Used 4-Sided Planer for sale (66,648)

Condition: excellent (used), Year of construction: 1994, 4 side planer 8 8 HARBS heads long table going 3 meters. Machine weight 5500 kg Nljdpel Dw Nxofx Ag Dja cardan drive. Head arrangement, bottom horizontal, right vertical, second right vertical, left vertical, top horizontal, bottom horizontal, top horizontal. Upper horizontal. 5.5 kW and 7.5 kW motors. Planing width 230 mm. Planing height 160 mm.

Condition: new, Year of construction: 2021, Max. working width 260 mm Min. working width 25 mm Max. working height 180 mm Min. working height 8 mm Feed speed 4/30 m/min Spindle speed 6000 rpm Tool holder spindle diameter ø 40 mm Tool diameter 1st lower spindle ø 125 mm Min. tool diameter 4th spindle ø 110 – 125 – 140 mm Max. tool diameter 4th spindle ø 200 m Min./Max. tool diameters (except 1st and 4th spindle) ø 110 / 200 mm Diameter and thickness of the undercutter ø 145 – 12 mm Length of the worktable 2500 mm Axial adjustment of the vertical spindles under the worktable - 90 mm Power of the lower planer spindle motor 4 kW Power of the right spindle motor 4 kW Power of the left spindle motor 4 kW Power of the upper spindle motor 5.5 kW Nledpfx Asv Dtwfjg Doa Power of the second, lower spindle motor 4 kW Power of the feed motor 2.2 kW Feed up/down 0.37 kW Worktable made of HARDOX steel standard Pneumatic pressure of the drive units standard Poly - V belts drive all spindles, withstand the highest efficiency of the power of the motors standard Independent motor unit for each spindle standard Drive system powered by the Cardan system standard Chip removal system standard Manual lubrication of the work table standard Direct start of the motor with illuminated buttons from the control panel standard Overall dimensions (length x width x height) 4300 X 1600 X 1700 mm Weight 2000 kg

Condition: used, Year of construction: 1999, total width: 1,260 mm, total height: 1,750 mm, Empty weight: 1.300 kg Dimensions (LxBxH): 175 x 126 x 175 cm Four-sided planer Griggio G18/4 Year of construction 1999 400 V, 23 kW, 47 Ampere Machine number: MC00029325 Tersa planing heads Min/max working width 25/180mm Min/max working height 7/120mm minimum workpiece length 450mm Feed speed 7 or 14m/min Spindle diameter 40mm Input table 2000mm Speed 6000 rpm 4 axles: Nodpfx Ajyff Rkjg Dsla 1st, bottom: 5.5kW 2nd/3rd, left/right: 7.5kW 4th, top: 7.5kW 3300x1600x1700mm, weight 1300kg - Year: 1999 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: MC00029325 - Transport dimensions: 1750mm x 1260mm x 1750mm (l x w x h) - Transport weight [kg]: 1300kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: excellent (used), functionality: fully functional, FOUR SIDE PLANER machine model FUTURA MODUL 4 220 second hand machine working conditions : excellent n.4 spindles ( n.4 indipendent motors ) CE mark : YES volt. 380/50 with tools : Yes . n.04 tools with interchangeable knives composition machine ( 4 spindles , 4 indipendent motors ) : 1° spindle : planer . motor power Hp 5,5 (Kw 4) 2° spindle : vertical right . motor power Hp 4 (Kw 3) 3° spindle : vertical left . motor power Hp 4 (Kw 3) 4° spindle : thickness planer . motor power Hp 5,5 (Kw 4) technical details : 2 speed feed . motor power Hp 1,3 / 1,7 (Kw 1 / 1,3) spindle rotation speed rpm 6000 feed speed : 8 / 16 mt./min max. useful working width mm. 220 max. useful working height mm. 120 shaft diameter mm.40 inlet length mm. 2300 lubrication system electric height adjustment . motor power Hp 0,25 (kw 0,2) total installed power: 18.6 HP (14 kW) instruction manual Nlodew Dz T Hepfx Ag Dsa CE certification

