Used Grinding Mill for sale (13,425)

Condition: new, travel distance X-axis: 5,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, position of the milling head: Universal-Diagonal-Fräskopf, spindle speed (max.): 6,000 rpm, table width: 1,100 mm, table load: 14,000 kg, table length: 5,100 mm, overall weight: 35,000 kg, torque: 1,178 Nm, spindle motor power: 53 W, Equipment: rotational speed infinitely variable, The LAGUN BM 5 is a highly stable bed-type milling center and impresses with its high stability, precision, reliability, and economical operation – all without requiring extensive foundation work. Your advantages: ✔ Delivery and commissioning by JMT technicians included ✔ Original spare parts available directly from stock ✔ Technical support and on-site service in Germany ✔ Training and instruction of operating personnel included ✔ Financing and lease-purchase options available upon request Bdjdpfjq Ixh Hjx Afwjg ✔ 24-month warranty Technical specifications: Control system: ✔ HEIDENHAIN TNC 7 control ✔ HEIDENHAIN 24" TFT screen ✔ HEIDENHAIN motors, measuring systems, and electronic handwheel HR-510 Cooling: Internal coolant supply (ICS) 36 bar Tool changer: 24-position drum magazine with dual gripper Chip disposal: 2 x articulated belt conveyors (front and rear) Preparation: Preparation for 4th axis (rotary table optional) Enclosure: Full enclosure (perimeter) Accuracy: Positional accuracy: ± 0.025 mm Repeatability: ± 0.008 mm Contact us – we will be happy to advise you and prepare a customized offer.

Condition: new, Year of construction: 2026, - belt length: 2000 mm - belt width: 75 mm - surface grinding area: 600 mm Bdodsp R N N Ispfx Afweg - belt speed: 15/30 m/s - colour: RAL 9007 - belt motor: 400 V 3,0/3,75 kW - suction capacity: ca. 630 m³/h - suction motor: 0,37 kW - dimensions LxWxH: 1100 x 550 x 1035 mm - weight: 105 kg

Condition: good (used), Spindle diameter: 80 mm Spindle nose: SK50 Spindle speeds: 11 - 1000 RPM X-axis movement: 1700 mm Y-axis movement: 1800 mm Z-axis movement: 1800 mm Spindle out (W-axis): 710 mm Table size: 1100 x 900 mm Elbo Digital readout: On Y-axis and Z-axis Featured with: - Turning table Bjdophl Ecspfx Afwsdg - Toolholders Spindle engine: 7,5 KW Machine LxWxH: 5100 x 2650 x 3300 mm Machine weight: 10 Ton

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 2,050 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 520 mm, rotational speed (max.): 12,000 rpm, CNC control Heidenhain TNC 430 32-fold tool changer coolant device 2x chip conveyor measuring feeler The hole X-axis travel is 2050mm. You can work in one move 2 meters. A dividing wall is also with the machine. Then the X-travel will be split. Technische Daten / technical details: X-Weg / X-travel 2050 mm Y-Weg / Y-travel 520 mm Bsdpfx Aou Hf Ryjfwodg Z-Weg / Z-travel 520 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 12000 UpM /rpm Werkzeugwechselmagazinplätze / number of tool places in changer 2x 32 Antriebleistung Spindel / drive capacity spindle 36 kW Gewicht ca. / weight 12800 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, Technical details: spindle diameter: 110 mm x-travel: 2000 mm y-travel: 1600 mm z-travel: 2000 mm control for program: TNC Heidenhain 360 B-axis (table): ja W-axis (spindle longitudinal): Planschieber mm tool taper: ISO 50 table-size: 1400 x 1250 mm machine dimensions LxWxH: 8,0 x 6,0 x 4,5 m weight of the machine ca.: 28 t with face slide 700mm , electronic hand control Bdjdju Idp Dspfx Afwog *

