Used Cse Ring Gear Vernier Caliper for sale (10,304)

Condition: good (used), Vernier caliper, vernier caliper, vernier caliper -Manufacturer: CSE, tooth width caliper sprocket caliper with fine adjustment -Measurement scale: mm -Vernier: on both sides -Dimensions case: 175/155/H30 mm Nwjdpfx Agok Hdr Norsl -Weight.: 0.5 kg

Condition: ready for operation (used), MEASURING CALIPER / SLIDE CALIPER / NEW - UNUSED SMW 3000x500mm Measuring length approx. 3000mm Jaw length approx. 500mm Pyddl Nsdeztfk Sspfx Agrswl Vernier scale 1/20mm according to factory standard Scale and slide made of aluminum profile Measuring jaws made of steel - rustproof, hardened Glare-free reading Weight approx. 3.8 kg incl. transport case Errors and omissions excepted.

Condition: as good as new (ex-display), Caliper / Measuring length 4 meters / New - Unused -SMV 4000mmx500mm -Measuring length: 4 meters -Jaw length: 500mm -Vernier 1/20mm according to factory standard Nedpey R S Ibjfx Agrewl -Scale / caliper made of aluminum -Jaws / tips made of hardened stainless steel -Glare-free reading -Weight approx. 6 kg -Incl. wooden transport case Errors and input mistakes excepted.

Condition: excellent (used), Two digital calipers Digital caliper Mitutoyo 551-231-10, measuring range 300mm Digital caliper Mitutoyo 500-181-U, measuring range 150mm Nwedpfxjw Tctrs Agrsl The batteries have been replaced or are in good condition. The measuring tools can be demonstrated on site by appointment. We only offer machines that are ready for demonstration in our warehouse, see "more offers from this supplier".

Condition: excellent (used), Herringbone Gear Generator MDV 2000 MDV 2000 Characteristics: Nodpfx Agofx Ibnsrewl Max. wheel diameter: 2000 mm Min. wheel diameter: 50 mm Max. module: 12 Min. module: 3

Condition: used, Crane motor, travel drive crane bridge drive with gearbox Sliding anchor motor, sliding anchor motor, three-phase electric motor, brake motor, crane motor, cable drive, crane drive, hoist motor, fine hoist motor Manufacturer: DEMAG Motor type: 24/10 KF8-2 Motor No.: 982869 Motor type: B5 Rated voltage: 380 VAC Rated frequency: 50 Hz Power stage 1: 0,58 kW = 715 rpm. Nwsdpfoptlblsx Agrol Power stage 2: 2,3 kW = 2900 rpm. with gearbox DEMAG type KS 12 Reduction gearbox fabric. no. 1909104 gear ratio: i = 118 with impeller for crane rail 2 pieces available, price per piece

Condition: used, Year of construction: 1974, max. wheel diameter 400 mm gear width 75 mm total power requirement 25 kW weight of the machine ca. 7 t L O R E N Z (Germany) High Performance Automatic Gear Shaper Model LS 400 Year 1975 Serial No. 12 592 _____ External gear, max. Ø 400 mm (possibly larger) Internal gear dia. 350 mm Gear width, max. 75 mm Module range 0.5 - 6 Length of stroke 82 mm Adjustment of stroke position 0 - 100 mm Distance between shaper spindle and machine body 250 mm Spindle taper MK 5 No. of strokes, roughing/finishing process 118 - 1,000 per min Table size 400 mm Table bore 125 mm Mounting height between table and shaper head 190 / 290 mm Axial travel of tool slide, approx. 295 mm No. of teeth, approx. 12-150 Feed range, tooth depth 0.01 - 0.063 mm/stroke Feed range, rotary feed by Tool-Ø 125 0.125 - 3.15 mm/stroke Spindle drive, approx. 19 kW Total electrical load, approx. 25 kW - 380 V - 50 Hz Weight 7,000 kg Accessories / Special Features * Hydrostatic straight guides with separate hydraulic aggregate. * Built-in raiser plate approx. 100 mm to increase height of shaper head. * Hydraulic universal workpiece clamping device built by RINGSPANN to clamp ring shaped workpieces on the inner diameter with various inserts to accommodate different workpiece diameters. * Stepless Regulation of number of strokes for improving roughing and finishing process * Automatic changeover of number of strokes, and automatic feed changeover for roughing and finishing work in up to 3 cuts. * Automatic and motor-driven fixing of shaping stroke in the upper position after work is finished. * Separate switch and control cabinet. Two-hand start. * Coolant equipment with magnetic chip conveyor and chip collection container. Nwedpfot Hww Dsx Agrol * Various change gears, shaping tool holders, etc. Condition : Satisfactory to Good. Machine can be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. Thank you for your interest. We always have a good selection of gear machines on stock. Please let us know what you need.

