Used Bench Lathe for sale (7,768)

Condition: good (used), Year of construction: 2006, control FANUC 21i-TB Control x-axis 390 mm z-axis 780 mm spindle taper A2-11 number of spindle speeds 2000rpm engine output 37 kW weight of the machine ca. 9000 kg dimensions of the machine ca. 1905,0 × 2720,0 × 3260,0 m Laodpfxsvzln Rj Am Nsa The machine has chucks that can produce gears from 100 to 500 mm. Special chuck is available

Condition: used, Year of construction: 2008, control 840 D Sinumerik weight of the machine ca. 25 t dimensions of the machine ca. 5100 x 3034 x 4500 mm Technical Details: Largest workpiece diameter Ø 1000 mm Internal workpiece diameter Ø 100-500 mm Largest workpiece length 500 mm Largest oscillation diameter 1250 mm Workpiece spindle flange diameter 520 mm Ledowwar Ispfx Am Nsaa Through-hole of the workpiece spindle Ø 45 mm Workpiece spindle speeds NC - programmable 0-440 rpm Table strokes: Z1/Z2 axis 1000 mm, X1/X2 axis approx. 1300 mm Table speed infinitely variable: Z axis 0-30 m/min, X axis 0-50 m/min Infeed speed infinitely variable 0.01-15 mm/min Infeed stroke-dependent 0.0005-0.1 mm Workpiece spindle positioning C-axis Operating voltage 3~400 VAC/50 Hz SINUMERIK 840 D control Machine connected load approx. 75 kW

Condition: good (used), Year of construction: 2019, machine/vehicle number: 25728, Equipped with: Hydraulic Unit Sinumerik 840D sl CNC Control Slim Line Operator Panel OP012 W/12 TFT-Color Display 19" Machine Control Panel 20 Tool ATC CAPTO C6 Multifunctional Tool Carrier For Turning and Driven Tools One Fixed Tool Unit Assembled To The Compound Slide W/Coolant Thru The Turning And Drilling Tools, Coolant For The Driven Spindle From The Outside Drilling Spindle Additional Drill Spindle For Orientation Chip Conveyor Coolant Equipment -Including piping and shut-off valve and flow control switch -To supply coolant to tools for coolant and flushing through the cutting tools -To supply coolant for flushing the work piece and chuck -To supply coolant for flushing the working area Paper Band Filter Immersion Cooler High Pressure Coolant Pump, 40 Bar Through Tools Flushing Pistol, Hand Held Air Cleaner - Mechanical Separation "Mist Collector" Tool Life Display Remote Diagnostics Signal Lamp Automatic Door For Loading W/Shuttle Load and Unload Shuttle Swivel Loader Automation Cell Tuned for Part Pallet Conveyor For 20 Raw And Finished Parts Pallets Pallets Designed for Part 596500 Handling System SPC Station (Maximum O 270 mm, Maximum H 150 mm, Maximum Wt. 12 kg) NIO Station (Closing forward leading gravity) Skiving Software (Hardware: Software and user surfaces for skiving technology) Measuring Probe (For measuring diameters and length of the workpiece in the machine) Measuring Software for Teeth Measuring (MDK and Flank Line, Software and User) Measuring Program (Automatically measuring program for measure the position of the two gears to each other, after using sister tools) SPC (Every X workpieces the MDK needs to be measured) Tool Changer (Precut, measurer and final cut) Skiving Tool Identification (Hardware, software for the identification of the skiving tool after tool change) Hydraulic Diagrams Coolant Diagrams Lubrication Diagrams Electrical Wiring Diagrams Hardcopy of Diagrams CF Certificates Specifications: Workpiece Spindle: -Speed: 0-7000 l/min -Power: 55,2 - 59,7 kW Tool: Capco C6 Tool Spindle: -Speed: 0-6000 l/min -Power: 29 - 41 kW Machine Weight, Floor Space and Voltage Supply: -Operating Voltage: 400V, 3 Phases, 50 Hz -Control Voltage: 24 V -Lighting Voltage: 240 V, 50 Hz -Floor Space: 2,700 x 2,600 mm -Height: 4,000 mm -Total Weight, Approximate: 16,000 kg Longitudinal, Z-Axis: -Stroke: 800 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Transverse, X-Axis: -Stroke: 900 mm -Rapid Rate: 24 m/min -Feed Force: 12 kN Tool Spindle, B-Axis: -Range: -20 / +90 Degree Y-Axis for Spindle Unit: -Stroke: 200 mm -Rapid Rate: 12 m/min -Feed Force: 6 kN C-Axis Main Spindle: Lsdpfx Amsw Iqums Njaa -Positioning Accurace: 9" Multifunctional Tool Carrier: -Power: 29 kW at 100% ED -Power: 41 kW at 44% ED -Torque: 141 Nm at 100% ED -Torque: 212 Nm at 44% ED -Spindle Speed: 0-6000 min-1 -B-Axis for Stepless Motion in a Range Of: -20/+90 Degree Tool Magazine: -Maximum Tool Diameter: 100 mm -Approximate Tool Length: 300 mm -Approximate Tool Weight: 12 kg Swivel Loader: -Maximum Workpiece Diameter: 270 mm -Height: 150 mm -Weight: 16 kg

