Used Axa 20Mr for sale (103)

Condition: new, AUTOMATIC DOUBLE SPEED MOTORIZED HYDRAULIC PRESS WITH RAPID POWER 20 TON Nedpfsrvz A Sjx Aixjwk Max capacity TON 20 Approach speed (in rapid) mm/min 1700 Working speed (in slow) mm/min 440 Cylinder rod stroke mm 300 Cylinder rod diameter mm 45 Shank diameter mm M14 Tank capacity liters 30 Max pressure bar 350 Voltage V 400 Frequency Hz 50-60 Motor Power kW 1.5 Max absorbed current A 3.8 Weight Kg 200

Condition: used, Year of construction: 2010, centre height 170 mm Control CNC Achse rotary table dia. 180 mm total power requirement 2 kW weight of the machine ca. 92 kg dimensions of the machine ca. 0,6x0,35x0,4 m Nodpozwxyhofx Aixjwk

Year of construction: 2011, condition: used, overall weight: 50,000 kg, total length: 9,500 mm, total width: 8,000 mm, total height: 5,200 mm, Working Area X-axis travel 3,900 mm Y-axis travel 2,940 mm Z-axis travel 1,100 mm B-axis (swivel head) 90° freely interpolating NC rotary table Ø 2,800 mm Max. workpiece weight 15,000 kg Spindle Tool holder SK 50 Spindle power 63 kW Max. torque 200 Nm Max. speed 6,000 min⁻¹ Feed Rapid traverse X/Y/Z 30 / 30 / 25 m/min Feed force 9,000 N Tool magazine Tool positions 20 Max. tool diameter 110 mm With free adjacent positions 180 mm Max. tool length 400 mm Rotary Table Clamping surface Ø 2,800 mm Max. transport load 15,000 kg Tangential moment 40,000 Nm Tilting moment 90,000 Nm Electrical connection values 3 × 400 V / 50 Hz Equipment HEIDENHAIN iTNC 530 HSCI NC rotary table Ø 2,800 mm Freely interpolating swivel head Portal design Full enclosure Automatic central lubrication Coolant system Chip conveyor Control panel on swivel arm Control: HEIDENHAIN iTNC 530 HSCI Travel X-axis: 3900 - mm Dimensions (LxWxH) approx.: 9500 x 8000 x 5200 mm 5-axis machining: Yes Travel Y-axis: 2940 - mm Nodpozwa Rnjfx Aixswk Movement B-axis: 90 - ° NC rotary table: Yes Travel Z-axis: 1100 - mm Weight approx.: 50,000 kg Year of construction: 2,011 Condition: in working order Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes

Condition: ready for operation (used), Year of construction: 2010, operating hours: 36,604 h, travel distance X-axis: 750 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 600 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, total height: 2,700 mm, total width: 2,250 mm, table width: 500 mm, table length: 1,000 mm, table load: 800 kg, overall weight: 8,500 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 30,000 W, number of slots in tool magazine: 22, product length (max.): 4,500 mm, number of axes: 4, This 4-axis AXA DBZ vertical machining centre was manufactured in 2010. It features an impressive X-axis travel of 2 x 750 mm for pendulum processing, Y-axis travel of 500 mm, and Z-axis travel of 600 mm. The machine includes a NC rotary table with hydraulic counter bearing and a plate-type tool changer. If you are looking to get high-quality machining capabilities, consider the AXA DBZ vertical machining centre we have for sale. Contact us for further details. • Spindle hours: 36,604 h (verified via image) • Operating Hours: 40,049.8 h • Machine ON hours: 81,189 h • Travel Range X-Axis: 2 x 750 mm (pendulum operation) • Travel Range Y-Axis: 500 mm • Travel Range Z-Axis: 600 mm • Clamping Surface / Table Size: 1350 x 500 mm right and left (2x) • Max. Table Load: 800 kg/m² • Spindle Type: Hollow shaft motor, water-cooled • Spindle Speed Range: 30 - 8,000 rpm (Max 10,000 rpm listed / Nmax 12,000 rpm) • Spindle Power (40% ED): 30.0 kW • Spindle Power (100% ED): 20.0 kW • Spindle Torque (40% ED): 143.2 Nm • Spindle Torque (100% ED): 95.5 Nm • Tool Holder: SK 40 • Tool Changer Capacity: 22 positions (Plate/Disc type) • - Max. Tool Diameter: 85 mm (135 mm with free adjacent spots)- Max. Tool Length: 400 mm- Max. Tool Weight: 8 kg (at L=400mm) / 5.5 kg (at L=200mm)- Rapid Feed X-Axis: 25 m/min- Rapid Feed Y-Axis: 25 m/min- Rapid Feed Z-Axis: 20 m/min- Electrical Connection Voltage: 3x 400V / 230V / N / PE, 50 Hz- Connected Load: 55 kVA- Backup Fuse: max. 100 A- Control Voltage: 24 V • Overall dimensions: 4500 × 2250 × 2700 mm • Tool changer: Plate-type tool changer • Design/configuration: Traveling column; Left/Right work areas (pendulum machining) • Safety/enclosure: Maintenance door Additional equipment • NC rotary table RTA 200 with hydraulic counter bearing (4th axis) • Clamping system: Hydraulics for right/left work areas, incl. rotary union for 4th axis • Internal coolant supply (IKZ) • Chip conveyor • Emulsion (coolant) system • Recooling unit (chiller) • A 4th axis is mounted on one clamping side. It is included with the delivery. Technical Specification Nwsdpey Edv Hefx Aixsk Taper Size SK 40

