Used Avia Face Plate Chuck for sale (16,311)

Condition: used, Year of construction: 2011, operating hours: 34,809 h, functionality: fully functional, TORNOS SA EvoDECO 16a with Elite 220 bar feeder Includes: - Base machine, 10 axes, FANUC 16i-TB - Synchronous 16mm rotating chuck including drive - C1 axis function - Polar coordinate function for C1 or C4 axis - S6 motor (8,000 rpm) for a maximum of 3 rotating tools on the tool system (X1-Y1), not synchronized with S1 - S2 motor (8,000 rpm) for a maximum of 3 rotating tools on the tool system (X2-Y2) - S3 motor (8,000 rpm) for a maximum of 3 end-facing rotating tools - Tailstock with positioned stop - C4 axis function - Limitation of the clamping stroke of the tailstock (system for fine adjustment of the clamping diameter) - Part extractor with adjustable pneumatic cylinder, including cleaning of the tailstock chuck with oil (maximum pneumatic cylinder stroke 150mm) - S5 motor (8,000 rpm) for a maximum of 6 rotating tools (synchronizable with S4) - 3-color light beacon, configurable (colors: yellow, red, green) - Centralized lubrication system, BIJUR type - Adaptation for operation without chuck (maximum part length 50mm) (requires one of options 0937 to 0941) - TB-DECO ADV programming software MOVABLE HEADSTOCK S1 (Z1) - 12,000 rpm - Right-hand bar rotation - Adaptation for SCHAUBLIN F22 chuck (no. 76-0071) TOOL SYSTEM (X1-Y1 / X2-Y2) - 2 independent carriages with 5 positions - 2 independent S2, S6 motors END TOOL - Independent carriage with 4 positions - Independent S3 motor INDEPENDENT TAILSTOCK (Y4-Z4) - 12,000 rpm - Adaptation for SCHAUBLIN F20 chuck (no. 76-201) COUNTER OPERATIONS (X4) - 6-position stations (3 end-facing and 3 transverse) MISCELLANEOUS - Device for evacuating and receiving parts outside the machine - Variable flow coolant pump - Lighting lamp - Electrical interface for fire protection system, compliant with CE and EMC standards NUMERICAL CONTROL - FANUC 16i-TB numerical control - 10" color screen - TB-DECO ADV programming software (version 750-005 + 750-0710) Itodpfx Anozd Shloyjk EQUIPMENT - Adaptation for F13 chucks - Long-type turning tool holder, 12x12mm or ½ inch section, right-hand bar rotation - Adaptation for chucks - Front clamping adjustment system for F13 chucks - Front clamping adjustment system for F20 chucks - Electrical interface 2004 (maxi2) including 2 sockets for adapting up to 2 peripherals of choice - Swiss 230 V socket - Oil mist extraction device

Condition: ready for operation (used), functionality: fully functional, WEILER COMMODOR from Bundeswehr stock -Good condition -Good operational condition -Maximum turning height 180mm -Maximum turning length 1000mm -Bar capacity 56 mm -Speed range 56 - 2000 RPM -Automatic longitudinal / facing feeds -Threading / Metric / Inch etc. -Tailstock MK 4 -Three-jaw chuck 250mm -Electric chuck guard -Multifix base and inserts -Coolant system -Chip guard -Machine documentation Isdpfxszuhfze Anystk Dimensions: L x W x H 2.5 x 1.3 x 1.7 meters / Weight 1500KG Errors and omissions excepted

Condition: used, diameter 550 mm hollow ca. 105 mm chuck width 105 mm weight / kg Ijdpsykva Tsfx Anyotk Face plate four-jaw chuck Diameter: Ø550mm Chuck width: 105mm Passage: approx. 105 mm

Condition: used, length 900 mm width 505 mm height 110 mm weight 310 kg The electro-magnetic clamping plate is in good, ready-to-use condition. Length: 900mm Width: 505mm Height: 110mm Weight: 310kg We have two identical magnetic chucks with the same dimensions. See Itedpezcgkyofx Anyok S9061

Condition: good (used), Year of construction: 1972, Turntable diameter: 1000 mm Torque at the spindle: 900 Itjdpfx Aozvbvpjnyek Total power requirement: 17 kW Machine weight (approx.): 6.1 t

