Used Toggle Press - Double Column for sale (25,803)

Condition: used, Year of construction: 1998, machine/vehicle number: 1 / 2000, Pressure total: 2000 ton Ram stroke: 900 mm Slide adjustment: 800 mm Shut height (stroke down, adjustment up): 1800 mm Free frontal opening L-R: 5040 mm Distance between oil tray: 4840 mm Distance between the columns F - B: 2600 x 2400 mm Table surface area : 5000 x 2700 mm Slide area: 5000 x 2700 mm Die cushion capacity in table: 400 ton Die cushion stroke: 350 mm Die cushion pad area: 4200 x 2100 mm Cushion pressure in ram: 200 ton Ejector stroke in ram: 200 mm Number of strokes: 8 - 14 s.p.m. Required power: 350 kW Height over floor approx.: 11350 mm Die weight at the ram max.: 40000 kg Die Weight total: 80000 kg Weight of machine approx.: 580 ton Standard configuration Moving bolster front sidePin diameter 52 mmForce in microinches = 400 tA SIEMENS control system is installed Godpfeyvz U Isx Ahzjiw The documentation is available.A packing list would be available, as an identical press has already been dismantled.

Condition: used, Year of construction: 1998, machine/vehicle number: 2 / 2000, Pressure total: 2000 ton Gedpfx Aheyvz Stozeiw Ram stroke: 900 mm Slide adjustment: 800 mm Shut height (stroke down, adjustment up): 1800 mm Free frontal opening L-R: 5040 mm Distance between oil tray: 4840 mm Distance between the columns F - B: 2600 x 2400 mm Table surface area : 5000 x 2700 mm Slide area: 5000 x 2700 mm Die cushion capacity in table: 400 ton Die cushion stroke: 350 mm Die cushion pad area: 4200 x 2100 mm Cushion pressure in ram: 200 ton Ejector stroke in ram: 200 mm Number of strokes: 8 - 14 s.p.m. Required power: 350 kW Height over floor approx.: 11350 mm Die weight at the ram max.: 40000 kg Die Weight total: 80000 kg Weight of machine approx.: 580 ton Standard configuration Moving bolster front sidePin diameter 52 mmForce in microinches = 400 tA SIEMENS control system is installed The documentation is available.A packing list would be available, as an identical press has already been dismantled.

Condition: used, Year of construction: 1985, Pressure total: 250 ton Ram stroke: 70 / 250 mm Slide adjustment: 160 mm Ejector in ram: 20 ton Ejector stroke in ram: 10 mm Shut height (stroke down, adjustment up): 520 mm Free lateral opening F-B: 1.300 mm Table surface area : 1.600 x 1.600 mm Slide area: 1.600 x 1.600 mm Number of strokes: 0 - 50 s.p.m. Required power: 33 kW Height over floor approx.: 5.500 mm Weight of machine approx.: 58 ton Roll feeder Material width: 1250 mm Material thickness: 0,3 - 1,6 mm Control: Siemens S7 Gisdpfsyvkukex Ahzjw

Condition: excellent (used), Year of construction: 1995, Manufacturer: ROVETTA Model: SC2-630 Gjdpfxoyv I N Se Ahzeiw Year: 1995 Condition: Used Stock number: 0393 Pressing force: 630 t Number of pressing points: 2 Ram stroke: 152 mm Ram adjustment: 203 mm Table size: 1,830 x 1,220 mm Ram size: 1,830 x 1,220 mm Usable front opening: 1,880 mm Strokes/min: 25-60 Main motor power: 58 kW

Condition: new, pressure 17,0 kN stroke 60 mm throat 105 mm Working height from to 75 -180 mm table surface area 170 x 130 mm spindle diameter 25 mm weight of the machine ca. 35 Kg Godpfx Aofv Avnshzeiw dimensions 260 x 130 x415 mm Knee lever hand presses SPECIAL PRICE!!! HK 1700 stroke 60 mm with crank with fine adjustment of working height Stand height 450 mm Even more pressure in production without additional effort. Maximum pressure performance shortly before the end of the stroke thanks to toggle lever technology. Particularly stable construction of the spindle head and column

Condition: new, pressure 8,0 kN stroke 40 mm throat 90 mm Working height from to 50 - 200 mm table surface area 120 x 160 mm weight of the machine ca. 22 Kg Gijdefv Avkopfx Ahzjw dimensions 160 x 230 x410 mm Knee lever hand press with fine height adjustment SPECIAL PRICE!!! • Working height adjustable by simply loosening the clamping screws on the stand • Working height fine adjustment for HK 800 = adjustment of the press head to the desired working height. The fine adjustment takes place forced in both directions via a threaded spindle • Hand lever arranged in a user-friendly manner, return via spring

