Used Column-Type Spot Welder for sale (39,568)

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Column-type spot welder PEI MOD. PBP 126 PX Year of manufacture: 2006 CE PEI POINT pneumatic spot welders are user-friendly and ideal for welding all types of metals. This machine is foot pedal operated with pneumatic drive and offers a maximum welding power of 25 kVA. The machine is also equipped with water-cooled electrode holder, electrodes, arms, and transformer. The upper arm is depth-adjustable and the lower arm is height-adjustable. Used • Pneumatic foot pedal operation • Maximum welding power: 25 kVA • Maximum capacity: 2.0 mm • Electrode force: 165 dan • Throat/Arms: 580 mm Nsdsw T Tlfepfx Adrowi • Depth-adjustable upper arm • Height-adjustable lower arm • Steel frame • 400 V, 50 Hz

Condition: excellent (used), Year of construction: 1995, x-travel 14000 mm y-travel 5000 mm z-travel 1500 mm w-axis 3000 mm column daylight 4000 mm column: max. dist. table - spindle nose 4500 mm workpiece weight 100 t table dimension - longitudinal 9000 mm table dimension - cross 3000 mm spindle taper ISO SK 50 spindle turning speed range 2-2500 U/min spindle motor 113 kW spindle diameter 200 mm max. torque on the spindle 9500 Nm feed in x - axis 1-10000 mm/min feed in y - axis 1-10000 mm/min feed range Z-direction 1-10000 mm/min rapid traverse 20000 mm/min height over floor 8600 mm control SIEMENS 840C weight of the machine ca. 360 t ATTACHMENTS angular milling head yes autom. tool clamping yes ball spindles yes guideway covers yes coolant unit yes high pressure cooling syst. (through spindle) yes closed cabin yes chip conveyor yes TECHNICAL DESCRIPTION 2 portal milling centres, each with 3 table pallets 9000 x 3000 mm: - Tool changer with 420 tools - Head pick-up system Njdpfxjvwgm Hs Adrswi - Video monitoring via camera - High pressure lubrication unit for inner cooling 70bar AVAILABLE HEAD UNITS: - Fixed angle head HS800C600 105 Kw 600 long - Fixed angle head HSD350C850 50 Kw 850 long - Fixed angle head HSD 40C880 12 Kw 880 long - Fixed angle head HSD 190C1000 30 Kw 1000 long - Vertical spindle unit VS800C 105 Kw 900 long - Universal spindle unit USIO40C 20 Kw B-axis rotatable at 1° at a time - Angle spindle unit SO800C905 - 22,5° fix - Angle spindle unit HSE1200CS -25° fix - Universal spindle unit (fork milling) USP475C 75 Kw 1/2° Hirth --> 1.350 1/min , B-Achse 0,5 Grad Hirth One additional drilling extension SE 350C plus 1 SE500C. DESCRIPTION OF CONDITION In 2011/2012 these 2 identical machines were retrofitted The milling length was extended to 14meters and an automatic changing system for table pallets was installed. Both machines can be seen under power by prior appointment.

Condition: good (used), Year of construction: 2005, x-travel 6000 mm y-travel 3500 mm z-travel 1500 mm control SIEMENS 840D table load 12 t height over floor 6300 mm table dimension - longitudinal 5000 mm table dimension - cross 2500 mm no. of tables 2 tool change unit 200 -fach weight of tools max. 30 kg tool taper HSK A 100 diameter of tools max. 250 mm workpiece length 500 mm spindle turning speed range 5-6000 U/min c-axis -10 bis 370 ° Nwjdpfsvwglvjx Adrji b-axis 5 bis -95 ° column daylight 3000 mm distance spindle nose and table 1500 mm weight of the machine ca. 161 t dimensions of the machine ca. 20.5 x 11 x 6.3 m This WALDRICH-COBURG Valutec portal milling machine is in very, very good condition and can be beautiful condition and can be inspected by arrangement with the seller.

Condition: good (used), Year of construction: 1991, x-travel 4000 mm Nwjdpfx Adovwgmgersi y-travel 2500 mm z-travel 1200 mm Control FIDIA M30 spindle 37 kW turning speeds 4500 U/min column daylight 2300 mm dist. milling spindle - table surface 1250 mm taper ISO SK-50 table dimension - longitudinal 3000 mm table dimension - cross 1500 mm The Ingersoll-Bohle 5-axis portal milling machine is in good condition and can be can be inspected by arrangement with the seller. Accessories: - High-frequency high-speed spindle 3.8 kW with 25,000 rpm. Description: - infinitely adjustable inclined axis milling head (speed 4500 rpm)