Condition: good (used), Year of construction: 2015, machine/vehicle number: 190630, turning length: 150 mm, turning diameter: 200 mm, spindle bore: 42 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 50 rpm, travel distance X-axis: 150 mm, travel distance Z-axis: 155 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, turning diameter over bed slide: 220 mm, overall weight: 5,000 kg, spindle nose: 140 Flat, bar diameter (max.): 51 mm, power: 0.015 kW (0.02 HP), The innovative front-facing spindle of the 2SP-150H helps create an automation-friendly lathe for small parts production. By moving the spindle off the side and incorporating the Okuma Gantry Loader (OGL) into the production line, parts can be loaded and unloaded automatically. An extremely compact footprint improves floor space utilization, while the popular dual spindle option significantly reduces cycle time. Equipped with: Okuma OSP-P300L CNC Control Laodpfx Ajrtrlzjm Noa 8" 3-Jaw Chuck Expanding Mandrel Turret Tooling Gantry Loader Pendant Controller Chip Auger Stack Light

Condition: used, Year of construction: 2005, TAKISAWA TC 350M CNC TURNING CENTRE MAKE TAKISAWA, MADE IN JAPAN MODEL TC – 350M L5 CONTROL FANUC 21-iTB YEAR 2005 TURRET 12 STATION MAXIMUM SWING 500.0 mm MAX TURNING DIAMETER 370.0 mm MAX TURNING LENGTH 500.0 mm TRAVEL X-AXIS 300.0 mm Z-AXIS 550.0 mm SPINDLE SPEED RANGE 2,500 RPM BAR CAPACITY 75.0 mm TBC PLUS C – AXIS MILLING Ljdpfx Asy Eyb Eom Noaa TAILSTOCK TOOL SETTING PROBE SWARF CONVEYOR 12” 3 JAW CHUCK TURRET TOOLING

Condition: excellent (used), Year of construction: 2013, Swing 806mm, Swing over cross slide 527mm, maximum cutting diameter 305mm, 533mm maximum cutting length, 50mm Bar capacity, Lodpsy Ex T Tsfx Am Njaa 8” chuck, 20Hp Spindle Motor, C axis 0.01 degrees, Y axis +/- 51mm, 4000rpm spindle speed, 6,000rpm milling speed, 12 Station turret, parts catcher, tailstock, tool setter, coolant

Condition: good (used), functionality: fully functional, turning diameter over cross slide: 420 mm, spindle bore: 71 mm, turning diameter: 710 mm, turning diameter over bed slide: 710 mm, turning diameter over top slide: 420 mm, turning length: 3,000 mm, Model: SN 71 B Serial No: 071300780049 Swing Over Bed: 710mm Swing Over Top Slide: 420mm Swing In Gap: 960 x 300mm Spindle Speeds: 10-1000 RPM Spindle Bore: 71mm Ledpfxjy Duc Ie Am Njaa Motor: 7.5 KW Machine With: 625mm 4 Jaw Chuck Fixed Steady Quick Change Toolpost Dimensions: 5000 x 1500 x 1750mm Weight: 3250 Kgs

Condition: ready for operation (used), Year of construction: 2014, turning diameter over cross slide: 370 mm, turning length: 2,000 mm, spindle bore: 104 mm, spindle speed (max.): 2,000 rpm, Model: Alpha 1550 XS Year: 2014 Control: FANUC Oi-TD Lodpfoy Dubwjx Am Neaa Swing Over Bed: 554mm Swing Over Cross Slide: 370mm Swing in Gap: 830mm Distance Between Centres: 2000mm Spindle Bore: 104mm dia. Spindle Speeds: 1 to 2000 RPM Machine with: 3 - jaw chuck 4 - jaw chuck Fixed Steady Quick Change Toolpost

Condition: excellent (used), Year of construction: 2006, Doosan Puma 700L Turning Centre with Fanuc Series 21i-TB CNC Control, 600mm Diameter Powered 3 Jaw Chuck, 3000mm Between Centres, Swing 1030 mm Turning dia 900 mm Fixed steady included Chip conveyor Lodpfx Amey Akdle Noaa Spindle motor 45 kw Power requirements 62.2 kva Dims 7.1 x 2.2 x 2.2 m 10 Position Tool Turret, Tailstock, Machine Weight 21500kg. S/No. P60L0377 (2006) Machine is in excellent used condition Videos can be sent on request