Condition: as good as new (ex-display), Year of construction: 2026, ST 3 classic F 23 – Combined Saw-Milling Machine With pivoting saw blade, pivoting milling spindle, and format sliding table made of anodized aluminum Stable steel cast iron construction Large support surface and precise cast iron table High-precision format sliding table made of anodized aluminum (travel distance 2250 mm) Large extension table (900 x 600 mm) with extendable aluminum telescope fence Max. saw blade diameter 315 mm with scoring device, pivotable from 90° to 45° Saw parallel fence with fine adjustment Stable saw unit and large, double-bearing milling unit ensure maximum stability, precision, smooth operation, and long service life Solid and precise machine table made of stress-free cast iron 3 milling speeds, manually adjustable from 3,500 - 10,000 rpm With clockwise/counterclockwise rotation of the milling spindle Standard arc milling guard Two 5.0 kW motors with high power reserves Cast iron milling unit mounted on both sides at the top precision ball bearings on top close to the pivot point four optimally graduated milling speeds, which enables the sharpening of workpieces Powerful motors Industrial motor, 100% duty cycle for continuous operation (full load) suitable Scope of delivery: Arc milling guard Anodized aluminum format sliding table Aluminum fence jaws Folding stops Technical data Dimensions of cast iron work table 1112 x 430 mm Fence length 2250 mm max. saw blade diameter with/without scoring 315 mm max. cutting height at 90°/45° 100/70 mm max. crosscut width 2660 mm Saw blade pivot 90° - 45° Cutting width 900 mm Bdjdpocnwydsfx Afwog Speed 4000 rpm Table saw - Spindle pivot 90° - 45° Spindle working length 100 mm max. tool diameter 210 mm max. tenon tool diameter 275 mm max. countersinking tool diameter 180 mm Speeds 3,500/7,000/10,000 rpm General - Motor power 400 V/50 Hz/S6 40% 2 x 5.0 kW (6.6 HP) Weight 470 kg Dust extraction port diameter 2 x 120 mm Dust extraction port diameter saw blade guard 60 mm Location: In stock, 54634 Bitburg - immediately available -

Year of construction: 2022, condition: as good as new (ex-display), AL-KO Grinding Table AST 1.5 BASIC The AL-KO Grinding Table AST 1.5 BASIC is the entry-level model in the AL-KO grinding table range. It is certified according to GS-HO-11 and bears the seal "Tested for wood dust according to BGI 739-1". YOUR ADVANTAGES Accessible from 4 sides Can be loaded with up to 150 kg Manual, tool-free height adjustment with scale Recessed longitudinal sides for edge grinding Workpiece-friendly beech wood grating (removable) Funnel-shaped air duct to the extraction nozzle TECHNICAL DATA AST 1.5 BASIC Bdsdpjdqzhbofx Afwsg Extraction nozzle 140 / 160 mm Required extraction capacity 1,500 m³/h Negative pressure at the nozzle at 22 m/s 1,000 Pa at DN140 mm 700 Pa at DN160 mm Adjustable working height from 735-1,015 mm Working area (W x L) 946 x 1,500 mm Dimensions (W x L) 1,000 x 1,600 mm Weight approx. 73 kg

Year of construction: 2024, operating hours: 1 h, condition: new, functionality: fully functional, machine/vehicle number: 86-731-85552647/18153792542, We are a company based in 9000 St. Gallen (Switzerland) and imported this planetary ball mill from China in 2024. The unit is brand new and unused. We have switched the machine on and let it run empty for a few minutes to verify its functionality. It comes with 4 x 25-liter nylon containers. Additionally, 120 kg of zirconium beads with a 1 mm diameter are available. ~ Manufacturer's Description: The YXQM series of planetary ball mills for mass production is a machine designed for production applications, built to handle medium-scale capacities to meet industrial requirements. It facilitates the smooth transition of materials from laboratory scale to full production, ensuring consistency and repeatability of processes and thus reliable material quality. The equipment is widely used across new energy, metallurgy, electronics, ceramics, geology, mining, construction materials, chemical industry, light industry, cosmetics, environmental protection, and other enterprise-level material production sectors. Extremely high centrifugal forces inherent to planetary ball mills generate intensive grinding energy, resulting in short milling times. These machines are ideal wherever the quality control process demands the highest standards of purity, speed, fineness, and reproducibility. This series can be equipped with vacuum jars, allowing samples to be ground under vacuum conditions. It is well suited for research tasks at scientific institutes, universities, and industrial R&D laboratories to verify the feasibility of scale-up to mass production, as well as for routine operations such as mixing and homogenizing soft, hard, brittle, or fibrous materials—from laboratory tests through to production. - Key Features: - High-performance, nanometer-scale grinding - Digital display, intuitive operation, precise parameter setting Bdedpfx Aeyilnzsfweg - Variable speeds from approx. 10 to 440/360 rpm, speed ratio 1:2 - Batch processing with up to 4×6/9 L samples, simultaneous processing of 4 materials - Electric lid opening and integrated crane for easy and convenient operation - Storage for 3 modes and 15 programs - Power failure protection with memory function and automatic restart - Suitable for dry, wet, vacuum, and protective atmosphere grinding - Machine stops upon lid opening; automatic interlock prevents accidental release - Equipped with rollers and swiveling feet for easy movement and stable operation Applications: Grinding, mixing, homogenizing, colloidal milling, mechanical alloying, mechanochemistry Fields of Application: New energies, geology/metallurgy, glass/ceramics, engineering/electronics, building materials, environment/recycling, agriculture, chemistry, medical, biology Feed material: Soft, hard, brittle, fibrous – dry or wet Size reduction principle: Impact, friction Feed size: < 5 mm soil, < 10 mm Final fineness: For colloidal milling, samples below 0.1 micron Number of grinding stations: 4 Grinding methods: Dry grinding, wet grinding, vacuum grinding, grinding under protective atmosphere