Condition: excellent (used), Year of construction: 2001, x-travel 2200 mm y-travel 3200 mm z-travel 1250 mm Control FIDIA C20 c-axis +/- 200 ° milling-head swivable +/- +90 ° milling-head swivable +/- -100 ° feeds X-axis 50 m/min feeds Y-axis 50 m/min feeds Z-axis 50 m/min tool taper HSK A63 tool change unit 16 Pos. spindle turning speed range 18000 U/min distance between columns 4060 mm dist. milling spindle - table surface 1796 mm connected load 238 kVA weight of the machine ca. 45 t dimensions of the machine ca. 9 x 7 x 5 m This JOBS LinX6 is in very good condition and can be viewed under power by arrangement with the seller. Description: Jobs LinX6 Type: 5-axis milling machine with movable gantry and fixed table Control: FIDIA C20 Year of manufacture: 2001 Travel X: 2200 mm Y travel: 3200 mm Z travel: 1250 mm A-axis travel: +90° / -100° C-axis travel: +200° / -200° Max. feed rate in X/Y/Z: 50 m/min Table clamping surface: 4000 x 2500 mm Clearance between columns: 4060 mm Clearance height between table and portal: 1807 mm Clearance height between table and spindle nose: 1796 mm Milling head: T2K D.01.06 Tool holder: HSK A63 Tool changer: 16-fold Spindle power: S1 from 6800 rpm 40KW Spindle speed: 250 - 18000 rpm Njdpoxa Hl Refx Adrowi Total connected load: 238 kVA Special equipment: - Siemens linear motors in all axes - JIMS / preparation for semi-automatic motor spindle change - Replacement spindle as spare part - External coolant supply / 1000L tank - Minimum quantity coolant dosing - Scraper conveyor - Renishaw TS27 tool measuring system - Ethernet connection - Manual control module Other: Complete documentation available Machine weight: approx. 45 tonnes Space requirements: 8.7 m (width) x 6.7 m (depth) x 5.1 m (height)

Condition: excellent (used), Year of construction: 2014, x-travel 2500 mm y-travel 3000 mm z-travel 1250 mm Control HEIDENHAIN iTNC530 spindle turning speed - stepless 22000 U/min c-axis +-300° milling-head swivable +/- +-110° tool taper HSK 63 A tool change unit 50 Pos. total power requirement 130 kW weight of the machine ca. 53,5 t dimensions of the machine ca. 7,6 x 7,3 x 5,7 m This ZIMMERMANN FZ33c is available immediately and in good condition. - NEW spindle received 6 months ago Nsdpfezak Hgjx Adrewi Description: Technical specifications of the machine and working ranges X-axis 2500 mm Y-axis 3000 mm Z-axis 1250 mm A-axis ± 110 ° C-axis ± 300 ° Includes vibration sensor Includes bearing temperature sensor Includes rotary joint for internal tool magazine feed (IKZ) 5-axis path control: Heidenhain iTNC 530/handwheel HR520, 15” TFT colour display Extraction system LTA Industrial Air Cleaning Machine room canopy 50-position tool changer, chain magazine, behind the machine Chip conveyor, ejection 60° to the left, front-facing No probe available!!! Blum Laser tool measurement ‘Control NT-Micro’ Clamping table Length x width x height 2500 x 3250 x 400 mm Table load 8000 kg/m² (max. 16000 kg) T-slots, arranged longitudinally 18H12 T-slot spacing 250 mm Dimensions, weights Footprint (excluding peripheral equipment) approx. 7600 x 7300 x 5650 mm Total weight approx. 53500 kg Electrical connection data Voltage (three-phase) 400 V Frequency 50 Hz Compressed air connection (to be provided by customer) Required air pressure 6 bar Average air consumption approx. 15 m³/h (depending on machine configuration) Linear axis drives Feed rate X, Y, Z axes 60 m/min Axis acceleration X, Y, Z axes up to 5 m/s² Rotary axis drives – VH30 Feed rate A- and C-axis 360 °/s Axis acceleration A- and C-axis 700 °/s² Resolution A- and C-axis 0.0001 Accuracies of linear axes – in accordance with VDI / DGQ 3441 Positioning accuracy X-axis P= 0.026 mm Y-axis P= 0.028 mm Z-axis P= 0.020 mm Repeatability X-axis Ps= 0.015 mm Y-axis Ps= 0.016 mm Z-axis Ps= 0.010 mm Resolution of measuring systems (interpol) A-, C-axis 0.0001° Accuracy of rotary axes – VH30 Positioning accuracy A- and C-axis P= 12" = 0.0033° Repeatability A- and C-axis Ps= 8" = 0.0022° VH30 milling head 2-axis milling head: VH30, Siemens Weiss milling spindle Spindle power S1 (100% duty cycle) 60 kW, Spindle speed 22,000 rpm, 95 Nm, HSK-A63 External dimensions of fork head L x W approx. 500 x 600 mm Nominal torque of rotary axes Control loop A: min. 1,200 Nm C: min. 1,047 Nm Clamped A and C axes: 3,000 Nm (Continuous grease lubrication with automatic relubrication system) Swivel axis – spindle nose 326 mm Tool holder HSK 63 A Tool clamping Spring clamp Tool unclamping Hydraulic Permissible tool weight 4.5 kg (manufacturer’s specification) Coolant supply External and internal Coolant/lubricant supply (emulsion) at the front of the milling spindle with belt filter system Volume 1500 l Pump 1: 40 l/min at 20 bar Pump 2: 20 l/min at 40 bar, Air blow at the front of the milling spindle

