Used Raboma Headstock for sale (379)

Condition: used, Year of construction: 1994, turning diameter over bed 350 mm turning diameter over slide rest 310 mm turning length 700 mm total power requirement 4,6 kW weight of the machine ca. 1,0 t Dimensions (HxWxD) 2.200 x 1.300 x 1.175 mm --> Technical data Centre height: 175 mm Bsdpfxjwc Dzwj Af Rsdc --> Centre width: 800 mm --> Swing diameter over bed: 350 mm --> Swing diameter over support: 310 mm --> Gap length in front of the faceplate: 145 mm --> Cross slide travel: 205 mm --> Top slide travel: 100 mm --> Tool cross-section: 20x20 mm --> Bed Width: 220 mm --> Height: 300 mm --> Headstock Spindle bore: 46 mm --> Spindle nose: DIN 55027-5 --> Spindle inner taper: 1:20 --> Tool holder: MK-3 --> Spindle speeds: 18 --> Speed range: 25 - 2000 rpm --> Tailstock Quill diameter: 50 mm --> Quill inner taper: MK-3 --> Quill travel: 140 mm --> Lateral adjustment: 10 mm --> Feed range Number of feeds: 256 --> Longitudinal feeds (128): 0.042 - 0.929 mm Rev --> Cross feeds (128): 0.015 - 0.338 mm Rev 3 - jaw chuck Multifix steel holder size B, 1 x inserts 2 x travelling steady rest, Operating instructions

Condition: used, Year of construction: 2019, bar material dia. 32/38 mm spindle passage 44 mm turning length 320 mm turning speeds 200-8000 U/min c-axis 0,001 Grad gripping station 32/38 mm turning length 120 mm turning speeds 200-8000 U/min c-axis 0,001 0 Bdodoy Hl Hijpfx Af Rjc number of tools 13 fix number of milling stations 4+5 driven control Mitsubishi Meldas M70 Number of axles 5+2 St. total power requirement 7,5 kW weight of the machine ca. 2850 kg dimensions of the machine ca. 2,5 x 1,4 x 1,75 + FMB m CNC sliding headstock machine Citizen L32-1M8, built 01/2019 with barloader FMB turbo 3-36 equipped with swarf & coolant tank, fire distiguisher. ON/OFF 29.564h (status 24.03.2026) Running hours 26.607h (status 24.03.2026) GBL function (standard) LFV function: no

Condition: used, Year of construction: 1994, functionality: fully functional, throat depth: 1,250 mm, Radial drilling machine Fab. Breda type. R 55-1250 Year of manufacture 1994 Technical details Bjdpjv Rpf Sefx Af Rodc Make: BREDA Type: R 55-1250 Throat: 1250 mm Drilling capacity in steel: 55 mm Drilling capacity in cast iron: 70 mm Tapping capacity in steel: M 50 Tapping capacity in cast iron: M 65 Drill spindle mount: MT 5 Throat: 1250 mm Cross travel of headstock: 930 mm Minimum/largest distance from base plate: 5360 – 1375 mm Vertical travel of the boom: 705 mm Spindle stroke: 310 mm Number of spindle speeds: 12 Spindle speeds: 30 – 1200 rpm Number of feeds: 8 Feeds: 0.06 – 1.0 mm/rev Base plate 2070 x 910 mm Clamping area base plate 1325 x 910 mm Motor power 4.4 kW - 380 volts Dimensions (L x W x H) 2.1 x 1.0 x 2.5 m Weight 3 t Accessories Drilling table 750 x 600 x 550 mm Cooling Hydraulic clamping All information is subject to change. A demonstration is available at any time in our showroom.

Condition: used, Year of construction: 1998, functionality: fully functional, Equipment: documentation/manual, CNC sliding headstock automatic lathe Make: STAR Model: SR-20 Year: 1998 with: FANUC 16-T control Back side machining Synchronised spindle Driven tools C-axis Bar feeder magazine FMB TURBO 3-26 Bdsdpjy Hg Hdsfx Af Roc

