Used Fagor Double Column Drawing Press - Mechanical for sale (28,778)

Condition: used, Year of construction: 2005, Pressure total: 400 ton Ram stroke: 500 mm Slide adjustment: 350 mm Daylight: 1250 mm Table surface area : 2500 x 1500 mm Slide area: 2500 x 1500 mm Die cushion capacity in table: 80 ton Die cushion stroke: 250 mm Lredpfx Akownn Rteujl Number of strokes: 15 - 30 s.p.m. Die weight at the ram max.: 4000 kg Required power: 70 kW Height over floor approx.: 8000 mm Weight of machine approx.: 150 ton Standard configuration 2 cushion cylinder 2 pads

Condition: used, Year of construction: 1986, Pressure total: 500 ton Stroke: 1100 mm Daylight: 1500 mm Table surface area : 2000 x 1250 mm Slide area: 2000 x 1250 mm Die cushion capacity in table: 160 ton Die cushion stroke: 300 mm Lodpfx Aksuqdqleuorl Approach speed: 650 mm / sec Required power: 55 kW Weight of machine approx.: 50 ton Standard configuration The press was completely overhauled mechanically, hydraulically and electrically in 2008.

Condition: used, Year of construction: 1989, Pressure total: 1400 ton Stroke: 950 mm Daylight: 2000 mm Table surface area : 3600 x 2500 mm Slide area: 3600 x 2500 mm Lredjuqdi Uepfx Akuol Die cushion capacity in table: 400 ton Die cushion stroke: 500 mm Die cushion pad area: 3060 x 1860 mm Approach speed: 400 mm / sec Working speed: 40 / 80 mm / sec Return speed: 400 mm / sec Oil volume: 5000 l Required power: 450 kW Weight of machine approx.: 240 ton Standard configuration with hydraulic tool clamps on the ram

Condition: used, Year of construction: 1996, machine/vehicle number: 14.194, Pressure total: 80 - 800 ton Ram stroke: 1600 mm Free frontal opening L-R: 2850 mm Free lateral opening F-B: 1000 mm Ljdpfx Aou Saaaskuorl Daylight: 1900 mm Table surface area : 2800 x 2000 mm Slide area: 2800 x 2000 mm Die cushion capacity in table: 32 - 320 ton Die cushion stroke: 400 mm Die cushion pad area: 2500 x 1700 mm Approach speed: 400 mm / sec Working speed: 5 -42,7 mm / sec Return speed: 420 mm / sec Required power: 246 kW Height over floor approx.: 7785 mm Weight of machine approx.: 100 ton No. of moving bolster: 1 pcs.

Condition: used, Year of construction: 2002, machine/vehicle number: 10857, Pressure total: 315 ton Stroke: 1100 mm Daylight: 2200 mm Table surface area : 2500 x 1000 mm Slide area: 2500 x 1000 mm Die weight at the ram max.: 6000 kg Approach speed: 600 mm / sec Working speed: 32 - 230 mm / sec Return speed: 600 mm / sec Required power: 158 kW Weight of machine approx.: 44 ton Lredpevmfzbofx Akusl Height over floor approx.: 6175 mm Automation

Condition: used, Year of construction: 2005, Pressure total: 400 ton Ram stroke: 500 mm Slide adjustment: 350 mm Daylight: 1250 mm Lrodjwnpavepfx Akuol Table surface area : 2500 x 1500 mm Slide area: 2500 x 1500 mm Number of strokes: 15 - 30 s.p.m. Die weight at the ram max.: 4000 kg Required power: 70 kW Height over floor approx.: 8000 mm Weight of machine approx.: 150 ton Standard configuration without cushion

Condition: used, Year of construction: 2006, machine/vehicle number: 18282, Pressure total: 140 ton Stroke: 800 mm Daylight: 1.004 mm Free frontal opening L-R: 2.060 mm Table surface area : 2.000 x 520 mm Slide area: 2.040 x 520 mm Working speed: 4 -20 mm / sec Rapid travel: 135 mm / sec Return speed: 120 mm / sec Weight of machine approx.: 14 ton Height over floor approx.: 4.810 mm Lrodpfx Aksuqd Nueuol Oil volume: 700 l

Condition: used, Year of construction: 2006, machine/vehicle number: 18282, Pressure total: 140 ton Stroke: 800 mm Lrsdjuqd S Aspfx Akusl Daylight: 1.004 mm Free frontal opening L-R: 2.060 mm Table surface area : 2.000 x 520 mm Slide area: 2.040 x 520 mm Working speed: 4 -20 mm / sec Rapid travel: 135 mm / sec Return speed: 120 mm / sec Weight of machine approx.: 14 ton Height over floor approx.: 4.810 mm Oil volume: 700 l