Condition: good (used), functionality: fully functional, We offer for sale a complete line for multi-point automatic welding of SCHLATTER brand steel wires. We have three fully operational production lines. There are also automatic machines for the production of transverse wires (so called slitting machines with a cutter). We also have a number of single point welding machines for steel wires. Nwedpfx Adotvpiloroi

Condition: used, Butler Elgamill CNC Travelling Column Bed Type Mill x 5000mm T slotted Table 8,000mm x 1030mm Column travel X 6200mm TBC Ram travel Y 1250mm TBC Vertical travel of Head Z 1950mm TBC Spindle speeds Various and a Max of RPM TBC Spindle Taper 50 Spindle drive motor HP TBC Power feeds Horizontal and Vertical 6 – 500 mm/min Rapid power traverse to all motions 2,000mm/min Complete With: Heidenhain CNC Control Manual Indexing Head Machine Data: Nodoyx Hv Aopfx Adrowi Machine weight 20,000kg

Condition: used, Technical details: x-travel: 6500/13150 mm y-travel: 4000 mm z-travel: 1250 mm w-axis: 2250 mm table surface area: 5500/12150 x 3000 mm max. workpiece weight: 70.000/105.000 kg ram head dimension: 480 x 510 mm milling spindle motor: 63 kW max. torque on the spindle: 3300 Nm tool taper: DIN 39871 AD ISO 50 milling head speed: 6,3 - 4000 U/min feed speeds: 1 - 24000 mm/min Nodpowc A Shjfx Adrewi w-axis: 1 - 6000 mm/min. distance between columns: 3500 mm passage: 3000 mm total power requirement: 120 kW weight of the machine ca.: 245 t dimensions of the machine ca.: 29,0 x 7,7 x 8,1 m The machine is in mint condition and was generally overhauled in 2020! with CNC SIEMENS 840 D autom. tool magazine for 153 tool stations autom. milling head magazine for 6 heads milling heads - straight - straight extended length - milling head -angular head standard - 4000 rpm, 144 x 2,5°, ISO 50 milling head -angular small extended length -40 kW, 4000 rpm, 1800 Nm, 144 x 2,5°, ISO 50 milling head -universal index - 40 kW, 4000 rpm, 2100 Nm, C-axis 144 x 2,5° , B-axis +/- 44 x 2,5°, ISO 50 coolant attachment, chip conveyor *

Condition: new, Year of construction: 2026, functionality: fully functional, machine/vehicle number: 9101, travel distance Y-axis: 4,600 mm, travel distance Z-axis: 1,600 mm, rotational speed (max.): 6,000 rpm, Equipment: rotational speed infinitely variable, Machine configuration: • PowerPortal4000 • 45° diagonal milling head (C 0.01° / A 0.01°) • Camera system integrated in SHW diagonal milling head • 4-point Hirth-type milling head interface • Heidenhain TNC 7 • HR 550 FS handwheel Nwodpfxoygtnas Adrsi • Heidenhain optimization for 5-axis machining • X = freely selectable, Y = 4,600 mm, Z = 1,600 mm • ToolCenter with 90 tools • Coolant system 2,500 l • Coolant pump 70 bar / 30 l/min • Coolant/air switching • Wash gun in the working area • Main drive 75 kW up to 6,000 rpm • Tool holder SK 50 BIG-PLUS • Panelling and grating • Double chip conveyor • SHW-UniScan • Sealing air • Operating mode 3 • Hexagon wireless probe • LED workspace lighting • Second camera in the working area