Condition: used, Technical details: measuring range X-axis: 3000 mm indexing: 0,1 mm weight: variable kg No. 1 Caliper/caliper gauge made of stainless and hardened steel Make INOX Nodpfx Aeu N Atwogrowl Measuring range 0 - 3000mm Reading 0.05mm via vernier Leg length approx. 280mm without measuring tips for internal measurement No. 2 Caliper/caliper gauge made of stainless and hardened steel Make Massi according to TGL Measuring range 2000mm Reading 0.1mm via vernier *

Condition: refurbished (used), Year of construction: 2027, functionality: fully functional, position of the milling head: Schwenkbar (45°), table diameter: 4,000 mm, total length: 13,300 mm, gear diameter: 5,000 mm, total height: 5,700 mm, total width: 7,500 mm, input frequency: 50 Hz, workpiece diameter (max.): 5,000 mm, type of input current: AC, milling length: 600 mm, spindle speed (max.): 125 rpm, spindle speed (min.): 10 rpm, travel distance X-axis: 2,750 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 1,750 mm, overall weight: 115,000 kg, distance table to spindle center: 3,300 mm, controller manufacturer: Siemens Sinumerik ONE, drive type: Sinamics S120, control type: CNC control, The machine has been in service for many years. The ZFWZ 5000 comes from Modul's Chemnitz gear machine construction division and is completely overhauled and delivered with a Siemens Sinumerik ONE control system by Serwema Retrofit Solutions, the company that holds the Modul design archive. Proven kinematics, new electrical components, new drives, and new safety technology: you get the performance of a new machine at a fraction of the price and with a delivery time of twelve months. Nwodpfx Asz Etmpegrjl The machine mills external gears, both straight-toothed and helical, up to module 40 using the hobbing process and up to module 50 using the single-indexing method. With the internal milling attachment, internal gears are produced for gear rings for large rolling bearings, rotary couplings, and planetary hollow gears, as required in wind power, mining, crane, and shipbuilding technology. Workpieces with a diameter of up to 5000 mm can be accommodated on the 4000 mm table. The milling head pivots by ±45°, and the 82 kW drive power at the milling head allows for both roughing with high material removal rates and finishing with precision. Technical data: max. workpiece diameter 5000 mm, table diameter 4000 mm, distance between milling spindle axis and table axis 300–1800 mm, distance between milling spindle axis and table surface 550–3300 mm, max. milling cutter diameter 500 mm, max. milling cutter length 600 mm, tangential travel 600 mm, milling cutter speed 10–125 rpm, drive power of milling head 82 kW, swivel angle ±45°. Installation dimensions approx. 13.3 × 7.5 × 5.7 m, weight approx. 115 t. The machine is delivered with a new Siemens Sinumerik ONE control system and Sinamics S120 drives, the latest Siemens generation with full spare parts and support availability, in a climate-controlled switch cabinet manufactured in-house. The user-friendly interface makes setup and programming possible without requiring in-depth G-code knowledge. Geometry acceptance is performed according to manufacturer's standards or DIN standards with a protocol, jointly with you in Chemnitz. The scope of supply also includes a machine safety fence with state-of-the-art safety technology, a new paint finish in RAL 5015/7035, a magnetic chip conveyor, circulation and loss-lubrication systems, a hydraulic unit, a coolant system, and the operating manual.