Condition: good (used), functionality: fully functional, Technical data (according to nameplate): Bodpfoymd Idsx Afwjdg • Manufacturer: Heckert Werkzeugmaschinen GmbH • Model: FU 315 • Year of manufacture: 1997 • Machine no.: 19019 • Temperature range: +5 to +35 °C • Total weight: approx. 3.1 t • Made in Germany Equipment / Features: • Universal milling head • Infinitely variable or widely graduated feeds (see diagram on the machine) • Coolant system • Electrical control cabinet (clearly arranged) • Digital display (see photos) • Heavy-duty machine construction • Very quiet operation

Condition: refurbished (used), Year of construction: 2025, operating hours: 50 h, machine/vehicle number: 3018-04, Country of manufacture: Switzerland Voltage: 380/50/3 Bjdpfx Afow T Sd Towjdg Net weight: 3100 kg Overall dimensions: 230x155x170 cm Installed power: 13 kVA Customs tariff position: 8460.2920 TECHNICAL SPECIFICATIONS MAIN DIMENSIONS Distance between centers: 650 mm Grinding capacity SpW+bs: -80 Stroke: 700 LONGITUDINAL SLIDE Max stroke: SpW+50 mm Minimum automatic feed: 1.5 mm Speed: 50-5500 mm/min Reversal delay: 0-6 sec Maximum table swivel: 12°/10°/8.5°/6° Pneumatic relief for table and workhead CROSS SLIDE Max stroke: 300 mm Rapid traverse: 60 mm Plunge grinding depth in diameter: 3.4 mm Feed 1: 0.012-6 mm/min Feed 2: 0.012-1.2 mm/min Feed per pulse: 0.001-0.05 mm GRINDING WHEEL HEADSTOCK Left-side wheel, external grinding: 400x80x127 mm Drive power: 5.5 kW Peripheral speed: 35 m/s RPM: 1670/2110 min-1 Internal grinding device for belt-driven spindles, including drive unit: 1.5 kW WORKHEAD Swivel range: 0-90° Continuously variable RPM: 30-1000 min-1 Internal taper: Morse 5 Collets: W-25 Drive power: 0.55 kW Maximum workpiece weight between centers: 130 kg Grinding load between centers: 100 Nm TAILSTOCK Internal taper: Morse 3 Quill stroke: 35 mm Fine adjustment for cylindricity correction: ± 40 μm TECHNICAL CHARACTERISTICS: GUARANTEED WORKING ACCURACY Straightness of the generator over 630 mm: 0.003 mm Roundness during chuck grinding: 0.0003 mm CONNECTION VALUES Maximum absorbed power: 13 kVA Maximum permitted voltage fluctuation: -15%/+10% Maximum permitted frequency variation: ± 3% Required compressed air pressure: 5 bar Unless otherwise stated or in case of error or omission, these technical details are provided without engagement.

Condition: excellent (used), Year of construction: 2020, operating hours: 4,800 h, functionality: fully functional, machine/vehicle number: NL154200702, Manufacturing origin: JP Voltage: 380 V / 50 Hz / 3-phase Net weight: 5,400 kg Customs tariff number: 8458.9100 Bdodpow T Sn Esfx Afweg TECHNICAL DATA Maximum turning diameter: 350 mm Turning length: 515 mm CNC control: M730UM MAPPS Celos Swing over bed: 923.8 mm Swing diameter above carriage: 755 mm Standard turning diameter: 260 mm Bar capacity: 34 mm Main spindle: Spindle speed range: 100 – 8,000 rpm Spindle motor power: 11 / 7.5 kW C-axis resolution: 0.001° Chuck diameter: 210 mm Subspindle: Maximum speed: 8,000 rpm Spindle nose: A2-5 Axis travels: X-axis travel: 260 mm Z-axis travel: 580 mm Y-axis travel: 100 mm (±50 mm) Turret: Number of turret stations: 20 Driven stations: 20 Tool shank diameter: 25 mm Maximum driven tool speed: 10,000 rpm Driven tool motor power: 5.5 / 3.7 kW Feed rates: Rapid traverse X-axis: 30 m/min Rapid traverse Z-axis: 30 m/min Rapid traverse subspindle: 30 m/min Rapid traverse Y-axis: 10 m/min Rapid traverse C-axis: 400 rpm Total power requirement: 31 kVA Approximate machine weight: 5.4 t Approximate machine dimensions: 4.0 x 3.0 x 3.2 m Errors and omissions excepted – data provided without obligation.