Condition: like new (used), MACHINE DATA TORNI TACCHI FTC model 51 OVERALL DIMENSIONS Center distance 4000 m/m Height 1550 m/m Width 1400 m/m Length 6200 m/m Weight 10.000 Kg Swing over bed 1120 m/m Swing over carriage 810 m/m Swing over gap 1350 m/m Hole through spindle 123 m/m Number of speeds 18 Range of speeds 7-550 / 1’ Horsepower of motor 25HP Morse taper № 6 Metric threads – inch – module – pitch 3 jaw chuck 450 m/m Face plate 850 m/m Extra face plate 1420 m/m Itsdsd Tm D Eepfx Anyek Good condition

Condition: used, diameter 600 mm hollow ca. 195 mm chuck width 140 mm weight 300 kg Ijdpfxsvvx H Aj Anyetk Face plate 4-B Face plate chuck Four-jaw chuck Diameter: Ø800 mm Chuck width: 140 mm Clearance: approx. 195 mm Jaw width: 80mm Weight: 300kg

Condition: good (used), Year of construction: 1966, functionality: fully functional, Digital measuring device Centre height: 150 mm Swing over bed: 300 mm Turning diameter in the gap with face plate: 405 mm Distance between centres: 1000 mm 3-jaw chuck, with chip guard Multiflex toolholder Isdpjx Eah Aefx Anyotk Spindle speeds: 33 - 2000 rpm Chip tray Tailstock quill diameter: 45 mm, quill travel: 100 mm Taper: MK 3 Machine dimensions: 2500 x 800 mm Weight: 1180 kg Operating manual

Condition: good (used), Year of construction: 1996, functionality: fully functional, machine/vehicle number: VM0429, turning diameter over cross slide: 196 mm, spindle bore: 42 mm, turning diameter over bed slide: 350 mm, center height: 170 mm, turning length: 650 mm, quill stroke: 140 mm, total length: 1,900 mm, total width: 1,100 mm, total height: 1,300 mm, spindle speed (max.): 3,250 rpm, spindle speed (min.): 20 rpm, metric thread steps: 51, type of input current: three-phase, overall weight: 1,350 kg, quill mount: MK 4, Equipment: rotational speed infinitely variable, Lead and feed screw lathe with digital display Colchester Master VS 3250 Digital display, 3 axes, Heidenhain Center height: 170 mm Distance between centers: 650 mm Swinging diameter over bed: 350 mm Swinging diameter over cross slide: 196 mm Spindle speed, stepless, from 20-3250 RPM (3 gear stages) Year of manufacture: 1996 Spindle bore: 42 mm Spindle mounting D1 4“ Camlock Tailstock taper MK 4 Tailstock quill travel: 140 mm Coolant pump Central lubrication of guideways Electromagnetic spindle brake Halogen lamp Longitudinal feeds from 0.036 to 1.2 mm/revolution Cross feed: half of the longitudinal values 51 metric thread pitches from 0.2 to 14 mm 56 Whitworth thread pitches from 2 to 56 threads/inch 20 module thread pitches from 0.2 to 3.5 module 20 diametral pitch thread pitches from 8 to 56 D.P. Operating manual and spare parts list, English Weight: 1350 kg L x W x H: 1900 x 1100 x 1300 mm Motor: 7.5 KW Including accessories: 3-jaw chuck, brand Pratt Burnerd 4-jaw chuck, Ø 200, brand Bison Quick-change collet chuck with lever 15 pcs. collets, Ø 1/1.5/2/3/4/5/6/7/8/9/10/12/13/14/15 mm Itjdpfx Anjzp Nknjysk 16 sets of soft jaws for 4-jaw chuck Quick-change tool holder Multifix with 5 tool holders incl. facing tool, cutoff tool, and internal turning tool 1 pcs. center punch 1 pcs. drill chuck, Ø 1 to 13 mm

Condition: used, Year of construction: 2000, Lg.no. 24489 Iedpfx Aou Uqbkjnyjtk Technical data: - Load capacity ( vertical ) 100 kg - Flat plate diameter 400 mm - Passage opening 60 mm - Face plate manually steplessly tiltable 0 - 135 ° - Rotation infinitely variable motorized 0.05 - 5 m/min - E. foot switch for start - stop - Table height in horizontal position without rollers approx. 750 mm - 3 jaw chucks - Drive 220 V - Space requirement approx. W 450 x H 850 x D 650 mm - Weight approx. 60 kg