Condition: excellent (used), Year of construction: 1994, operating hours: 1,930 h, functionality: fully functional, travel distance X-axis: 7,200 mm, travel distance Y-axis: 4,200 mm, travel distance Z-axis: 1,750 mm, feed rate X-axis: 15,000 m/min, feed rate Y-axis: 15,000 m/min, feed rate Z-axis: 15,000 m/min, total length: 15,000 mm, table length: 5,000 mm, total width: 15,000 mm, spindle speed (min.): 10 rpm, spindle speed (max.): 4,000 rpm, total height: 7,500 mm, table height: 1,350 mm, distance between stands: 3,500 mm, type of input current: AC, table load: 65,000 kg, workpiece weight (max.): 65,000 kg, distance table center to spindle nose: 2,300 mm, overall weight: 210,000 kg, spindle motor power: 50,000 W, MACHINE DATA Machine type: Portal milling machine - double column for continuous 5 axis operation Manufacturer: WALDRICH COBURG Model: 15 S - 10 FPF 300 NC Year of construction: 1994 Condition: Fully refurbished 2015 Functionality: fully functional Operating hours: 1,931 h TECHNICAL DETAILS Number of controlled axes: 5 travel distance X-axis: 7,200 mm travel distance Y-axis: 4,200 mm travel distance Z-axis: 1,750 mm spindle speed (max.): 4,000 rpm working width: 3,500 mm PROVISION Machine location: Ljubljana, Slovenia Availability: now Delivery conditions: FCA Pick up at location: Ljubljana Shipping costs: upon request Planer-milling machine - double column: completely overhauled in 2014 / 2015 by Waldrich Coburg (basically everything except the casting): > New control unit > New cables > New motors > New electrics > Guideways overhauled DESCRIPTION - Heavy double-column machine for processing complex shapes - 2 pallet stations with 2 pallets (load capacity 65t each) - Machine with CNC control SIEMENS 840D sl - In 2014, conversion of the control system to SIEMENS 840D sl (incl. complete cabling and control cabinet) - in 2015 replacement of all axis motors - Various angle milling heads - NC-controlled milling head with 50 kW milling power / clamping 2.5° each with Hirth serration (type USP300C450F15S) - 2-axis NC-controlled fork head with 40 kW milling power (type UFN00SZ500) - Automatic tool changer for 76 tools (ISO 50 and 60) Nwodpfx Adovv N I Rjrsi TECHNICAL DETAILS Travel X / Y / Z: 7,200 / 4,200 / 1,750 mm Milling width: 3,500 mm Distance spindle nose to table: 2,300 mm Milling power: 50 kW Speed: 10 - 4,000 rpm Front spindle diameter: 150 mm Spindle holder: ISO 60, ISO50 Control: Siemens 840D sl Pallet size: 3,000 x 5,000 mm Pallet load: max. 65 t Number of pallets: 2 pieces Tool changer: 76 slots Feed rate: 10 - 15,000 mm/min MACHINE DETAILS Pick-up power: 92 kW Weight: 210 t Spindle hours: 1,931 h Switch-on time: 7,870 h Bed dimensions: 12.5 x 2.3 x 0.78 m; 28.5 t Pallet dimensions: 5.35 x 3.0 x 0.4 m; 22 t Main pallet carrier dimensions: 5.1 x 2.9 x 0.5 m; 25 t Dimensions of bed section: 3.8 x 2.9 x 0.5 m; 10 t Milling spindle box dimensions: 4.1 x 1.9 x 1.5 m; 13.5 t Left/right column dimensions: 4.1 x 1.3 x 1.7 m; 10.5 t Exhaust air slide dimensions: 8.5 x 0.7 x 1.2 m; 1.1 t Control cabinet dimensions: 7.9 x 0.6 x 2.1 m; 2.8t THIS IS A TOP CLASS MACHINE FOR MOST ACCURATE WORK; HIGHLY EFFECTIVE. MACHINE IS ASSEMBLED AND UNDER POWER:

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 06651, travel distance X-axis: 6,800 mm, travel distance Y-axis: 3,700 mm, travel distance Z-axis: 1,500 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 10 m/min, total length: 15,000 mm, total width: 7,500 mm, spindle speed (max.): 4,000 rpm, total height: 7,000 mm, table height: 1,100 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 10 m/min, distance between stands: 3,300 mm, type of input current: three-phase, table load: 50,000 kg, rotational speed (max.): 4,000 rpm, distance table center to spindle nose: 2,110 mm, overall weight: 110,000 kg, spindle motor power: 50,000 W, control cabinet length: 7,000 mm, control cabinet height: 2,000 mm, control cabinet width: 600 mm, Equipment: rotational speed infinitely variable, MODEL: Portal Type AGE: 1992 S/N #: 06651 CATEGORY: Mills, Planer Type, CNC CAPACITY: X-Axis Travel: 6800 mm Y-Axis Head Travel: 3700 mm Z-Axis Ram Stroke: 1500 mm, fixed crossrail Ram Cross Section: 500 mm x 500 mm Distance Between Columns: 3300 mm Distance Table To Ram Face: 2110 mm, vertical passage 2000 mm Table Size: 6000 x 2500 mm Spindle (Quill) Diameter: 250 mm Spindle Taper: ISO #50 Spindle Speeds: 0-4000 RPM Spindle Motor: 50 KW EQUIPPED WITH: FIDIA System C20 CNC Control, new in 2002 CNC biaxial continous milling head Universal Milling Head with Auto Indexing Right Angle Head with Auto Indexing Straight Milling Head Nwjdpsyahv Sjfx Adroi Wagons for Head Change and Tool Pick-up Change Hydrostatic Bearings Coolant System Full Length Chip Conveyors both side Way Covers Rapid movements: Z-10.000 mm/min, X and Y-15.000 mm/min Table load: max 50.000 kg Weight of the machine: 110.000 kg Outside dimensions: 15.000 x 7.500 x 7050 mm Machine has been tested before dismantling and is fully operational, all mechanical components in excellent condition, electrics new in 2018. Machine available from stock. The price is now SPECIAL FROM STOCK. Once we will reassemble the machine, price will grow significantly. We can assist you to assemble and run up the machine.