Condition: new, Working width (finished size) 23 – 180 mm Working height (finished size) 6 -105 mm Min. length of single workpiece 300 mm Feed speed 6 – 12 m/min Motor power horizontal spindles 2 x 7.5 kW Motor power vertical spindles 1 x 7.5 kW Spindle speed 6000 rpm Spindle diameter 35 mm Clamping length vertical spindles 120 mm Clamping length horizontal spindles 190 mm Nsdpfx Ajiiv Dcsg Dsla Manual lubricant pump Profile capacity without axial adjustment on vertical spindle 10 mm Los roller integrated in the outfeed table Suction DM 4 x 120 mm Including OPTIONS: - Motor-driven feed roller in front of the planer with lever for quick changeover - Front vertical printing unit in front of the left vertical spindle - Feed table length 2300 mm - Tool package consisting of 4 planing heads and a joint rebate cutter

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, planing height: 150 mm, spindle diameter: 40 mm, planing width: 230 mm, total height: 2,000 mm, total length: 7,600 mm, overall weight: 6,500 kg, number of spindles: 8, Leadermac, Hypermac 823 8 spindles Planing width 15–230 mm Planing thickness 10–150 mm Minimum workpiece length 200 mm Spindle speed 6000 rpm Spindle diameter 40 mm Permitted saw circle – vertical spindle: 112–232 mm, horizontal: 100–225 mm Feed speed 6–24 m/min 6500 kg Nledpfoxmlk Sex Ag Dsa Length 7600 mm Height 2000 mm Depth 2000 mm 400 volt Manual in Dutch and English

Condition: used, Technical data: Max planing width: 170 mm Max planing height: 130 mm Spindle diameter: 40 mm Number of spindles: 6 Spindle sequence: bottom 4 kW right 3 kW left 5.5 kW right 5.5 kW top 5.5 kW bottom 4 kW Each spindle driven by a separate motor Number of upper steel feed rollers: 7 Number of upper rubber feed rollers: 2 Stepless feed speed adjustment – 4 kW Nlodpeyhndrsfx Ag Dea Feed by chains Lubrication pump for worktable Pressure: 6 atm. Electric raising of the machine body Power supply: 400 V Total power: 33 kW Overall dimensions: Length: 5000 mm Width: 1300 mm Height: 1560 mm

Condition: like new (used), Max planing width: 220 mm Max planing height: 120 mm Spindle diameter: 40 Number of spindles: 4 Njdjtqwkxjpfx Ag Dsla Order of spindles: bottom 4 kW right 3 kW left 3 kW top 4 kW Working table lubrication pump Electric lifting of the body Power supply: 400 V

Year of construction: 1996, condition: reconditioned (used), machine/vehicle number: 16319, max. machining dimensions 220 x 120 mm Njdpeh Euvmjfx Ag Dsla (raw wood dimension max. 230 x 130 mm) min. machining dimensions 15 x 6 mm, automatic positioning "Hecht-Posiomat", feed rate 6 - 22 m/min, feed roller pressure 6 bar, spindle diameter D = 40 mm, max. chip removal 10 mm feed table 2.000 mm, feed motor 2,2 kW, height adjustment 0,37 kW, dressing spindle 4 kW, joining spindle 4 kW, left profile spindle 4 kW, thickness spindle 5,5 kW, glazing bead separation, ex location Seevetal, in "as is" condition as viewed, subject to prior sale, without freight and packing

Condition: ready for operation (used), Year of construction: 1983, Brand: Weinig Model: U 17 A Machine no: 1387-2940 Year of manufacture: 1983 Working height: 1700 mm Working width: 1200 mm 7 spindles in order: Below (4 kW, 5.5 hp), Right (4 kW, 5.5 hp), Left (5.5 kW, 7 hp), Right (4 kW, 5.5 hp), Above (5.5 kW, 7 hp), Under (4 kW, 5.5 hp), Universal (5.5 kW, 7 hp) 40 mm spindles Tiltable feeding-unit Nlodpfevydwzex Ag Dea Variable feed speed: 6-36 m/min Switch for the security fence Infeed path for planer Brand: Sacot Length: 4000 mm Width: 200 mm Output table Length: 3500 mm Width: 200 mm Lifting table Length: 2350 mm Width: 1200 mm Stock no: 2002037BXM

Condition: used, Year of construction: 2011, functionality: fully functional, machine/vehicle number: 116387, planing height: 160 mm, planing width: 260 mm, total width: 145 mm, total height: 170 mm, total length: 375 mm, workpiece weight (max.): 2,100 kg, workpiece height (max.): 160 mm, compressed air connection: 8 bar, type of input current: three-phase, workpiece width (max.): 260 mm, input voltage: 400 V, table length: 2,500 mm, number of spindles: 4, extraction connection diameter: 250 mm, power: 18 kW (24.47 HP), input frequency: 50 Hz, input current: 63 A, Equipment: motor brake, Weinig Cube 4-sided planing machine for sale. Offered for sale due to very little use in our workshop. Originally supplied and always serviced by De Groot Bewerkingmachines. Machine operates perfectly. Currently disconnected and packed, but can be demonstrated in operation upon serious interest. Year of manufacture: 2011 Weight: 2,100 kg Connection value: 400V 63Ah Air pressure: 8 bar Power: 18 kW (25 hp) Extraction connection: 250 mm 1x Max. planing width: 260 mm Max. planing height: 160 mm Minimum planing length: approx. 400 mm Infeed table length: 2,500 mm All values adjustable via touchscreen display Visible removal indication by laser lines Total machine length: 375 cm Total machine width: 145 cm Total machine height: 170 cm Njdpfx Aoxhcizjg Dola Incl. planing heads with knives. This is a good quality machine.

Year of construction: 2009, condition: reconditioned (used), 4-SIDED 5-HEAD PLANER TOS SVITAVA LIGNUM 4-SIDED 5-HEAD PLANER TOS SVITAVA LIGNUM Nlodondcg Nepfx Ag Dja 5-HEAD PLANER 240 MM WITH A GROOVED TABLE AFTER A COMPLETE RENOVATION FWH 225mm 23kW total power

Condition: excellent (used), Year of construction: 1981, 4-SIDE PLANER MOULDING MACHINE WEINIG UNIMAT 17 A With 5 spindles Technical specifications: Working width: max 180 mm Working height: 120mm Spindle speed: 6000 rpm Diameter of the spindle: 40 mm Smallest tool diameter: 100mm Max. tool diameter: 160mm Max. diameter of the vertical spindles : 180mm Max. tool diameter of the 2nd right spindle: 195mm Max. tool diameter of the upper spindle: 200mm Max. tool diameter of the lower spindle: 180mm Feed speed variable: 7 - 18 m / min Throughfeed with springs pressure Trasmissione a catena ( non cardanica) Nodpfxjgqruno Ag Djla Spindle arrangement: 1. spindle bottom hotizontal(planer), KW 4 2nd spindle vertical right KW 3 3rd spindle vertical left- KW 4 4th spindle upper horizontal KW 5,5 5th spindle bottom horizontal KW 4 1 set of Planing tools are included Volt 380/50 hz SECOND-HAND MACHINE IN GOOD CONDITIONS, TESTED IN OUR WORKSHOP BEFORE DELIVERY

Year of construction: 1990, condition: reconditioned (used), 4-sided planer unimat U23, 7 heads Njdpfxspqxnxj Ag Dsla 4-sided Weinig 7-head planer, 7 universal arrangement: horizontal, lower vertical, right, left, vertical, right, vertical, upper horizontal, lower horizontal, and the last universal. The drive is realized by means of cardans. The drive is secured with Rotax clutches. Pressure of the element using pneumatics. Feed smoothly regulated by an inverter. Machine feed 0-42 m/min. 2.5 kW and 7.5 kW engines. Grinding table and a new one. Additionally, new wiring and new electrics. The machine has been completely renovated. Warranty .

Condition: ready for operation (used), Year of construction: 1991, functionality: fully functional, Planing width 220 mm 6 heads with universal .Controlled from a portable console .The machine has safety guards . Nlodpsud Raxjfx Ag Doa

Condition: ready for operation (used), Four-sided planer / construction timber planer Njdpew Dn Uqsfx Ag Dsla Maximum width: approx. 55 cm Maximum height: approx. 14 cm Immediately available Location: Austria, near Grieskirchen

Condition: excellent (used), Year of construction: 2016, Steton 5-head four-sided planer. Steton 5-head four-sided planer. The machine after the review does not require a financial contribution. Technical data: - max width of the workpiece 23 cm - max height 13 cm spindle diameter 40mm - 1 - Horizontal bottom 23 cm Nlsdsi Apuhspfx Ag Dea - 2 - vertical right 13 cm - 3 - vertical left 13 cm - 4 - horizontal upper 23 cm - 5 - universal 360 degree soundproofing cabin - electric setting of planing thickness - two types of feed speed

Condition: excellent (used), Year of construction: 1997, machine/vehicle number: 180.1001, functionality: fully functional, input voltage: 380 V, input current: 32 A, input frequency: 50 Hz, We are offering this very well-maintained Hoffmann + Kuhnheinrich 180 four-sided planer, year of manufacture 1997. Manufacturer: Hoffmann + Kuhnheinrich GmbH Machine type: 180 Year of manufacture: 1997 Nlsdpoy D Nc Nofx Ag Dja Machine no.: 180.1001 Voltage: 380 V Rated current: 32 A Frequency: 50 Hz If you have any questions or require more information, please feel free to send us a message or give us a call.

Condition: good (used), Year of construction: 1996, Weinig Unimat 23 four-side planer - German production - grooved top - year of production 1996 - pulling rollers in the table top TECHNICAL PARAMETERS: planed width 230 mm planing height 160 mm grooved top spindle diameter 40 mm 1 lower spindle 7.5 kW 2 right spindle 7.5 kW 3 left spindle 7.5 kW 4 upper spindle 11 kW 5 lower spindle 7.5 kW feed smoothly adjustable 6-36 m / min 5.5 kW feed motor power six top steel pulling rollers Nedpfxoh Dwl De Ag Dsla two upper rubber pulling rollers three pullers in the table top pneumatic feed pressure pneumatic shoe clamp spindles with brakes pre-table length 1970 mm electric height adjustment central lubrication (split) diameter of nozzles 140 mm dimensions of the machine (length / width / height) 410/200/180 cm weight ~ 3000 kg

Condition: excellent (used), Year of construction: 1995, Weinig Profimat 23E four side planer - German production - year of production 1995 - right and left spindles with a face milling cutter ensuring parallelism and a right angle of 900 - element width measurement - electronic width adjustment TECHNICAL PARAMETERS: planing width 230 mm planing height 120 mm electronic planing width control 1 lower spindle 4 kW 2 right spindle 4 kW 3 left spindle 4.2 kW (face milling) 4 spindle right 4.2 kW (face milling) 5 upper spindle 7.5 kW element width measurement electric height adjustment of the feed rollers electric height adjustment of the upper spindle spindle diameter 40 mm six top steel rollers yen top roller, rubber one roll in the table top pulling pneumatic pressure feed on cardan shafts pre-table length 2470 mm diameter of nozzles 140 mm Machine dimensions Nljdpoibq Nisfx Ag Dea 456x240x220 weight 4000 kg

Condition: good (used), Year of construction: 2002, Weinig Unimat 23 EL four side planer - machine in stock - German production - year of production 2002 - DTR TECHNICAL SPECIFICATIONS: - planing width 230 mm - planing height 170 mm - feed adjustable on the inverter 6-26 m / min - spindle diameter 40 mm 1 lower spindle 7.5 kW 2 right spindle 7.5 kW 3 left spindle 7.5 kW 4 upper spindle 7.5 kW 5 lower spindle 7.5 kW 6 upper spindle 7.5 kW - 4 kW feed motor power - feed on cardan shafts - pneumatic pressure - five top steel rollers - four upper rubber rollers - electric height adjustment - diameter of the stub pipe 140 mm - central lubrication - length of the top 1980 mm Machine dimensions: Nlodpfshhyr Ajx Ag Doa - length 520 cm - width 210 cm - height 210 cm - weight 4000 kg

Condition: as good as new (ex-display), Year of construction: 2025, Double side planer (Double Surface Planer ) extra wide 400 mm Maximum working width 400 mm Maximum working height 200 mm Heavy cardan feed system Special spike feedsystem Unlike the conventional chain drive systems, this machine employs a patented synchronized transmission system along the four fitting columns. Nodpey Dpmusfx Ag Dela Electronic height adjustment Spiral cutterheads top and bottom Latest generation IE-3 motors Spindle and feed brakes CE

Condition: used, Number of boring spindles 5 St. Nlodpfx Ajxu H R Aog Dsa Working width 170 mm Working height 120 mm Length of the planing table 2.000 mm Feed motor 2,2 kW Feed speed 5-24 m/min.

Condition: used, Year of construction: 2017, Number of boring spindles 4 St. Working width 230 mm Nljdpjy Ery Hefx Ag Dsa Working height 160 mm Feed motor 11 kW Feed speed 60 m/min. Planer and moulder Weinig type Powermat 2400 for four-sided planing and profiling of timber including infeed mechanization Weinig High Mech E 1. The machine has a Memory Plus system with electronic positioning (radial) of the spindles 3

Condition: new, Year of construction: 2026, planing width 30-260 mm planing height 10-200 mm number of spindles 6 Nlodpfxey Ehzto Ag Doa Weight 6650 kg