Condition: excellent (used), Year of construction: 2016, Specifications Manufacturer: IMV Model: DM125 Year: 2016 Condition: Used Lodpfx Aoyw Uf Ajkuorl Stock number: 0396 Ram force: 1,250 t Number of press points: 2 Drive: Eccentric with stroke adjustment Ram stroke: 250–400 mm Strokes/min: 5–35 Vertical daylight below bolster, CBRA: 1,150 mm Table dimensions: 4,500 x 2,000 mm Ram dimensions: 4,500 x 2,000 mm Side column window: 2,600 mm Max. front column window: 4,900 mm Transfer cart: 2 units present Main motor power: 290 kW Press weight: 310,000 kg

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, pressing force: 250 t, table width: 1,200 mm, table length: 2,000 mm, overall weight: 55,000 kg, DGUV certified until: 09/2026, ram adjustment: 150 mm, stroke adjustment: 40,200 mm, Raster Punching and Forming Press RSU 2500 - 2000 P Desch Compact Drive Electronic Press Force Measurement System Hydraulic Overload System 3-part Tie Rod, Cast Design Tool Carrier Table and Ram Clamp Raster VWA Hydraulic Roller Feeder, Band Width 500 mm, with Topochrom Roller Coating Ram Surface: 1000 x 2000 mm Strokes per minute: 20 – 150 Lrjdpfx Ajxcbbrekujl Stroke Adjustment: 40 – 200 mm Raziol Segment Roller Oiler Optional with Kohler Strip System 20030.400/9-2000.2H

Condition: used, Year of construction: 1998, machine/vehicle number: 1 / 2000, Pressure total: 2000 ton Ram stroke: 900 mm Slide adjustment: 800 mm Shut height (stroke down, adjustment up): 1800 mm Free frontal opening L-R: 5040 mm Distance between oil tray: 4840 mm Distance between the columns F - B: 2600 x 2400 mm Table surface area : 5000 x 2700 mm Slide area: 5000 x 2700 mm Die cushion capacity in table: 400 ton Die cushion stroke: 350 mm Die cushion pad area: 4200 x 2100 mm Cushion pressure in ram: 200 ton Ejector stroke in ram: 200 mm Number of strokes: 8 - 14 s.p.m. Required power: 350 kW Height over floor approx.: 11350 mm Die weight at the ram max.: 40000 kg Die Weight total: 80000 kg Weight of machine approx.: 580 ton Standard configuration Moving bolster front sidePin diameter 52 mmForce in microinches = 400 tA SIEMENS control system is installed Lredpjyvz U Iefx Akujl The documentation is available.A packing list would be available, as an identical press has already been dismantled.

Condition: used, Year of construction: 1998, machine/vehicle number: 2 / 2000, Pressure total: 2000 ton Ram stroke: 900 mm Slide adjustment: 800 mm Shut height (stroke down, adjustment up): 1800 mm Free frontal opening L-R: 5040 mm Distance between oil tray: 4840 mm Distance between the columns F - B: 2600 x 2400 mm Table surface area : 5000 x 2700 mm Slide area: 5000 x 2700 mm Die cushion capacity in table: 400 ton Die cushion stroke: 350 mm Lrodpfx Aoyvz Stjkuel Die cushion pad area: 4200 x 2100 mm Cushion pressure in ram: 200 ton Ejector stroke in ram: 200 mm Number of strokes: 8 - 14 s.p.m. Required power: 350 kW Height over floor approx.: 11350 mm Die weight at the ram max.: 40000 kg Die Weight total: 80000 kg Weight of machine approx.: 580 ton Standard configuration Moving bolster front sidePin diameter 52 mmForce in microinches = 400 tA SIEMENS control system is installed The documentation is available.A packing list would be available, as an identical press has already been dismantled.