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 650 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Technical specifications: Centre distance: 750 mm Centre height: 180 mm / (250 mm optional) Workpiece weight: 100 kg (between centres) – 250 kg (supported between centres) Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MT 4, stepless speed adjustment 30–450 rpm, swivel range 0–90° Tailstock: MT 4, quill stroke 45 mm, quill offset adjustment Quill force: 200–600 N manual, (up to 2500 N adjustable as option) Table swivel adjustment: 12.5 degrees Cross slide travel: 80 mm Rapid traverse distance: 50 mm Coarse adjustment with air cushion: 280 mm External grinding spindle motor: 4 kW / (5.5 kW optional) Stepless speed setting of the grinding wheel via potentiometer Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 1.1 kW Hydraulic motor: 1.5 kW Lubrication motor: 0.1 kW Hydraulic tank: 80 litres Machine weight: Net 3,500 kg Feed drive via DC motor Air-cushioned rapid adjustment of the grinding spindle head for fast and precise positioning. Bodpfjiv Audex Af Rjdc Separate drive for external and internal grinding spindles. Fully automatic operation, feed movement controlled via handwheel switch: rapid feed, rapid return, grinding operation, feed stop, mym-feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding zones Workpiece headstock with steplessly adjustable drive, with live and lockable spindle. Digital feed control with Siemens panel and Siemens PLC for plunge and traverse grinding, input for retraction, infeed values, feed rates, spark-out times, idle strokes, compatible with traditional Karstens infeed control, with colour Siemens touch panel. Scale in X and Z axis by HEIDENHAIN. Comparable with Weiss / EMAG / GP cylindrical grinders / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat / Bahmüller / Fortuna.

Condition: excellent (used), Year of construction: 1980, Karstens K11 1000 Bdodpfxoh Rit Ej Af Rsc This Karstens K11 comes from a university environment and was only used very sparingly. All cables and hoses in the wet area have been replaced. It has extremely low operating hours. As we specialize in Karstens cylindrical grinding machines, we can offer you full service (electrical and mechanical) for the machine after purchase. Technical Data: Centre distance: 1000 mm Centre height: 180 mm Workpiece weight: 70 kg (between centers, cantilevered), 250 kg (between centers) Grinding wheel diameter: 400 mm Workpiece spindle: Morse Taper 4, infinitely variable speed 30–450 rpm, swiveling range 0–90° Tailstock: Morse Taper 4, quill stroke 45 mm Tailstock rest beside Z-axis table Quill force: 200–600 N Table swivel: 12.5 degrees Travel of infeed spindle: 80 mm Rapid traverse: 50 mm Coarse adjustment air cushion: 280 mm External grinding spindle motor: 4 kW Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 0.55 kW Machine weight: net 3,500 kg Infeed drive by DC motor Air cushion-supported rapid adjustment of the grinding spindle headstock for fast and safe positioning at the grinding station. Separate drives for spindles for external and internal grinding. Fully automatic operation cycle, feed movement controlled via rotary switch: Rapid advance, rapid retraction, grinding mode, feed stop, mym-feed adjustment. Automatic longitudinal grinding cycle Central coolant supply for all grinding stations Workpiece headstock with infinitely adjustable drive for rotating and lockable spindle. Infeed control for longitudinal grinding and plunge grinding, settings for retraction, feed amounts, feeds, spark-out times, idle strokes. Digital readout for X-axis by Heidenhain Paper band filter unit can be offered on request. Comparable to Weiss/ EMAG/ GP-cylindrical grinders/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 1000 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Bdsdpfx Asiv Au Eef Rec Technical specifications: Centre distance: 1100 mm Centre height: 180 mm (250 mm optional) Workpiece weight: 100 kg between centres (unsupported), 300 kg between centres Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MT 4, infinitely variable speed control 30–450 rpm, swivelling range 0–90° Tailstock: MT4, quill stroke 45 mm Quill force: 200–600 N manually, (up to 2500 N adjustable, option) Table swivel: 10° Cross slide travel: 80 mm Rapid traverse: 50 mm Coarse adjustment (air cushion): 280 mm External grinding spindle motor: 4 kW (5.5 kW optional) Infinitely variable grinding wheel speed adjustment via potentiometer Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 1.1 kW Hydraulic motor: 1.5 kW Lubrication motor: 0.1 kW Hydraulic tank: 80 litres Net machine weight: 3,800 kg Infeed drive via DC motor Air cushion-supported rapid adjustment of the grinding spindle head for fast and safe positioning to the grinding position. Separate drive for the spindles for external and internal grinding. Fully automatic operation, infeed movements controlled via rotary selector switch: rapid advance, rapid return, grinding mode, infeed stop, micrometre infeed. Automatic longitudinal grinding cycle Central coolant supply to all grinding points Workpiece headstock with infinitely variable drive for rotating and lockable spindle. New digital infeed control with Siemens panel and Siemens PLC for traverse and plunge grinding; input for retraction, infeed amounts, feed rates, spark-out times, idle strokes; compatible with the original Karstens infeed control; with coloured Siemens touchscreen; HEIDENHAIN scales in X and Z axes. Comparable to Weiss/EMAG/GP cylindrical grinding machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat /Bahmüller/Fortuna