Condition: new, pressure 500 kN stroke 40 mm throat 73 mm Working height from to 60 - 150 mm table surface area 115 x 70 mm Gjdpfsf Nb Exex Ahzsiw weight of the machine ca. 10 Kg .Toggle lever hand press SPECIAL OFFER!!! • Working height adjustable by simply loosening the clamping screws on the stand • Working height fine adjustment for HK 800 = adjustment of the press head to the desired working height. The fine adjustment takes place forced in both directions via a threaded spindle • Hand lever arranged in a user-friendly manner, return via spring

Condition: good (used), Year of construction: 1977, Druck 250 t Staenderweite 1120 mm Hub 250 mm Entfernung Tisch/Stoessel, gr. Hub oben, Verst. oben 500 mm Tischflaeche 1100 x 900 mm Tischhoehe ueber Flur 950 mm seitlicher Staenderdurchgang 700 mm Godpfx Aex Ug Djhzoiw Stoesselflaeche 1100 x 900 mm Geschwindigkeit ab mm/s Geschwindigkeit auf mm/s Arbeitsgeschwindigkeit mm/s Ölinhalt 730 l Antriebsleistung 56 kW Gewicht 25 t Raumbedarf (BxTxH) 2,3 x 1,55 x 3,96 m Zusatzinformationen u mit oelhydr. Antrieb, hydr. (§20) und elektr. Steuerung nach UVV, Lichtschranke (Sick), obere und untere Hubbegrenzung, druck- und wegabhaengig steuerbar, Schnittschlagdaempfung, Kurzhubsteuerung, neue Steuerung (Mitsubishi), Sicherheitssteuerung (PNOZ Multi), Bildschirmsteuerung mit Touch-Screen, Schaltschrank

Condition: used, Eccentric stamping press HAULICK + ROOS, Type RVD 125 Double-column eccentric press Machine No. 212560, Year of manufacture 1981 Pressing force 125 tons Table size 880 x 800 mm Table opening 470 x 140 mm Column distance 900 mm Column distance, side 415 mm Ram stroke 45 mm Ram adjustment range 0-80 mm Installed height as shown in the picture 340 mm Stroke rate 50 to 300 strokes/min Motor power, main drive 22 kW Power connection 380 volts, 50 Hz - Double connecting rod drive with 4-bearing eccentric shaft for off-center ram pressure load - Adjacent electrical cabinet - NC roller feed EBU, width 250 mm, year of manufacture 2003 Gsdpfxjhlnzkj Ahzjiw - Adjacent control panel for the roller feed - Strip feed direction from left to right Space requirement (press) L x W x H 3000 x 2000 x 3020 mm Transport height 2950 mm Weight of the press approx. 11 tons

Condition: reconditioned (used), Year of construction: 1983, Power: 2.000 kN Frequency: 60 rpm Stroke, adjustable: 20 - 120 mm Daylight: 450mm (max. stroke up) Ram adjustement: 100mm Size of bolster: 850 x 810mm Opening in bolster: 00 x 50mm Ram area: 750 x 810mm Motor power: 22 kW Gsdpfogpxc Ssx Ahzjiw equipped by: - 1pc. con rod - 6pc. guideways - hydraulic overload - motorized oil lubrication - motorized ram adjustment - manuel stroke adjustment - pneumatic ram balancing cylinder - anti vibration machine feet

Condition: good (used), Year of construction: 1989, Power: 1.000 kN Size of bolster: 800 x 750 mm Distance betw. columns: 900mm Size of ram: 800 x 600mm Daylight: max. 800 mm Stroke: 480 mm Speed: Fast down: 300 mm/s Working: 30 mm/s Fast up: 300 mm/s Electric power total: app. 31 kW Gjdpfx Ahed E U Nnezeiw Weight: app. 13.000 kg Size of footprint: app. 1,6 x 2,90 x 3,8m (T x B x H) • die cushion, activ, 400kN, stroke 200mm • allowed for 2-hand working • equipped by oil - air chiller • ram guiding by 4 pc. hard chromed Guiding columns

Condition: used, Double-column hydraulic press, NEFF type RHS 125 Z Hydraulic drawing press Machine no. 3973, year of manufacture 1983 Pressing force 125 tons Column width 1050 mm Column opening, side 550 mm Table area 1000 x 800 mm Ram area 1000 x 800 mm Ram stroke 350 mm Installation height max. 750 mm Table height above floor 960 mm Drawing cushion force approx. 12 tons at 105 bar Drawing cushion stroke 100 mm Through-hole in the table Ø 202 mm Rapid traverse speed, downward approx. 360 mm/sec Rapid traverse speed, upward approx. 360 mm/sec Working speed approx. 36 mm/sec Oil tank capacity approx. 1000 liters Motor power, main pump 22 kW Motor power, control pump 4 kW Motor power, control pump 2.2 kW Power connection 400 volts, 50 Hz - Hydraulic drawing cushion under the table with a hole through the table plate Ø 202 mm - Precise 4-way column guidance on the ram corners - Stepless pressing force adjustment - Adjustable fixed stop, electrically controlled via a hydraulic motor Gjdsguvtljpfx Ahzjiw - Stroke damping - 2-hand control panel for releasing the lifting motion on the press - Control cabinet positioned next to the press (1600 x 500 mm) - Documentation including operating manual, electrical wiring diagram, and PLC program printout available Space required for the press L x W x H 2600 x 2400 x 4270 mm Weight approx. 14 tons Good condition

