Used Guilliet Four Side Planer Guilliet Kxy for sale (23,491)

Condition: new, Year of construction: 2021, Max. working width 260 mm Min. working width 25 mm Max. working height 180 mm Min. working height 8 mm Feed speed 4/30 m/min Spindle speed 6000 rpm Tool holder spindle diameter ø 40 mm Tool diameter 1st lower spindle ø 125 mm Min. tool diameter 4th spindle ø 110 – 125 – 140 mm Max. tool diameter 4th spindle ø 200 m Min./Max. tool diameters (except 1st and 4th spindle) ø 110 / 200 mm Diameter and thickness of the undercutter ø 145 – 12 mm Length of the worktable 2500 mm Axial adjustment of the vertical spindles under the worktable - 90 mm Power of the lower planer spindle motor 4 kW Power of the right spindle motor 4 kW Power of the left spindle motor 4 kW Power of the upper spindle motor 5.5 kW Power of the second, lower spindle motor 4 kW Power of the feed motor 2.2 kW Feed up/down 0.37 kW Worktable made of HARDOX steel standard Pneumatic pressure of the drive units standard Poly - V belts drive all spindles, withstand the highest efficiency of the power of the motors standard Independent motor unit for each spindle standard Drive system powered by the Cardan system standard Chip removal system standard Manual lubrication of the work table standard Direct start of the motor with illuminated buttons from the control panel standard Kedpfxsv Dtwfo Akwjdt Overall dimensions (length x width x height) 4300 X 1600 X 1700 mm Weight 2000 kg

Condition: ready for operation (used), functionality: fully functional, Maximum planing width: 230 mm Maximum planing height: 120 mm Spindle diameter: 40 mm 4 heads plus one universal head Head configuration: Bottom, right, left, top, universal Motor power: 4 kW (bottom), 5.5 kW (right), 4 kW (left), 4 kW (universal) Spindle rotation speed: 6000 RPM Table lubrication Kdodpjy N Rb Rsfx Akwjt Electric height adjustment (up/down) Two feed speeds Year of manufacture: 1999 Weight: 2320 kg Voltage: 400 V

Condition: good (used), Planer moulder 230/120 mm, profiling capable, year 2006 Kodpfxsxn Upts Akwedt

Condition: excellent (used), Year of construction: 2016, Steton 5-head four-sided planer. Steton 5-head four-sided planer. The machine after the review does not require a financial contribution. Technical data: - max width of the workpiece 23 cm - max height 13 cm spindle diameter 40mm - 1 - Horizontal bottom 23 cm Kodji Apuhepfx Akwodt - 2 - vertical right 13 cm - 3 - vertical left 13 cm - 4 - horizontal upper 23 cm - 5 - universal 360 degree soundproofing cabin - electric setting of planing thickness - two types of feed speed

Year of construction: 1988, condition: like new (used), Location Kłodawa 66-415 Conditions of delivery OWN RECEIPT Cost of delivery Kdjdpfxjdx Elmo Akwst Customer cover Start type to be agreed Description Comments Four-sided planer, banding machine, Gabbiani spichetting machine Max planing width: 160 mm Max planing height: 100 mm Min. Element length: 180 mm Spindle diameter: 30 mm Number of spindles: 6 Spindle order: down rights, left, Mountain, Mountain bottom Crawler feed: top, bottom Smooth infeed adjustment: 4 - 34 m / min It is possible to work feed at an angle of: 0 ° - 30 ° Feed on cardanach Manual spindle height adjustment Adjustable heads in all directions Automatic lubrication of the track All bearings replaced with Teflon Machine after a full review The machine is adapted to the production of parquet and slats Dust Extractors: 6 x 120 mm Power supply: 400 V Total power: 26.2 kW Dimension of the machine Length: 4060 mm Width: 1500 mm Height: 1200 mm important: planed tables in the whole machine and leveling, setting angles and

Condition: excellent (used), Four-sided planer Weinig Profimat 22 N, 6 heads – the last one is universal. Tools included. Work video of the machine available. Very good condition. Ready for operation. Kedpfxoxyxaaj Akwjdt

Condition: good (used), working width 180 mm Kdodpfx Ajyncgbjkwot working height 120 mm 1 lower spindle 3.7 kW 2 right spindle 3 kW 3 left spindle 3.7 kW 4 upper spindle 3.7 kW two feed speeds: 6 and 12 m/min

Condition: excellent (used), Max planing width: 230 mm Max planing height: 155 mm 2 feed speeds Electrically adjustable height/width Bottom spindle motor: 4 kW Right/left spindle motor: 7.5 kW Top spindle motor: 7.5 kW Kodpexz Uitjfx Akwsdt