Condition: excellent (used), Year of construction: 1990, functionality: fully functional, machine/vehicle number: 3.8203, travel distance X-axis: 7,570 mm, travel distance Y-axis: 4,900 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 10 m/min, total length: 18,700 mm, table length: 6,850 mm, table width: 2,250 mm, total width: 8,500 mm, spindle speed (min.): 5 rpm, spindle speed (max.): 2,000 rpm, total height: 7,050 mm, table height: 300 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 10 m/min, distance between stands: 2,750 mm, type of input current: AC, table load: 60,000 kg, workpiece weight (max.): 60,000 kg, distance table to spindle center: 2,500 mm, overall weight: 145,000 kg, spindle motor power: 63,000 W, feed length W-axis: 2,000 mm, MODEL: Portal Type AGE: 1990 S/N #: 3.8203 CATEGORY: Mills, Planer Type, CNC CAPACITY: X-Axis Travel: 7570 mm Y-Axis Head Travel: 4900 mm Z-Axis Ram Stroke: 1000 mm, W-axis traverse movement: 2000 mm Njdpfxeyl S Ngs Adrowi Ram Cross Section: 500 mm x 500 mm Distance Between Columns: 2600-2750 mm Distance Table To Ram Face: 2500 mm Table Size: 2x3000+850 mm x 2250 mm, two tables for split or integral operation Spindle (Quill) Diameter: 225 mm Spindle Taper: ISO #50 Spindle Speeds: 0-2000 RPM Spindle Motor: 63 KW EQUIPPED WITH: SIEMENS System 840D CNC Control, new in 2008 CNC biaxial continous milling head Universal Milling Head with Auto Indexing Right Angle Head with Auto Indexing Straight Milling Head Wagons for Head Change and Tool Pick-up Change Hydrostatic Bearings Coolant System Full Length Chip Conveyors Way Covers 63 KW Spindle Motor Rapid movements: W-2000 mm/min, Z-10.000 mm/min, X and Y-15.000 mm/min Table loads: 30.000 kg+30.000 kg, max 60.000 kg Weight of the machine: 143.000 kg Outside dimensions: 18.700 x 8.500 x 7050 mm

Condition: excellent (used), Year of construction: 1985, pressure 25 t Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical : MABU (D) High Speed 4 Column Automatic Punching Press model 25 VP / RC year 1985 Nwodpozbu Spefx Adrji Press force nominal 25 to Punching Speeds 120 - 600 strokes/min Stroke length adjustable 7 - 62 mm Ram adjustment range 50 mm Mounting height 225 - 310 mm Table size 560 x 640 mm Distance between columns sides 320 / 340 mm Distance between columns front/back 380 / 400 mm Opening in table / clamping plate 120 x 230 mm Ram clamping plate size 240 x 280 mm MABU Strip feed RACER 11 Max. strip width 150 mm Max. feed stroke 120 mm Main drive approx. 3 kW Total drive approx. 3,5 kW - 380 V - 50 Hz Weight approx. 2.400 kg Accessories / Special Features: • MABU Strip feed device model RACER 11 RCTF, mounted on the left side, stroke adjustable, infeed height adjustable, • Automatic continuous stroke and single stroke available as well as inching mode, piece counter, blow out device • Sep. control cabinet and switch cabinet, Vibration dampening machine shoes • Large, soundproof cabin (disassembled) • Various accessories, manuals and former safety test reports Condition : very good, press was regularly maintained ! Please click here to view soon a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We always have a large selection of all kinds of presses available. Please let us know your requirements.

Condition: used, Year of construction: 2022, x-travel 5.230 mm y-travel 2.750 mm z-travel 1.100 mm control Heidenhain TNC 640 Tool bore DIN69871 A50 BIG PLUS main drive 32/43 kW torque S1/S6-60% 752/1.011 Nm speeds Spindel stufenlos 6.000 U/min ca. 70 kw Nedpfx Adjzgxgmorjwi weight of the machine ca. ca. 43 t Installation dimensions (length x width x height) ca. 12,2 x 5,7 x 5,1 m In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical features & accessories: - Heidenhain TNC640 control system with HR510 handwheel and digital drives - 60-station tool changer - Internal coolant supply (ICS) for vertical spindle with 1000L tank and automatic water/air switching - Direct axis measurement via Heidenhain linear scales - Coolant system with paper belt filter and magnetic separator - Automatic central lubrication - Rigid tapping (threading without compensating holder) - Oil-cooled ball screw (internal) in the X-axis - Spindle oil cooler - Automatic machine shut-off - Screw-type chip conveyors on both sides of the table - Hinged-belt cross chip conveyor Accessories, pictured tools, and workholding devices are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data/specifications, and prior sale.

