indexing accuracy: rotary axis ± 15" / swivel axis ± 30" Electrical Equipment Information: - 1x drilling process monitoring - 1x CNC control 840D (Solution Line) Connection Data: - Operating voltage: 3AC 400V ± 10% - Frequency: 50 Hz - Control voltage: 24 V DC - Total rated power: 25 kW Additional Machine Equipment: - 2 x holders for resilient drill bushing holders, arranged on the drill bushing carrier - For max. drilling Ø18 mm.

Condition: ready for operation (used), -Drill diameter: 5~25 mm -Drilling depth: 1000 mm Ljdpfx Asdgpltskyern -Tailstock -Tank -Pump -Filter

Condition: good (used), Year of construction: 1979, TBT T30-4-750/1000 -Drill diameter ~30 -Drilling depth 750 / Extension ~1000 -Tank Lredsd Ri H Espfx Akyjn -Pumps -Loading device -Tailstock

Condition: reconditioned (used), -Drill diameter: 5~25 mm -Drilling depth: 1500 mm Lsdpfshuil Rjx Akysrn -Tailstock -Tank -Pump -Filter

Condition: good (used), - Drilling diameter: 5-30 mm - Drilling depth: 750~900 mm - Modifications according to customer requirements Lodpfe Dcz Dex Akyorn

Condition: refurbished (used), Year of construction: 2000, functionality: fully functional, drilling depth: 600 mm, rotational speed (max.): 6,000 rpm, center height: 250 mm, controller model: SIEMENS Sinumerik 840 D, workpiece diameter (max.): 25 mm, No reserve price – guaranteed sale to the highest bidder! The machine has been completely overhauled! TECHNICAL DETAILS Working depth: 600 mm Working diameter: 4 – 25 mm Number of spindles: 2 Centre height: 250 mm Centre distance: 203.2 mm Speed range: 1,000 – 6,000 rpm Feed rate: 0 – 300 mm/min Rapid traverse: 6,000 mm/min MACHINE DETAILS Lrjdpfxsxpvbto Akyen Control system: SIEMENS Sinumerik 840 D (Retrofit) Drilling system: Single-lip deep hole drilling Main drive: 2 x 5.5 kW EQUIPMENT - Single functions for machine setup - Semi-automatic operation for manual loading - Robust spindle carriage - Machine monitoring with spindle speed display - Table plate in special cast design - Safety guard with sliding door - Machine bed with hardened and ground linear guides - Internal coolant supply through drilling spindle - Electrical equipment according to IEC standards - Separate control cabinet with safety devices - Control panel in working area

Condition: used, Year of construction: 1974, operating hours: 10,000 h, functionality: fully functional, machine/vehicle number: 8002/6410, drilling depth: 1,000 mm, drill diameter: 30 mm, type of input current: three-phase, spindle motor power: 21 W, table length: 1,000 mm, input voltage: 550 V, mount diameter: 160 mm, number of spindles: 1, drilling capacity: 1,000 mm, quill diameter: 30 mm, Equipment: rotational speed infinitely variable, Deep hole drilling machine for up to 1000 mm and 30 mm diameter, used for drilling aluminium, regularly serviced, includes a significant quantity of drills. Machine is fully operational and in continuous use. Siemens control, Simatic PANEL, documentation available. Ledpfxjx Ehg Te Akyjrn

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Lodertrx Rjpfx Akyorn Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Condition: excellent (used), The machine was used to connect the cooling channels in the carbide cutting tool. Lredszfy Txepfx Akyen

Condition: used, Year of construction: 2024, Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard configuration, equipped with: - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release sequence, including electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic drilling depth extension for end-face drilling. This saves the need to adjust the drilling depth when switching from flat-face to end-face drilling (+10 mm, e.g., with dowel length 35 mm, flat-face drilling depth 14 mm, end-face drilling depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill bit changeover. - Easy pivoting of the drilling unit from 0° to 90°, assisted by gas cylinders. - 1 clamping beam movable on Y-axis with 3 pneumatic clamping cylinders, for workpieces up to max. 80 mm height. Ideal fence system consisting of: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops. - Quick-change system, easily switchable from right to left stop for mirrored drilling of shelves in carcass construction; also suitable for line boring in system 32. - Side stops and position adjustments, as well as drilling height position, via mechanical digital counters on the support table. - Side stops can be easily folded away for fastest set-up change from carcass to frame or line drilling. - Clamping arms for the clamping beam enable line boring positions up to max. 300 mm. - Optimized three-stage tool system. Includes 1 set of dowel drill bits: - 5 carbide dowel bits, Ø 8x77 mm, right - 4 carbide dowel bits, Ø 8x77 mm, left Basic machine Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard version, equipped with: - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release, electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic extension of drilling depth for end drilling saves the need to adjust depth when switching from flat to end drilling (+10 mm, e.g. for dowel length 35 mm, flat-side depth 14 mm and end-side depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill changeover. - Easy pivoting of the drilling unit from 0° to 90°, gas spring assisted. - 1 clamping beam, Y-axis adjustable, with 3 pneumatic clamps for workpieces up to max. 80 mm high. - Ideal stop system comprising: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops, quick-change system, easily switched from right to left for mirrored shelf drilling in carcass constructions, also usable for line boring in system 32. - Side stops and adjustable positions, as well as drill height position, via mechanical digital counters on the support table. - Side stops can be folded away easily for shortest retool time from carcass to frame and line boring operations. - Clamping arms for the clamp beam suitable for line-boring positions up to max. 300 mm. - Three-stage optimized tool system. Lredpjxnlflofx Akyjn Extraction funnel, dust tested, Ø 120 mm 1 set for line boring in system.

