Used Gleason Bevel Gear Shaping Machine for sale (70,747)

Condition: good (used), gear diameter: 508 mm, total height: 1,780 mm, total length: 2,990 mm, total width: 2,200 mm, MODEL 610 GLEASON GEAR ROUGHER/FINISHER Equipped with: Hydraulic Workholding Pendant Control Chip Conveyor Index Plate Geneva Cam Change Gears Hydraulic System Coolant System Manuals Specifications: Rjdertrykspfx Ankecd Maximum Gear Pitch Diameter: 20" Cutter Diameters: 9", 10.5", 12",14",16", 18" Whole Depth: 1.250" Root Angle: 60 to 80 deg. Face Width: 3.0" Extreme Ratio (Minimum): 2.25 to 1 Number of Teeth: 20 to 75 Diameter of Taper Hole at Large End: 3-27/64" Cutter Speeds (Per Minute) for Roughing: 15.6' to 87.7' Feeds (Seconds Per Tooth) for Roughing: 3 to 35 Cutter speeds (Per Minute) for Finishing: 6.8' to 20.5' Feeds (Seconds Per Tooth) for Finishing: 3 to 9 Floor Space: 118" x 86.5" x 70" H Weight: 17,500 lbs.

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. Rcjdpfx Anjw N S E Aekod The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: excellent (used), Capacity M16 module Rcjdpfx Anezql Ufsked Table diameter: 1,200 mm Maximum workpiece diameter: 1,500 mm Milling slide travel: 600 mm Table center hole diameter: 250 mm

Condition: used, Year of construction: 2005, Technical details: workpiece diameter: 63,5 mm centre distance: 350 mm honing length max.: mm total power requirement: kW weight of the machine ca.: 6 t dimensions of the machine ca.: 2,70x2,x2,60 m Technical data G0504 working space Length of the clamping surface mm 1550 Number of T-slots mm 2 Width of the T-slots mm 18 Distance between T-slots mm 180 Center height (tailstocks) mm 350 Swivel range of the fine wheel head (U-axis) degrees Center distance - tailstock / fine wheel min./max. mm 120/225 Input resolution (all NC axes) mm / degrees Delivery slide Movement range (= Z-axis travel) mm 105 Input resolution mm tool Outside diameter min./max. mm 225/275 Hole diameter mm 160 Width mm 60 workpiece Outside diameter min./max. mm 40-150 Module min./max. mm 1.25-4.0 Rcodpfx Answrh H Nsksd Tooth width max. Mm 45 weight Weight of the machine approx. Kg 5500 Operating fluid requirements Cooling lubricant recommendation, see chap. 8th Hydraulic fluid HLP D 46 approx. Itr 100 Speeds and feeds Tool speed (continuously adjustable) max. 1 / min 2000 Feed rates Rapid traverse / feed Z direction up to m / min 2 X direction up to m / min 2 U-direction up to m / min 2 V-direction up to m / min 2 C3 direction max.degree / sec 12 Electrical equipment Operating voltage V 400 Control voltage / lighting voltage V DC / AC 24/2 Frequency Hz 50 Power requirement approx. KVA 27 If the electrical installation has to be carried out according to customer specifications, only the information in the electrical documentation applies. Motor data Servo drives: Nm 1 / min Tool drive C1 27.0 00 Workpiece drive C2 27.0 00 X-axis 20.0 00 Z-axis 20.0 00 U-axis 6.0 00 Vertical portal (V1 axis) 6.0 00 Portal horizontal (U1 axis) Gripper axis of rotation C3 5.0 00 Loading slide (X1 axis) 5.0 00 Three-phase motors: KW 1 / min Hydraulic motor 1.5 1410 Central lubrication 0.07 Coolant pump 4 2840 Hydraulic equipment Delivery rate Itr / min 21 System pressure bar 50 Clamping pressure for: headstock max. Bar 35 Clamping tailstock min./max. bar 20 Only available if required. Not all limit values ??can necessarily be reached at the same time. If several maximum values ??come together in a processing task, performance restrictions must be expected! We reserve the right to make changes to the specified constructions, dimensions and weights *