Condition: used, Year of construction: 1991, x-travel 5300 mm y-travel 2500 mm z-travel 1200 mm Table load 60000 kg column daylight 2700 mm workpiece height max. 1700 mm Table dimensions 5000x2250 mm control Heidenhain type 430 Maschine wurde überholt machine is retofit Nwodpfx Asyq Swhjdrei The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, feed length X-axis: 2,500 mm, feed length Y-axis: 1,400 mm, feed length Z-axis: 1,500 mm, spindle speed (max.): 4,000 rpm, table load: 5,000 kg, CNC: SELCA 4045PD AXES TRAVELS X-axis longitudinal travel: mm 2500 Y-axis transverse travel: mm 1400 Z-axis vertical travel: mm 1500 TABLE Table size: mm 1200X1200 Load capacity: kg 5000 Number of divisions: 360.000 T-slots: No. 7 – pitch mm 127 Table axis motor power: kw 6 KOSMO 5 AUTOMATIC BI-ROTARY HEAD Continuous power: kW 28 KOSMO head spindle speed: giri/min 4.000 Plane positioning with HIRTH serration Rear plane rotation: 2,5° Front plane rotation: 3° Tool taper: DIN 69871-A50 Drawbar: DIN 69872-28 (50) PALLET CHANGER: DCN 100 CP Nwsdpjzg Hqyofx Adrei MACHINE COMPLETE WITH • Electronic handwheel • Electronic thermal expansion compensation device for the head • High-pressure through-spindle coolnat • Chip conveyor: Double front and rear chip conveyor • Sidesalpa tool machine – 40 positions • Full enclosure • Instruction manuals • CE declaration of conformity

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, Double Column Milling M/C - Gantry Type Brand: FOREST-LINE ALBERT / Type: MODUMILL 300G / Year of construction: 1999 Extensive modernizations in 2008 and 2021 ! Machine with interchangeable vertical and horizontal milling heads with automatic indexing. The machine can be inspected by appointment. Very well-kept, continuously maintained condition! TECHNICAL DATA: - CNC Control: SINUMERIK 840D - Travels X/Y/Z: 11.450 / 3.500 / 1.250 mm Cross-section of the Z-axis slider: 360 x 360 mm - Gantry passage: 3.000 - Height below vertical spindle: 1.400 mm - Working clamping width: 2.500 mm - Fixed table dimensions: 5.000 x 2.500 mm - Longitudinal pallet system EQUIPMENT: - Tool changer (chain magazine): 80-positions - Cooling through the spindle centre - 2 chip conveyors - Gantry panelling - Touch probe, Brand: RENISHAW - Electronic hand wheel - Remote diagnosis - Tool management and wear management - CE marking Electrical connection values: - Total power requirement: 130 kVA - External dimensions of the machine: 22,6 x 8,0 x 6,3 m Nwedpfxjzfbi Ij Adrsi There is no guarantee for correctness and completeness of the technical details and accessoires. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request.

Condition: ready for operation (used), Year of construction: 2024, functionality: fully functional, Gantry Portal Milling Machine / Manufacturer: WALDRICH SIEGEN Type: PF-S-150 - 1953: Original year of manufacture (originally a workbench) - 1974: Reconstruction by the manufacturer WALDRICH SIEGEN to a portal milling machine (completely new milling support) - 2001: Modernised to CNC, with new electrical control cabinet - 2015: Modernization / Reconstruction to NC table drive - 2024: Reconstruction to crossbeam drive (gantry) Nwjdpfx Ajyz Ru Usdrei Machining options: - Milling/Boring: horizontal/vertical The machine can be inspected by appointment under power. Condition: Ready for operation. TECHNICAL DATA / DESCRIPTION: Travel distances of feed axes (CNC): - Table: 14.000 mm - Crossbeam support: 4.500 mm - Crossbeam: 4.000 mm - Stand passage: width 4.545 mm - Clear width: 4.200 mm - Height from table to spindle: 4.000 mm - Quill: 450 mm - Table size / clamping: 14.000 x 4.350 mm - Table load: max. 200 tons (10 tons point load) - Drive power of main spindle motor: 125 kW - Total machine weight: approx. 350 tons - Space requirement for entire machine: Length 40 / Width 10 / Height above floor 9 m EQUIPMENT / ACCESSORIES: - CNC control: SINUMERIK 840D - Documentation - Additional comprehensive equipment ... No guarantee is given for the completeness and accuracy of the technical information and equipment. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request.

