Used Schiess Cnc Lathe for sale (11,774)

Condition: excellent (used), ROMI GL 240 2 Axis CNC Lathe Swing over Z axis cover mm 420 Maximum cutting diameter mm 300 Lredpfx Aaezu Nggj Rjr Maximum cutting length mm 400 Travel (X axis) mm 188 Travel (Z axis) mm 400 Spindle nose ASA A2-5" Spindle hole diameter mm 58 Bar capacity (dia.) mm 51 Speed range rpm 6 to 6000 Rapid traverse (X & Z axis) m/min 30 Number of stations atc 12 AC spindle motor hp/kW 20/15

Condition: used, Daewoo Puma 12S-3A CNC Turning Centre Year: 1996 Fanuc Series O-T CNC Control C-Axis Spindle Live Tooling Ljdpfx Aaozrt Dws Rjrr 12 Station Servo Turret Hydraulic Chuck Swing Over Bed: 570 mm Maximum Turning Diameter: 430 mm Maximum Turning Length: 770 mm Serial Number 3P100044 90 mm Bar Capacity 91 mm Spindle Bore A2-8 Spindle Nose Spindle Speeds: 25–3,000 rpm 18.5/22 kW AC Spindle Motor X Axis Travel: 260 mm Z Axis Travel: 800 mm Rapid Traverse: X 20 m/min, Z 24 m/min Automatic Lubrication Coolant System Swarf Conveyor Fully Enclosed Splash Guarding

Condition: used, Year of construction: 2009, turning height: 3,500 mm, workpiece weight (max.): 20,000 kg, turning diameter: 3,400 mm, faceplate diameter: 2,950 mm, workpiece diameter (max.): 3,300 mm, VERTICAL LATHE SCHIESS CNC FAGOR 8070 (C-AXIS + LIVE TOOLING) TECHNICAL SPECIFICATIONS Brand: Schiess Model: TVMF 320-3000 Year: 2009 Maximum turning diameter: 3400 mm Maximum turning height: 2580 mm Load capacity: 20 t C-axis (0.001°) CNC: Fagor 8070 (70 kW) Table diameter: 2950 mm Distance between columns: 3300 mm Angular milling head PRICE AND FURTHER INFORMATION ON REQUEST Ljdpfxsxh Hmko Aa Rjrr (CNC, SIEMENS, HASS, LAGUN, FAGOR, CINCINNATI, HEIDENHAIN, MACHINING, PINACHO, MORISEIKI, MILLING MACHINE, LATHE, GRINDER, BORING MACHINE, PRESS, LASER, SHEAR, PRESS BRAKE)

Condition: excellent (used), Year of construction: 1985, functionality: limited functionality, Description Technical information Swing over bed 420 mm Distance centre tot centre 1000 mm Max longitudinal travel Z-axis 1028 mm Max cross travel X-axis 335 mm Spindle coneA2-6 Dia of spindle bore 56 mm Power on the spindle20/25 hp Number of speeds16 - 4000 rpm CommandMazatrol Cam T3 Total power needed18,5 kW - 32,9 kVa Length 3734 mm Width 1893 mm Height 2401 mm Weight 4400 kg Toolchanger yes Number of tools 16x - rotating yes Ledpfxsvk E Ayo Aa Rsrr milling tools C-axis Robo flex automatic loading system tooling included Measuring arm included MAZATROL CAM T-3 CNC Accessories Tailstock, Evoquator, Tool Attachments, Presetting Machine weight 4700 kg Axis C Yes