Condition: like new (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 25582, Equipped with: Fanuc 30ia Control Hydraulic System Coolant System Chip Conveyor Pneumatics Lube System Jib Crane Change Gears Mist Collector Njdpfx Aszn Aymjgrowl Transformer Work Light Stack Light Specifications: Extreme Ratio: 10:1 Root Angle Range (B-Axis): -5 deg. TO 90 deg. Equivalent Root Angle Range: -8 deg. to 90 deg. (Equivalent refers to cradle type machine.) Face Hobbing: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -152 mm TRI-AC Cutter w/13 Blade Groups Max. Full Depth: 0.550" Max. Face Width: 1.6" Face Milling: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -7.5" Diameter Cutter Max. Full Depth: 0.625" Max. Face Width: 1.6" Max. Swinging Base Travel (B-Axis): -5 deg. to 90 deg. Max. Vertical Travel (Y-Axis): -4" to 7" Max. Horizontal Travel (X-Axis): -6" to 4" Sliding Base Travel (Z-Axis): 2" to 12" Machine Center to Work Spindle Face (Fixed): 4.5" Tooth Number: 5 to 200 Inclusive Cutting Diameters: Conventional Face Milling: 1.1" to 7.5" Helixact: 100mm to 200mm Fine Pitch: 102mm to 152mm Coarse Pitch: 152mm only Speeds: B-Axis--Swinging Base (Degrees per Second): 30deg./sec. A-Axis--Work Spindle (Face Milling)(RPM): 0-75 A-Axis--Work Spindle (Face Hobbing)(RPM): 0-375 C-Axis--Cutter Spindle (RPM): 30-500 X-Axis--Horizontal (Inches per Second): 4.92"/sec. Y-Axis--Vertical (Inches per Second): 4.92" Z-Axis--Sliding Base (Inches per Second): 4.92"/sec. Work Spindle: Diameter of Taper at Large End (#39 Taper): 3-29/32" Taper per Foot: 39/64" Depth of Taper: 3" Floor Space: 95.75" x 63.5" Height (less mist collector): 90.75" Approx. Weight: 22,000 lbs

Condition: used, Universal Milling Machine VERNIER type FV Travel X: 1000 mm Travel Y: 300 mm Travel Z: 600 mm Cone SA 40 Spindle speed: from 32 to 1500 RPM Table size: Length 1500 x Width 320 mm Horizontally + vertically tilting head Njdjzzz Rkspfx Agrswl Scale 3 axes ACURITE Auto Feeds X - Y - Z Length: 2200 mm Depth: 2100 mm Total height: 1900 mm Weight: approx 2,5 T

Condition: used, Year of construction: 2007, control Siemens Sinumerik 840 D weight 57.000 kg voltage 400 V Gleason PFAUTER CNC gear hobbing machine P 2400/2800 for gear cutting of cylindrical and worm gears as well as all other regularly occurring rollable profiles and shapes on the cylindrical workpiece circumference. Large gear hobbing machines from Gleason offer maximum productivity for roughing and finishing cylindrical gears for many industries: wind turbines, industrial gearboxes, mining and shipbuilding, gear machining and many more. The power range of the drive takes future tool developments into account. Of course, the gear hobbing head drive is also backlash-free. These machines are particularly well suited for use with state-of-the-art, cutting materials, regardless of whether dry or wet machining is preferred. The machine can be used for dry or wet machining and is also equipped with the appropriate chip conveyor for both machining methods. The machine is equipped with an internal profile milling head as a motorised milling head. --> Working range and technical data Nominal workpiece diameter: 2.400 mm --> Largest millable diameter approx.: 2.800 mm --> Smallest/largest distance between cutter and workpiece axis: 100/1.200 mm --> Largest axial slide travel (special design): 1.300 mm --> Largest clampable cutter (internal milling head): --> Diameter max: 440 mm --> Max. cutter width: 90 mm --> Swivel range of the internal profile milling head/vertical axis: +/- 15° --> Milling mandrel taper: HSK-B160 --> Maximum milling cutter travel: 300 mm --> Table diameter: 2.500 mm --> Part wheel diameter: 2.200 mm --> Table bore --> Diameter: 800 mm --> Depth: 875 mm --> Maximum table load approx.: 40.000 kg --> Max. feed and rapid traverse speeds: --> axial (Z-axis): 4.000 mm/min --> radial (X-axis): 3.000 mm/min --> tangential (Y-axis): 3.000 mm/min --> Milling cutter cooling lubrication device/electric centrifugal pump: approx. 150 l/min --> Increased drop height of magnetic chip conveyor: 1,600 mm --> Increased main stand: 1,300 mm axial slide travel --> Internal profile milling head as motor milling head instead of standard motor milling head --> Max. millable profile depth in steel with approx. 600 N/mm² strength: approx. 65 mm --> Infinitely variable milling speed: 50 - 150 min?¹ --> Max. milling cutter diameter: 440 mm Nwedpfx Aewzyp Isgrel --> Min. milling cutter base circle diameter: 310 mm --> Max. milling cutter width: 90 mm --> Min. internal diameter at 0° bevel angle: 800 mm+) --> Max. workpiece height at 0° bevel angle: 600 mm --> Max. workpiece ring thickness (including clamping device): 500 mm >> Wet and dry, 2 chip conveyors, table diameter 2500 mm