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 176308, Country of manufacture: Switzerland Voltage: 400 / 380 / 50 / 3 Net weight: approx. 350 kg Dimensions: 82x85x156 cm Installed power: max 2 kVA Customs classification: 8460.3930 TECHNICAL SPECIFICATIONS GRINDING WHEEL SPINDLE UNIT Spindle speed (both rotation directions): 2,500 / 3,500 / 5,000 / 7,100 rpm Grinding wheel motor power (2,800 rpm): 0.4 HP Vertical slide stroke (linear): 100 mm Micrometric stop adjustment travel: 25 mm Micrometric stop readout accuracy: 0.01 mm WORKPIECE SPINDLE UNIT Workpiece spindle speed (both directions, continuous): 100–900 rpm Motor power: 0.2 HP Indexing plate teeth count: 120 Angular vernier reading: 20' Collet type: W-20 Horizontal travel: 100 mm Rapid feed per handwheel turn: 2 mm Micrometric feed per handwheel turn: 0.1 mm Micrometric feed per scale division: 0.001 mm SPINDLE HEAD SWIVEL RANGE (a) Main direction: 165° Fixed ratchet increments: every 3° Increments with micrometric screw: every 2' (b) Grinding plane: approx. 15° Stop: at 0° Cross movement range: 80 mm Micrometer travel: 25 mm Reading precision: 0.01 mm Extraction motor power (2,800 rpm): 0.25 HP All technical specifications provided without guarantee and subject to possible errors or omissions. Bdsdpfx Afew T S Sqowog

Condition: good (used), Year of construction: 1995, Control: HEIDENHAIN TNC 415 B Travel: X= 600, Y= 400, Z= 420 mm Speed range: 20 – 4000 rpm Gear stages: 3 Bedpfxew Uin Se Afwedg Spindle taper: SK 40 Quill stroke: 75 mm Spindle motor: 5.9 kW Feed range: 1 – 5000/6000 mm/min (manual/programmed) Rapid traverse x, y: 7 m/min Rapid traverse z: 6 m/min Clamping area: 900 x 458 mm Weight: approx. 2300 kg With coolant system, electronic handwheel, various tools (without cabinet)

Condition: like new (used), Year of construction: 2014, Siemens 840 D Swivelling control panel including SIEMENS 840 D Solution Line control system. Travel X axis: 8000 mm Travel Y axis: 1300 mm Travel Z axis: 2200 mm Tool system: SK 50; Capto C8 Main spindle: 20–4000 RPM 3D volume model of the machine HEIDENHAIN measurement system on all axes. Automatic central lubrication with pressure and time monitoring for all axes and moving components. Measuring probe system RENISHAW RMP60 M Tool breakage detection via probe BRANKAMP CMS collision monitoring with two measuring channels: Center height, Fibro rotary clamp: 1100 mm Center width, Fibro rotary clamp: 900–3000 mm Max. swing diameter, Fibro rotary clamp: 2200 mm Fibro rotary table D=1600; 250 RPM Carousel rotary table FIBRODYN 1600 mm: Table surface 6000x2000 mm d’Andrea facing slide Universal milling head Automatic tool changer ATC, 80 tool magazine slots in M version: 3 milling head slots High-pressure pump 30 bar Bdsdpfx Afew Syv Uoweg Operating hours: 4261 h