Condition: good (used), Year of construction: 1980, machine/vehicle number: 622336, Offer 22681 Technical Data: Rsdpozp E Ucofx Ankscd - Drilling capacity in steel ST 60: 30 mm - Drill spindle mounting: MK 3 - Drill spindle stroke: 160 mm - 9 drill spindle speeds: 90 - 1450 rpm - Overhang: 300 mm - Table with 2 T-slots - Table dimensions: 400 x 450 mm - Max. distance table - drill spindle: 660 mm - Height adjustable via rack and pinion with hand crank - Drive: 400 V / 1.2 kW - Space requirement: approx. W 600 x H 2100 x D 850 mm - Weight: approx. 300 kg - Including: - Drill chuck - 10 HSS drill bits, 8 – 20 mm

Condition: defective spare-parts repository (used), functionality: not functional, workpiece diameter (max.): 400 mm, According to the electrician, the main motor needs to be rewound. The carbon brushes should be replaced, and two coils in the control cabinet need to be replaced as well. Up until the motor failure, the machine was fully operational. Rcedpfx Anezp R Tksked

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: K215202, working width: 120 mm, working height: 200 mm, overall weight: 3,500 kg, spindle speed (min.): 2,800 rpm, rotational speed (min.): 6,000 rpm, height adjustment type: mechanical, type of input current: three-phase, For sale: Reignmac RMM520 four-side moulder, 5-head configuration, designed for efficient, high-volume processing of wooden components. The machine is fully operational, carefully prepared for immediate use, and ready to be commissioned by the new owner. The offer includes a complete line with additional buffer magazines at both infeed and outfeed, facilitating material handling and increasing productivity. Technical specifications: - Manufacturer: Reignmac (Reignmac Machinery Co., LTD) - Model: RMM520 - Type: Four-side moulder - Number of heads: 5 - Working width: 20 – 200 mm - Working thickness: 8 – 120 mm - Spindle speed: approx. 6000 RPM - Power supply: 380 V / 50 Hz / 3 phase - Total power: 28.6 kW - Weight: 3500 kg - Year of manufacture: 2010/08 - CE: Yes Feed speed: - Feed speed after upgrades: up to 45 m/min Technical condition: - Machine is 100% fully functional - Ready for operation - On-site inspection at Layman furniture factory recommended (possibility to test in operation) Rcjdpfx Ansywkk Usksd Included equipment: - Reignmac RMM520 (5-head) - Infeed and outfeed buffer magazines - Safety guards with inspection windows - Control panel - Extraction system connections Important information: - Machine is sold without cutters / cutting tools Applications: - Drawer sides and furniture components - Mouldings, rails, blanks - Wooden elements for further processing On-site inspection at the company is possible. Forklift loading available. Please contact us for more information.

Condition: used, Year of construction: 1991, functionality: fully functional, total length: 4,920 mm, total height: 2,500 mm, total width: 2,855 mm, workpiece diameter (max.): 200 mm, For sale is a Mikron A35 CNC gear hobbing machine in well-maintained and operational condition. The machine impresses with its high precision, reliability, and productivity, and is ideally suited for the economical production of gears and toothed components. Technical data: Rodpfx Aozphw Tjnkscd Manufacturer: Mikron Model: A35 CNC Machining process: CNC gear hobbing Max. workpiece diameter: 200 mm Max. module: 3.0 / 4.5 Max. workpiece length: 400 mm Cutter speed: up to 1,500 rpm The technical specifications correspond to the standard specifications of the Mikron A35 CNC. Condition: Fully functional Regularly maintained Inspection possible under power after prior arrangement Available immediately or by agreement.

Condition: excellent (used), max. wheel diameter 175 mm gear width 350 mm max. module 3 min. module 0,5 Rodsznnitjpfx Ankscd weight of the machine ca. 0,9 t dimensions of the machine ca. 1,2 x 0,8 x 1,4 m