Condition: as good as new (ex-display), Year of construction: 2022, pressing force: 400 t, Press design double column press Thermally neutral 80 - 120 °C Number of operating sides 1 side Forces Pressing force max. 4000 kN Free ripping force max. 400 kN Pressure build-up time Closed die steel to steel Max. 4 sec. Dimensions 3,800 mm long and 4,475 mm wide Max. Opening width 800 mm Stroke 800 mm Table height above floor 1100 mm Height above floor (headroom) approx. 4300 mm Lrjdpfx Akeph Uk Neusl Hall height min. 5500 mm parallel deviation at 20°C +/- 0,1 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.2 mm/m Weight Total weight of press without operating materials and table plate approx. 28 t Press table Table size 1500x1500 mm Speeds Fast closing with 100 mm sec. Pressing speed 8 - 3 mm sec. Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of pressing cylinders/driving cylinders 1 pc. Operating pressure max. 300 bar Pressing pressure build-up time 4 sec. Pressure accuracy during pressing stroke +/- 3 bar Main pump BOSCHREXROTH axial piston pump approx. 145 L/min Oil volume approx. HLP 46 MW 1000 liters Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Auxiliary pump BOSCHREXROTH, gear pump 10 L/min Pressure stabilization for up to 300 sec. Electrical system Main supply 400 V AC Control voltage 24 V DC Frequency 50 Hz Connection hydraulics main motor 40 kW Sliding table press with 400 T capacity, Closing speed up to 100 mm/ ( adjustable via touch screen ) Opening speed up to 100 mm/sec ( adjustable via touch screen ) Starting press speed 10 mm/sec ( adjustable via touch screen ) table top size 1500x1500mm ram size approx. 1600x1500mm Oil temperature monitoring 55 degree warning, 60 degree shutdown Automatic lubrication ( adjustable via touch screen ) Free positioning of the ram ( adjustable via touch screen ) SICK/PILZ light barriers 14 mm, front, up to 1800 mm height Hydraulic and mechanical ram protection Circuit oil cooling ( adjustable via touch screen ) Ejector in table, 20 T press force, 350mm travel Ejector moves outwards with the table Table plate milled flat, with DIN 22 T grooves Pressure adjustment from 60 T to 400 T ( adjustable via touch screen ) Travel limitation either by pressure or position Set-up mode, single stroke and cycle sequence ( adjustable via touch screen ) Swiveling control panel on the cabinet Two-hand operation, with opening button, manual/single stroke/cycle switchover button Installation, commissioning, instruction against separate charge The control is supplied by SIEMENS. ( S 7 1200 ) Also the touch screen monitor with 9 inch. The remote maintenance unit SECOMEA -Ethernet is included in the delivery. The side of the press has two 1000 mm high and 800 mm wide windows with double doors. (sliding table press, hydraulic press, hydraulic press, double column press)

Condition: as good as new (ex-display), Year of construction: 2020, pressing force: 20 t, Double column press 20 T capacity, a) Closing speed up to 10 mm/sec b) opening speed up to 30 mm/sec c) table size between columns 1400x1100 mm d) ram size between columns 1400x1100 mm e) Manual lubrication (via grease nipple) f) UKF pump-cooling-filtration ( electrical cooling ) g) Pressure adjustment from 4 T to 20 T ( adjustable via rotary control ) h) Travel adjustable via slide control Type of construction Press design Double column press ,hydraulic Thermally neutral 80 - 120 °C Number of operating sides 1 side Forces Pressing force max. 200 kN Free ripping force max. 20 kN Pressure build-up time Closed tool Steel on steel Max. 4 sec. Dimensions Max. Opening width 500 mm Stroke 300 mm Table height above floor, approx. 900 mm Height above floor (headroom) approx. 2800 mm Hall height min. 3,500 mm Parallel deviation at 20°C #ERROR! mm Deflection Determined at max. clamping force with 2/3 occupancy < = 0.4 mm/m Weight Total weight of the press without operating materials approx. 3 to Table cut-out Size 1100x850 mm Speeds Fast closing with 9 mm sec. Pressing speed 9 mm sec. Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of press/driving cylinders 2 pcs. Operating pressure max. 280 bar Pressing pressure build-up time 3-5 sec. Pressure accuracy during pressing stroke +/- 5 bar Lrjdpfxjhmbhqo Akujl Main pump BOSCHREXROTH/PARKER approx. 35 L/min Oil volume approx. HLP 46 D 150 litres Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Circulation pump for cooling ACS approx. 6.5 L/min Electrical system Main supply 400 V AC Control voltage 24 V Frequency 50 Hz Hydraulic connection Main motor 3 kW Total connection Approx. 5 kW

Condition: new, pressing force: 400 t, pressure:400 t distance between columns:3400 mm stroke:500 mm total power requirement:55 kW weight of the machine ca.:49 t draw back pressure:26 t pump capacity:131 Lt./min dimensions:7.900 x 5.500 x 4.300 mm :5000 mm :2800 mm table height over floor:700 mm distance between table / ram:1000 mm :700 l traversing speed:0-33 mm/sec. down speed:0-10 mm/sec Lrjdpfx Aofhcc Rjkuol :0-25 mm/sec.