Condition: used, YOM 2013 Chuck Size – 150mm Bar Capacity – 53mm Swing – 430mm Spindle Speed - 4,000 RPM Control - Siemens 802D Distance Between Centers – 1000mm X-Axis Travel – 220mm Z-Axis Travel – 1065mm Swing Over Cross Slide – 200mm Motor – 10 HP 4-Way Tool Post Tailstock Over Dimensions (Approx.) 2.75m x 1.3m Lodpfx Amsy Dtuis Njaa Weight (Est.) 2800kgs

Condition: used, 4 Axis Year Of Manufacture: 1998 8” Chuck Ledpsy Drunjfx Am Nsaa 2 Turrets – Turret 1 – 12 Stations Turret 2 – 8 Stations Programable Tailstock 750mm Between Centres Live Tooling C Axis Touch setter Y axis Swarf Conveyor Okuma OSP 7000L Control

Condition: ready for operation (used), Year of construction: 2008, spindle speed (max.): 6,000 rpm, overall weight: 6,500 kg, Fanuc 18ITB parts diameter 130 mm, length 110 mm spindle speed 7500 rpm 12-station turret Laedpfx Aox Irzvjm Nja max tool speed 6000 rpm power 24 kW, chip conveyor

Condition: good (used), Year of construction: 2000, functionality: fully functional, turning diameter over cross slide: 410 mm, turning length: 490 mm, turning diameter: 370 mm, spindle bore: 62 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 45 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 490 mm, rapid traverse X-axis: 25 m/min, rapid traverse Z-axis: 20 m/min, rotational speed (min.): 45 rpm, rotational speed (max.): 4,500 rpm, total height: 1,745 mm, total length: 2,200 mm, total width: 1,720 mm, overall weight: 4,200 kg, spindle nose: JIS A2-6" (DIN 55021-6), Equipment: rotational speed infinitely variable, The machine is still in good condition and comes very well equipped with tooling! Additional options & accessories: - Super-precision version with Turcite on the guideways of both axes, minimum input is 0.0001 mm in diameter and length. - Tool measuring arm Ledpfjy Eywtex Am Njaa - A large amount of tooling such as turning tools, 3-jaw chucks, soft jaws, etc. Weight & dimensions: approx. 4,200 kg 2,200 x 1,720 x 1,745 mm (LxWxH)

Year of construction: 2000, operating hours: 1,223 h, condition: used, total length: 3,900 mm, total width: 2,250 mm, total height: 2,040 mm, Empty weight: 5.000 kg - Year: 2000 - Documentation available: Yes - CE certificate present: No - Serial number: UC-2742 - Operating hours: 1223 - Drive system: CNC - Control system brand: Fanuc - Control system type: O-T - Power [kW]: 28.0 - Swing over bed [mm]: 520 - Carriage turning diameter [mm]: 350 - Distance between centres [mm]: 650 - Spindle bore [mm]: 87 - Max. spindle speed [rpm]: 3500 - Options: Turret, Three-jaw chuck, Chip conveyor - Transport dimensions: 3900mm x 2250mm x 2040mm (l x w x h) - Transport weight [kg]: 5000kg - Transport packages [pcs.]: 1 Laodpfxey Ew Ezs Am Nja Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), Vertical lathe BERTHIEZ Brand: BERTHIEZ Table diameter: 2550 mm Max. turning diameter: 2800 mm Machinable height: 2300 mm Max. load: 25 t Ledjy Egb Sopfx Am Nsaa Speeds: 1 - 160 rpm Floor dimensions: 4000 x 4000 mm

Condition: excellent (used), Year of construction: 2018, turning diameter over cross slide: 800 mm, spindle bore: 92 mm, turning diameter: 800 mm, turning length: 6,000 mm, total length: 9,000 mm, total width: 1,900 mm, total height: 2,100 mm, spindle speed (max.): 1,400 rpm, spindle speed (min.): 14 rpm, HeidenHain ND-780 with 3 axis Read-outX, Zo, Z  HeidenHain LS388C Scales 2 x CE Chuck covers for 500 & 900 mm SCHUNK 3 chuck Ø 400-102  Bison 4 chuck.... Steady rest Ø 30 - 210 mm Steady rest Ø 210 - 370 mm DBC Turning Length: 6000mm Swing over bed Ø: 800mm Swing over cross slide Ø:520mm Swing in the gap Ø: 870mm Gap length: 320mm Spindle bore: 92mm Spindle power: 15kW Bed width: 550mm Spindle taper: 6Mk Speeds / ranges: 14 - 1400rpm Length: 9000mm Width: 1900mm Height: 2100mm Weight: 7670kg Lasdpfxovn Svuo Am Noa