Condition: ready for operation (used), The U2PRW cutting and drilling machine is designed for processing slats and furniture fronts made of solid wood or MDF. The machine works in a semi-automatic cycle. During one cycle the machine performs: cutting at a given angle (in the range of 45 - 90 degrees) and drilling in the jammed plane, or the edge of the element. - Made in Poland TECHNICAL PARAMETERS: Rcjdoq Ii Dlopfx Ankjd max. height of cut material 60 mm max. width of cut material at an angle of 45° 70 mm max. width of the material at an angle of 90° 150 mm max. length of cut material 2200 mm min. length of cut material at 45° 455 mm diameter of main saw 250 or 300 mm undercutter diameter 100 mm max. diameter of bottom milling cutter 35 mm max. depth of bottom milling 15 mm diameter of face drill embedment and bottom milling cutter 10 mm Drill head (face drilling): spindles 4 axial spacing of spindles 32 ; 32 ; 40 mm linear arrangement of spindles max. depth of face drilling 60 mm installed power 7 kW working pressure 0.6 Mpa overall dimensions (length / width / height) 4300 / 1600 / 1570 mm Machining units The machine is equipped with two machining units. The left unit, which is fixed, and the right unit - a sliding unit. Each machining unit consists of the following sub-assemblies - units: a main saw, an undercutting unit, a drilling unit that drills into the jammed plane, and a drilling unit that drills into the bottom of the workpiece. Bottom hole drilling unit The described aggregate is installed as an option. It is used in the processing of corner ties for doorframes with adjustable width. It makes a blind bore , for the can connector. The picture shows the mounted red cover which is at the same time the base for the machined angle strips and the cover with chip extractor. Workpiece pressure The machine tool is also equipped with a clamping system operating in two planes. The clamping area includes horizontal and vertical clamps. The horizontal clamps are responsible for pressing against the vertical bases and straightening the workpiece. Vertical ones, on the other hand, are responsible for immobilizing the workpiece during machining. The horizontal pressure always precedes the vertical pressure. Control The machine's control is clear, easy to use and functional. It allows switching on or off all aggregates separately, additionally with division into left and right sides. All aggregates have independent drive. The right-hand processing unit is set by pressing the control buttons on the control panel. The executive mechanism is a gearbox with an electric motor driving a trapezoidal screw. An electronic control system US with an operator panel and digital display is used to read and set the length of the workpiece. This system is also responsible for automatic corrections to the counter readings when the cutting angles change by 45° and 90°. In addition, it is responsible for automatic basing.

Condition: used, Year of construction: 1967, functionality: fully functional, machine/vehicle number: 150:10486, gear diameter: 150 mm, total height: 1,400 mm, total width: 800 mm, workpiece diameter (max.): 150 mm, spindle speed (max.): 1,000 rpm, spindle speed (min.): 112 rpm, overall weight: 1,300 kg, tool diameter: 50 mm, For sale is a reliable Koepfer 150 gear hobbing machine. This machine is ideally suited for the economical production of spur gears, pinions, and other types of gears, both for individual parts and for series production. Rcjdezfhyyepfx Anked

Condition: excellent (used), functionality: fully functional, I would be happy to add technical data to the document for you. Gear Hobbing Machine conventional Country of origin: Germany Technical specifications Details Rcsdpfx Anozmqaloked max. wheel diameter 600 mm gear width 250 mm max. module 8 total power requirement 2.2 kW machine weight approx. 2000 kg machine dimensions approx. 2500 x 1600 x 1900 mm cutter diameter max. 250 - 285 mm clamping table diameter 460 mm table hole 70 mm accessories: various Control unit conventional Additional information Documents I would be happy to add technical data to the document for you. I would be happy to add technical data to the document for you. Gear Hobbing Machine

Condition: excellent (used), Year of construction: 1972, functionality: fully functional, For sale: this involute gear grinding machine. It is connected and can be tested. Comes with numerous accessories. Technical specifications: max. gear diameter: 7100 mm gear width: 1500 mm max. module: 45 table diameter: 4000 mm grinding wheel diameter x width: 400 x 500 mm max. helix angle: 45 degrees hobber diameter: 500 mm hobber speed: 9–63 rpm total power consumption: 47 hp Rcodpfexwlthox Ankjd Machine weight: 160,000 kg A video of the machine can be sent via WhatsApp.

Condition: ready for operation (used), Year of construction: 1959, functionality: fully functional, machine/vehicle number: 80, total height: 1,900 mm, total width: 2,200 mm, total length: 1,500 mm, power: 5 kW (6.80 HP), empty load weight: 2,500 kg, No minimum price – guaranteed sale to the highest bidder! MACHINE DETAILS Drive system: Conventional Power: 5.0 kW Dimensions & Weight Dimensions (L x W x H): 1,500 x 2,200 x 1,900 mm Weight: 2,500 kg Rcsdpfjzk Dzqex Anked Transport packages: 3 EQUIPMENT Documentation

Condition: good (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: 107253, Please provide us with your offer price. Rjdpozlrfyofx Ankecd Sales only within Europe, including Turkey. Price excludes packaging; delivery condition: FCA (machine location). ===== Technical data can be found in the attached handout. Any warranty is excluded. We assume no liability for the accuracy of the technical data and year of manufacture, for the completeness of accessories and tool equipment, or for compliance with all safety and environmental protection requirements mentioned in the accident prevention regulations. No sales to private individuals.

