Used Miotal® Precision Surface Grinding Machine for sale (68,253)

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 1761-1700, 457 x 152mm capacity. Equipped with magnetic chuck, power rise and fall to wheel head, table guard, coolant system, and dust extraction. Iasdpsnxi Uuefx Ahzow SPECIFICATION Jones & Shipman Model 540P Working Surface of table 457 x 152mm Longitudinal traverse of table, hand and hydraulic 483mm Total cross traverse of table, hand and hydraulic 168mm Floor to table height 1035mm Table traverse speed range per min 1.5 – 18m Cross feed range per stroke at each reversal 0.178 – 1.78mm Micrometer cross feed graduated in Vertical feed adjustment in increments of 0.002mm Vertical movement of wheelhead (max) 280mm Wheel spindle center to table (min) 50mm Size of grinding wheel 180 x 13 x 31.75mm bore Speed of wheel 2880rpm Wheelhead motor 1.5kW Hydraulic pump motor 0.55kW Machine in Imperial execution MACHINE EQUIPPED WITH Magnetic chuck Power rise and fall to wheel head Table guard Wheel guard Coolant System Dust extraction

Condition: excellent (used), Year of construction: 1984, functionality: fully functional, machine/vehicle number: BO 94392, A familair machine in any toolroom, this Jones and Shipman 540P is equipped with a 6″ x 18″ magnetic chuck, power rise and fall, coolant system and dust extraction. A toolroom institution: USED Jones & Shipman Model 540P Horizontal Spindle Surface Grinding Machine Specification Working Surface of the table 457 x 152mm Longitudinal traverse of table, hand and hydraulic 483mm Total cross traverse of table, hand and hydraulic 168mm Floor-to-table height 1035mm Table traverse speed range per min 1.5 – 18m Cross-feed range per stroke at each reversal 0.178 – 1.78mm Micrometer cross feed graduated in Vertical feed adjustment in increments of 0.002mm Vertical movement of wheelhead (max) 280mm Wheel spindle centre to table (min) 50mm Size of grinding wheel 180 x 13 x 31.75mm bore Speed of wheel 3000rpm Iaodpfx Ajnxi R Ushzsw Wheelhead motor 1.5kW Hydraulic pump motor 0.55kW Machine in Imperial execution Machine equipped with Magnetic chuck Power rise and fall to wheel head Table guard Wheel guard Coolant System Dust extraction Lighting

Condition: used, grinding length: 1,850 mm, grinding width: 830 mm, grinding height: 700 mm, table length: 1,700 mm, table width: 500 mm, CNC ECS 2400 GRINDING LENGTH: 1850 MM GRINDING WIDTH: 830 MM GRINDING HEIGHT: 700 MM TOTAL STROKE: 2000 MM TRANSVERSAL STROKE: 750 MM MOTOR POWER: 14.7 KW GRINDING WHEEL SPEED: 1450 RPM ELECTROMAGNETIC TABLE 500 X 1700 MM COOLING TANK WITH PAPER FILTER WHEEL DIMENSIONS: 450 X 76 X 127 MM Iaodpfezl Dnmex Ahzsw OVERALL DIMENSIONS: 6100 X 3240 X 3000 MM WEIGHT: 14,500 KG

Condition: used, functionality: fully functional, table dimensions: 830mm x 200mm magnet dimensions: 600mm x 200mm grinding wheel dimensions: 250mm stroke x:720mm y:250mm z:320mm automatic feeds on x and y axes z-axis height electrically adjustable Ijdpfjzi Hkfex Ahzoaw height:1600mm x length:1800mm x depth 1500mm weight: 1700kg Financial information VAT/margin: Margin: The displayed price includes VAT (VAT not deductible for businesses)

Condition: excellent (used), Year of construction: 1988, functionality: fully functional, Jung JF 520 D year of manufacture 1988 magnet 500 x 175 mm max. grinding area 600 x 220 mm Iedjzba Ngopfx Ahzjaw variable speed variable magnetic field strength automatic start diaform coolant/filter tank 3 x flange 1 x clamp documentation machine is powered on for inspection

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, grinding length: 1,000 mm, grinding width: 600 mm, Perfect PFG60100AHR surface grinder year of manufacture: 2005 magnetic table: 1000 x 600 mm max. grinding area: 1000 x 600 mm variable magnetic force automatic feed coolant/filter tank 5 grinding wheels and various grinding stones Iajdpfxozbrpfo Ahzjw documentation machine is powered on for inspection

Condition: good (used), functionality: fully functional, Jung F40 Iajdpszbbklsfx Ahzjw sinusoidal magnet, 300 x 150 mm cooling water tank 9x grinding disc documentation the machine is powered on for inspection.