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, number of spindles: 2, spindle speed (max.): 4,500 rpm, turning length: 145 mm, turning diameter: 240 mm, travel distance X-axis: 130 mm, travel distance Z-axis: 145 mm, Horizontal, twin-spindle CNC lathe with 2 turrets in two working areas and 2 loading portals! The machine underwent an overhaul in 2023! TECHNICAL DETAILS Turning diameter max.: 240 mm Turning length max.: 145 mm Travel X-axis: 130 mm Travel Z-axis: 145 mm Distance between spindles: 340 mm Rapid traverse X/Z-axis: 24 m/min Guidance X-axis: Roller linear guide Guidance Z-axis: Round guide, 145 mm Number of spindles: 2 Spindle drive power: 11 / 7.5 kW Max. spindle speed: 4,500 rpm Torque: 93 Nm Spindle nose: JIS A2-5 Chuck size: 210 mm (8 inches) Lredpfeztxlcex Aa Rsr Number of turrets: 2 Turret type: BT turret Tool positions per turret: 8 Shank size for external turning tools: 20 × 20 mm Max. shank diameter for boring bars: 40 mm MACHINE DETAILS Control: Fanuc 32i-B Working areas: 2 Power connection: 30 kVA Dimensions & Weight Footprint: 4,500 × 2,440 mm Overall height with loader: 2,550 mm Weight: 4,400 kg Loading portal GT Twin with two independent portals Dual gripper for raw and finished parts Turning station Control unit with cable Max. workpiece diameter: 120 mm Max. workpiece length: 80 mm Max. workpiece weight: 3 kg EQUIPMENT Stack magazine, on the left side Parts conveyor belt, on the right side Chip conveyor, on the rear side Coolant tank Coolant supply through both spindles for flushing the clamping devices Various tool holders Various clamping devices Documentation and wiring diagrams

Condition: used, Year of construction: 1997, functionality: fully functional, spindle bore: 66 mm, spindle speed (max.): 4,500 rpm, travel distance X-axis: 185 mm, travel distance Z-axis: 540 mm, quill travel distance: 130 mm, quill diameter: 80 mm, BRIDGEPORT ROMI POWERPATH 15 - Manufacturer: Bridgeport / Romi - Model: PowerPath 15 - Year: 1997 - Machine Type: CNC Turning Center Lrodpfx Aaezvf Dwe Rsr - CNC Control: Fanuc Series 21i – To be confirmed - Number of Axes: 2 - Chuck Size: Approx. 203 mm / 8" - Swing Over Bed: Approx. 440 mm - Maximum Turning Diameter: Approx. 280 mm - Maximum Turning Length: Approx. 540 mm - X-Axis Travel: Approx. 185 mm - Z-Axis Travel: Approx. 540 mm - Spindle Bore: Approx. 66 mm - Bar Capacity: Approx. 51 mm - Spindle Nose: A2-6 - Spindle Speed: Up to 4,500 rpm - Spindle Speed Range 1: Approx. 15–1,500 rpm - Spindle Speed Range 2: Approx. 45–4,500 rpm - Spindle Motor Power: 15 HP / approx. 11.2 kW - Turret Capacity: 12 tools - Tailstock: Included / To be confirmed - Tailstock Quill Diameter: Approx. 80 mm - Tailstock Quill Travel: Approx. 130 mm - Chip Conveyor: Included

Condition: used, Harrison Alpha 1350XS CNC Toolroom Lathe (2010) Swing Over Bed 350 mm Swing Over Cross Slide 196 mm Swing in Gap 535 mm Distance Between Centres 650 mm Maximum Turning Diameter 350 mm Lrodpfszq Ddxsx Aa Rjr Spindle Speed Range 1 – 3,500 rpm Fanuc Oi-TD CNC control Harrison Alpha conversational programming Fanuc Manual Guide i Full ISO G-code programming capability 2-axis CNC control (X and Z) Electronic handwheel operation Machine Weight Approx. 1,800 kg Machine Dimensions (L × W × H) 2,400 × 1,700 × 1,500 mm