Condition: used, Machine not operational - control system not functioning Available at a special price Double-column hydraulic press ALPHA TEC -- ALPHATEC Type RPS 5000 Factory No. 300487, Year of Manufacture 2006 Pressing force: 500 tons Distance between columns (front and rear): 2520 mm Table area: 2500 x 2500 mm Ram area: 2500 x 2500 mm Ram stroke: 600 mm Maximum installation height: 600 mm Table height above floor: approx. 900 mm Tank capacity: approx. 1000 liters Ram retraction force: approx. 22 tons Adjustable forward speed: 100-800 mm/s Pressure build-up to 5000 kN: approx. 0.7 sec. Return stroke speed: approx. 300 mm/s Main motor power: 75 kW Control pump motor power: 2.2 kW Power supply: 400 Volt, 50 Hz - 8-fold flat guide for the ram - Hydraulic ram locking in the top dead center position - Adjacent control cabinet (200 x 50 cm) - Electrical control system SIEMENS PLC S7-314 - Operation via SIEMENS OP 170-B (5.7") - 2-hand control panel located beside the machine - Floor-level installation - Table top 2510 x 2530 x 135 mm (approx. 6700 kg) - Central lubrication system - Operating manual with circuit diagrams Space requirement (L x W x H): 372 x 260 x 460 cm Space requirement for horizontal transport (L x W x H): 460 x 372 x 260 cm Weight: approx. 50 tons The machine was used for straightening heated steel flanges. From insolvency – in good condition. Godpfjdzqptsx Ahzsiw

Condition: used, Double-column hydraulic press SCHÖN Type SH 25 Machine no.: 4453 Year of manufacture: 1999 Pressing force: 25 tons Column width: 500 mm Lateral column clearance: 120 mm Table surface: 440 x 320 mm Table opening: Ø 175 mm Ram surface: 360 x 220 mm Clamping pin bore: Ø 40 mm Max. ram stroke: 100 mm Max. installation height: 270 mm Table height above floor: 900 mm Motor power: 7.5 kW Connection voltage: 380 V, 50 Hz Equipment: - Safety light curtain SICK, type FGS 300-11 - Two-hand operation Gsdpjw A Amrefx Ahzsiw - Stroke counter - Rapid and working stroke - Stroke limitation dependent on pressure or position - Mechanically adjustable fixed stop - Pressing force regulation - Adjustable pressing time 1–10 s (pressure holding time) - Adjustable return stroke speed - Blow-off device electrically pre-wired, without air valve - Manual hydraulic tool safety, adjustable via handwheel Dimensions (L x W x H): 1300 x 1200 x 2200 mm Weight: approx. 1200 kg Good condition

Condition: excellent (used), Year of construction: 2001, Manufacturer: ROVETTA Model: S4-800 Year: 2001 Condition: Used Stock number: 0392 Builder: Rovetta Slide force: 800 tons Number of driving points: 4 Slide stroke: 700 mm Slide adjustment: 350 mm Strokes per minute: 10-24 Die height (low stroke, high slide adjustment): 1,100 mm Usable distance between front posts: 4,200 mm Gsdpeyq Tdpjfx Ahzoiw Bolster table size: 4,000 x 2,000 mm Slide dimensions: 4,000 x 2,000 mm Movable table height: 600 mm Side window size: 3,400 x 1,900 mm Number of cushions: 1 Blankholder cushion - total force: 150 tons Lower blankholder cushion stroke: 250 mm Lower blankholder working area: 1,500 x 1,000 mm.