Condition: refurbished (used), I.M.M.U. BONARDI PLANO MILLING MACHINE - DISTANCE BETWEEN COLUMNS 1220mm - LENGHT 4000mm - HEIGHT 950mm Rsdpfod Avz Iex Ankjcd

Condition: excellent (used), Year of construction: 2008, Siemens Sinumerik 840 D, 5 axes controlled. Rcodpfx Asza Egbenkjd Wheel diameter max 2000 mm 700 mm wheel width Machine weight 35,000 kg Space requirements approx. 6.9 x 8.4 x 3.7 m

Condition: ready for operation (used), functionality: fully functional, Material thickness: 3 – 35 mm Cutting speed: variable, max. 1.8 m/min Rcedpfx Aoyk U I Asnksd Minimum material length at edge: 60 mm Maximum edge width: 12 mm (adjustable) Edge head motor power: 400 W Edge head: resharpenable Edge angles: 30°, 45°, 22.5°, 37.5°, 50° Dimensions: 470 x 294 x 523 mm Machine weight: 30 kg

Condition: good (used), max. module 2 Rcjdszkvuvjpfx Ankod hobbing length 135 mm total power requirement 2,2 kW weight of the machine ca. 1420 kg dimensions of the machine ca. 2,00 x 1,60 x 1,43 m --> Technical specifications Maximum milling diameter: Ø 150 mm --> Maximum milling length: 135 mm --> Maximum module: 2 --> Spindle bore: Ø 24 mm --> Spindle mount: MK-4 --> Cutter speeds: 140–1120 rpm --> Automatic feeds Equipment and accessories: Coolant system, cutters, change gears, operating instructions

Condition: used, Year of construction: 2004, functionality: fully functional, CNC gear hobbing machine Control: Siemens 840 D Power Line Rsdpjzkwvnefx Ankocd Technical data: Max. workpiece diameter: 150 mm Table diameter: 145 mm Max. table speed: 800 rpm Distance between centers: 10 – 200 mm Max. axial travel: 250 mm Swivel angle of milling head: +/- 45° Max. tailstock travel: 300 mm Max. rapid traverse rate: 17,000 mm/min Drive power of milling head: 19 kW Max. module: 3 mm Max. speed of milling spindle / tool speed: 4,500 rpm Max. diameter of hobbing cutter: 80 mm Max. length of hobbing cutter: 200 mm Dimensions approx.: 5.5 x 3.7 x 3.1 m Weight approx.: 9,500 kg Equipment: Chip conveyor Oil mist extraction / oil extraction Oil cooler Steady rest with lowering device and vertical adjustment Rotary ring loader with two workpiece grippers Loading belt system for automatic feeding 5 milling arbors / hobbing cutter holders: 1 x Ø 22 mm 2 x Ø 27 mm 1 x Ø 32 mm 1 x Ø 40 mm Other: Video recordings via WhatsApp

Year of construction: 1991, condition: good (used), Ref. -No.: 10656 Redpfezkpx Usx Ankjcd Manufacturer: PFAUTER Type: PE 150 Year of construction: 1991 Type of control: CNC Control: Sinumerik 840 Storage location: Halberstadt Country of origin: Germany Turning Speeds: 150 - 600 RPM Tool Taper: SK 40 Machine length: 4700 mm Machine width: 3600 mm Machine Height: 2800 mm Weight: 8 t Workpiece Diameter: 150 mm Maximum tooth width.: 150 - 200 mm Table diameter: 160 mm Table drilling: 63 mm Max. cutter diameter: 130 mm Max. cutter length: 220 mm swivel angle: +/- 45° Further information: - The machine has been completely converted to Siemens 840D, including the motors and control cabinet. - The milling head was completely overhauled by Pfauter in 2013. - The low-voltage system and magazine conveyor are included. - It is equipped with a deburring station. The machine can be viewed while powered on by prior arrangement.