Condition: used, ZERBST DP/S3 cnc Heavy Duty Lathe Manufacturer: ZERBST (Germany) Lrsdeztff Nspfx Aa Ror Year: 1991 Machine Type: Heavy Duty Facing & Centre Lathe simens control Maximum Turning Diameter: Ø1,600 mm Distance Between Centres: 4,700 mm Spindle Bore: 110 mm Main Motor Power: 55 kW Spindle Speed: 3.5 – 450 rpm Bed Design: Triple guideway cast iron bed Control : Siemens Tailstock: Powered tailstock Thread Cutting: Yes Maximum Workpiece Weight: Up to 12,500 k

Condition: like new (used), Year of construction: 2021, functionality: fully functional, machine/vehicle number: ML0377-000140, turning length: 1,280 mm, turning diameter: 376 mm, spindle bore: 780 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 260 mm, travel distance Y-axis: 105 mm, travel distance Z-axis: 1,350 mm, spindle motor power: 22,900 W, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (min.): 200 rpm, turning diameter over bed slide: 780 mm, type of input current: three-phase, We offer this Doosan PUMA 2600LY II CNC turning and milling center in like-new condition, manufactured in 2020. The machine has not been put into operation and has not been turned on since it was new. Power-on time: 0 Model: PUMA 2600LY II Lrodpoy Nmdnsfx Aa Rer Serial number: ML0377-000140 Supply voltage: 380 V Number of phases: 3 Frequency: 50/60 Hz Rated power: 49.06 kVA Interrupting capacity: 5 kA Current at full load: 74.65 A Short-circuit capacity: 10 kA Circuit diagram version: P210SYH840A07 Weight: 7400 kg Date of manufacture: 2020-11 - Hydraulic chuck 255 mm (10”) – 3-jaw, with a set of soft jaws and a set of hard jaws - Hydraulic unit - Coolant system with a high-pressure pump (min. 7 bar) - Box guideways for all axes – induction hardened - Slant bed (min. 30°) - Work area lighting - Front door safety switch - Leveling pads - Color monitor - Conversational/Graphic programming support - Turret (min. 12 stations) - Tool holder kit: min. 2 straight driven holders; 2 angular driven holders; 8 static holders for drills and boring bars - Full telescopic covers for guideways - Full machine enclosure - Programmable tailstock (MT5 center) - 3-color status light (stack light) - Automatic tool presetter / tool probe - Tool monitoring system - Electrical filter - Bar feeder interface - Automatic parts catcher and parts box - Thermal compensation function - Direct drive spindle - Spindle speed: min. 4000 RPM - Built-in network card (Ethernet) - USB port - Hinged belt-type chip conveyor - Oil skimmer - Toolbox - Radial driven tool holder x2, Axial driven tool holder x2 If you have any questions or require additional information, please send us a message or contact us by phone.