Condition: good (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 610 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 610 mm, - ULTIMAX 4 control - toolchanger for 24 tools - coolant through spindle - chip screw - electronical hand wheel - measuring feeler Renishaw Technische Daten / technical details: Verfahrweg X / X-Travel 610 mm Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 610 mm Tischgröße / table size 760x510 mm Werkzeugschaft / spindle taper SK40 Drehzahlbereich / spindle speed 10-10000 UpM /rpm Anzahl der Werkzeugplätze / tool places in ATC 24 fach Eilgang / rapid feed 30 m/min Bodpfx Afox D A Ddowjdg Gewicht der Maschine ca. / weight 4700 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, Year of construction: 1987, Technical details: spindle diameter: 110 mm x-travel: 1985 mm y-travel: Spindelstock vert. 1270 mm z-travel: Tisch längs: 1260 m. Setzstock/1490 m. Setzstock mm table adjustment: nein ° B-axis (table): 360 W-axis (spindle longitudinal): axial: 710 mm U-axis: Planschieber radial: 250 mm control for program: Heidenhain 320 tool taper: ISO 50 table-size: 1600 x 1400 mm table rotating: 360 ° table load: 6,3 t range drill spindle revolution per minute: 6,3 ... 1250 / 4 step U/min revolution per minute: Plansupport: 6,3 ... 315 / 2 step U/min feed steps: Tisch: 5...2500 und Spindelstock vert. 5...2500 mm/min total power requirement: ca. 90 kW weight of the machine ca.: 30 t Tailstock Facing slide 700 Bdsdpfx Afeu Utwbjweg Electronic handwheel max. turning Ø for drilling: 630mm max. turning Ø for facing: 1250mm At the moment the Horizontal Boring and Milling Machine has an electrical fault in the control (unknown). Our offer/sale is as described and as is! *

Condition: reconditioned (used), Year of construction: 1985, functionality: fully functional, planing height: 130 mm, spindle diameter: 40 mm, planing width: 230 mm, rotational speed (min.): 6,000 rpm, planer shaft diameter: 40 mm, Weinig Hidromat H22B .9 spindles. Passage 230 x 130 mm. Станок посельно ТО. Machine for the production of high-quality propellant. year of manufacture: 1985. №0220 - 739 Speed of feeding 6-60m/min, electric engine-15 kW, hydromotor. РАСПОЛОЖЕНИЕ ШПИНДЕЛЕЙ / МОЩНОСТЬ ДВИГАТЕЛЕЙ: 1. Горизонтальный нижний – 5.5 KW. 2. Vertical right – 5.5 kW. 3. Вертикальный левый –5.5 kW; 4. Горизонтальный верхний - 5.5 kW, counterpora 5. Горизонтальный нижний - 5.5 kW, counterpoise 6. Vertical right – 5.5 kW. 7. Vertical left –5.5 kW 8. Горизонтальный верхний - 5.5 kW, контропора + джоинтер 9. Горизонтальный нижний - 11 kW, контропора + джоинтер Bdjdpfx Asvk Sptofwjg Spindle speed 6000 rpm diameter of spindles-40mm Автоматический насос резиги стола. Пневмо прижим, давление вудка 6 Bar 5 leading rollers in the table There are video scrolling mechanisms

Condition: excellent (used), Year of construction: 2009, Bernardo FM 45 V drilling and milling machine. The FM 45 V drilling and milling machine offers an optimal price-performance ratio thanks to the standard spindle feed. The dovetail guide of the gear head ensures maximum precision and stability. Drilling capacity in steel 32 mm Drilling capacity in cast iron 40 mm Throat 260 mm Spindle speed (12) 50 - 2520 rpm Spindle mount MK 4 Quill stroke 120 mm Quill feed (3) 0.12 / 0.19 / 0.26 mm/rev Table size 820 x 240 mm Distance spindle / table 40 - 485 mm Travel path (x / y) 550 / 190 mm Height adjustment of milling head 400 mm T-slot size 14 mm T-slot distance 55 mm Motor output power S1 100% 0.85 / 1.1 kW (400 V) Motor input power S6 40% 1.1 / 1.5 kW (400 V) Bjdpfxovutw Hs Afwedg Machine dimensions (W x D x H) 1150 x 850 x 1450 mm Weight approx. 285 kg Standard with automatic spindle feed and thread cutting device Large speed range 50 - 2520 rpm (12 levels) Dovetail guide for x, y and z axes, adjustable via wedge strips Versatile application options, slot milling, face milling, boring,.... Solid large cross table, precisely surface-machined Milling: spindle feed via handwheel Drilling: spindle feed via handwheel High-quality aluminum motor, designed for continuous operation Stable and vibration-free cast design Simple and quick speed change using a gear lever Pivoting milling head for angle drilling, milling bevels, etc. Location: from stock 54634 Bitburg - available at short notice -