Condition: excellent (used), Year of construction: 2019, drilling depth: 3,000 mm, total length: 11,500 mm, total width: 4,300 mm, total height: 2,350 mm, rotational speed (max.): 1,800 rpm, spindle motor power: 44,000 W, Deep hole drilling machine Tacchi - FT 350 x 3000 MACH-ID 9650 Make: Tacchi Type: FT 350 x 3000 Control: SIEMENS 840D Year: 2019 High precision accuarcy ( two step proces) 1e step  cutting using skiving knives 2 step cold-form rollers for highest surface toleraces For Superfinishing Hydraulic and Pneumatic Cylinders / Rods ECOROL Boring heads in diameter: 40/50/63/80/90/100 mm Maximum out side diameter 250 mm Swing over bed 700 Center height 350 mm Lsdozdq Ecspfx Akyern Drilling carriage Rapid feed rate both directions 6000 mm/Min Max. Drilling thrust 35000 N Feeder carriage Rapid movement 5000 mm/Min Thrust against workpiece 35.000 N Hydraulic approach stroke 150 mm Max. drill Ø steel:200mm Spindle bore: 85mm Drilling depth: 3000mm Power on spindle: 44kW Speeds / ranges: 1800Rpm Length: 11500mm Width: 4300mm Height: 2350mm Weight: 14450kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: like new (used), Year of construction: 2012, AGIECHARMILLES drilling EDM machine, model DRILL 20, manufactured in 2012. Travel: X 300, Y 200, Z 300. Maximum drilling depth: 200 mm. Ljdpjzd D Rrjfx Akyorn Table: 400 x 300 mm. CNC unit with 12" TFT touchscreen. Sequences drilling points until the electrode is used up. Maximum workpiece weight: 300 kg. 30A generator. Electrode diameter: 0.1 - 3.0 mm. Dielectric pump pressure: 70 bars. Dielectric tank capacity: 16 liters.

Condition: excellent (used), 10 x Deep-hole drill bits, manufacturer Botek 3 pieces, 6.5 x 320 mm 2 pieces, 10.2 x 190 mm Ledpfxehl Awdo Akyorn 3 pieces, 10.4 x 250 mm 1 piece, 11 x 350 mm 1 piece, 11 x 270 mm Weight: 1.5 kg

Condition: good (used), Tools , drills will come without tool cabinet. Ljdpfezd D N Ijx Akysrn Last picture, only come tolls without tool holders from up side of tool trolley. Tool trolley not come

Condition: excellent (used), functionality: fully functional, Deep Hole Drilling Unit / Deep Hole Drill Manufacturer: POREBA Type: Deep Hole Drilling Attachment / Drilling Rig Condition: Used, good technical condition Technical Data Feed stroke: up to 900 mm Weight: approx. 780 kg Electrically driven feed system Heavy-duty industrial construction Integrated control panel Complete unit with drive motors Description Offered for sale is a robust deep hole drilling unit manufactured by POREBA. The attachment is suitable for installation on large conventional lathes or special-purpose machine tools and features an electrically driven feed system with a travel of up to 900 mm. Its rigid construction provides excellent stability and precision during deep hole drilling operations. The unit is supplied complete with drive motors, control panel, and mounting components visible in the photographs. Advantages ✔ Heavy-duty industrial design ✔ Feed travel up to 900 mm ✔ High rigidity and stability ✔ Electrically driven feed system ✔ Suitable for deep hole drilling applications ✔ Proven POREBA engineering Ljdpfxezcvuuj Akyjrn Transport Approximate weight: 780 kg Loading assistance available

Condition: used, Year of construction: 2000, Number of spindles in row: 11 Number of horizontal spindles: 3 Cup hinge boring head: yes, Blum Lodjxc Hi Ujpfx Akyorn Drill pitch: 32mm Power consumption: 2.2kW Drilling unit: swiveling

Condition: used, Year of construction: 2017, Number of drilling spindles: 21 units Pitch: 32 mm Drill chuck: Clamping surface, drill shank: 10 mm Operation: Foot pedal Tools: Yes, in mm Drilling direction: from below and from the front Lsdpfxeihghrs Akysrn Swiveling: Manually Swiveling angle: only 0° or 90° Max. pass-through height: 80 mm Max. pass-through width: 750 mm Number of material clamps: 3 units Type of material clamping: pneumatic Design: Stationary Stop system: only for this series Weight approx.: 400 kg Motor power: 1.5 kW Dust extraction diameter: 120 mm Location: Customer