Condition: good (used), power: 257 kW (349.42 HP), first registration: 12/2005, fuel type: diesel, axle configuration: 6x4, fuel: diesel, color: blue, gearing type: mechanical, suspension: steel, total length: 9,900 mm, total width: 2,500 mm, total height: 3,400 mm, loading space length: 6,700 mm, loading space width: 2,500 mm, loading space height: 1,360 mm, Year of construction: 2005, Equipment: EBS, differential lock, electric window regulation, power assisted steering, power mirror, trailer coupling, = Additional options and accessories = - Leaf spring suspension - Differential lock - Air-suspended seats - Air horn - Radio/CD player - Rotating beacon - Tow hitch = Additional information = Suspension: Leaf spring suspension Front axle: Steered; Tire tread depth left: 70%; Tire tread depth right: 70% Rear axle 1: Dual tires; Differential lock; Tire tread depth left (inside): 70%; Tire tread depth left (outside): 70%; Tire tread depth right (inside): 70%; Tire tread depth right (outside): 70%; Reduction gear: External planetary axles Rear axle 2: Dual tires; Differential lock; Tire tread depth left (inside): 50%; Tire tread depth left (outside): 50%; Tire tread depth right (inside): 50%; Tire tread depth right (outside): 50%; Reduction gear: External planetary axles Nodpfjzzpfisx Agrswl Number of cylinders: 6 Technical condition: good Optical condition: good

Condition: used, Automatic Multi-purpose Iron Twister GLASER Type GDM 3 motor-driven rod twisting machine equipped with ring bending attachment, profile bending machine Year of manufacture: 1977 Twisting length: 1200 mm Twisting speed (Level 1): approx. 10 rpm Twisting speed (Level 2): approx. 20 rpm - Spindle drive via large geared motor - Arch and ring bending machine, not complete - with HAWE hydraulic unit up to 600 bar for auxiliary functions - 4-square tool holder for twisting tools Motor power: 3.3 kW Power supply: 380 Volt, 50 Hz Space required (L x W x H): 2120 x 720 x 1100 mm Weight: approx. 600 kg Njdpow Dgi Tefx Agrjwl Good condition

Condition: used, Universal Milling Machine VERNIER FV 250 E Travel X: 800 mm Travel Y: 300 mm Njdpfxozz Hyks Agrewl Travel Z: 500 mm Cone: SA 40 Spindle speed: from 45 to 2000 RPM Table size: 1060 x 250 mm Horizontally + vertically tilting head Auto Feeds X - Y - Z Lubricant pump Voltage: 380 V Width: 1600 mm Depth: 2000 mm Total height: 1700 mm Weight: approx 2 T

Condition: ready for operation (used), Year of construction: 1988, SARATOV 5C280P Spiral Bevel Gear Grinding Machine - 2 machines Max. gear diameter: 800 mm Max. module: 16 Max. gear ring width: 125 mm Number of teeth: 5-150 Spindle speed range: 20-125 rpm Main motor power: 7.5 kW Overall dimensions (LxWxH): 3170x2180x2200 mm Weight: 15 t Video of the machine in operation available! SARATOV 5C276 Straight Bevel Gear Grinding Machine Module, mm: 10 Max. gear wheel diameter, mm: 500 Max. gear wheel cone distance, mm: 250 Max. gear ring width, mm: 80 Min. angle of dividing cone (pitch), degrees: 5 Number of wheel teeth: 10 – 150 Distance between spindle and machine center, mm: – max. (stock angle 5 degrees) 375 mm; – min. (stock angle 90 degrees) 75 mm Nedpoum Ez Rofx Agrjwl Stroke, mm: 100 Slider double stroke, spm: 48 – 400 Motor capacity, kW: 4.0 Machine weight, kg: 8750

Condition: like new (used), functionality: fully functional, overall weight: 7,000 kg, This machine is configured with 4 fully electronic CNC axes and has integrated software that generates the automatic program. Description Maximum gear diameter: 400 mm Gear width: 76 mm Stroke: 82 mm Rotation: 150 - 700 rpm Module: min. 0.5 mm Module: max. 6 mm Nwedpfx Agewvbqijrol Machine weight: approx. 7500 kg Electrical equipment: – Operating voltage: 380/400 V – Protection: 20kva Machine with new CNC Siemens 808D Siemens drives and servomotors New update 2025 Screens for automatic program generation Automatic cycles NR12 Included in Chip conveyor Coolant tank Automatic lubrication Digital pressure controls Hydrostatic guide