Condition: used, Cast bed Length: 2410 mm Width: 1500 mm Thickness: 550 mm 8 T-slots 50 x 27 mm Iedpfx Aezmxrienyetk with 2 opening (possibility to close them) 1 opening L 560 x W 500 mm 1 opening L 480 x W 360 mm Weight: approx 5 T

Condition: excellent (used), Year of construction: 2010, grinding length: 330 mm, grinding wheel diameter: 250 mm, total width: 1,765 mm, total length: 1,830 mm, total height: 2,441 mm, grinding diameter: 20 mm, type of input current: three-phase, workpiece diameter between centers: 20 mm, spindle speed (max.): 10,000 rpm, feed length X-axis: 29 mm, feed length Y-axis: 350 mm, feed length Z-axis: 100 mm, feed rate X-axis: 29 m/min, feed rate Y-axis: 350 m/min, feed rate Z-axis: 100 m/min, grinding spindle motor power: 9 W, grinding spindle speed: 7,600 rpm, overall weight: 3,000 kg, input frequency: 50 Hz, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, input voltage: 400 V, workpiece spindle speed (max.): 3,000 rpm, Equipment: rotational speed infinitely variable, Rollomatic ShapeSmart NP5 — CNC cylindrical grinding machine (pinch/peel) with 3-axis loading robot Year of manufacture 2010 · CNC pinch/peel cylindrical grinding machine · Ø 0.025–20 mm · 3-axis loading robot Five-axis pinch/peel cylindrical grinding machine from Rollomatic SA (Le Landeron, Switzerland) for the rough and finish machining of cutting tools, punches, micro-drills, and forming and ejector pins. The original factory invoice from Rollomatic from 2010 for this machine is available, which documents the design, drives, axis travels, and included equipment. KEY DATA - Grinding diameter Ø 0.025 – 20.0 mm · Shank diameter Ø 1.0 – 20.0 mm · Grinding length max. 330 mm - Control system GE FANUC 320iA, 8 axes (5 machine axes + 3 robot axes), NanoGrind user interface on PC - Roughing spindle 8.5 kW, wheel Ø 250 mm, max. 7,600 min⁻¹ · Finishing spindle 1.4 kW, wheel Ø 150 mm, max. 10,000 min⁻¹ - Workpiece spindle with collet chuck W20, 0 – 3,000 min⁻¹ - Axis travels Y 350 mm · Z 100 mm · X and V each 29 mm with glass scale, resolution 0.00005 mm - Loading robot 3 axes, workpieces Ø 1.0 – 16.0 mm, length 30 – 300 mm, magazine 150 – 1,000 pieces - 1830 × 1765 × 2441 mm · approx. 3,000 kg · 3 × 400 V, 50 Hz, max. 15 kW WHAT MAKES THIS MACHINE SPECIAL - Pinch/peel process: Roughing and finishing wheels engage with the workpiece simultaneously — high accuracy of roundness and short cycle times in one pass SCOPE OF DELIVERY - Machine complete: Machine bed, full splash guard, electrical cabinet, pneumatics unit, control panel with 15" screen and PC keyboard - Control system GE FANUC 320iA with 8 axes, Rollomatic NanoGrind user interface on PC - P4Smart software for offline programming and simulation - Roughing station with 8.5 kW spindle (90° design) and finishing station with 1.4 kW direct drive spindle, both with PerfectArbor mounting - Monoblock shank guide with pneumatic pressure lever - Workpiece spindle with collet chuck W20 - Integrated three-axis loading robot with base plate for Rollomatic cassettes - Cassettes and collet chucks from the machine's inventory — the exact scope will be listed definitively for the shipping date - Transport-safe packaging on a wooden pallet, loading onto your truck included - Coolant filter and cooling system as well as extraction are not included in the scope of delivery — both were centrally installed at the previous owner - Fire extinguishing system and grinding wheels are not included in the scope of delivery Iedpfx Aozvh Uxonystk AVAILABILITY AND INSPECTION Availability: End of September 2026, ex warehouse Velten. Demonstration, trial grinding and measurement only after prior appointment — installation and commissioning will be carried out by an external service partner. PROCESSING Location 16727 Velten near Berlin (Germany) · FCA Velten incl. loading · 100% prepayment · Delivery 1–2 working days after payment receipt · Price on request · All technical data in the attached data sheet. Technical data according to manufacturer's documents (Rollomatic factory invoice from 2010 for this machine and series catalog) — information provided, no agreement on characteristics within the meaning of §§ 434, 443 BGB. We will confirm individual values definitively during the inspection or upon specific request. Subject to errors and prior sale.