Condition: new, We offer you spare parts of all kinds for your conventional or CNC Karstens / EMAG WEISS / GP cylindrical grinding machine—covering your tailstock, workpiece headstock, grinding spindle headstock, ball screw spindles, glass scales, grinding wheel flanges, drive motors, axis drives (BOSCH SIEMENS), ECKELMANN controls, bellows, bearings, K11/K21 infeed controls (new and used), as well as Z-axis reversing blocks for exchange. We service machines from year of manufacture 1955 onwards: ASA-ASE-K10-K11-K12-K13-K16-K19-K21-K22-K23-K24-K25-K26-K27-K28- K29-K33-K35-K37-K50-K51-K52-K53-K57-W11-W21-GP cylindrical grinding machines—all assemblies based on Karstens design. Comparable/ EMAG-WEISS/ GP cylindrical grinding machines/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat. Bdedpoup Aikofx Af Rjc

Condition: as good as new (ex-display), Year of construction: 2026, Center height: 181 mm Center distance: 650 mm Maximum grindable workpiece diameter: 360 mm Max. load (overhung): 1000 N / 100 kg Max. load (between centers): 3000 N / 300 kg Z-axis Table swivel angle: 10° Table drive hydraulic: 0–4 m/min X-axis Cross slide travel: 80 mm Rapid traverse (hydraulic): 50 mm Coarse positioning—air cushion: 280 mm Infeed drive via DC motor Rapid feed rate: 48 mm/min/Ø Infeed process: Plunge / Longitudinal grinding 4 pre-selectable feed rates: mm/min/Ø 0.01–48 4 pre-selectable infeed increments: mm/ 0.001–0.1 Spark-out during end stop grinding: s 0–99 / 0–99 strokes Jog infeed: mm/Ø 0.001 Grinding spindle headstock—universal, swiveling: degrees 0–180 Grinding wheel (external): D x width x bore mm 500x100x127 or 203.2 Grinding wheel (face, option): D mm 250x32x76.2 Grinding wheel (internal, option): D mm (2–250) Drive power (external, face): kW 5.5 (7.5) Drive power (internal): kW 2.2 Peripheral speed (external): m/s 35 (50) Grinding wheel wear (external): mm/Ø 160 Wheel guard width: mm 100 Grinding spindle diameter: mm 60 Internal spindle mount: mm 80 (100) Workpiece headstock: Infinitely variable drive, MK 4: 1/min 30–270/ 50–450 Workpiece spindle lockable Bsdpfx Afotqf Sqj Redc Spindle mount: mm MK 4/24 Spindle nose for flange mounting: MK 4 mm cylindrical Ø63H6 x 6 Workpiece headstock swivels on the rotary part: degrees 0–90 Tailstock: Quill mount / quill diameter: mm MK 4/750 Quill stroke mm: 45 Quill force N: 100–800 / 250–1400, adjustable Quill actuation: manual (foot switch) Quill fine adjustment: ±40μm Connections: Total power requirement of the machine: kW 6.5–10 Grinding spindle headstock: kW 5.5 (7.5) Workpiece headstock: kW 0.55 (1.1) Coolant cleaning: kW 0.75–2.2 Guideway lubrication pump: kW 0.1 Hydraulic pump: kW 1.5 Hydraulic tank: liters 80 Pneumatics: bar 6 Similar to Weiss/ EMAG/ GP cylindrical grinding machines/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat/ Bahmüller/ Fortuna