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, Equipment: documentation/manual, CNC-controlled vertical machining center AXA VSC-3-3000-M Year of manufacture: 1995 Control system: Heidenhain TNC 407 Technical data: X-axis travel: 3000 mm Y-axis travel: 420 mm Z-axis travel: 480 mm Table size: approx. 3000 x 500 mm Spindle connection: SK40 Speed range: up to 6000 rpm 22-tool automatic tool changer Coolant system Heavy-duty frame construction Special features: Additional angular/universal milling head 4-/5-axis machining possible Flexible machining of complex workpieces Ideal for toolmaking, mechanical engineering and single-part production The machine is in good condition. Nsdpfsy U Hy Tex Aixjwk Inspection under power is possible by arrangement.

Year of construction: 2012, condition: ready for operation (used), Travel X/Y/Z: 2x 800mm/600mm/600mm, speed: 4000rpm, table spindle nose distance: 180mm-780mm, max. tool diameter/length: 85mm/135mm, rapid traverse X/Y/Z: 25m/25m/20m/min, feed force: 9000N, ground clamping surface: 2x 1000mm/500mm. Dimensions X/Y/Z: approx. 6600mm/3000mm/3200mm, weight: approx. 18000kg. Documentation available. Nedpfxotyymce Aixowk

Year of construction: 1988, condition: ready for operation (used), Travel X/Y/Z: 1820mm/350mm/480mm, table dimensions X/Y: 1900mm/450mm, tool holder: SK40, speed: 12000rpm, tool positions: 22, dimensions X/Y/Z: approx. 5100mm/2800mm/3100mm, weight: approx. 7000kg, control: Heidenhain TNC 355. Njdpfx Aot Dpn Njixowk

Condition: ready for operation (used), Year of construction: 1996, Travel X/Y/Z: 740mm/500mm/480mm, tool holder: SK40, tool positions: 22, max. spindle speed: 4700rpm, control: Heidenhain TNC 426 PA. Machine dimensions: approx. 3000mm/2400mm/2700mm, weight: approx. 5000kg. The machine was used exclusively for machining plastic and operated without metalworking fluid. The coolant system must be repaired. The backup battery of the control is depleted and must be replaced. Inspection possible by arrangement. Nedpfx Aozukt Usixjwk

Condition: used, Year of construction: 1999, AXA VHC-2-M E vertical / horizontal machining centre X-axis travel mm 2.360 Y-axis travel mm 500 Z-axis travel mm 630 B-axis degrees -90 / +90 (Index 2,5°) Rapid traverse m/min 25 (X / Y) Table dimensions mm aprox. 2.400x600 Max. spindle speed rpm 6.000 Tool holder / taper SK 40 DIN 69871 A Tool magazine capacity 22 Nwedpfoztkzpex Aixok