Condition: used, Fixed Bed Milling Machine VERNIER DB 420 Travel X: 1200 mm Travel Y: 420 mm Travel Z: 600 mm Command HEIDENHAIN Spindle SA40 Spindle speed: from 40 to 2000 RPM Table size: 1600 x 400 mm Horizontal + vertical tilt head Spindle motor: 7,5 KW Feeds: auto X - Y - Z Voltage: 380 V Nedpfszw A Dwsx Agrjwl Width with ends table: 2700 mm Depth: 2500 mm Total height: 2200 mm Weight: approx 4,5 T

Year of construction: 1971, condition: used, Technical details: max. wheel diameter: 300 mm max. module: 5 module min. : 0,5 max. workpiece weight: 60 kg weight of the machine ca.: 4,0 t dimensions of machine: 1800x1850x2500 mm dimensions electric cabinet: Nr. 1: 1930x400x1920 mm dimensions electric cabinet: Nr. 2: 800x230x1950 mm dimensions:: Abluftanlage: 1400x700x560 mm dimension cooling device LxWxH: 1,2 x 1,0 x 0,45 m Electronically controlled tooth flank grinding machine up to module 5 and a Ø of 240 - 300 mm feed speed per workpiece revolution infinitely variable 0.4 - 3.2 mm max./min. Number of teeth: 130 / 12 max./min. Pressure angle: 30° / 14°30` max./min. Spiral pitch with 24 teeth: 6000 / 200 mm max. tooth helix angle, both sides: 45° Speed of the grinding worm: 1900 rpm without dressing device Equipment: approx. 77x change transmission wheels, pipe extensions and various tools Nwedpfjvc Apbjx Agrjl Two of these machines are for sale. Both machines are supplied via two common control cabinets and an exhaust air system. *

Year of construction: 1971, condition: used, Technical details: max. wheel diameter: 300 mm max. module: 5 module min. : 0,5 max. workpiece weight: 60 kg Nsdpfxevc An Dj Agrjwl weight of the machine ca.: 4,0 t machine dimensions LxWxH: 1,8 x 1,9 x 2,5 m dimensions electric cabinet LxWxH: Nr. 1: 1,95 x 0,4 x 1,95 m dimensions electric cabinet LxWxH: Nr. 2: 0,8 x 0,23 x 1,95 m dimensions:: Abluftanlage: 1,4 x 0,7 x 0,55 m Electronically controlled tooth flank grinding machine up to module 5 and a Ø of 240 - 300 mm feed speed per workpiece revolution infinitely variable 0.4 - 3.2 mm max./min. Number of teeth: 130 / 12 max./min. Pressure angle: 30° / 14°30` max./min. Spiral pitch with 24 teeth: 6000 / 200 mm max. tooth helix angle, both sides: 45° Speed of the grinding worm: 1900 rpm without dressing device Equipment: approx. 69x change transmission wheels, pipe extensions and various tools Two of these machines are for sale. Both machines are supplied via two common control cabinets and an exhaust air system. *

Condition: used, Year of construction: 1973, machine/vehicle number: 24109, Equipped with: Stock Divider Hydraulic Work Clamping Chip Conveyor Cutter Clamping Bolt Index Plate Nwsdexdfa Ujpfx Agrjl Change Gears Hydraulic System Coolant System Specifications: Min. Outside Cone Distance: 2.75" Max. Cone Distance: 10" Max. Gear Pitch Dia.: 20" Cutter Diameters Utilized: 9 - 18" Root Angle: 55 - 80 deg. Face Width: 3" Number of Teeth: 20 -75 Diameter of Taper Hole at Large End: 3-27/64" Taper Per Foot: .50" Depth of Taper: .625" Cutter Speeds: 6.8 to 16.5 RPM Feeds (seconds/tooth): 3 to 9 Main Motor: 5hp, 900 rpm Hydraulic Motor: 7.5hp, 1800 rpm Approx. Floor Space: 118" x 86.5" Needed Overall Height: 70" Approx. Net Weight: 16,000 lbs Shipping Weight Boxed for Export: 17,000 lbs