Condition: excellent (used), Year of construction: 2001, Manufacturer: ROVETTA Gisdeyq Tdiopfx Ahzsw Model: S4-1500 Link Drive Year: 2001 Condition: Used Stock number: 0391 Manufacturer: Rovetta Number of strokes: 4 Ram force: 1500 tons Ram stroke: 763 mm Ram adjustment: 400 mm Daylight (bottom dead center, ram up): 1,200 mm Distance between front uprights: 5,700 mm Die bed dimensions: 5,500 x 2,500 mm Ram dimensions: 5,500 x 2,500 mm Moving table height: 600 mm Side window size: 3,400 x 1,900 mm Main motor power: 319 kW Blankholder (total force): 150 tons Blankholder stroke: 250 mm Blankholder working area: 2,000 x 1,200 mm Strokes per minute: 8-24

Condition: used, Year of construction: 1988, functionality: fully functional, Press capacity 5,000 kN Table area 2,400 mm x 1,700 mm Ram area 2,400 mm x 1,400 mm Gedpjyg Emzjfx Ahzsiw Adjustable stroke 25 mm - 200 mm Ram adjustment max. 200 mm Stroke rate 20 - 100 spm Drive power 84 kW Machine weight approx. 62,500 kg with roller feeder/straightener combination + decoiler Further data and photos available on request

Condition: used, Double-column hydraulic press SCHÖN Type UTE/B 50 Machine No. 5509 Year of manufacture: 1971 Pressing force: 50 tons Column span: 550 mm Column clearance (side): 150 mm Gijdpfjv Srfwex Ahzew Table size: 480 x 380 mm T-slot width in machine table: 18 mm Table opening: Ø 70 mm Ram area: 490 x 280 mm Clamping pin bore: Ø 40 mm Max. ram stroke: 150 mm Max. installation height: 390 mm Table height above floor: 890 mm Rapid approach speed: approx. 130 mm/sec Working speed: approx. 20 mm/sec Return speed: approx. 130 mm/sec Motor power: 4 kW Power supply: 380 Volt, 50 Hz - Stepless pressing force adjustment - Rapid and working stroke - Pressure or stroke-dependent stroke limitation - Adjustable pressure holding time, press time extension 0.5–6 s - Mechanically adjustable hard stop via handwheel on ram - SICK light barrier, Type LVU - Stroke counter - Double column guide on ram Space requirement (L x W x H): 1100 mm x 1050 mm x 2320 mm Weight: approx. 1.5 tons Good condition

Condition: excellent (used), Year of construction: 2003, Manufacturer: ROVETTA Year: 2003 Condition: Used Giedoxlh Rfopfx Ahzsw Stock number: 0385 Pressing force: 630 tons Number of connecting rods: 4 Slide stroke: 300 mm Slide adjustment: 250 mm Die clearance at BDC: 950 mm Strokes per minute: 15/65 Maximum front opening: 5,200 mm Table dimensions: 5,000 x 2,630 mm Slide dimensions: 5,000 x 2,630 mm Main motor power: 132 kW

Condition: excellent (used), Year of construction: 1993, functionality: fully functional, Manufacturer: GIGANT Model: G2-1200/2 Year: 1993 Condition: Used Stock number: 0375 Gsdpfjx R U Idex Ahzjiw Pressing force: 1200 t Number of pressing points: 2 Die table size: 3,700 x 2,700 mm Ram size: 3,700 x 2,700 mm Ram stroke: 1,000 mm Max. vertical clearance: 1,590 mm Die opening at BDC: 610 mm Lower blankholder stroke: 400 mm Movable bolster: Present at the front

Condition: ready for operation (used), Two mechanical large-format double-column eccentric punching presses Rhodes (UK) are available. Press force: 350t, table dimensions X/Y: 1750mm/920mm, ram dimensions X/Y: 1550mm/615mm, ram stroke: 101mm, ram adjustment: 100mm, stroke rate: 50 strokes/min, max. installation height: 483mm, side opening X/Y: 630mm/380mm, table height: 933mm, weight: approx. 43000kg. Documentation available. On-site inspection is possible. Gedpoyfv I Tsfx Ahzeiw

Year of construction: 1978, condition: used, pressure 40 t Gisdjq Rhkwopfx Ahzjw distance between columns 600 mm stroke 150 mm table surface area 600x410 mm ram surface 220x130 mm table height 850 mm weight of the machine ca. 2,5 t

Year of construction: 1978, condition: used, pressure 25 t distance between columns 580 mm stroke 150 mm dayligth 370 mm table surface area 560x400 mm ram surface 400x350 mm hole in the table 80 mm Gsdpfx Ahelp U Arozjiw weight of the machine ca. 2,5 t dimensions of the machine ca. 1500x500x2500 m

Year of construction: 1977, condition: used, pressure 200 t distance between columns 500 mm stroke 150 mm ram surface 320 mm table surface area 470x400 mm Gisdpfx Aslp Uz Uohzjw weight of the machine ca. 12 t dimensions of the machine ca. 2000x2000x2700 mm

Year of construction: 1979, condition: used, pressure 160 t distance between columns 850 mm stroke 400 mm ram surface 800x700 mm 300 mm pressure of ejector 20 t table surface area 800x700 mm total power requirement kW weight of the machine ca. 12 t Gisdolp Uz Ropfx Ahzow dimensions of the machine ca. 1800x1800x4200 m