Condition: used, Year of construction: 1960, x-travel 500 mm breite 450 mm Iaodpfxozkbqio Ahzsw serial number 386 weight of the machine ca. 1,8 t

Condition: used, Year of construction: 1986, Surface Grinding Machine MONOPRECIS 1DR - #2 Travel X: 400 mm Travel Y: 150 mm Maxi grinding height (Z): 220 mm Year of construction: 1986 Axes X - Y - Z manual Iasdozk D D Eepfx Ahzow Magnetic chuck: manual / tilted Magnetic chuck dimensions: 255 x 130 mm Grinding wheel dimensions: Ø max 170 mm Voltage: 380 V Dimensions (L x W x H): 1300 x 1100 x 1600 mm Weight: approx 500 kg

Condition: ready for operation (used), Year of construction: 2011, DELTA LC 500 – Circular table grinding machine - CE marking - Year of manufacture 2011 - Magnetic table – Rotary table 500 mm - Max. grinding diameter 500 mm - Distance column – grinding spindle axis 315 mm - Grinding height max. magnetic clamping plate – grinding wheel 215 mm - Grinding spindle speed 2840 rpm - Fine adjustment via micrometer 0.01 mm - Coarse adjustment (height adjustment) motorized via keyboard - Spindle motor 3 kW - Dimensions of the grinding wheel 200x80x78 mm - Machine enclosure - Coolant system - Documentation Iaodpezkvz Njfx Ahzjw Dimensions: L x W x H 1.3 x 0.8 x 1.8 meters / Weight 800 kg Errors and omissions excepted.

Condition: used, Year of construction: 2000, functionality: unexamined, grinding width: 600 mm, workpiece weight (max.): 650 kg, The Brand AS 6030 is a robust and precise surface grinding machine, ideal for use in tool and mold making, as well as in single-piece and series production. With a grinding area of 600 × 300 mm and a table load capacity of up to 650 kg, it is suitable for heavy workpieces and demanding grinding tasks. Control: Chevalier control system with a numerical display and axis control, suitable for automated grinding cycles and manual interventions. The massive cast iron body, precise guides, and stable spindle technology ensure excellent surface quality and dimensional accuracy. Year of manufacture 2000, well-maintained condition, immediately ready for use. Documentation available. Model AS 6030 Manufacturer Brand Werkzeugmaschinenfabrik AG Year of manufacture 2000 Grinding area 600 x 300 mm Table load capacity max. 650 kg Control Chevalier Grinding wheel Approx. Ø 300-350 mm Spindle drive Approx. 3.6 kW Guides Precision guides / linear guides Dressing system manual or CNC-controlled Coolant system available Iaodpfxszkua Ro Ahzsw Weight Approx. 2,200 kg Condition used, well-maintained, fully functional

Condition: used, Year of construction: 1985, grinding length 600 mm grinding width 200 mm total power requirement 7,5 kW weight of the machine ca. 2,3 t Iaedpfx Ahowd Tx Ujzow

Condition: excellent (used), Year of construction: 1978, grinding length 500 mm Iedpfx Ahszbczrszeaw grinding width 200 mm

Condition: used, Year of construction: 2000, grinding length 1600 mm grinding width 600 mm workpiece height 500 mm total power requirement 50 kW Isdjt Hxcbjpfx Ahzoaw

Condition: used, Year of construction: 1998, grinding length 2000 mm grinding width 600 mm total power requirement 17 kW Iaodpfx Aev S Ip Ejhzow weight of the machine ca. 10 t

Condition: excellent (used), Year of construction: 2015, grinding length 500 mm grinding width 250 mm Iajdpfx Ahexy S Dxszsw

Condition: excellent (used), Year of construction: 1965, grinding length 600 mm grinding width 250 mm Isdexy S D Eopfx Ahzjaw