Condition: used, Year of construction: 1997, functionality: unexamined, turning diameter over cross slide: 455 mm, turning length: 1,000 mm, turning diameter: 680 mm, spindle bore: 107 mm, spindle speed (max.): 2,800 rpm, spindle speed (min.): 4 rpm, travel distance X-axis: 320 mm, travel distance Z-axis: 1,097 mm, spindle motor power: 30,000 W, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 30 m/min, GILDEMEISTER CTX 600 CNC LATHE – 2,000 MM TURNING LENGTH – Ø107 MM SPINDLE BORE – 12-STATION VDI 50 TURRET For sale is a powerful and robust Gildemeister CTX 600 CNC lathe, manufactured in Germany in 1997. With a turning length of approximately 2,000 mm, a large spindle bore of approximately 107 mm and a hydraulic 400 mm SMW Autoblok chuck, the machine is ideally suited for machining large, heavy and long workpieces. This is a solid, German-built industrial lathe with a rigid, heavy-duty construction, powerful spindle, hydraulic tailstock and 12-station VDI 50 tool turret. It is a particularly attractive machine for workshops looking to expand their turning capacity without the high investment cost of a newer machine. The CTX 600 is suitable for individual parts, repair work, tooling, shafts, flanges and small- to medium-series production. MAIN TECHNICAL DATA: Lsdpfx Aaozmqdke Rorr Manufacturer: Gildemeister Drehmaschinen GmbH Model: CTX 600 Year of manufacture: 1997 Serial number: 361208 Country of manufacture: Germany CNC control: Grundig EltroPilot Maximum turning length: approx. 2,000 mm Maximum turning diameter: approx. 480 mm Spindle bore: approx. 107 mm Spindle speed: up to approx. 3,000 rpm Main spindle power: approx. 27–30 kW Chuck: hydraulic SMW Autoblok 3-jaw chuck Chuck diameter: approx. 400 mm Tool turret: 12 positions Tool interface: VDI 50 Tailstock: hydraulic Electrical supply: 400 V / 50 Hz Total connected load: 58.5 kVA Machine weight: approx. 9,000 kg EQUIPMENT AND ADVANTAGES: – Large working capacity for long and heavy components – Large spindle bore of approximately 107 mm – Powerful main spindle – Hydraulic 400 mm SMW Autoblok chuck – 12-station VDI 50 tool turret – Hydraulic tailstock – Coolant system – Chip conveyor – Tool holders shown in the photographs – Rigid and proven Gildemeister construction – Spare parts and service support still available on the European market The machine is complete and available immediately. It can be inspected and tested by prior appointment. Additional photographs and a video of the machine can be provided upon request. Loading and transport can be arranged separately. This is an excellent opportunity to acquire a large-capacity, proven German CNC lathe at a fraction of the cost of a comparable newer machine. The price is net, plus VAT where applicable. All technical information is provided to the best of our knowledge and is subject to verification. The offer is non-binding, and the machine remains subject to prior sale.

Condition: used, Year of construction: 1997, functionality: fully functional, turning diameter over cross slide: 450 mm, turning length: 420 mm, turning diameter: 350 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 180 mm, travel distance Z-axis: 420 mm, overall weight: 3,500 kg, KEGAI TUR-15 Manufacturer: Ikegai Model: TUR-15 Machine Type: CNC Turning Center Year: 1997 CNC Control: Fanuc Series 18-T Drives: Fanuc Alpha Series Number of Axes: 2 Swing Over Bed: Approx. 450 mm Maximum Turning Diameter: Approx. 350 mm Maximum Turning Length: Approx. 410–420 mm X-Axis Travel: Approx. 170–200 mm Z-Axis Travel: Approx. 420 mm Chuck: 8" Hydraulic Chuck Spindle Nose: A2-6 Spindle Bore: Approx. 57–61 mm Bar Capacity: Approx. 45–51 mm Spindle Speed: Up to 4,000 rpm Spindle Motor Power: Approx. 11 kW / 15 HP Turret Capacity: 12 Stations Tailstock: Included Chip Conveyor: Included Machine Dimensions: Approx. 2,440 × 1,470 × 1,575 mm Machine Weight: Approx. 3,300–3,700 kg Lsdpfx Aszvmytea Rerr

Condition: good (used), Year of construction: 2007, functionality: fully functional, turning length: 1,500 mm, turning diameter: 710 mm, Used Okuma Multus B400W Max. turning diameter Ø 710 mm Turning length 1500 mm Ljdpfx Aasyrf T Ss Rjrr Kuka robot 140 kg without handling attachment 2 spindles, 7 axes, loading conveyor - loading station - unloading station - 950 mm swing 12+15" chuck 70 bar high-pressure pump