Condition: new, Year of construction: 2021, Optimill MB 4PV Drilling and Milling Machine including Accessories (New, Unused Condition): Itsdoyxyivjpfx Anyek Included accessories: - 20-piece set of packing plates - RTE 165 rotary table - SPW 12 58-piece clamping tool assortment - 4x SE55 leveling feet with vibration dampers - MK4/M16 ER32 3-20 mm collet chuck set Heavy, robust cast construction High smoothness due to ground gears running in an oil bath Forward and reverse operation Automatic quill feed with manual fine feed Motorized positioning of the Z-axis Motorized table feed for the X-axis Coolant system Machine lamp Gear head swivels ± 45° Massive dovetail guide of the column, hand-scraped, for maximum stability and precision Height-adjustable, large protective screen with microswitch Drill depth stop Digital position display DRO 5 Drilling / tapping function Heavy-duty, large cross table, precisely machined surface with T-slots and adjustable gib strips Solid cast machine base with chip tray Single-speed quality industrial motor Wide speed range from 60 - 2,760 rpm via 2 infinitely variable speed ranges SIEMENS SINAMICS V20 frequency inverter Dimensions and weights: Length approx. 1,600 mm Width/Depth approx. 930 mm Height approx. 2,110 mm Weight approx. 495 kg Drilling-Milling Head: Drilling-milling head tilt range ± 45° Drilling-Milling Capacity: Maximum face mill size: 63 mm Maximum end mill size: 26 mm Drilling capacity in steel (S235JR): 24 mm Continuous drilling capacity in steel (S235JR): 20 mm Electrical Data: Drive motor power: 1.5 kW Connection voltage: 400 V Mains frequency: 50 Hz Horizontal Milling Table: Length: 800 mm Width: 240 mm Distance vertical spindle to milling table max.: 420 mm T-slot size: 14 mm Number of T-slots: 3 T-slot spacing: 80 mm Coolant System: Coolant pump(s) drive rating: 100 W Standards and Approvals: Standard: DIN EN 55011 EMC class: C2 Travel Range: X-axis manual: 560 mm Y-axis manual: 195 mm Z-axis manual: 350 mm X-axis automatic: 480 mm Vertical Spindle: Throat: 258 mm Spindle taper: MK 4 Speed range: 60 – 2,760 rpm Number of speed ranges: 2 Speed control: electronic Drawbar: M16 Quill diameter: 75 mm Quill travel: 120 mm

Condition: used, Year of construction: 1973, machine/vehicle number: 24109, Equipped with: Stock Divider Hydraulic Work Clamping Chip Conveyor Cutter Clamping Bolt Iedpfx Anexdfa Ueyetk Index Plate Change Gears Hydraulic System Coolant System Specifications: Min. Outside Cone Distance: 2.75" Max. Cone Distance: 10" Max. Gear Pitch Dia.: 20" Cutter Diameters Utilized: 9 - 18" Root Angle: 55 - 80 deg. Face Width: 3" Number of Teeth: 20 -75 Diameter of Taper Hole at Large End: 3-27/64" Taper Per Foot: .50" Depth of Taper: .625" Cutter Speeds: 6.8 to 16.5 RPM Feeds (seconds/tooth): 3 to 9 Main Motor: 5hp, 900 rpm Hydraulic Motor: 7.5hp, 1800 rpm Approx. Floor Space: 118" x 86.5" Needed Overall Height: 70" Approx. Net Weight: 16,000 lbs Shipping Weight Boxed for Export: 17,000 lbs

