CNC LATHE MAZAK SLANT TURN 25-ATC C AXIS SLANT TURN 25-ATC C

Year of construction: 1971, condition: used, Technical details: max. wheel diameter: 300 mm max. module: 5 module min. : 0,5 max. workpiece weight: 60 kg weight of the machine ca.: 4,0 t dimensions of machine: 1800x1850x2500 mm dimensions electric cabinet: Nr. 1: 1930x400x1920 mm dimensions electric cabinet: Nr. 2: 800x230x1950 mm dimensions:: Abluftanlage: 1400x700x560 mm dimension cooling device LxWxH: 1,2 x 1,0 x 0,45 m Pedpevc Apbofx Anpspu Electronically controlled tooth flank grinding machine up to module 5 and a Ø of 240 - 300 mm feed speed per workpiece revolution infinitely variable 0.4 - 3.2 mm max./min. Number of teeth: 130 / 12 max./min. Pressure angle: 30° / 14°30` max./min. Spiral pitch with 24 teeth: 6000 / 200 mm max. tooth helix angle, both sides: 45° Speed of the grinding worm: 1900 rpm without dressing device Equipment: approx. 77x change transmission wheels, pipe extensions and various tools Two of these machines are for sale. Both machines are supplied via two common control cabinets and an exhaust air system. *

Year of construction: 2016, condition: new, 1 unit of a completely overhauled, unused industrial bevel-helical gearbox from ASUG. TGL 21815. All gearbox parts have been replaced, with the exception of the housing!!! Clutch: 800 mm (only one half available) Maximum torque: 27,829 Nm Gear ratio: i = 1:80 Maximum power: 51 kW Ppsdpfx Anegwlrdjpju Oil capacity: 170 kg Speed: n1 = 1400 Speed: n2 = 17.5 Weight: 1450 kg Shaft diameter d1: 65 mm Shaft diameter d2: 160 mm Shaft height h1: 500 mm Overall height h2: 925 mm Length of base: 1170 mm !! The gearbox does not have an oil cooler !!

Condition: used, cone distance min./max. 0-108 mm Pitch angle min/max 5°/84° Psdpfxsyh Rmme Anpepu Control GE Fanuc Series 0-GC Pitch diameter (1:1 ratio) 152 mm pitch diameter (10:1 ratio) 216 mm Diametral pitch (finest/coarsest) 1.3/8.5 Mod. Face width gear wheel max. 35 mm Knife spindle - Speed range 41-121 U/min working spindle speed range 0-33.33 U/min weight 9025 kg dimensions of the machine ca. 2707 x 2720 x 2200 mmxmmxmm Equipment/accessories: - 18-piece cutter set - Chip conveyor - Technical documentation

Year of construction: 2002, condition: excellent (used), Parts in contact with the product are made of stainless steel 1.4571, the rest of the dryer is made of 1.4301. Machine Name: Continuous Horizontal Vacuum Paddler Dryer used Manufacturer: AVA / Holland Merten GmbH Ppodpeitcu Ejfx Anpsu Type: HTK 200 Construction year: 2002 Speed: 107 rpm Material: 1.4301 Driving force: 5,5 kW Model: EExdellCT4 Total content: 235 Liter Parts in contact with product: 1.4571 Equipment: Double jacket, mechanical seal Dimensions: L 3400 x W 1100 x H 1500 mm Empty weight: approx. 1600 kg Technical documentation: Yes Message: Operating temperature 130°C Design temperature 200°C Internal pressure mixer -1/+3 bar Pressure double jacket +6 bar Accessories: Base frame Condition: Used