Condition: used, Year of construction: 1980, max. wheel diameter 2500 mm gear width 0 mm max. module 34 min. module 1 total power requirement ca. 15 kW weight of the machine ca. 15 t dimensions of the machine ca. 4,20 x 2,00 x 2,90 m Rodpfx Ast Hw Aaonkjcd Extra große ZR-Prüfmaschine, Gegenhalter

Condition: used, Year of construction: 1980, max. wheel diameter 2500 mm gear width 1200 mm max. module 32 min. module 3 total power requirement 25 kW weight of the machine ca. 60 t dimensions of the machine ca. m Gear , min. / max. 180 / 2,500 mm Module 3 - 32 Helix angle, max. 10 - 35 ° Gear width for straight gears 1,200 mm Stroke length, approx. 100 - 1,200 mm No. of strokes 80 - 350 /min Stroke position adjustable 300 mm Stroke speed 4 - 40 mm Max. weight of workpiece, approx. 18,000 kg Min. / max. no. of teeth 16 / 576 Table size x bore 1,400 x 500 mm Grinding wheel Ø, approx. 500 mm Grinding wheel peripheral speed 34 m/s Total electrical load, approx. 45 kW - 380 V - 50 Hz Weight of machine, approx. 60,000 kg Accessories / Special Features: * Hydrostatic guides in grinding slide, table and in all other guideways. * Completely covered working area with sliding doors. * Automatic grinding process for various cycles, with settings for roughing, finishing, fine finishing and automatic dressing cycle after preset number of teeth. * Profile correction is possible via appropriate dressing, as well as additional movement of grinding slide (depth and width crowning). * Approx. 50 change gears. * Grinding slideTilt display device. * Large coolant device with band filter and oil mist exhaust. * Separate switch cabinet. * Separate hydraulic unit. * Separate oil cooling unit. Condition : Very good. Machine can soon be inspected in our showrooms. Rcodpfet Hwqqox Anked It is not under power at present. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. The machine comes directly from a first class gear factory, where it was grinding Quality 5 - 6. Grinding diagrams are available. This type and quality of machine is rarely available. Thank you for your interest. We always have a good selection of gear machines available. Please let us know what you need.

Condition: used, Year of construction: 1996, workpiece diameter 240 mm centre distance 0 mm honing length max. 500 mm max. module 5 total power requirement 12 kW weight of the machine ca. 5000 kg Rcjdpfxet Hwvms Ankod dimensions of the machine ca. m

Condition: used, Year of construction: 1985, max. wheel diameter 80 mm gear width 150 mm max. module 2,5 min. module total power requirement 10 kW weight of the machine ca. 2400 kg M I K R O N (Switzerland) Fully Automatic Gear Hobber for Worm Gears Model A 33 / 1 Year 1985 Ser.-No. 14.06/14.07/14.15 _____ max. gear- without feed magazine approx. 80 mm max. gear- with feed magazine approx. 50 mm Module max. 2, / 2,5 Axial milling length approx. 150 mm max. workpiece-mounting length approx. 200 mm Milling slide can be swivelled up to 90 degrees Milling cutter - 24 - 50/63 mm Rsdpfet Hw D Rsx Ankjcd Max. radial distance of milling slide 0-14/18 mm Milling cutter adjustment max. 25 mm Milling cutter speed 212 - 2.000 rpm Axial feed range infinitely adjustable 0,05 - 4,0 mm/workpiece rotation radial infinitely adjustable 0,2 - 200 mm/min. Milling spindle drive 3 kW Total electrical load approx. 10 kW - 50 Hz - 380 Volt Weight approx. 2.400 kg Accessories/Special Features: " Fully automatic operation cycle and minimum idle times due to programmable SIEMENS Program Controls S 5 for all machining steps i.e. rapid gear, feed, milling cutter on/off for the loading device, tailstock, possibly shifting, etc. with unit counter, program numbering including 30 different numeric error displays Pneumatic workpiece-loading and unloading facility parallel to work piece axis upright for rod workpieces approx. 140 mm long x 8 mm , including pneumatic double gripper for loading and unloading of work pieces. Raw parts are inserted into change cassettes externally and then placed into the loading device. The double gripper places the parts between workpiece spindle and tailstock, the tailstock spindle sleeve pushes the parts in the main spindle collet and clamps them simultaneously. The finished parts are ejected from the main spindle, then placed back again into the finished parts cassette by the gripper. The whole process is electrically monitored and checked. The complete loading facility is encased by plexiglass. " Hydraulic work piece clamping device including collets and hydraulic ejector " separate cooling system with magnetic separator * separate hydraulic system * various change gears This machine is set up for worm gears/armature shafts that can be used for adjustable car seats, window lifters, etc.