Condition: used, Year of construction: 2013, grinding length 800 mm grinding width 400 mm workpiece height 375 mm Control Siemens 840 D total power requirement 18 kW weight of the machine ca. 2,6 t Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : GEIBEL & HOTZ CNC horizontal surface & profile grinding machine model FS 840 KT CNC year 2013 Serial no 38040513 _____ Grinding length max. (table movement 850mm) 800 mm Grinding width max. (cross movement 400mm) 450 mm Mounting height under new grinding wheel 375 mm Distance table – center of spindle min / max 140 – 525 mm Standard size of magnetic plate 800 x 400 mm Max. table load 700 kg Table speed 5 – 35.000 mm/min Cross-/Vertical quick feed 5 – 4.000 mm/min Grinding wheel measurements 300 x 50 x 76,2 mm (350 x 100 x 76,2) Cutting spped max. 45 m/s Grinding spindle-drive approx. 9 kW Total electrical load approx. 18 kW - 400 V - 50 cycles Weight approx. 2.600 kg Accessories / Special Features: • Machine is equipped with a simple to use but freely programmable SIEMENS CNC control model 840 D SolutionLine with additional GEIBEL&HOTZ grinding software. User friendly interface, supported by dialog and graphics, simple programming, also of complex grinding wheel profiling and easy connecting of all the usual grinding cycles. • electronic handwheel for 3 axis. • Table movement is actuated by ball screw drive (KT), which allows both very high and very low table speeds and is also ideal for profile grinding. • Cross feed (Z) and infeed (Y) effected by ball screw drive with incremental glass scale. • Diamond dressing device mounted on the left side of the table (also for profile dressing); additional driven diamond roller dressing device (table-mountable) with automatic dressing cycle, including compensation. • HOFMANN balancing device EasyBalancer EB3100 (with installed rpm & vibration sensor) • Unfortunately currently only a small magnet 110 x 200 mm available. • Separate band filter coolant filtration unit • Complete enclosure of the working area with electronically safeguarded sliding doors, separate switch cabinet, lamp for working area, various accessories, manuals, etc. Ijdpfx Aswd Tx Ijhzeaw Condition : very good, universal machine for all sorts of grinding tasks ! Please click here to view a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We always have a large selection of surface grinders – CNC or conventional - available. Please let us know your requirements.

Condition: used, Year of construction: 1998, grinding length 800 mm grinding width 500 mm workpiece height 425 mm total power requirement 15 kW weight of the machine ca. 4,5 t Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical : GEIBEL & HOTZ CNC Cycle Controlled Precision Surface Grinding Machine model FS 850 GT SL year 1998 Serial no 1012580698 _____ Grinding length max. (table movement 900 mm) 800 mm Grinding width max. (cross movement 500 mm) 500 mm Mounting height under new grinding wheel 425 mm size of magnetic plate 800 x 500 mm Max. table load 1.100 kg Table speed 2 – 28 m/min Cross feed intermittend 3 – 60 mm/stroke Cross-/Vertical quick feed 4.000 mm/min Grinding wheel measurements 400 x 100 x 127 mm Grinding spindle-drive approx. 9 kW Total electrical load approx. 22 kW - 400 V - 50 Hz Iodot Hxamspfx Ahzsaw Weight approx. 4.500 kg Accessories / Special Features: • Dialog-guided GEIBEL & HOTZ automatic CNC cycle control model SL for 3 axes. Graphically supported data input in absolute dimensions or via teach-in procedures for preprogrammed grinding and dressing cycles. SIEMENS LCD display with softkeys for setting all parameters and easy monitoring axis movements and work progress. • Electronic handwheel for 3 axes X, Y, and Z, feed rate switchable from 0.01 / 0.1 / 1 mm/rev. • table movement is effected by a rolling ring thread drive (GT), which allows both very high and very low table speeds with constant torque and very high efficiency. • cross and vertical movements are effected by a ball screw drive with incremental glass scale. • Single-point diamond dresser mounted on the table for aut. dressing cycle and aut. compensation • MPM automatic grinding wheel balancing device. • Mounted electromagnet plate 800 x 500 mm with adjustable holding force • Wet grinding facility with universal fleece belt filtration unit • Complete enclosure of the working area with electronically safeguarded sliding doors • sep. switch cabinet, sep. mobile control panel, various accessories, manuals , etc. Condition : very good, with the wide grinding wheel for large surface grinding ! Please click here to view soon a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We do always have a large selection of Grinding machines in stock – please let us know your requirements !