Condition: excellent (used), - Number of spindles: 4. - Planing width: max 120 mm. - Planing height: max 100 mm. - Motor power: typically 4 x 3 kW. - 4 feed speeds - Spindle diameter: 30 mm. Kodpfx Akoygy Tpowedt

Condition: good (used), Planing working width, mm 510 Maximum height for double-sided planing, mm 200 Maximum height for four-sided planing, mm 150 Lower planing shaft with 4 knives, electric motor 5.5 kW Upper planing shaft with 4 knives, electric motor 7.5 kW Right spindle diameter 40 mm, electric motor 4 kW Left spindle diameter 40 mm, electric motor 4 kW Kdsdpfx Akjxvfwkowet Electric height/width adjustment

Condition: excellent (used), Four-sided planer KP5-220, manufactured in Taiwan. Maximum planing width: 230mm Maximum planing height: 130mm 2 feed rollers in the table Number of spindles: 5 The motor for the fifth spindle is mounted on the floor. Feed on the cardan shafts with stepless adjustment. Spindles are fully adjustable. Kdsdpok Ttknefx Akwot The machine operates quietly and without vibrations, and has been inspected and found to be in very good condition. Tables are chrome-plated.

Condition: good (used), WEINIG Quattromat four-sided planer max planing width 220mm max planing height 120mm Kdjdpfx Akov Hqn Towjt 4 heads, heads included bottom spindle - 4KW, right and left 7.5KW, top - 5.5KW feed on cardan shafts with smooth adjustment electric lifting up and down electric adjustment of planing width branded machine preserved in good condition

Condition: excellent (used), Weinig four-sided planer max planing width 230mm max planing height 120mm 5 heads, bottom-5,5KW; left and right-11KW, top-11KW, bottom-5,5KW feed - 4KW fully adjustable heads electrically adjustable up and down and planing width 40mm spindles feed on gimbal rollers, with smooth adjustment Ksdpfxjrigxys Akwsdt WEINIG brand solid planer, length of the machine 415cm machine checked in original condition

Condition: good (used), Year of construction: 2006, machine/vehicle number: 108111, functionality: fully functional, working width: 240 mm, planing height: 160 mm, working height: 180 mm, Four-sided planer after service inspection, machine weight 3900 kg Kjdpsvrq U Dofx Akwedt

Condition: excellent (used), functionality: fully functional, FOUR SIDE PLANER machine model FUTURA MODUL 4 220 second hand machine working conditions : excellent n.4 spindles ( n.4 indipendent motors ) Kdedpfxjw Dz T He Akwjt CE mark : YES volt. 380/50 with tools : Yes . n.04 tools with interchangeable knives composition machine ( 4 spindles , 4 indipendent motors ) : 1° spindle : planer . motor power Hp 5,5 (Kw 4) 2° spindle : vertical right . motor power Hp 4 (Kw 3) 3° spindle : vertical left . motor power Hp 4 (Kw 3) 4° spindle : thickness planer . motor power Hp 5,5 (Kw 4) technical details : 2 speed feed . motor power Hp 1,3 / 1,7 (Kw 1 / 1,3) spindle rotation speed rpm 6000 feed speed : 8 / 16 mt./min max. useful working width mm. 220 max. useful working height mm. 120 shaft diameter mm.40 inlet length mm. 2300 lubrication system electric height adjustment . motor power Hp 0,25 (kw 0,2) total installed power: 18.6 HP (14 kW) instruction manual CE certification

Condition: excellent (used), Year of construction: 2014, TECHNICAL DATA: Working width 230 mm, working height 120 mm, five heads, spiral-knife cutterheads, head arrangement: bottom/right/left/top/bottom, infeed table length 2500 mm, electric height adjustment, stepless feed speed control, pneumatic material pressure, motor with integrated brake, cutterhead speed 6000 rpm, total weight 2000 kg, motor power ratings: 5.5 kW/7.5 kW/7.5 kW/4 kW, year of manufacture unknown. Kdedey D Sfyepfx Akwet

Condition: as good as new (ex-display), Demonstration machine Standard equipment: Solid machine frame Long feed table Optimal price/performance ratio Noise protection hood Digital display of width and height settings 100% Made in EU (developed, built, quality-tested) Technical data: Planing width (finished size) min./max. 25 - 180 mm Kedpfx Akovrvxbjwedt Planing height (finished size) min./max. 10 -105 mm Min. workpiece length (individual workpiece) 350 mm With group feed 250 mm Feed table length 1700 mm Cutter shaft speed 6000 rpm Spindle diameter 40 mm Planer head diameter 120 mm Clamping length of vertical spindles 120 mm Clamping length of horizontal spindles 190 mm Feed speeds 6/12 m/min Feed roller diameter 120 mm Motor power feed 0.8/1.1 kW Motor power horizontal spindles 4 kW + 4 kW Motor power vertical spindles 4 kW + 4 kW Motor output at 100% duty cycle 17.1 kW Extraction connection: 2 x 120 + 1 x 150 mm Weight approx. 950 kg Prices subject to change, errors, printing and typesetting errors reserved