Condition: refurbished (used), Year of construction: 2026, Karstens K11 1000 Full Equipment The cylindrical grinding machine has been completely overhauled by PS-Karstens. The machine has been tested and is in very good condition. Since we specialize in Karstens cylindrical grinding machines, we can offer you comprehensive service (both electrical and mechanical) for the machine after purchase. Technical Data: Centre distance: 1000 mm Centre height: 180 mm Workpiece weight: 100 kg (unsupported), 250 kg (between centers) Grinding wheel diameter: 400 mm Workpiece spindle: MT 4, steplessly adjustable speed 30–450 rpm, swiveling range 0 - 90° Tailstock: MT4, quill stroke 45 mm, fine adjustment for the quill Quill force: 200-600 N, hydraulically operated via foot pedal Table swivel angle: 10 degrees Infeed spindle travel: 80 mm Rapid traverse travel: 50 mm Coarse adjustment with air cushion: 280 mm External grinding spindle motor: 4 kW Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 0.55 kW Bodpfxeh Riwdj Af Rjdc Machine weight: net 3,800 kg Infeed drive by DC motor Air cushion assisted rapid adjustment of the grinding spindle headstock for fast and safe positioning of the grinding position. Separate drive for spindles for external and internal grinding. Fully automatic operation cycle, infeed motion via star dial switch: Rapid approach, rapid return, grinding mode, infeed stop, micron infeed. Automatic longitudinal grinding cycle Central coolant supply to all grinding positions Workpiece headstock with steplessly adjustable drive for live and lockable spindle operations. Infeed control for longitudinal and plunge grinding, input for retraction, infeed amounts, feeds, spark-out times, empty strokes Digital readouts for grinding spindle B-axis, workpiece spindle, X and Z axes from HEIDENHAIN Paper band filter unit approx. 250 L Similar to Weiss / EMAG / GP cylindrical grinders / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat / Bahmüller / Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 1000 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Technical Data: Centre distance: 1100 mm Centre height: 180 mm / (250 mm optional) Workpiece weight: 100 kg between centres, 300 kg with support Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MT 4, infinitely variable speed from 30-450 rpm, swivel range 0 - 90° Tailstock: MT4, quill stroke 45 mm Quill force: 200-600 N manual, (up to 2500 N adjustable = optional) Table swivel: 10 degrees Infeed spindle travel: 80 mm Rapid traverse: 50 mm Coarse adjustment with air cushion: 280 mm External grinding spindle motor: 4 kW / (5.5 kW = option) Infinitely variable speed adjustment of grinding wheel via potentiometer Internal grinding spindle motor: 2.2 kW Workpiece spindle motor: 1.1 kW Hydraulic motor: 1.5 kW Lubrication motor: 0.1 kW Hydraulic tank: 80 litres Net machine weight: 3800 kg Infeed drive via DC motor Air cushion-supported rapid adjustable grinding spindle stock for fast and safe positioning to grinding location. Separate drive for spindles for external and internal grinding. Fully automatic operating sequence, infeed movement via rotary dial switch: Rapid approach, rapid return, grinding operation, infeed stop, mym-infeed. Bsdpfxeh Rimmo Af Rjdc Automatic longitudinal grinding cycle Central coolant supply for all grinding zones Workpiece headstock with infinitely variable drive for both live and lockable spindle operation. New digital infeed control with Siemens panel and Siemens PLC for longitudinal grinding and plunge grinding, inputs for retraction, infeed amounts, feed rates, spark-out times, dwell strokes; compatible with the old Karstens infeed control; with colour Siemens touch panel. Similar to Weiss/ EMAG/ GP cylindrical grinders/ Studer/ Kellenberger/ Schaudt/ Tschudin/ Tacchella/ Dannobat/ Bahmüller / Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Centre height: 181 mm Centre distance: 1000 mm Maximum grindable workpiece diameter: 360 mm Max load cantilevered: 1000 N (100 kg) Max load between centres: 3000 N (300 kg) Z-axis: Table swivel angle: 10° Table drive, hydraulic: 0–4 m/min X-axis: Cross slide travel: 80 mm Rapid traverse (hydraulic): 50 mm Coarse adjustment – air cushion: 280 mm Bdedpjtqf Rzofx Af Rec Infeed drive by DC motor Rapid infeed speed: 48 mm/min/Ø Infeed cycle: Plunge grinding / Longitudinal grinding 4 preselectable speeds: mm/min/Ø: 0.01–48 4 preselectable infeed increments: mm: 0.001–0.1 Automatic shut-off during stop-grinding: 0–99 s or 0–99 strokes Stepwise infeed: mm/Ø: 0.001 Grinding headstock universal, swivelling: 0–180° Grinding wheel (OD): D x width x bore: 500 x 100 x 127 mm or 203.2 mm Grinding wheel (face, option) D: 250 x 32 x 76.2 mm Grinding wheel (ID, option) D: 2–250 mm Drive power, external/face: 5.5 (7.5) kW Drive power, internal: 2.2 kW Peripheral speed, external: 35 (50) m/s Grinding wheel wear (OD): mm/Ø: 160 Guard width: 100 mm Grinding spindle diameter: 60 mm Internal spindle mounting: 80 (100) mm Workpiece headstock: Infinitely variable drive: MK 4, 1/min: 30–270 / 50–450 Workpiece spindle lockable Spindle mounting: MK 4/24 mm Spindle nose for flange attachment: MK 4, cylindrical Ø63H6 x 6 mm Headstock swivels on rotating part: 0–90° Tailstock: Quill mounting / Quill diameter: MK 4, 750 mm Quill stroke: 45 mm Quill force, N: 100–800 / 250–1400 adjustable Quill operation: manual (foot switch) Quill fine adjustment: ±40 μm Connections: Total machine connected load: 6.5–10 kW Grinding headstock: 5.5 (7.5) kW Workpiece headstock: 0.55 (1.1) kW Coolant filtration: 0.75–2.2 kW Lubrication pump – guideways: 0.1 kW Hydraulic pump: 1.5 kW Hydraulic tank: 80 l Pneumatics: 6 bar Comparable to: Weiss / EMAG / GP cylindrical grinders / Studer / Kellenberger / Schaudt / Tschudin / Tacchella / Dannobat