Condition: as good as new (ex-display), Year of construction: 2020, operating hours: 200 h, functionality: fully functional, workpiece weight (max.): 150 kg, grinding length: 500 mm, grinding wheel diameter: 455 mm, grinding diameter: 300 mm, workpiece weight between centers: 150,000 g, type of input current: three-phase, workpiece diameter between centers: 500 mm, grinding wheel width: 75 mm, spindle speed (max.): 500 rpm, spindle speed (min.): 10 rpm, grinding spindle motor power: 7,500 W, overall weight: 4,600 kg, Demonstration CNC cylindrical grinding machine with automation setup Brand OKAMOTO Model OGM-350 P NCIII Isdpjzn U S Iofx Anyotk Year of manufacture 2020 Control: Fanuc Oi Model D Operating hours: approx. 200 hours Technical specifications Maximum swing diameter: 320 mm Maximum distance between centers: 500 mm Maximum workpiece diameter to be ground: 300 mm Maximum workpiece weight between centers: 150 kg Maximum workpiece weight: flange + chuck + workpiece: 40 kg Grinding wheel: Diameter x width x bore: 455 x 75 x 127 mm Wheel speed: Continuously variable Circumferential speed: 45 m/sec Grinding headstock (x-axis) Maximum travel: 300 Swivel angle: Non-swivel Workpiece table (z-axis) Travel: 870 mm Swivel angle: 0 – 10° Workhead Fixed/Live Center Design MK 4 Taper Chuck Spindle Bore Diameter 20 mm Spindle Speed ​​10 – 500 rpm Swivel Angle: Non-Swivel Tailstock Tailstock Type: Manual Fine Taper Adjustment Quill Travel 30 mm MK 4 Taper Chuck Drive Power Grinding Wheel Drive 5.5 kW Total Power 20 kVA Dimensions/Weight Length x Width x Height approx. 3400 x 2330 x 1950 mm Machine Weight approx. 4,600 kg Standard Equipment: 2 Carbide Centers Full FANUC Keyboard with Radius Compensation for Creating ISO Programs Workshop Programming: Graphic Software for Grinding and Dressing Cycles with Teach-in Function GAP Eliminator Shoulder Positioning Constant Table coolant flush 3 color LED lamp Documentation Leveling screws and support plates Operating tool set Accessories Automation preparation Automatic door Automation interface Grinding wheel guard fully open when door is open Miscellaneous Signal lamp Tailstock with electric quill retraction 1 flange 1 grinding wheel Options upon request: Paper belt filter on request Clamping devices on request Commissioning and training on request (Commissioning by Okamoto is required for warranty purposes) Transport on request

Condition: used, overall weight: 16,000 kg, first registration: 01/1999, loading space length: 5,394 mm, loading space width: 2,489 mm, loading space height: 2,576 mm, Year of construction: 1999, GLEICH VEHICLE CONSTRUCTION PR.+PL. ? ATLAS AK 190.1 ? 16.3M CRANE? ----VEHICLE HISTORY GERMAN VEHICLE VIDEO AVAILABLE UPON REQUEST 2 UNITS AVAILABLE / 1 WITH FASSI CRANE / 1 WITH ATLAS CRANE ----VEHICLE EQUIPMENT ----VEHICLE DATA GROSS VEHICLE WEIGHT: 16,000 KG OVERALL LENGTH: 7,450 MM ----CRANE PLATFORM MOUNTING POINTS: APPROX. 5.86 M ----CRANE SUPERSTRUCTURE ATLAS CRANE MODEL: AK 190.1 A4 YEAR OF MANUFACTURE: 1999 MAXIMUM WORKING PRESSURE: 300 BAR MAXIMUM LIFTING CAPACITY AT 2.2 M OUTREACH: APPROX. 6,550 TO 7,400 KG MAXIMUM OUTREACH: 16.3 M WITH APPROX. 710 TO 770 KG LIFTING CAPACITY CRANE OPERATED VIA SEPARATE DIESEL ENGINE ----BODY FLATBED WITH CURTAIN SIDE MANUFACTURER: Gleich Fahrzeugbau GmbH FLOOR MADE OF APPROX. 30 MM WATERPROOF BONDED FILM FACED PLYWOOD SIDE PANEL HEIGHT: 800 MM SIDE WALLS FOLDABLE AND REMOVABLE FIXED FRONT WALL REAR WITH DOUBLE DOORS AND BAR LOCKING MECHANISM LASHING POINTS INTEGRATED INTO EDGE PROFILE SUBFRAME MADE OF STEEL, AUXILIARY FRAME ACCORDING TO DIN EN 283 284 ----TARP/CURTAIN ROOF COLOUR APPROX. RAL 9010 SLIDING CURTAIN LIGHT GREY SLIDING ROOF, SIDEWAYS OPENING FRONT AND REAR ----INTERNAL DIMENSIONS LENGTH: 5.4 M HEIGHT: 2.57 M WIDTH: 2.49 M ----CONDITION UVV INSPECTION OF LOADING CRANE PERFORMED NO SAFETY-RELATED DEFECTS FOUND CRANE FULLY FUNCTIONAL CRANE REMOTE CONTROL AVAILABLE ----EXPORT SALES ONLY WITH DEPOSIT (MINIMUM 500 – 2000 €) EXPORT SALES ONLY WITH DEPOSIT MIN. 500 – 2000 € CUSTOMS EXPORT CLEARANCE (EXW) WITHIN 10 MIN. (APPROVED EXPORTER) 5-DAY, 30-DAY PLATES, AND 17–21 DAYS AUSTRIAN PLATES, EURO 1 VEHICLE RESERVATIONS ONLY VIA E-MAIL FUNCTION VERBAL RESERVATIONS ARE NOT VALID! A deposit of at least 500.00 € / 1,000.00 € is required for sales to EU or third countries. (For sales to the EU and third countries, a deposit/guarantee of at least €500.00 / €1,000.00 will be levied.) Subject to changes, errors, and prior sale! See more vehicles on our homepage: Sale is exclusively subject to our terms and conditions – see homepage. Important note – Important information: Despite careful verification of all details in our listing, errors may occur. Some of these may be due to transmission errors in the systems of the various platform providers. Therefore, all specifications are made without guarantee and do not represent legally binding characteristics. Iedpfxex Sbckj Anyjtk Legal notice: This sales advertisement does not constitute an offer in the sense of §145 BGB. Rather, it is information provided for the initiation of a contract. All details are given without guarantee and do not constitute warranted characteristics.