Condition: used, Year of construction: 1989, Four-sided planer FUTURA ROTOMAT 220/5 with fifth milling spindle Kedpsxx Tb Nsfx Akwedt

Condition: excellent (used), functionality: fully functional, working width 230mm working height 120mm 4 heads heads adjustable in two axes Kodpfx Akoyxlq Sswodt diameter of spindles 40mm control of planing dimensions from the panel star/delta start of spindles two feed gears table top lubrication system year of production 1998

Condition: like new (used), Feeder for four-sided planer VANHOLD, 0.55 kW Kedpfx Ajyq Hxmjkwedt

Condition: new, Year of construction: 2025, functionality: fully functional, Material feed unit for four-sided planer IF-100 Maximum and minimum length of workpiece: 1050 – 6100 mm Maximum and minimum width of workpiece: 50 – 247 mm Maximum and minimum thickness of workpiece: 12 – 100 mm Feed speed controlled by frequency inverter: 20–100 m/min Kdsdpfx Aksxz Ax Nowst Main motor power: 5 kW Accelerating upper feed rollers: 2 pcs Accelerating lower feed rollers: 2 pcs Driven feed rollers: 3 pcs Feed roller dimensions: 180 × 100 mm Feed motor power with flat chain: 0.37 kW Number of flat feed chains: 5 pcs

Condition: used, Technical data: Max planing width: 230 mm Max planing height: 140 mm Diameter of the spindles: 40 mm Number of spindles: 4 Order of spindles: bottom 5.5 kW right + left 11 kW top 7.5 kW feed 3 kW Manual adjustment of all heads Number of top steel pulling rollers: 4 Number of top rubber pulling rollers: 1 1 rubber roller in the top Extraction spigot diameter: 130/150 mm Infinitely adjustable feed rate: 4-26 m./min Feed on gimbals Kdodpfx Aeqv Awijkwst Working table lubrication pump Pressure: 6 atm. Electric lifting of the body Power supply: 400 V Overall dimensions: Length: 4180 mm Width: 1720 mm Height: 1740 mm

Condition: used, Technical data: Max planing width: 230 mm Max planing height: 120 mm Spindle diameter: 40 mm Number of spindles: 5 Spindle sequence: Kedpfsmiik Tsx Akwjdt down 5.5 kW right + left 11 kW up 7.5 kW universal 5.5 kW Each spindle on a separate motor Number of upper steel pulling rollers: 5 Number of upper rubber pulling rollers: 3 1 rubber roller in the table top Extraction port diameter: 150 mm Smooth feed adjustment: 4-24 m/min Cardan feed Table lubrication pump Pressure: 6 atm. Electric lifting of the body Power: 400V Overall dimensions: Length: 4240mm Width: 1550mm Height: 1560mm

Condition: excellent (used), Technical data: Max planing width: 230 mm Max planing height: 130 mm Spindle diameter: 40 mm Number of spindles: 5 1, 4, 5 spindle on a separate engine 2, 3 spindle on one engine Number of upper steel pulling rollers: 4 Kdjdpfx Aov Tyg Eskwjt Number of upper rubber pulling rollers: 3 Diameter of the extraction nozzle: 100, 110, 140 mm Smooth feed adjustment: Feed on cardans Work table lubrication pump 1 smooth roller in the table top Pressure: 6 atm. Electric lifting of the body Power supply: 400 V Total power: 35 kW Overall dimensions: Length: 4860 mm Width: 1640 mm Height: 1670 mm

Condition: used, Technical data: Max planing width: 240 mm Max planing height: 130 mm Spindle diameter: 400 mm Number of spindles: 4 Spindle order: bottom right left top Each spindle on a separate engine Toothed roller in the table before the first head Number of upper steel pulling rollers: 4 Number of upper rubber pulling rollers: 1 Smooth feed adjustment Feed on cardans Worktable lubrication pump 2 smooth rollers in the table Pressure: 6 atm. Kdedpfev Um Tbox Akwot Electric lifting of the body Power supply: 400 V Total power: 28 kW Overall dimensions: Length: 3780 mm Width: 1800 mm Height: 1800 mm