Condition: new, Year of construction: 2024, pipe diameter (max.): 90 mm, bending angle (max.): 190 °, bending radius (max.): 250 mm, total length: 5,800 mm, total width: 1,550 mm, total height: 1,750 mm, warranty duration: 12 months, sheet thickness aluminum (max.): 4 mm, sheet thickness steel (max.): 4 mm, MAXIMUM CAPACITY : Ø90X4MM MAXIMUM BENDING RADIUS : 250MM DEGREE OF TWIST : 190 DEGREE WORKING LENGTH : 4000MM MOTOR POWER : 27.5KW LENGTH : 5800MM WIDTH : 1550MM HEIGHT : 1750MM BENDING SPEED : CHANGEABLE STANDARD FEATURES One set of bending molds in the dimensions required by the customer Servo Motorized Feed Axis Servo Motorized Rotation Axis Automatic Mailing of Detailed Work Report Servo Bending Axis (SFB 38-CNC/R1) Gearbox Driven Bending System (51-65-76-90) CNC Control Unit with mobile 21" color screen 3D Simulation Twisting Displaying Daily, Weekly and Monthly Total Production Amount Calculating the total length of material to be used Calculate the estimated bending process time Convert X-Y-Z data to Y-B-C Getting remote assistance Portable foot pedal with emergency stop Manual - Automatic Twisting Bending with - Without Bending Safety plate with switch behind the bending head Automatic headstock lubrication system (SFB 38 CNC/R1) Hydraulic Crimping Bsdeu Hiu Aopfx Af Redc Hydraulic Malafa Hydraulic Stop Hydraulic Oil Cooler Hydraulic Linear Slider system Hydraulic Clamp Electrical panel safety lock and keyed panel lock Electric Panel Cooler Protected Against Overload

Condition: new, Year of construction: 2024, pipe diameter (max.): 76 mm, bending angle (max.): 190 °, bending radius (max.): 250 mm, total length: 5,800 mm, total width: 1,550 mm, total height: 1,750 mm, warranty duration: 12 months, sheet thickness aluminum (max.): 4 mm, sheet thickness steel (max.): 4 mm, MAXIMUM CAPACITY : Ø76X4MM MAXIMUM BENDING RADIUS : 250MM DEGREE OF TWIST : 190 DEGREE WORKING LENGTH : 4000MM ENGINE POWER : 23 KW LENGTH : 5800MM WIDTH : 1550MM HEIGHT : 1750MM BENDING SPEED : CHANGEABLE Bsdpfx Afju Hix Is Rodc STANDARD FEATURES One set of bending molds in the dimensions required by the customer Servo Motorized Feed Axis Servo Motorized Rotation Axis Automatic Mailing of Detailed Work Report Servo Bending Axis (SFB 38-CNC/R1) Gearbox Driven Bending System (51-65-76-90) CNC Control Unit with mobile 21" color screen 3D Simulation Twisting Displaying Daily, Weekly and Monthly Total Production Amount Calculating the total length of material to be used Calculate the estimated bending process time Convert X-Y-Z data to Y-B-C Getting remote assistance Portable foot pedal with emergency stop Manual - Automatic Twisting Bending with - Without Bending Safety plate with switch behind the bending head Automatic headstock lubrication system (SFB 38 CNC/R1) Hydraulic Crimping Hydraulic Malafa Hydraulic Stop Hydraulic Oil Cooler Hydraulic Linear Slider system Hydraulic Clamp Electrical panel safety lock and keyed panel lock Electric Panel Cooler Protected Against Overload