Condition: excellent (used), functionality: fully functional, Schaublin 135 High-Precision Lathe with 3-Axis K&C Digital Readout NEW and Accessory Cabinet in Excellent Ex-University Condition! Technical Data: >> Centre height: 135 mm >> Distance between centres: 630 mm >> Swing over bed: 315 mm >> Spindle mount: Camlock D1-4 >> Spindle bore: 40 mm >> Longitudinal and cross feeds: 0.025–0.35 mm/rev >> Metric thread pitches: 0.25–14 mm >> Tailstock: MT3 >> Infinitely variable speed range: 55–3000 rpm >> Total power requirement: 4.45 kW >> Weight: approx. 1200 kg Accessories: >> 3-axis digital readout by K&C (new), 12 months manufacturer’s warranty with user manual Functions: Switching mm/inch, coordinate selection ABS/INC, value halving, reference mark, tool programming for up to 200 tools, taper calculation, radius/diameter display, quick zeroing, count direction reversal >> Accessory cabinet containing: - 160 mm 3-jaw chuck with two sets of jaws Itsdpfxjx H Szyo Anyok - Multifix B toolholder with 3 pockets - Internal and external collets with quick-change system - Change gears - 4-jaw chuck - Face plate - Fixed and travelling steady rests - Coolant system - Centres - Operating manual - And much more About the machine: For sale is a Schaublin 135 high-precision lathe. The machine is in excellent condition, coming from a university and only lightly used. Equipped with a NEW K&C 3-axis digital readout and a comprehensive range of accessories. You are invited to inspect the machine under power on site to verify its condition.

Condition: used, Year of construction: 1973, turning diameter over bed 490 mm turning diameter over slide rest 280 mm turning length 2000 mm Itedpfxetqqvvo Anyek centre height 245 mm centre distance 2000 mm spindle bore 62 mm total power requirement 7,5 kW weight of the machine ca. 3,5 t dimensions of machine L x W x H 3,78 x 1,17 x 1,42 m Accessories: 3-jaw chuck 240 mmø, face plate 400 mmø, MULTIFIX-tool post, solid steady, coolant