Condition: like new (used), Year of construction: 2025, GANNOMAT "JUNIOR 323" FRAME DOWEL AND SLOT MORTISING MACHINE Complete in standard configuration as per price list 01/22/D with: - Precision collet chuck for ER 40 collets Ø 3–26 mm, including collets Ø 10 / 13 / 16 / 20 - Motor 1.5 kW, 2800 rpm Lrodjxdttiopfx Akyon - Positioning via digital counter - Pneumatic 2-level positioning adjustment (0–100 mm) - Max. drilling depth: 150 mm - Precision indexing rail with 12 mm pitch, featuring: - Center detent and lateral adjustment 320 mm - 2 pneumatic safety clamping cylinders - Complete fence system consisting of: • 1 center stop and 1 stop for oversized frames • 1 round stop bar approx. 850 mm long (can be mirrored from left to right) • 2 flip stops - Tiltable slot mortising device with 2 program cams (400V, 3Ph, 50Hz, 1.5kW) - Extraction hood Ø 80 mm, dust-tested - Central mitre stop 45° - Pair of auxiliary workpiece supports, pivotable (left and right) - Drill head holder - 3-spindle drilling head, 32 mm pitch (can be rotated 90°) - Chassis with 4 wheels for easy machine movement Availability: Short-term – immediately –

Condition: used, Year of construction: 2014, complete in standard configuration with: - Fully automatic electronic control with foot pedal for clamping-drilling-unclamping, electric jog operation, - Automatic return of the drilling unit after reaching the preset drilling depth - Automatic extension of drilling depth when end-grain drilling saves the need to adjust drilling depth from flat to end-grain drilling. (+10 mm, e.g. with dowel length 35 mm, drilling depth flat side 14 mm, drilling depth end-grain 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drill feed 0-70 mm) incl. 21 quick-change chucks (Ganner system) for easy bit changes. - Simple swiveling of the drilling unit from 0° to 90°, supported by gas cylinder. - 1 clamping beam, movable in Y-axis with 3 pneumatic clamping cylinders, for workpiece height up to max. 80 mm. - Ideal stop system consisting of: - 1 stop fence 1800 mm for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops, with quick-change system, easily swappable from right to left for mirror-image shelf drilling in carcass constructions, also suitable for line boring in System 32. - Side stops and position settings, as well as drilling height position via support table using mechanical digital counters. - Side stops can be easily swiveled away, for the quickest changeover from carcass to frame and line boring. - Clamping arms for clamping beam designed for line boring positions up to max. 300 mm. - Ideal three-stage... Weight: approx. 400 kg gross, approx. 350 kg net. Dimensions (L x W x H): 1.35 m x 1.25 m x 1.40 m Equipment: 1 extraction hood, dust tested, ø 120 mm. 1 set for line boring in System 32 complete with: 1 base fence 1050 mm (aluminum profile 40x40 mm), 1 setting gauge for line boring. 1 frame dowel device complete with: 1 center stop, 1 round stop rod 850 mm long, 2 stops. Location: Nattheim. Lrsdpfx Asyyxkhskyen

Condition: used, Year of construction: 2009, functionality: fully functional, travel distance X-axis: 200 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 300 mm, workpiece weight (max.): 200 kg, table width: 300 mm, overall weight: 800 kg, table length: 400 mm, empty load weight: 800 kg, drilling depth: 250 mm, feed length Y-axis: 300 mm, feed length Z-axis: 250 mm, feed rate X-axis: 200 m/min, Electrode diameter: between 0.3 mm and 3.0 mm. Drilling depth and speed: The maximum drilling depth can reach 300 mm, and the drilling speed ranges between 30-60 mm/minute, depending on the material quality. Ledpezcwz Ajfx Akysrn Fully functional, with a digital Mitutoyo measuring system. Ready for immediate use.

Condition: used, Hole rows + fitting drilling machine LAUTENSCHLÄGER Meplamat 300 pneumatic hold-down device, Lrsdpfxovtm Aye Akyen pressing device, stop rulers

Condition: used, Working width 720 mm Lrjdpfxjlfcn Ee Akyon hollow max. 820 mm bore depth horizontal 120 mm boring depth: vertikal 45 mm

Condition: used, Year of construction: 1981, machine/vehicle number: 800 02 81 46, type of input current: three-phase, Specialized EDM drill (eroding machine / hole starter EDM machine) Lrsdpfxey Su Iyo Akyjn This machine is primarily used in metalworking as a hole starting EDM machine or for spark eroding the removal of broken tools (such as taps, drills, or reamers) from valuable workpieces. This is done with extreme precision without damaging the surrounding thread or material.