Condition: new, Year of construction: 2024, pipe diameter (max.): 65 mm, bending angle (max.): 190 °, bending radius (max.): 250 mm, total length: 4,950 mm, total width: 1,250 mm, total height: 1,600 mm, warranty duration: 12 months, sheet thickness aluminum (max.): 3 mm, sheet thickness steel (max.): 3 mm, MAXIMUM CAPACITY : Ø65X3MM MAXIMUM BENDING RADIUS : 250MM DEGREE OF TWIST : 190 DEGREE WORKING LENGTH : 3000MM MOTOR POWER : 15.5KW LENGTH : 4950MM WIDTH : 1250MM HEIGHT : 1600MM BENDING SPEED : CHANGEABLE Bjdju Hi Rqopfx Af Rjdc STANDARD FEATURES One set of bending molds in the dimensions required by the customer Servo Motorized Feed Axis Servo Motorized Rotation Axis Automatic Mailing of Detailed Work Report Servo Bending Axis (SFB 38-CNC/R1) Gearbox Driven Bending System (51-65-76-90) CNC Control Unit with mobile 21" color screen 3D Simulation Twisting Displaying Daily, Weekly and Monthly Total Production Amount Calculating the total length of material to be used Calculate the estimated bending process time Convert X-Y-Z data to Y-B-C Getting remote assistance Portable foot pedal with emergency stop Manual - Automatic Twisting Bending with - Without Bending Safety plate with switch behind the bending head Automatic headstock lubrication system (SFB 38 CNC/R1) Hydraulic Crimping Hydraulic Malafa Hydraulic Stop Hydraulic Oil Cooler Hydraulic Linear Slider system Hydraulic Clamp Electrical panel safety lock and keyed panel lock Electric Panel Cooler Protected Against Overload

Condition: new, Year of construction: 2024, pipe diameter (max.): 38 mm, bending angle (max.): 190 °, bending radius (max.): 250 mm, total length: 4,280 mm, total width: 1,000 mm, total height: 1,500 mm, warranty duration: 12 months, sheet thickness steel (max.): 3 mm, MAXIMUM CAPACITY : Ø38X3MM MAXIMUM BENDING RADIUS : 250MM DEGREE OF TWIST : 190 DEGREE WORKING LENGTH : 3000MM MOTOR POWER : 7.5KW LENGTH : 4650MM WIDTH : 1000MM HEIGHT : 1500MM BENDING SPEED : CHANGEABLE STANDARD FEATURES One set of bending molds in the dimensions required by the customer Servo Motorized Feed Axis Servo Motorized Rotation Axis Automatic Mailing of Detailed Work Report Servo Bending Axis (SFB 38-CNC/R1) Gearbox Driven Bending System (51-65-76-90) CNC Control Unit with mobile 21" color screen 3D Simulation Twisting Displaying Daily, Weekly and Monthly Total Production Amount Calculating the total length of material to be used Calculate the estimated bending process time Convert X-Y-Z data to Y-B-C Getting remote assistance Portable foot pedal with emergency stop Manual - Automatic Twisting Bending with - Without Bending Bedpju Hi T Ejfx Af Rsdc Safety plate with switch behind the bending head Automatic headstock lubrication system (SFB 38 CNC/R1) Hydraulic Crimping Hydraulic Malafa Hydraulic Stop Hydraulic Oil Cooler Hydraulic Linear Slider system Hydraulic Clamp Electrical panel safety lock and keyed panel lock Electric Panel Cooler Protected Against Overload

Condition: new, neu ca. 12 - 14 Wochen ab Auf Spanien 50410 € 952.75 € 35 mm MK 4 390 mm 94- 2.225 (16) 50 Hz 113 U/min M35 1660 mm 1510 mm 2600 mm 910 kg 180 mm Bedpjynmtxofx Af Rjdc 190 - 650 mm 1310 mm 125 mm 400 x 420 mm 0,10 - 0,18 - 0,24 (3) mm/min 750 - 1.500 U/min ERLO (MADE IN SPAIN) FOR DEMANDING WORKSHOP USE drilling and milling machine automatic feed precision electromagnetic clutches geared drive cross table fixed base and displaceable headstock control panel cooling equipment with electric motor pump hand wheel for fine tuning clamping device for tools adjustable stop drill guard OPTIONAL EQUIPMENT (PRICES ON REQUEST): Digital read out for drilling depth Tapping device Motorized longitudinal and/or transverse feed Digital read out for table axes and/or drill head height adjustment