Condition: good (used), Year of construction: 2001, Cutting 90°: 330 Cutting flat 90°: 330 x 330mm Cutting speed Vario:12 - 120 Pedpeu R R Acjfx Anpepu Circle blade size: 6830 x 41 x 1,3mm Power: 7.5kW Length: 4600mm Width: 2150mm Height: 2310mm Weight: 4300kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm dimensions of the machine ca. 3,6/3,5 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your is: Kellenberger Kel-Varia Baureihe mit Kelco 90 Steuerung. Mechanische Überholung: -komplette Maschine nach Kellenberger Messprotokoll überholt -Neue servicefreundliche Kabine -Neulackierung Elektrische Überholung: -Neue moderne CNC-RUNDSCHLEIFMASCHINEN-Steuerung -Neu aufgebauter Schaltschrank -Neue Antriebstechnik -Austausch sämtlicher elektrischer Leitungen Berus Druckschalter etc. -Neue Absolut-Glasmaßstäbe in x- und z -Neuer Absolut Drehgeber (Bei-B-Achse) Standardausstattung: -WSS mit Konus MK5, optional mit Adapter MK5/Kurzkegel -RST mit MK4 Konus. Optional mit Feinverstellung -Schleifspindelstock T1/T2/T3 -T1 Schleifscheibendurchmesser 400mm -T2 Schleifscheibendurchmesser 300mm -T3 Innenschleifeinrichtung riemengetrieben. -Schleifspindelmotor 4,4kW -B-Achse hochauflösend -Marposs Messsystem zur Schleifscheibenvermessung. -Längspositionierung Marposs -GAP Control (Sensor am Schleifspindelstock) Optionen gegen Aufpreis: -HF Innenschleifspindel Pjdpfx Anjuwv H Hspopu -Hochgenauer, höchst kippsteifer Werkstückspindelstock -Messteuerung Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: excellent (used), Year of construction: 2021, operating hours: 3,000 h, travel distance X-axis: 6,100 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 950 mm, CNC Travelling Column Milling Machine – Fully Retrofitted by REM (2021) Powerful and versatile heavy-duty milling machine, completely modernized by REM specialists in 2021 with state-of-the-art Heidenhain TNC 320 control. Ready for immediate production use. KEY SPECIFICATIONS: • X-axis (transversal travel): 6,000 mm • Y-axis (vertical head travel): 2,000 mm • Z-axis (axial slide travel): 950 mm Podpfx Aon D N H Tsnpspu • Dual-spindle head | Head rotation: 360° • Spindle speed: 1,000 – 4,000 rpm • Spindle taper: ISO 50 (automatic locking/unlocking) • Head dimensions: 290 × 290 mm • Spindle motor power: 15 kW (DC) • Machine weight: approx. 32 tonnes • CNC Control: Heidenhain TNC 320 WHY BUY FROM REM? ✔ Machine fully inspected and tested in working conditions ✔ Modern CNC retrofit – new electrics, new drives ✔ Documentation and technical support available ✔ Export worldwide | Competitive shipping Ideal for heavy component machining in aerospace, energy, and heavy industry. Contact us today for full technical specifications, photos, and video demonstration.

Condition: excellent (used), Year of construction: 2006, operating hours: 53,244 h, functionality: fully functional, Technical Data – Gleason Phoenix II 600HC (CNC Hypoid Gear Cutting Machine) Working Area Max. workpiece diameter: Ø 600 mm Max. tooth depth: 24.6 mm Max. gear width: 110 mm Number of teeth: 1–300 Pjdpfx Ansxwzu Iepjpu Cutterhead size face milling (FM): 18" diameter Cutterhead size hobbing (FH): 210 mm radius Max. cutter spindle speed: 600 min⁻¹ Work Spindle Front taper diameter: Ø 203 mm Taper bore diameter: Ø 181 mm Bore depth: 884 mm Max. work spindle speed: 600 min⁻¹ Dimensions and Weight Footprint L × W × H: 4.4 × 3.5 × 3.5 m (incl. peripherals) Machine weight: 26,000 kg Connection Data Total connected load: 139 kVA Main fuse: 200 A Operating voltage: 400 V Mains frequency: 50 Hz Control voltage: 24 V DC

Condition: used, Year of construction: 1988, Technical details: turning diameter over bed: 360 mm turning dia. over face-slide: 160 mm turning length: 800 mm longitudinal traverse (z-axis): 810 mm facing movement (x-axis): 205 mm control: TX-8 spindle passage: 60 mm revolution per minute: 63 - 3150 / 2 step U/min feed:: 10.000 mm/min. Ppjdpfsu Rqabjx Anpou tool turret - number of stations: 8 operating hours - idle run: 8834 h tailstock taper ISO: SK30 DIN 2080 tailstock quill stroke: 105 mm operating pressure: 40 bar total power requirement: 38 kW Weight approx.: 3,1 t dimension machine xH: 1,8 x 3,3 x 1,8 m dimensions of hydaulic: 580 x 400 x 750 mm Equipment: Lathe chuck Ø 200 mm, hydraulic Feed force Z-axis = 8 kN and X-axis = 5 kN Coolant system control panel Accessories Fine adjustment device for tool set-up *

Condition: good (used), Year of construction: 2006, operating hours: 40,000 h, functionality: fully functional, machine/vehicle number: M086, spindle speed (max.): 1,500 rpm, spindle speed (min.): 15 rpm, spindle motor power: 22,000 W, Vertical turret lathe with CNC Control: FANUC Series 18i-TB Number of turrets: 1 Number of tools stations: 12 Ppjdpfstmq Ukex Anpeu Chip conveyor: 3508734 Boring bar holder: dia. 50 mm The machine is still under power.