Condition: new, Year of construction: 2025, - belt length: 2000 mm - belt width: 75 mm Bsdpoxwph Ajfx Afwsdg - surface grinding area: 600 mm - belt speed: 30 m/s - colour: RAL 9007 - belt motor: 400 V 3,75 kW - suction capacity: ca. 630 m³/h - suction motor: 0,37 kW - dimensions LxWxH: 1100 x 550 x 1035 mm - weight: 105 kg

Condition: used, CNC Milling Machine DECKEL Type FP 3 A Tool-tool milling machine with handwheels, also for conventional operation Serial No. 2206 - Built in 1982 GRUNDIG CNC 2101 CNC control system Travel paths X: 490 mm, Y: 300 mm, Z: 340 mm Table size 705 x 425 mm Spindle mount SK 40 Quill stroke 100 mm Spindle speed 25 - 2500 rpm, 21 steps Feed rate 5 - 500 mm/min, continuously variable Rapid traverse speed 1200 mm/min Spindle motor power: 2/4 kW, pole-changing Power supply: 380 V, 50 Hz - GRUNDIG CNC 2101 CNC control system - Mechanical handwheels for all three axes - Universal tilt-and-turn table Bdedpfx Ajv R E Rdjfwjg - Vertical milling head tilts and is manually adjustable by 200 mm - Hydro-mechanical tool clamping - Coolant system in the machine base - Protective enclosure at the front and sides with three hinged doors - Control cabinet adjacent (L x W = 600 x 430 mm) Space requirement: L x W x H: 1900 x 1700 x 1950 mm Weight: 1700 kg (machine 1540 kg + electrical cabinet 160 kg) Very good condition

Condition: excellent (used), Grinding length 600 mm Grinding width 320 mm Max. workpiece height 500 mm Longitudinal table travel 750 mm Cross table travel 340 mm Grinding wheel diameter 350 mm Grinding wheel width 40 mm Spindle speed 1500 rpm Vertical rapid traverse 400 mm/min Power 3.7 kW Automatic feed Magnetic chuck Coolant system Bjdpjw Hy Twefx Afwodg Weight 2500 kg

Condition: used, functionality: fully functional, machine/vehicle number: 40/35-22, Price on request Used Gear Grinding Machine Brand: NILES Type: ZSTZ 630 C3 Max. gear diameter = 630 mm Tooth width = 215 mm Module = 1 – 12 Bdodewl Aunopfx Afwsg Number of teeth = 5 – 140 Table diameter = 500 mm Stroke = 500 mm Grinding wheel diameter = 270 – 350 mm Swivel range = 45° Strokes = 75 – 315 per minute Weight approx. = 6.3 t

Condition: good (used), Year of construction: 2018, functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 550 mm, CNC control Sinumerik 828D Bdedpfx Afewu Tpnoweg 24-fold automatic tool changer chip conveyor coolant through spindle device measuring feeler Technische Daten / technical details: Verfahrweg X / X-Travel 1020 mm Verfahrweg Y / Y-Travel 520 mm Verfahrweg Z / Z-Travel 550 mm Tischgröße / table size 1100x500 mm Drehzahlbereich / spindle speed 10000 UpM /rpm Anzahl der Werkzeugplätze / tool places in changer 24 fach Antriebsleistung Spindel / drive capacity spindle 9/22 kW Gewicht der Maschine ca. / weight 5500 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: good (used), Year of construction: 1991, Control: Heidenhain TNC 407 Travel range: X = 600, Y = 400, Z = 420 mm Spindle speed range: 20 – 4000 rpm Bdsdpfx Ajwvif Ujfweg Gear stages: 3 Tool holder: SK 40 Quill stroke: 75 mm Spindle motor: 5.9 kW Feed rate range: 1 – 5000/6000 mm/min (manual/program) Rapid traverse rate x, y: 7 m/min Rapid traverse rate z: 6 m/min Clamping surface: 900 x 458 mm Weight: approx. 2300 kg With coolant system, electric handwheel, and measuring probe (defective).

Condition: used, Year of construction: 2013, max. wheel diameter 260 mm Bodpex R U Hgsfx Afwsdg gear width 320 mm max. module 4,5 min. module 0,5 Control SIN 840D max.helical angle +/- 45 ° total power requirement 68 kW weight of the machine ca. 15,50 t dimensions of the machine ca. 3,25 x 3,25 x 3,30 m Fire extinguishing system Siemens Sinorix TM Knoll Filtering system VL1500/8000 year 2017 Wekal loading cell