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, Double Column Milling Machine- Gantry Type | Year of construction: 2010 The machine can be inspected under power by appointment. Condition: Operational / ready for use. Technical specifications: - X-axis (Gantry): 14.000 mm - Y-axis (Support slide): 11.000 mm - Z-axis (RAM): 3.000 mm - Drive power RAM: 100 kW - Passage width max.: 6.500 mm - Faceplate diameter: 5.000 mm Nsdpsy Dvwyofx Adrewi - Control: SINUMERIK 840D sl The machine is very well equipped. No guarantee is given for the completeness and accuracy of the technical data and equipment. - Subject to prior sale - Discreet sale. Detailed technical data sheet and information on equipment available on request.

Condition: used, Year of construction: 1996, functionality: limited functionality, CNC-Planer-Type Milling M/C - Double Column (Milling and Turning Center) | Brand: DÖRRIES SCHARMANN | Type: 4FZT | Year of construction: 1996 A high-performance gantry milling machine designed for machining large workpieces. Its primary applications include the milling and turning of large, complex workpieces. Nwjdpfx Adeyuptzersi The machine can be inspected under power by appointment. Condition: Consistent with the year of manufacture; some parts require refurbishment. - A high-quality machine, and therefore well worth modernization / a complete overhaul / highly recommended. TECHNICAL SPECIFICATIONS: Main Dimensions: - Machine width: 13.230 mm - Machine height over the floor: 8.450 mm - Machine length: 31.100 mm - Working length: 11.000 mm - Clearance width: 4.400 mm - Clearance height from the table surface to the spindle nose of the standard milling head: 3.000 mm Table: - Table width: 3.450 mm - Total table length: 13.400 mm - Length of individual table: 6.200 mm - Total clamping area: 3.450 x 11.000 mm - Clamping area of single table: 3.450 x 5.000 mm - Maximum total workpiece weight: 112 tons - Maximum workpiece weight per table: 80 tons Crossbeam: - Travel: 2.000 mm Milling and boring support: - Drive power for milling and boring (spindle): 80 kW - Max. speed of the drive shaft (spindle): 2.500 rpm EQUIPMENT / ACCESSORIES: - 2 tables - 8 machining heads - Control: SINUMERIK 880 - 2 x chip conveyors - Documentation - CE marking No guarantee for completeness and accuracy of technical data and equipment. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request.

Condition: new, Year of construction: 2026, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, cutting height (max.): 330 mm, cutting width (max.): 330 mm, control type: CNC control, actuation type: electric, rotational speed (max.): 85 rpm, rotational speed (min.): 34 rpm, total height: 1,400 mm, total length: 2,150 mm, total width: 2,000 mm, overall weight: 1,499 kg, table height: 650 mm, Equipment: CE marking, documentation/manual, rotational speed infinitely variable, CNC COLUMN TYPE METAL BANDSAW M2-330C The MTP 330×330 Column Type Metal Bandsaw is a professional cutting machine designed for manufacturing facilities, metal workshops, and steel processing companies. Thanks to its rigid column construction, efficient hydraulic system, and large cutting capacity, the machine delivers excellent cutting accuracy, reliability, and operator comfort. The column-guided design ensures stable movement of the saw frame, resulting in precise cuts and extended blade life. The machine is ideal for cutting profiles, pipes, shafts, bars, and solid materials made of structural steel, stainless steel, aluminum, and other non-ferrous metals. MAIN ADVANTAGES • Rigid column-type construction • Maximum cutting capacity: 330 × 330 mm • Hydraulic feed system • 4 blade speed settings • Efficient coolant system • High cutting accuracy and repeatability • Designed for continuous operation • CE certified PRECISE CUTTING The rigid construction and professional blade guidance system ensure high-quality cutting results while reducing material waste. The hydraulic feed allows smooth adjustment of the cutting process according to the type and size of the material being processed. POWERFUL DRIVE SYSTEM The bandsaw is equipped with a 4 kW main motor and a 0.75 kW hydraulic power unit, ensuring reliable performance even when cutting large material sections. COOLING SYSTEM An integrated coolant pump with a power output of 60 W effectively removes heat generated during cutting, extending blade life and improving cutting quality. APPLICATIONS • Steel profiles • Round and rectangular tubes • Solid bars • Steel shafts • Structural components • Stainless steel • Aluminum and non-ferrous metals Thanks to its large cutting capacity, the machine is suitable for both single-piece and serial production. SAFETY The machine is equipped with protective covers, safety switches, and CE-compliant safety features to ensure safe operation in accordance with European standards. TECHNICAL SPECIFICATIONS Maximum cutting capacity: 330 × 330 mm Blade speed: 34 / 51 / 60 / 85 m/min Feed stroke: 500 mm Blade size: 34 × 1.1 × 4115 mm Main motor power: 4 kW Hydraulic motor power: 0.75 kW Coolant pump power: 60 W Material feeder dimensions: 600 × 360 × 630 mm Working table height: 650 mm Weight: 1499 kg Machine dimensions: 2150 × 2000 × 1400 mm DELIVERY AND SUPPORT We organize machine transportation throughout Europe. We provide technical support, assistance with machine selection, and access to spare parts and service. CONTACT US Nwedpozd T H Asfx Adrji If you require additional information or a personalized quotation, our specialists will be happy to assist you. We also invite you to explore our full range of metalworking machinery available on our website.