Condition: new, Year of construction: 2019, pressing force: 275 t, pressure:275 t Ljdpfxefxyigs Akuorl distance between columns:3000 mm total power requirement:30 kW weight of the machine ca.:40 t draw back pressure:27 t pump capacity:Axialpumpe mit Proportionalventil :6000 mm :max. 3000 mm Table dimensions:6000 x 3000 mm table height over floor:700 mm distance between table / ram:1100 mm :450 l traversing speed:auf X und Y, 30-33 mm/sec. down speed:2-10 mm/sec :2-50 mm/sec. Cylinder hub:900 mm Cylinder diameter:440 mm Stestle extension:200 / 200 mm / Ø :40 mm Siemens Control System:S7 1200 Monitor Siemens 9":Touch Panel Tax desk:tragbar

Condition: used, Year of construction: 1969, press capacity 250 t spindle diameter 160 mm ram stroke range 180 mm stroke speed 71 Hub/min column daylight 450 mm Lrodpfx Akjyt R Epjujl table surface area 560x450 mm ram surface 450x400 mm total power requirement 12 kW weight of the machine ca. 9 t The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), Year of construction: 1995, Manufacturer: ROVETTA Model: SC2-630 Year: 1995 Condition: Used Stock number: 0393 Pressing force: 630 t Number of pressing points: 2 Ram stroke: 152 mm Ram adjustment: 203 mm Table size: 1,830 x 1,220 mm Ram size: 1,830 x 1,220 mm Usable front opening: 1,880 mm Strokes/min: 25-60 Main motor power: 58 kW Lrjdpfsyv I N Sjx Akuel

Condition: used, Year of construction: 1985, Pressure total: 250 ton Ram stroke: 70 / 250 mm Slide adjustment: 160 mm Ejector in ram: 20 ton Ejector stroke in ram: 10 mm Shut height (stroke down, adjustment up): 520 mm Free lateral opening F-B: 1.300 mm Table surface area : 1.600 x 1.600 mm Slide area: 1.600 x 1.600 mm Number of strokes: 0 - 50 s.p.m. Required power: 33 kW Height over floor approx.: 5.500 mm Weight of machine approx.: 58 ton Roll feeder Material width: 1250 mm Lredpjyvkukofx Akuol Material thickness: 0,3 - 1,6 mm Control: Siemens S7

Condition: used, Year of construction: 1997, pressure 1000 t distance between columns 1260 mm stroke 315 mm no. of strokes 10, 21 - 42 /min distance table/ram, max. stroke up, adjustment up 1295 mm table surface area 1250 x 800 mm table height over floor 670 mm side window 830 mm capacity of ejector in table 63 t ejector stroke of ejector in table 75 mm capacity of ejector in ram 16 t stroke of ejector in ram 23 mm ram surface 1250 x 800 mm ram adjustment 20 mm feeding length transfer 0 - 250 mm closing travel of each rail programmable 0 - 140 mm no. of strokes of the transfer 42 /min power requirement 135,0 kW weight 120,0 t Dimensions (WxDxH) 5,9 x 4,8 x 7,95 m Lrodpovuukujfx Akusl height above floor 6,95 m height beneath floor 1,0 m with DC drive, pneumatic clutch, motoric ram adjustment, pneumatic counterbalance in ram, mechanical ejector in table (pneumatically controlled), mechanical ejector in ram, ram interlocking, die clamping system in table and ram, motoric oil circular lubrication, grease lubrication control of the press: Siemens S 5 - CNC 2-Achs-Transfer (Fabrikat Dreher, Type STV-D Modell 350/100-SO, Bj. 2008), Steuerung Siemens S 7 - cleaning system (make Beyss, yom. 1989) as is where is, WITHOUT putting into operation, stored in dismantled condition The press was previously installed in a soundproof enclosure, which is not part of the scope of delivery Video at seller's site before dismantling available

Condition: good (used), Year of construction: 1977, Druck 250 t Lsdpfxox Ug De Akuorl Staenderweite 1120 mm Hub 250 mm Entfernung Tisch/Stoessel, gr. Hub oben, Verst. oben 500 mm Tischflaeche 1100 x 900 mm Tischhoehe ueber Flur 950 mm seitlicher Staenderdurchgang 700 mm Stoesselflaeche 1100 x 900 mm Geschwindigkeit ab mm/s Geschwindigkeit auf mm/s Arbeitsgeschwindigkeit mm/s Ölinhalt 730 l Antriebsleistung 56 kW Gewicht 25 t Raumbedarf (BxTxH) 2,3 x 1,55 x 3,96 m Zusatzinformationen u mit oelhydr. Antrieb, hydr. (§20) und elektr. Steuerung nach UVV, Lichtschranke (Sick), obere und untere Hubbegrenzung, druck- und wegabhaengig steuerbar, Schnittschlagdaempfung, Kurzhubsteuerung, neue Steuerung (Mitsubishi), Sicherheitssteuerung (PNOZ Multi), Bildschirmsteuerung mit Touch-Screen, Schaltschrank