Condition: used, Year of construction: 2026, CORMAK 400 metal lathes is a new, improved version of the popular metal processing lathes. Among other things, the tool holder cover, spindle bearing system, new digital readout have been improved. They are suitable for production plants, workshops and tool shops. They are perfect for unit and small lot production. NEW, IMPROVED MODEL !!! high-quality and reinforced spindle bearing system new guards system compliant with CE standards the latest model of digital axis reading reinforced and modernized lathe base with drawers for tools and an extendable chip tray Characteristics of the machine REINFORCED, RIBBED SURFACE OF THE LATHE'S BED PROVIDES MAXIMUM REDUCTION OF VIBRATION, ADDITIONALLY PRECISE GRINDED, HARDENED BED DIGITAL READOUT OF THE AXIS IN STANDARD EQUIPMENT LARGE SPINDLE BORE PROVIDES OPTIMUM PERFORMANCE 52 mm THE APPROPRIATE BED WIDTH ENSURES STABLE AND PRECISE WORKING CONDITIONS MACHINE EQUIPPED WITH HIGH-QUALITY AND HARDENED SPINDLE BEARING SYSTEM Isdpfx Anszp E A Tjyetk EFFICIENT MACHINING THANKS TO TWO AUTOMATIC FEEDS AND EQUIPMENT WITH A ROLLER AND A DRAFT BOLT HARDENED WHEELS IN THE SPINDLE GEAR ADJUSTABLE CLUTCH OVERLOADS ON THE PULL SHAFT POSSIBILITY TO MACHINE THE FULL RANGE OF THREADS WITHOUT REPLACING THE WHEELS IN THE GUITAR FEED CHOICE LOCK: THROUGH SCREW OR SHAFT THE REMOVABLE BRIDGE ENABLES THE WORKING OF ELEMENTS WITH AN INCREASED DIAMETER RETRACTABLE CHIP DRAWER AND TOOL DRAWERS FOR BETTER AND EFFICIENT WORK Technical data MAXIMUM TURNING DIAMETER 400 mm MAXIMUM TURNING DIAMETER OVER THE BED 250 mm MAXIMUM TURNING DIAMETER IN THE SELECTION OF THE BRIDGE 520 mm TURNING LENGTH IN DEAD CENTRES 1000 mm BED WIDTH 218 mm SPINDLE END CAMLOCK D5 SPINDLE CONE MK6 SPINDLE BORE 52 mm SPINDLE ROTATION RANGE 65-1810 rpm SPINDLE SPEED NUMBER 16 ranges RANGE OF LONGITUDINAL FEED (40) 0,053 - 1,291 mm RANGE OF TRANSVERSE FEED (40) 0,011-0,276 mm THE MAXIMUM DIMENSION OF THE TOOL 20 mm x 20 mm METRIC THREAD 0,4-7 mm INCH THREAD 4-60 T.P.I. MODULAR THREAD (22) 0,4-3 mm THREAD D. P. (28) 8-84 D. P. TAILSTOCK QUILL DIAMETER 50 mm TAILSTOCK QUILL STROKE 110 mm TAILSTOCK TAPER MT4 ENGINE POWER 2,2 kW PUMP POWER 0,1 kW WEIGHT 640 kg DIMENSIONS 2000x820x1650 mm EQUIPMENT digital readout steady rest follow rest 200 mm 3-jaw chuck 200 mm 4-jaw chuck face plate 280 mm dead center MK4 x 2 reduction sleeve MK6/MK4 keys PLEASE NOTE!!! This machine is a returned item; it has bodywork and paintwork damage but is in working order. NO WARRANTY!!!

Condition: used, Year of construction: 1995, functionality: fully functional, machine/vehicle number: 185, turning diameter over cross slide: 800 mm, spindle bore: 180 mm, turning diameter: 1,000 mm, turning diameter over bed slide: 1,000 mm, turning length: 2,000 mm, faceplate diameter: 900 mm, Potisje lathe PA - 50 - DC. Excellent condition. Itedpfeww Igmox Anyok Steady and following rests included, along with face plate. Cone attachment on the lathe.

Condition: excellent (used), Mounting plate, scribing plate, measuring plate, measuring table, straightening plate, scribing plate, test plate, inspection plate, precision measuring table -Clamping surface: 3000 x 2000 mm -Quantity: 3 mounting plates available -Price: per piece -Note: The mounting plates can be screwed together end-to-end, as the end faces are milled. -Possible clamping surfaces: 3x 3000 x 2000 mm (1x 9000 x 2000 mm) (1x 6000 x 3000 mm) -Sheet thickness: 60 mm -Plate: with supporting ribs Itjdpfx Answ Dzk Esyjk -Dimensions each: 3000/2000/H360 mm -Weight: 4500 kg/unit