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: X4S405, turning diameter over cross slide: 370 mm, turning length: 2,000 mm, turning diameter: 554 mm, spindle bore: 104 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 1 rpm, travel distance Z-axis: 2,000 mm, rotational speed (min.): 1 rpm, rotational speed (max.): 2,000 rpm, total height: 1,750 mm, total length: 4,100 mm, total width: 2,000 mm, type of input current: three-phase, overall weight: 3,600 kg, Harrison Alpha 1550 XS CNC / Manual Lathe Model: Alpha 1550 XS Lsdpfx Aaezux S Eo Rsrr Year: 2017 Control: Fanuc Oi-TF Swing Over Bed: 554mm Swing Over Cross Slide: 370mm Swing In Gap: 830mm Distance Between Centres: 2000mm Spindle Bore: 104mm Spindle Speeds: 1-2000 RPM Machine with: 3 Jaw Chuck Quick Change Toolpost with Holders Fixed Steady Dimensions: 4100 x 2000 x 1750mm Weight: 3600Kgs

Condition: used, Year of construction: 2007, operating hours: 9,546 h, functionality: fully functional, machine/vehicle number: R2EVO401, turning diameter over cross slide: 210 mm, turning length: 500 mm, turning diameter: 210 mm, spindle bore: 45 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 24 m/min, overall weight: 2,600 kg, Equipment: documentation/manual, EMCO 45 E45 with bar feeder EMCO Compact Load The machine is in good condition, complete with manual, and is fully functional. The machine can be inspected in Span until August 28, 2026; the loading date is scheduled for September 2, 2026. Sale due to replacement investment in a new CNC lathe. Control system: Siemens 810D Turning length with chuck: 500 mm Max. turning diameter between centers: 210 mm Bar diameter: 45 mm Rapid traverse rates: 24/20 m/min Spindle stock: DIN 55026/KK5 12-position tool turret VDI-30 6 powered stations C-axis Tailstock with hydraulic quill, MK-4 Power chuck Röhm KFD-HE 170/3 Ledpfxjzlihlo Aa Rorr Removal and loading of the machine will be carried out by Hametec; the loading date is September 2, 2026. The buyer is responsible for arranging transport.

Condition: used, Year of construction: 1993, CNC Lathe REALMECA type T400 Travel X: 200 mm Travel Z: 600 mm Numerical Command: NUM 750 Between points distance: 700 mm Max machining diameter: Ø 210 mm Spindle speed: from 100 to 4000 RPM 12 tools Turret VDI 20 3-jaws chuck Ø 140 mm Year of construction: 1993 Spindle motor: FANUC Tailstock: CM4 Hydraulic Tailstock + Chuck Lubrification Ljdpszwcpgofx Aa Rsrr Voltage: 380 V Dimensions (L x W x H): 2500 x 1500 x 1700 mm Weight: approx 3 T

Condition: used, Year of construction: 1989, functionality: not functional, turning length: 600 mm, turning diameter: 350 mm, spindle bore: 105 mm, spindle motor power: 22 W, total length: 3,063 mm, total width: 1,660 mm, overall weight: 4,300 kg, Equipment: documentation/manual, The machine is not functioning due to a fault in the regulator. All the machine's mechanical properties are perfect. The machine is very rigid and can achieve tolerances as tight as 0.01 mm. It can also be used as spare parts. Lrodpfszwdamjx Aa Rjr

Condition: used, Year of construction: 2014, operating hours: 21,950 h, functionality: fully functional, turning length: 669 mm, turning diameter: 330 mm, spindle bore: 88 mm, spindle speed (max.): 3,400 rpm, overall weight: 5,700 kg, bar passage: 75 mm, chuck outer diameter: 250 mm, Equipment: rotational speed infinitely variable, - Siemens 828 - Main spindle 3,400 rpm - Siemens motor - 12-position Sauter turret for 12 driven tools Lsdjyzr Tropfx Aa Rsrr - Tool holder VDI 40 - 3-jaw chuck Ø 250 mm - C-axis - Chip conveyor - Coolant system and through-spindle coolant (IKZ), 20 bar - Work area lighting - Foot pedal for power chuck - CE certification

Condition: good (used), Year of construction: 1999, 1 Muratec MT12 CNC lathe with dual spindle and dual turret Lrsdsy Ta Stepfx Aa Ror Fanuc CNC control Year: 1999 Supplied with all tooling and tool holders.