Condition: used, Eccentric punch press HAULICK + ROOS type RVD 125 double column - eccentric press Machine No. 212560 Year of construction 1981 pressure force 125 ton. table size 880 x 800 mm table opening 470 x 140 mm column width 900 mm column width lateral 415 mm ram stroke 45 mm slide adjustment travel 0-80 mm Installation height on the picture 340 mm Stroke rate 50 to 300 strokes/min. Motor power main drive 22 kW Mains connection 380 volt, 50 Hz - Double connecting rod drive with 4-fold eccentric shaft for off-center ram pressure load - adjacent electrical cabinet - NC roll feed EBU, width 250 mm, year 2003 - adjacent control panel for roll feed - strip running direction from left to right space requirement (press) L x W x H 3000 x 2000 x 3020 mm Lrjdpfx Akohlnzkoujl transport height 2950 mm weight of the press approx. 11 ton.

Condition: excellent (used), Year of construction: 2001, Manufacturer: ROVETTA Model: S4-800 Year: 2001 Condition: Used Stock number: 0392 Builder: Rovetta Slide force: 800 tons Number of driving points: 4 Slide stroke: 700 mm Slide adjustment: 350 mm Strokes per minute: 10-24 Die height (low stroke, high slide adjustment): 1,100 mm Usable distance between front posts: 4,200 mm Bolster table size: 4,000 x 2,000 mm Slide dimensions: 4,000 x 2,000 mm Movable table height: 600 mm Side window size: 3,400 x 1,900 mm Number of cushions: 1 Blankholder cushion - total force: 150 tons Lower blankholder cushion stroke: 250 mm Lrsdpfx Aoyq Tdpskusl Lower blankholder working area: 1,500 x 1,000 mm.

Condition: excellent (used), Year of construction: 2001, Manufacturer: ROVETTA Model: S4-1500 Link Drive Year: 2001 Condition: Used Stock number: 0391 Manufacturer: Rovetta Number of strokes: 4 Ram force: 1500 tons Ram stroke: 763 mm Ram adjustment: 400 mm Daylight (bottom dead center, ram up): 1,200 mm Distance between front uprights: 5,700 mm Die bed dimensions: 5,500 x 2,500 mm Ram dimensions: 5,500 x 2,500 mm Moving table height: 600 mm Side window size: 3,400 x 1,900 mm Main motor power: 319 kW Blankholder (total force): 150 tons Blankholder stroke: 250 mm Blankholder working area: 2,000 x 1,200 mm Lsdpfxjyq Tdij Akuorl Strokes per minute: 8-24

Condition: used, Machine not operational – control system not running Special price Double-column hydraulic press ALPHA TEC -- ALPHATEC Type RPS 5000 Serial No. 300487 Year of manufacture: 2006 Pressing force: 500 tons Column gap front and rear: 2520 mm Table surface: 2500 x 2500 mm Ram surface: 2500 x 2500 mm Ram stroke: 600 mm Installation height max.: 600 mm Table height above floor: approx. 900 mm Tank capacity: approx. 1000 liters Ram retraction force: approx. 22 tons Adjustable approach speed: 100-800 mm/s Pressurization to 5000 kN: approx. 0.7 sec. Return speed: approx. 300 mm/s Main motor power: 75 kW Control pump motor power: 2.2 kW Power supply: 400 Volt, 50 Hz - 8-position flat guide for the ram - Hydraulic ram locking at TDC - Freestanding control cabinet (200 x 50 cm) - Siemens PLC control S7-314 - Operation via Siemens OP 170-B (5.7”) - Two-hand control desk, freestanding - Floor-level installation - Table plate 2510 x 2530 x 135 mm (approx. 6700 kg) Lsdpfx Akodzqptjuorl - Central lubrication - Operating manual with circuit diagrams Required space (L x W x H): 372 x 260 x 460 cm Required space for horizontal transport (L x W x H): 460 x 372 x 260 cm Weight: approx. 50 tons The machine was used for straightening heated steel flanges. From insolvency – in good condition.