Condition: excellent (used), Conventional lathe Inv. no. 3506 Ayel-Tech Model BT 400 * Turning length: 1000 mm * Swing diameter: 400 mm * Spindle bore: 52 mm!!! * Spindle speed: 70 - 2000 rpm * 3-axis digital readout SINO Lajdpoxp Idgjfx Am Nsa * Foot brake * Coolant system * Machine lamp * Safety cover * Fixed steady rest * Follow rest * 3-jaw chuck * 4-jaw chuck * Emergency stop * Change gears * Chip guard/rear panel * Documentation * 400V

Condition: new, turning diameter: 360 mm, center width: 1,000 mm, – Centre distance 1000 mm – Swing over bed 360 mm – Swing over cross slide 215 mm – Swing in gap 540 mm Laodpsy Ev Tkjfx Am Noa – 45–1800 rpm – 2-speed motor – Spindle bore 51 mm – Longitudinal and cross feed – Digital position display (Sino) on three axes – Brake – Coolant system – Lighting – Safety cover – Fixed steady rest – Travelling steady rest – Three-jaw chuck – Four-jaw chuck – Emergency stop – Documentation – 400V

Condition: used, Year of construction: 1995, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, Mori Seiki Lathe 3 Axes X, Z, C Model SL-45 MC Year 1995 Fanuc CNC Without jaw chuck With tooling With chip conveyor With documentation Complete machine Laodpfxoy Emz Es Am Noa

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, CNC Turning and Milling Center Okuma Multus B300II-W Control: OSP-P 300SA Year of manufacture: 2022 Internal machine no. 55 X-axis: 580 mm Y-axis travel: (+80/-80 mm) 160 mm Z-axis: 935 mm B-axis: up to 225°, positioning in 0.001° increments W-axis: 1,000 mm Turning length: 900 mm Turning diameter: 630 mm Tool holder: HSK A63 Tool magazine: 40 positions Equipment: - Tool monitoring system Lajdpfsy Ewy Sex Am Nsa - Tool measuring device - ONE touch IGF - Hinged belt conveyor - Coolant tank incl. 20 bar pump - Preparation for in-process measurement - Tool height adjustment in Y-axis for turning tools - Hi-Cut Pro high speed control

Condition: used, Year of construction: 2001, turning diameter 550 mm turning length 900 mm control Fanuc O-TC weight of the machine ca. 8165 kg Lodpfx Ajx Sr Eiom Njaa

Condition: used, Year of construction: 2006, spindle speed (max.): 5,000 rpm, total width: 45,000 mm, total length: 19,900 mm, total height: 23,000 mm, travel distance X-axis: 165 mm, travel distance Y-axis: 80 mm, bar length: 600 mm, CNC Lathe (with 2nd spindle, 3 turrets and Y-axis) Spindle bore diameter 65 mm Spindle speed 5.000 R/min Spindle motor 25/20 kW Spindle speed counter spindle 5.000 R/min X-axis movement 165 / 165 / 165 Y-axis movement 80 mm Z-axis movement 220 / 150 / 650 mm W-axis movement (subspindle to mainspindle) 690 mm C-axis indexing 0,0001° Laodpfjy Egpiox Am Noa Number of turret 3 Number of tools on turret 12 (3x 12) Tool taper VDI 30 Bar feeder LNS Quick Load Servo 65 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, turning diameter over bed 1650 mm turning diameter over slide rest 1200 mm turning length 7500 mm turning dia. in gap 2500 mm spindle diameter 105 mm speed 3,55 - 180 (x24) U/min voltage 380 V 4-jaw faceplate Ø 1.600 mm Steady rest Ø 700 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. Lasdpfxoyqthbs Am Noa We look forward to your visit. Your Markus Hirsch Team

Condition: used, turning diameter over bed 1150 mm turning diameter over slide rest 800 mm turning length 6300 mm spindle diameter 100 mm speed 4-800 (x24) U/min turning dia. in gap 1500 mm Rapid toolpost Power compound Rapid traverse 4-jaw chuck ø (mm): 800 Laedpfx Asyqtl Hsm Noa Fixed steady rest ø (mm): 2x 400 Through-spindle cooling The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), Year of construction: 1983, Faceplate diameter: 1250 mm Max. turning diameter: 1400 mm Max. turning height: 1180 mm Max. ram stroke, vertical: 750 mm Table load capacity: 5,000 kg Faceplate speed range: 4 - 210 rpm Vertical slide swivel adjustment: 45° Feed range: 0.044-8 mm/rev Rapid traverse: 2 m/min Machine dimensions (L x W x H): approx. 2715 x 2665 x 3950 mm Total weight: approx. 16,500 kg Laodpey Ex Epsfx Am Nsa Accessories / Special features: • 2-axis digital display, make ACU-Rite • Faceplate Ø 1250 mm with 4 jaw chucks • 5-position turret head Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany