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, AXA VHC-2-1760-XTS Nodjzrgz Aopfx Aixowk

Condition: used, Year of construction: 2003, CNC machining center, universal Manufacturer: AXA Type: VPC 40 U Nwodpfx Aiowwt Nmjxjk Year of manufacture: 2003 CNC control: Heidenhain TNC 430 Travel distances: X/Y/Z = 2,300 x 1,200 x 600 mm NC rotary table dimensions: 1,100 x 1,100 mm Fixed table dimensions: 1,100 x 1,100 mm Tool holder: SK40 Tool magazine: 60 positions Spindle speed: 10,000 rpm Weight: approx. 20 tons 3826ä

Condition: used, Year of construction: 2009, x-travel 2.360/2x 930 mm y-travel 600 mm z-travel 600 mm table surface area 2.750 x 600 mm Control Siemens 840 D spindle tunring speed 30 - 6.000 U/min tool taper SK 50 number of tool places 26 Pos. Number of working hours ca. 50.884 h connected load 69 KVA weight of the machine ca. 20 t In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical features & accessories: - Handwheel, Heidenhain HR 410 - Chip conveyor - External belt filtration system Accessories, tools, and workholding devices shown are included in the scope of delivery Nodpfx Aezqgh Hjixowk only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: used, Travels 2.240 x 420 x 480 mm with an SK 40 DIN 69871 A spindle running 60–6.000 rpm. Controlled by a HEIDENHAIN TNC 430 PA with Heidenhain LS 186 linear scales on all three axes and Deutsche Star ball screws. Tool changer for 22 SMK tool pockets. Equipped with through-spindle coolant at 20 bar, external band filter unit, hinged-belt chip conveyor and a B axis. The 2.240 mm X travel is laid out as two 700 mm clamping zones for pendulum machining. Njdjzpbm Uspfx Aixowk

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 480 mm, controller model: Heidenhain TNC 407, rotational speed (max.): 6,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range X-axis: 3,000 mm Travel range Y-axis: 420 mm Travel range Z-axis: 480 mm Nwsdpfxezncnqs Aixok Table size: approx. 3,000 × 500 mm Spindle connection: SK40 Maximum speed: 6,000 rpm Tool changer: 22-position MACHINE DETAILS CNC control: Heidenhain TNC 407 EQUIPMENT Additional angular/universal milling head Coolant system Documentation/manual 4/5-axis machining: possible Machining of complex workpieces: possible

Condition: ready for operation (used), Year of construction: 2004, Make: AXA Type of machine: VHC 2-4000 M/E Year of manufacture: 2004 Nedszkr S Rspfx Aixowk Control system: Heidenhain TNC 430 Machine's weight: 19.500 kg Tool holder: SK 40 DIN 69871 A spindel speed: 6.000 U/min x-travel: 4.000 mm y-travel: 600 mm z-travel: 800 mm Speed range: 30–6.000 U/min Spindle lock: SK40 Operating time: 28.060 h Chip removal device: Ja Cooling system: Ja Tailstock: Ja (MK4, manuell) Chuck size: 400 mm (RTA 3-400) Traverse Z-axis: 800 mm Table dimensions: 4.440 × 600 mm Number of tools in the magazine: 36 Clamping assembly: SK40 3D Measuring probe: Ja (Renishaw MP10E) : Nein : Ja (Schwenkkopf ±90° / Teilung 1°)

Condition: good (used), Spindles, machining unit, automatic drilling machine, drilling machine, pillar drilling machine Multi-spindle drilling machine -System without control -1x Spindle machining units -2x sleds -Max. feed stroke: 110 mm -Speed: 1400 rpm -Built-in collet: 6 mm Nedpfx Aieb A I Dxexjwk -Weight: 350 kg

Condition: used, Hydraulic power pack, hydraulic pump, hydraulic pump, hydraulic pump -Motor: 0.25 kW 1410 rpm -Max. Pressure: 110 bar -Max. Liter output: l/min -Hydraulic tank -Pressure relief valve: 1 -Valve: 1 -Dimensions: 350/250/H435 mm -Weight: 32 kg Nwsdpjdpyzrefx Aixjk

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, For technical specifications, please refer to the images. Nwjdpfx Aezhuwqsixsk Available starting in early October 2026.

Condition: good (used), Year of construction: 2008, Universal machining center: Fahrständer Machine type: AXA VHC 2 - 1760 XTS Control: Siemens 840 D ShopMill Year: 2008 SPECIFICATIONS Travel Nsdpfxszimr Ao Aixewk X-Axis: 1.760 (2 x 630) mm Y-Axis: 600 mm Z-Axis: 800 horizontal oder 770 vertikal mm A-Axes B-Axes: +/- 100°, hydraulisch geklemmt, stufenlos interpolierend Rapid motion: (X/Y/Z): 40 / 40 / 30 m/min. Amount of controlled axes: 5 Spindle speeds: 30 - 6.000 rpm Spindle power: 30 kW Torque: 143 Nm Tool: SK 40 Toolchanger Tool capacity: 36 NC rotary table: AXA RTA 4L-520 face plate: Ø 520, für vertikalen & horizontalen Aufbau mm Tailstock: manuell, Spitzenhöhe 280 mm Machine weight: 12.000 kg Req. space (LxBxH): 5,2 x 3,4 x 3,3 m Equipment Internal cooling: 30 bar Chip conveyor: links abwerfend, integrierter 200 l Kühlmittelbehälter cooling system Cooling tank: 400 l Caliper: 3 D, Renishaw RMP 60 mit RMI Empfänger (kabellose Ausführung) wahlweise Verwendung der Aussenkühlung mit Durckluft oder Emulsion Direct linear scales: Heidenhain Working mode: 4 Flachführungen gehärtet Gegenführungen mit Gleitbelag (Turcite) beschichtet Erneuerung des Gleitbelag des Grundschlittens X/Y in 2022.

Condition: used, Year of construction: 1986, BAZ Axa VSC1 3000, year of manufacture 1986 Nwedpfx Aioxurgiexek

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 2,600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 850 mm, controller model: Heidenhain iTNC-530, spindle speed (max.): 6,000 rpm, The machining center underwent a complete overhaul and was repainted in 2025! TECHNICAL DETAILS Travel distances Travel distance X-axis: 2,600 mm Travel distance Y-axis: 700 mm Travel distance Z-axis: 850 mm Spindle Spindle speed: 6,000 rpm Distance from spindle nose to table surface with vertical head: 40 - 890 mm Distance from spindle nose to table surface with horizontal head: 250 - 1,100 mm Spindle interface: HSK A63 Spindle motor power: 20 kW Table Table size: 3,060 x 800 mm Max. table load: 1,200 kg/m² Feed rate Rapid traverse rate X/Y-axis: 40,000 mm/min Rapid traverse rate Z-axis: 30,000 mm/min Swivel head Automatic swivel head B-axis: ± 90° Smallest automatic head rotation B-axis: 0.001° Tool magazine Number of tool magazines: 2 Tool positions per tool magazine: 22 Total tool positions: 44 Tool diameter max.: 85 mm Tool length max.: 400 mm Nsdpfezkhvfsx Aixowk MACHINE DETAILS Control model: Heidenhain iTNC-530 Footprint: 9,600 x 3,300 mm Machine height: 3,400 mm EQUIPMENT Continuously variable, automatically swiveling head on B-axis ± 90° Two tool magazines, each with 22 positions High-pressure coolant supply through the spindle Chain-type chip conveyor Operating and maintenance manuals CNC manuals The following work was carried out on the machine in 2025 for the overhaul: Disassembly and overhaul of the ball screw drive or the axis spindle, and replacement of the bearings of the X, Y and Z axes Re-grinding of the wedge/guide strips of the X, Y and Z axes Repair of the dual tool changer, including replacement of the defective encoder, sensor and energy chain Straightening and replacement of bent sheet metal Replacement of oil and filters, and cleaning of the tank Disassembly of the machine table for repair, calibration and cleaning Repair of the coolant tank with restoration of the float switches, paper filter sensors and pumps Repair and/or replacement of push buttons, damaged cables, fans, connectors and sensors of the dual workstation Replacement of the bellows of the X-axis with new parts