Year of construction: 1995, condition: excellent (used), Sliding headstock The machine is in very good condition Bdjdpfx Afsgv U R Tj Rjc Technical data in the last photo

Condition: used, Year of construction: 2023, operating hours: 1,285 h, QUASER UX_500 C 23.12.2025 Year of manufacture: 2022, Commissioned: 2023, Like-new, flawless condition, Only 1,285 production hours Standard Specification: - Siemens 828 D PPU29 control with 15" touchscreen - Adjustable operator panel (tiltable and rotatable) - Heat exchanger for climate-controlled electrical cabinet - Tool system: SK40_BigPlus, suitable for holders with/without face contact according to DIN 69871 - Pull studs according to DIN 69872 - Portable electronic handwheel - Double-arm tool changer with 30 stations - Pneumatically actuated tool change door - Direct position measuring system on rotary axis - Direct position measuring system on tilting axis - Infrared receiver for workpiece and tool measurement - Three-color signal beacon - Coolant spray gun - External air blast for dry machining - Automatic central lubrication for ball screws - Computer-optimized, heavy machine base from heavily ribbed cast iron - Sturdy and rigid portal-type machine design - Chip disposal consisting of work area chip flushing system with Grundfos pump (75 L/min at 3 bar) Bjdpfxey D T H Ee Af Rodc - Chip channels made of stainless steel - Two auger conveyors in the work area - Full work area protection with two corner view windows and two work lights - Flood coolant with 4 ring nozzles at spindle nose, Grundfos pump (75 L/min at 3 bar) - Machine color: RAL 7035 light grey - Coolant tank, spindle headstock, and doors painted RAL 9005 deep black Existing Siemens options: - SW option: Kinematic measurement cycle 996 for Siemens 828 D - Cycle for measuring the center point of rotary and tilting axes - SW option: In-process measuring cycles for Siemens 828 D - Measurement cycles for automatic workpiece inspection/measurement - Workpiece zero-point probing with infrared 3D probe - Operating manual UX500 Siemens 828 D - SW option 3D simulation - Network drive management Further details, including video, available upon request by email.

Condition: ready for operation (used), Year of construction: 2017, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, overall weight: 4,350 kg, number of axes: 3, This 3-axis ONA QX4 die-sinking EDM machine was manufactured in 2017. It features an X-axis travel of 600 mm, Y-axis travel of 400 mm, and Z-axis travel of 400 mm. The work tank dimensions are 1060 x 750 x 480 mm, accommodating a maximum workpiece weight of 1500 kg. If you are looking to get high-quality die-sinking capabilities, consider the ONA QX4 machine we have for sale. Contact us for further details. • Work tank dimensions (L x W x H): 1060 x 750 x 480 mm • Maximum workpiece weight: 1500 kg • Maximum electrode weight: 100 kg • Distance table to headstock: 200–600 mm • Voltage: 400 V • Frequency: 50 Hz Bdjdpfx Asy Eq Ipof Roc • Current: 25.8 A • Power: 17.9 kVA • Minimum air supply: 6 bar • Generator unit weight: 350 kg

Condition: excellent (used), Year of construction: 2017, Control: Heidenhain iTNC 640 HSCI Location: Germany, under power Travels X Longitudinal: 14100 mm Y Vertical: 5000 mm Z Ram: 1550 mm Headstock Spindle power: 51/36 (40%/100%) KW Spindle Torque: 1500 NM Spindle speed: 5000 rpm Spindle Taper: ISO 50 Ram size: 420 x 420 mm C- axis integrated: 0.001° - continuous Desh gearbox Heads and Head changer Automatic pickup station for: 3 places Head 1: Uhami 30 continuous A and C axis 180°+, 180°- Head 2: Uhami 30 continuous A and C axis 180°+, 180°- (New in 2022) Head 3: horizontal spindle extension: 400 mm Head 4: horizontal spindle extension: 800 mm Head 5: ISO 40 vertical head to be mounted on horizontal spindle extension Tables Table 1 Size: 3000 x 3000 mm V- Travel: 2400 mm Bdjdpfx Aey D T Hlef Roc Table load capacity: 50 Tonnes Table 2 Size: 2500 x 2000 mm V- Travel: 2400 mm Table load capacity: 30 Tonnes Additional information: Floor plates: 2 pcs. 4000 mm x 2000 mm, 2 pcs. 5000 mm x 2000 mm Working Area separation Tool changer Robot type Spindle through coolant Chip conveyor 3D probe Movable operator platform Wireless Handwheel CE marking Approx. 14000 programming hours Continous heads, continous tables