Year of construction: 2018, condition: used, x-travel:1600 mm y-travel:1300 mm z-travel:700 mm distance between columns:1500 mm distance spindle center to table:225-925 mm table-size:1800 x 1300 mm table load:4000 kg T-slot (width-distance-quantity):22x 160 x 8 mm spindle taper:HSK-A 63 spindle speed:24000 U/min spindle drive:25/33 kW Spindle motor torque:72.6/95.8 N.m. rapid traverse in x-y-z axis:30000 mm/min Cutting feed rate X/Y/Z axis:1~20000 mm/min Tool changer:20 fach max. tool diameter:100/130 mm max. tool length:300 mm max. tool weight:8 kg total power requirement:80 kva Weight approx.:22 t Machine size (LxWxH):5660 x 5295 x 3930 mm CNC controller:Heidenhain TNC 620 spindle:IBAG electric spindle 24000rpm HSK-A63 Scales:Heidenhain automatic tool changer:20 fach chip conveyor - auger:2 Stk. Used portal milling machine with extensive accessories at a special introductory price. Important manufacturers of the components used in this storage machine are: Controllers and Servomotoren of Heidenhain, type TNC 620 Ball Screw Bearing - Japan Nsk X ball screw spindle Taiwan Hiwin Y Ball Bearing Taiwan Hiwin Z ball screw spindle Taiwan Hiwin 3 Axes Linear Guide - Japan Thk Or Germany Rexroth Electric screw unit - Hsk A63-24000rpm from IBAG Linear Encoder - Heidenhain Pneumatic System - Japan Smc Lubrication - Japan Showa Nwedpfohx R Dvox Adrji Covers - Hema Air conditioning - Taiwan Kaokung Spindle water cooler - Taiwan point 3 axles Cable towing - Germany Igus Clutch - Germany KTR Company - Germany Mecano Relay - Omron Electricity - Germany Schneider MPG hand wheel - Japan Tosoku Further information on the machine, standard accessories and special accessories can be found in the appendix. Of course, we also gladly organize for you the delivery free house including assembly / commissioning and ready for handover as well as instruction

Condition: used, Year of construction: 2018, travel distance X-axis: 2,300 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,000 mm, table length: 2,300 mm, table width: 1,600 mm, spindle speed (max.): 10,000 rpm, spindle nose: SK 50, Used CNC portal milling machine KRAFT VM-2018B with Heidenhain TNC 620 Year of manufacture: 2018 Storage location: Germany Delivery time: short term Payment: 100% before loading Warranty: none Machine description The KRAFT VM-2018B is a precise and powerful CNC portal milling machine with HEIDENHAIN TNC 620 control, ideal for heavy-duty and high-precision machining processes. Thanks to its robust design and high-quality components, it is ideal for demanding milling tasks in tool and mold making as well as in series production. Highlights & features Monoblock cast iron bed and cross beam for maximum rigidity and precision FEM-optimized machine design BF gearbox with 26 kW motor for high torque (662 Nm) Feed roller linear guides P-class (very low coefficient of friction 0.003-0.006) C3 ball screws with double nut - high load capacity & accuracy Spindle: SK50, 10. 000 rpm, direct drive Heidenhain TNC 620 control Spindle cooling & IKZ 20 bar Coolant system, oil separator, air conditioning for control cabinet Full enclosure, TÜV-approved, CE-compliant Technical data Nsdpfx Aewkg T Sjdrswi Travel (X/Y/Z): 2,300 / 2,000 / 1,000 mm Table size: 2,300 × 1,600 mm T-slots: 8 × 22 × 180 mm Max. Table load: 8 t Distance spindle nose - table: 180-1,180 mm Rapid traverse X/Y: 20,000 mm/min Rapid traverse Z: 15,000 mm/min Feed range: 1-10,000 mm/min Positioning accuracy (VDI/DGQ3441): 0.020

Condition: excellent (used), Welding current max.: 5kA Welding force: 45-150N Closing stroke: pneumatic Welding pressure: pneumatic, resetting unit with disk spring Force adjustment: Proportional valve Electrode shape: cylindrical, 6mmØ --- Welding control: optional (according to recommendation) --- equipped with: - Base body with welding heads on aluminum - Modular design - Electrodes top and bottom with feed cylinder Nwsdpfstq Ez Ejx Adrji - Welding head top F120K with repositioning unit - pneumatic valve units - Pneumatic air cooling unit for electrodes - Workpiece carrier on dovetail guide, for exact positioning to electrodes positioning to electrodes --- Warranty 6 months --- Training + commissioning on request --- Spot welding electrodes + spare parts available from stock --- Further information on our homepage