Year of construction: 2003, condition: excellent (used), Working travels 6000x1000x1200mm B-Axis milling head +/-90° Table size 6400x1000mm Spindle taper HSK-100 Spindle speeds -9000 rpm Nwjdped Rz Uvsfx Aixjk Tool changer 80 pos. Control SIEMENS 840D Coolant through spindle Tool measuring device Zero point clamping system 3R MARCELS MASCHINEN CH

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 1,760 mm, controller manufacturer: HEIDENHAIN, controller model: TNC410 M Digital, spindle speed (max.): 6,000 rpm, number of axes: 3, This 3-axis AXA Vario vertical machining centre was manufactured in 2000. It features an internal coolant supply and is equipped with a Heidenhain TNC 410 M Digital control system. The machine is in very good condition and fully operational. If you are looking to get high-quality machining capabilities, consider the AXA Vario vertical machining centre we have for sale. Contact us for further details. • With internal coolant supply • Control System: Heidenhain TNC 410 M Digital • Condition: Very good / Fully operational Technical Specification Through-spindle Coolant Yes Nwedpfx Ajzbuxpeixok

Condition: good (used), Year of construction: 2004, functionality: fully functional, feed length X-axis: 940 mm, feed length Y-axis: 520 mm, feed length Z-axis: 600 mm, rapid traverse X-axis: 25 m/min, CNC Vertical Machining Center AXA VCC You are welcome to inspect the machine in our factory while it is running. If you are interested, we will send you demonstration videos of the machine. The AXA VCC is a robust CNC vertical machining center from the German manufacturer AXA Entwicklungs- und Maschinenbau GmbH, based in Schöppingen. The machine is ideally suited for the precise and efficient machining of demanding workpieces in mechanical engineering, mold making, and general metalworking. The machine is equipped with a Siemens Sinumerik control system, which provides reliable operation, efficient programming, and high process reliability. Overall, it is a solid and versatile vertical machining center from a renowned German manufacturer that guarantees high precision, performance, and reliability in industrial production. PS CNC Service Germany GmbH & Co. KG Nwsdpfx Aey Ufrhsixsk Espelkamp You are in the best hands with us – professional, reliable, and with a passion for machines! All information is provided without warranty.

Condition: new, Year of construction: 2026, functionality: fully functional, input voltage: 400 V, AXA ELECTRO-HYDRAULIC PRESS WITH MOVING CYLINDER. Capacity: 150 tons. Dual automatic speed with rapid traverse. Special electrical panel with fast/slow switch for one-hand operation. Moving cylinder with 816 mm traverse stroke. Internal daylight from shoulder to shoulder: 1500 mm. Ram stroke: 300 mm. No. 01 AXA PM150/15 ELECTRO-HYDRAULIC PRESS WITH MOVING PISTON – NEW CONDITION “CE” MARKED. -DUAL AUTOMATIC SPEED WITH RAPID TRAVERSE. -COMPLETE WITH A SPECIAL ELECTRICAL PANEL FOR FAST/SLOW SWITCH FOR ONE-HAND OPERATION. -TECHNICAL DATA SHEET ATTACHED. -Applied force: 150 tons -Cylinder stroke: 300 mm -Internal daylight: 1504 mm -Approach speed (rapid traverse): 1450 mm/minute -Working speed (slow): 105 mm/minute -Cylinder ram stroke: 300 mm -Cylinder ram diameter: 110 mm -Stem diameter: M30 -Tank capacity: 50 liters -Max. pressure: 350 bar -Voltage: 400 V, Frequency: 50-60 Hz -Power: 3 kW motor -Max. current consumption: 7.3 A -Weight: 1500 kg GALTECH distributors. • 2MP block. • No. 2 VIVOIL external gear unidirectional pumps. One for rapid approach and return (calibrated at 20 bar), and one with adjustable pressure controlled by a handwheel to set the required power. • Maximum pressure valve with mechanical lock to prevent overpressure. Nwjdpfx Aielruhdoxok • Standard pressure gauge to display the applied force. • INTECH electrical panel certified according to current regulations and with independent CE marking.