Condition: good (used), Year of construction: 1999, 1 MURATEC MT12 CNC lathe Double-spindle, double-turret Year 1999 1 STAUBLI RX90 robot with control center Lrodey Ta Sgopfx Aa Rsr All tooling and tool holders included.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, turning diameter over cross slide: 272 mm, turning length: 1,250 mm, turning diameter: 470 mm, spindle bore: 80 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 50 rpm, travel distance X-axis: 1,250 mm, rotational speed (min.): 50 rpm, rotational speed (max.): 2,500 rpm, total height: 1,850 mm, total length: 2,700 mm, total width: 1,350 mm, type of input current: three-phase, overall weight: 2,300 kg, XYZ Proturn CNC/Manual Lathe Model: Proturn 410 Control: Proto Trak LX2 Swing Over Bed: 470mm Swing In Gap: 730mm Lsdpfjzux Iyox Aa Rerr Swing Over Cros Slide: 272mm Distance Between Centres: 1250mm Spindle Speeds: 50-2500 RPM Spindle Bore: 80mm Machine With: 300mm 3 Jaw Chuck Quick Change Toolpost with Holders Dimensions: 2700 x 1350 x 1850mm high Weight: 2300 Kgs

Condition: defective spare-parts repository (used), Year of construction: 1990, functionality: not functional, turning length: 600 mm, turning diameter: 300 mm, travel distance X-axis: 175 mm, travel distance Z-axis: 670 mm, spindle motor power: 11 W, rotational speed (min.): 3,500 rpm, total length: 2,620 mm, total width: 1,480 mm, overall weight: 4,000 kg, bar passage: 65 mm, spindle nose: MT-NO.7, Equipment: documentation/manual, DAINICHI F25 CNC turning center, manufactured in Japan. A robust and reliable CNC lathe suitable for precision turning and general production applications. The machine offers a rigid construction, hydraulic chucking, and automatic tool changing, making it suitable for both small and medium production series. The machine is available for inspection and can be demonstrated upon request. TECHNICAL SPECIFICATIONS CNC control: FANUC CNC turning center Maximum turning diameter: approx. 300 mm Maximum turning length: approx. 600 mm Swing over bed: approx. 500 mm Spindle bore: approx. 65–77 mm* Spindle speed: up to approx. 3,000–3,500 rpm* Turret: automatic turret, 10 stations* Hydraulic chuck Hydraulic tailstock Coolant system Chip conveyor* * Specifications to be confirmed according to the individual machine configuration. ADVANTAGES DAINICHI, Japanese machine construction Robust and rigid CNC turning center FANUC CNC control Lrodpfxozwdqrj Aa Rsr Hydraulic chuck and tailstock Suitable for general turning and production work Machine available for inspection Immediate availability < < < THE MACHINE HAS A FAULT ON THE REGULATOR AND IT IS NOT FUNCTIONAL. IT CAN BE REPAIRED OR USED FOR SPARE PARTS. > > > IT HAS AN ALMOST NEW 3-WAY JAW CHUCK.