Condition: used, Year of construction: 2007, greates pass round over bed 650 mm Swing dia. over traverse guideway 420 mm Distance between centres 2.000 mm control Sinumerik Siemens slide travel X-axis 440 mm slide travel Z-axis 2.000 mm turning speed range - main spindle 1 - 3.000 min/-1 power capacity - main spindel 33 / 27 / 22 kW transmission ratio 2 spindle diameter in front bearing 140 mm Itodjzp Rvlopfx Anyjk spindle bore 106 mm standard chuck diameter 250 - 400 mm spindle head DIN 55026 / A8 turret head 12 pos. turning tool - shaft cross cut 32 x 32 mm rapid traverse X: 5 m/min rapid traverse Z: 10 m/min feed range X: 0,001 - 1.000 mm/min feed range Z: 0,001 - 2.000 mm/min power feed coss 9.000 N power feed longitudinal 12.000 N diameter of quill 100 mm quill travel 200 mm taper of center MK 6 total power requirement 38 kW weight of the machine ca. 6,0 t dimensions of the machine ca. 6,0 x 2,5 x 2,0 m CNC - Lathe DMT KERN - CD 650 / 2000 - only 3,446 operating hours - incl. boring bar with holder for cross slide - incl. face plate 600 mm - incl. traveling steady rest max. 160 mm - incl. fixed steady rest max. 160 mm - incl. fixed steady rest max. 250 mm (not pictured) - incl. fixed steady rest max. 350 mm (not pictured) - incl. spare parts package - NO additional tools included

Condition: good (used), Year of construction: 1988, Description: Heavy-duty, high-precision horizontal lathe with Rohm hydraulic clamping system, slide with two working positions, Sauter 4-position tool turret, circular turning unit, CNC 6 axes, tailstock, chip conveyor. Suitable for both high-volume material removal and high-precision turning. Machine modified with a 2000 mm face clamping plate and increased in size. Year of production: 1988 Made in: Germany Itodpfxoxmb Ado Anysk Turning diameter over bed: 2500 mm Turning diameter over telescopic covers: 2200 mm Turning diameter over slide: 1400 mm Turning length: 6000 mm Three-jaw chuck table: 2000 mm Spindle bore: 200 mm Attachment for circular turning Workpiece weight: 4,500–40,000 kg Turret head: 4 positions Spindle speed range: 4 – 400 rpm Main motor Siemens 95.5 kW Maximum torque: 40,000 Nm Overall power requirement: 125 kW Control: CNC SIEMENS 8T, 6 controlled axes Machine weight: 43,000 kg Required space: 13,000 x 4,000 mm

Condition: ready for operation (used), Year of construction: 2018, operating hours: 14,317 h, functionality: fully functional, travel distance X-axis: 520 mm, travel distance Y-axis: 360 mm, travel distance Z-axis: 350 mm, controller model: Fanuc i, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 520 mm Travel range, Y-axis: 360 mm Travel range, Z-axis: 350 mm Spindle speed: 12,000 rpm Distance spindle to base plate: min. 150 mm / max. 500 mm Table area: 650 × 375 mm Table load: 2 × 200 kg Tool weight: max. 2.8 kg Tool magazine: 14 positions MACHINE DETAILS Control system: Fanuc i Dimensions & Weight Dimensions (L x W x H): 3,230 × 1,620 × 2,507 mm Machine weight: approx. 5,200 kg Operating hours: 14,317 h Itsdszul R Iopfx Anyok EQUIPMENT Rigid tapping – thread drilling without compensation chuck Spindle overspeed and power display Telescopic guards on the X, Y, and Z axes Rapid traverse in the X, Y, and Z axes Door safety switch 3-color indicator light Work area lighting Coolant supply from a 200-liter tank via adjustable coolant nozzles at the spindle nose Internal cooling Machine cover, closed on top / Top cover Oil skimmer Pneumatic clamping system A, 1 pair per pallet Automatic work area door with safety strip Coolant system with delivery pressure: 4.5 bar

Condition: good (used), Year of construction: 1975, Offer 24204 Isdpfx Anox Tqg Ijyjtk Technical data: - Maximum swing diameter over bed: 420 mm - Centre distance: 1000 mm - Spindle bore: mm - Tailstock quill taper: MT 4 - Tailstock quill travel: 200 mm - Spindle speeds: 40 - 2000 rpm - Longitudinal & facing feeds - Metric thread pitches - Imperial threads - Module threads - Drive: 400 V - Includes: 3-jaw chuck - SWS steel toolholder with 3 inserts - Space required: approx. W 2800 x H 1250 x D 950 mm - Weight: approx. 2200 kg