Condition: excellent (used), Year of construction: 1996, grinding length 600 mm grinding width 350 mm total power requirement 7,5 kW Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : Iasdpfxsx Haryj Ahzew GEIBEL & HOTZ CNC horizontal surface & profile grinding machine model FS 635 - Z CNC year 1996 Grinding length max. (table movement 660 mm) 600 mm Grinding width max. (cross movement 360 mm) 350 mm Mounting height under new grinding wheel 375 mm Distance table – center of spindle min / max 140 – 525 mm Standard size of magnetic plate 600 x 350 mm Table size 820 x 350 mm Max. table load 400 kg Table speed 5 – 35.000 mm/min Cross movement, intermittently 3 – 40 mm Cross-/Vertical quick feed 5 m/min Grinding wheel measurements 300 x 50 x 76,2 mm Grinding spindle speeds, variable 1.000 – 3.000 rpm Grinding spindle-drive approx. 7,5 kW Total electrical load approx. 15 kW - 400 V - 50 Hz Weight approx. 2.600 kg Accessories / Special Features: • SIEMENS CNC control model 840 D with comprehensivel GEIBEL&HOTZ grinding software. User friendly interface, supported by dialog and graphics, simple programming also of complex grinding wheel profiling and easy linking of grinding cycles. • All standard grinding-programms and cycles as surface and multiple surfaces grinding with roughing-finishing-sparkout- return, plunge in grinding, automatic dressing cycle with compensation, etc. • electronic handwheel for 3 axis; cross feed (Z) and infeed (Y) effected by ball screw drive. • Table movement is actuated by belt drive (Z), which allows both very high and very low table speeds and is also ideal for profile grinding. • Hydraulically upwarding diamond dressing device mounted on the left side of the table (also for profile dressing); additional fixed dresser with automatic dressing cycle, including compensation. • Mounted sinus tilting magnetic plate 600 x 200 mm, fine pole division. • Separate paper band coolant filtration unit, separate switch cabinet, lamp for working area, various accessories, manuals, etc. Condition : very good, universal machine for all sorts of grinding tasks ! Please click here to view a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We always have a large selection of surface grinders – CNC or conventional - available. Please let us know your requirements.

Condition: used, Year of construction: 1969, grinding length 500 mm grinding width 200 mm workpiece height 250 mm total power requirement 5,5 kW weight of the machine ca. 2500 kg dimensions of the machine ca. m J U N G Horizontal High Precision Surface- and Profile Grinding Machine Model HF 50 RD, Year 1969, partially reconditioned in 2021 Serial-no. 4082 _____ Grinding length max. 500 mm Grinding width max. 200 mm Table size 600 x 200 mm Grinding height under grinding wheel approx. 250 mm Table cross travel approx.. 230 mm Table slide cross stroke 0,2 - 8 mm/table stroke Table longitudinal travel max.. 550 mm Table speed longitudinal 1 – 20 m/min. Measurement of grinding wheel 225 x 25 x 51 mm Grinding wheel speed infinitely adjustable 1.000 - 4.500 rpm Vertical feed 0.001 - 0.01 mm/stroke Grinding spindle drive infinitely variable load 0,4 – 1,5 kW Total electrical load 5,5 kW - 380 V – 50 cycles Weight approx. 2.500 kg Accessories/Special Features: • Due to the infinitely variable speed range of the grinding wheel this design is especially suited for grinding of high alloyed steels and carbide, hardmetal, etc. • Set up switches for plunge-in or normal pendular-grinding with automatic Iasdpfx Ast Hwziohzsw infeed • Automatic infeed of grinding slide during surface- and/or profile grinding, (plunge-in cut)with automatic stop of infeed by contact-Gauge. • motorized rapid feed of grinding head up/down • Manual straight grinding wheel-dressing device mounted above the grinding wheel • Manual Table mounted, swivable magnetic chuck make BRAILLON size 400 x 200 mm • separate converter cabinet for infinitely variable speed regulation and with respective display of cutting speed in m/sec. • Wet grinding facility including coolant tank and bandfilter cleaning device, separate standing, • Including 3 separate flanges, some grinding wheels, service tools, etc. Condition : good – can be inspected here under power, partially reconditioned by a JUNG Specialist (table pistons, lubrication, infeed system, Dresser, covers, etc.) Delivery : ex stock – as inspected Payment : net– after completion of contract

Condition: ready for operation (used), functionality: fully functional, grinding length: 800 mm, grinding width: 350 mm, Magnet, 800 x 350 mm. Iajdpfx Ahjzimmmozsw

Condition: ready for operation (used), Year of construction: 1986, functionality: fully functional, The machine is in good working order. See the video. Iaodpfxozimhwo Ahzew

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, The machine is in good working order. See the video. Iaodpfezimgyjx Ahzow

Condition: used, Year of construction: 2001, functionality: unexamined, grinding length: 800 mm, grinding width: 600 mm, grinding height: 400 mm, grinding wheel diameter: 400 mm, grinding wheel width: 100 mm, grinding spindle motor power: 20,000 W, Used surface grinding machine and profile grinding machine, year of manufacture 2001, partially overhauled in 2019, ELB-SCHLIFF model PERFEKT-FUTURE BD 8 -F- Schleicher-Unicon CNC Electro-magnetic clamping plate 500 x 300 x 4 mm, new pole pitch in 2019 Coolant system featuring combination of permanent magnet and paper band filter Iedpfx Ahoywk Akezjaw Adjustable coolant supply nozzle Grinding wheel flange