Condition: used, Year of construction: 1990, functionality: fully functional, turning length: 250 mm, turning diameter: 160 mm, travel distance X-axis: 100 mm, travel distance Z-axis: 290 mm, The machine is fully workable but the sub spindle is out of order and the Tool Eye is manual swivable Mazatrol T 32-2 CNC control main spindle: collet chuck device 8-fold revolver bar loading device Technische Daten / technical details: max. Drehdurchmesser / max. turning diameter 160 mm max. Schwingdurchmesser / max. rotary diameter 300 mm Drehlänge / turning length 250 mm X-Weg / X-travel 100 mm Z-Weg / Z-travel 290 mm Durchlass / spindle hole 40 mm Drehzahl / spindle speed 45-4500 UpM /rpm Gewicht der Maschine / weight 3500 kg Ledpjzmfdxefx Aa Rerr Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: good (used), Year of construction: 2015, machine/vehicle number: 190630, turning length: 150 mm, turning diameter: 200 mm, spindle bore: 42 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 50 rpm, travel distance X-axis: 150 mm, travel distance Z-axis: 155 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, turning diameter over bed slide: 220 mm, overall weight: 5,000 kg, spindle nose: 140 Flat, bar diameter (max.): 51 mm, power: 0.015 kW (0.02 HP), The innovative front-facing spindle of the 2SP-150H helps create an automation-friendly lathe for small parts production. By moving the spindle off the side and incorporating the Okuma Gantry Loader (OGL) into the production line, parts can be loaded and unloaded automatically. An extremely compact footprint improves floor space utilization, while the popular dual spindle option significantly reduces cycle time. Equipped with: Okuma OSP-P300L CNC Control 8" 3-Jaw Chuck Lrjdpjrtrlzefx Aa Rjr Expanding Mandrel Turret Tooling Gantry Loader Pendant Controller Chip Auger Stack Light

Condition: ready for operation (used), Year of construction: 2019, functionality: fully functional, machine/vehicle number: 1 770 58 449, turning length: 740 mm, turning diameter: 160 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 1,500 rpm, travel distance X-axis: 280 mm, travel distance Z-axis: 1,130 mm, spindle motor power: 30,000 W, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 60 m/min, rotational speed (min.): 1,500 rpm, rotational speed (max.): 4,500 rpm, total height: 2,950 mm, total length: 4,350 mm, total width: 2,550 mm, feed length X-axis: 280 mm, feed length Z-axis: 1,130 mm, feed rate X-axis: 30 m/min, feed rate Z-axis: 60 m/min, type of input current: three-phase, torque: 191 Nm, overall weight: 12,000 kg, chuck outer diameter: 215 mm, spindle nose: A6, mount diameter: 40 mm, Technical data UNIVERTOR AS90/400 (German) Manufacturer: J.G. WEISSER SÖHNE GmbH & Co. KG Type: UNIVERTOR AS90/400R RT General features: Machine type: Horizontal shaft turning center with pick-up loading Area of application: Complete machining of shafts and rotationally symmetrical components Loading: Integrated pick-up automation Processing types: Green turning, hard turning, roughing, finishing Tool carrier: 12-way turret with electric drive (VDI 40) Additional options: Driven tools, rotary turning, NC-adjustable steady rest, measuring probe Main spindle: Spindle bearing diameter: 90 mm Spindle flange: A6 according to DIN 55026 Drive power (100/40% ED): 18/23 kW or 23/30 kW Nominal speed: 1,500 rpm Maximum speed: 4,500 rpm Torque (100/40% duty cycle): 115/146 Nm or 151/191 Nm Travel paths & axes: Max. turning diameter: 160 mm Max. chuck diameter: 215 mm Center distance: Max. 740 mm Travel paths X/Z axis: 280 mm / 1,130 mm Max. feed force X/Z (40% duty cycle): 10 kN / 8 kN Lrsdpfevw Slhex Aa Rer Max. travel speed X/Z: 30 m/min / 60 m/min Tailstock: Pressure force: 850 daN Center center holder: MK4 Max. speed: 4,500 rpm Dimensions & weight: Machine dimensions (L×W×H): 4,350 × 2,550 × 2,950 mm Weight: 12,000 kg

Condition: good (used), Year of construction: 2000, center width: 2,000 mm, Control system: SIEMENS 840 D (manual turning) Spindle module replaced in 2008. Swinging diameter over the bed: 630 mm Swinging diameter over the carriage: 370 mm Spindle bore: 105 mm Distance between centers: 2,000 mm The machine is supplied with a 250 mm manual chuck. Spindle speed range 1: 4 - 430 rpm Spindle speed range 2: 430 - 2500 rpm Lsdsy A I I Iopfx Aa Rjrr Power of the main motor: 18.5 kW S6-40%