Condition: like new (used), Year of construction: 2017, Year: 2017 Control: Heidenhain iTNC 640 HSCI Location: Germany, under power Travels X Longitudinal: 14100 mm Y Vertical: 5000 mm Z Ram: 1550 mm Headstock Spindle power: 51/36 (40%/100%) KW Spindle Torque: 1500 NM Spindle speed: 5000 rpm Spindle Taper: ISO 50 Ram size: 420 x 420 mm Bdsdjy D Tzpjpfx Af Rjc C- axis integrated: 0.001° - continuous Desh gearbox Heads and Head changer Automatic pickup station for: 3 places Head 1: Uhami 30 continuous A and C axis 180°+, 180°- Head 2: Uhami 30 continuous A and C axis 180°+, 180°- (New in 2022) Head 3: horizontal spindle extension: 400 mm Head 4: horizontal spindle extension: 800 mm Head 5: ISO 40 vertical head to be mounted on horizontal spindle extension Tables Table 1 Size: 3000 x 3000 mm V- Travel: 2400 mm Table load capacity: 50 Tonnes Table 2 Size: 2500 x 2000 mm V- Travel: 2400 mm Table load capacity: 30 Tonnes Additional information: Floor plates: 2 pcs. 4000 mm x 2000 mm, 2 pcs. 5000 mm x 2000 mm Working Area separation Tool changer Robot type Spindle through coolant Chip conveyor 3D probe Movable operator platform Wireless Handwheel CE marking Approx. 14000 programming hours Continous heads, continous tables

Condition: good (used), Year of construction: 1970, functionality: fully functional, Data : Tip width 300 mm Tip height 150 mm External grinding spindle 4.0 kW Grinding wheel max. 400 x 80 x 127 mm Spindle cone MK4 Bdodpfxoy Hdmze Af Rjc Workpiece headstock 0.55 kW Workpiece speeds 30 - 450 rpm Internal grinding spindle 1.5 kW

Condition: good (used), Year of construction: 2003, travel distance X-axis: 14,000 mm, travel distance Y-axis: 4,000 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 2,500 rpm, feed length W-axis: 900 mm, spindle diameter: 152 mm, FPT MAR-X 3, 2003 CNC SELCA 4045 PLUS DIGITAL, Built 2003, CNC can be changed to Heidenhein 620. FPT TRT25. Rotary Table, 25 Ton. Two axis Head, 144 x 144. Bdjdpfxowdm A Hs Af Rjc X, Column travel 14.000 mm Y, Headstock vertical travel 4.000 mm Z, Ram stroke 1.500 mm W, Spindle Ø 152,4 mm 900 mm Spindle taper ISO 50 Spindle speed 0 - 2.500 rpm Spindle motor 48 kW Automatic tool changer 40 Tools FPT TRT25. Rotary Table, 360.000° 2.500 x 2.500 mm Rotary Table longitudinal travel 2.000 mm Table load 25 Ton

Condition: used, Year of construction: 2007, functionality: fully functional, travel distance X-axis: 3,100 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 3,000 rpm, table length: 1,800 mm, table width: 2,000 mm, feed length W-axis: 700 mm, workpiece weight (max.): 12,000 kg, milling spindle length: 700 mm, FPT CASTEL RED HEIDENHEIN TNC 430. Built in 2007. X=3100mm Bdedpfxjwdiu Ej Af Rjc Y=2000mm Z=1000mm Table 2000 x 1800 mm, 12 Ton Cooling through spindle. X Column travel 3,100 mm Y Headstock vertical travel 2,000 mm Z spindle stroke 700 mm W Column in spindle direction 1,000 mm Spindle diameter 130 mm Spindle diameter ISO 50 Spindle speed 3000 rpm Spindle motor 37 kW Rotary table size 1,800 x 2,000 mm Table load 12 tons C-axes 360,000°