Condition: refurbished (used), Year of construction: 2013, operating hours: 50 h, functionality: fully functional, workpiece weight (max.): 500 kg, table diameter: 450 mm, total length: 7,200 mm, gear diameter: 500 mm, total height: 3,300 mm, total width: 4,500 mm, input frequency: 50 Hz, type of input current: three-phase, milling length: 240 mm, spindle speed (max.): 450 rpm, table bore: 125 mm, spindle speed (min.): 100 rpm, travel distance X-axis: 325 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 400 mm, overall weight: 16,800 kg, distance table to spindle center: 710 mm, controller manufacturer: Siemens Sinumerik 840D sl, drive type: Sinamics S120, control type: CNC control, Equipment: documentation/manual, A Pfauter PE 500 for the economical production of straight and helical spur gears up to module 12 and 500 mm in diameter – completely overhauled by SerWeMa with Siemens Sinumerik 840D sl, equipped with a gripper unit and a 32-position workpiece storage for unmanned operation. The machine is ready for operation in our hall in Chemnitz: you can inspect it under power, and if desired, we will mill your own sample part and you can take delivery of the machine here. No delivery time, no risk. Sold by Serwema Retrofit Solutions, the company that carried out the overhaul and knows the machine inside out. The general overhaul included complete geometric overhaul by grinding and scraping, new roller bearings in the main drive and in the milling head, measuring and reconditioning the worm gear, overhauled or new ball screw drives, overhaul of hydraulics, lubrication and coolant system, and new electrical equipment with Sinumerik 840D sl, Sinamics S120 and new axis motors. An electronic generating gear controls all generating and single-part machining processes, and an NC-controlled crash recovery protects the tool and workpiece in the event of a power or phase failure. New paint in RAL 7035/5015 with oil and coolant resistant two-component paint, acceptance of geometry according to SerWeMa protocol based on DIN ISO 6545. The machine controls six CNC axes: X radial, Y tangential, Z axial, A milling head swivel, B milling cutter drive and C table drive. The SerWeMa gear cutting software guides you through workpiece and tool data via masks, without the need for programming: up to three position-oriented gearings per workpiece, each with its own tool, up to three cuts per gearing with simultaneous or counter-rotating movement, form corrections for convex, conical and convex-conical profiles, lead-in and lead-out phase correction, chamfer milling, dimension correction via tooth width, two-roll or two-ball gauge, measuring stop, shift strategy with defect management per generating cutter and cutting force monitoring with automatic retraction. Technologies: generating milling, single-part milling and worm gear milling both radially and tangentially. A hand-held device with a handwheel allows setup directly in the working area. Technical data: max. workpiece Ø 500 mm, max. module 12, max. milling cutter Ø 200 mm, max. milling cutter length 240 mm, shift travel 200 mm, milling cutter speed 100–450 rpm, swivel angle +25°/−45°, travel radial 325 mm (axis distance 25–350 mm), travel axial 400 mm (310–710 mm), table diameter 450 mm, table bore 125 mm, connection power approx. 60 kVA. Installation dimensions incl. automation approx. 7.2 × 4.5 × 3.3 m, weight approx. 16.8 t. Equipment: machine enclosure, chip conveyor, gripper unit with two grippers, workpiece storage with 32 positions, preparation for emission extraction (150 mm nozzle, Harting connector on the machine roof). Documentation complete in German: operating manual, electrical diagrams with parts lists, hydraulic and lubrication diagrams. Serwema optionally offers: trial part milling in our factory, additional milling arbors, assembly and commissioning at your location, operator training and a control system upgrade to Sinumerik ONE. Spare parts and service come from a single source, worldwide, even after the purchase. Nodpjz Et E Eofx Agrowl

Condition: good (used), gear diameter: 508 mm, total height: 1,780 mm, total length: 2,990 mm, total width: 2,200 mm, MODEL 610 GLEASON GEAR ROUGHER/FINISHER Equipped with: Hydraulic Workholding Pendant Control Chip Conveyor Index Plate Geneva Cam Change Gears Hydraulic System Coolant System Manuals Specifications: Maximum Gear Pitch Diameter: 20" Cutter Diameters: 9", 10.5", 12",14",16", 18" Whole Depth: 1.250" Root Angle: 60 to 80 deg. Nodpfx Agertrykjrowl Face Width: 3.0" Extreme Ratio (Minimum): 2.25 to 1 Number of Teeth: 20 to 75 Diameter of Taper Hole at Large End: 3-27/64" Cutter Speeds (Per Minute) for Roughing: 15.6' to 87.7' Feeds (Seconds Per Tooth) for Roughing: 3 to 35 Cutter speeds (Per Minute) for Finishing: 6.8' to 20.5' Feeds (Seconds Per Tooth) for Finishing: 3 to 9 Floor Space: 118" x 86.5" x 70" H Weight: 17,500 lbs.

Condition: good (used), Year of construction: 2001, Equipped with: Power Stock Fanuc 5-Axis CNC Control 160M 400mm Honing Wheel X Axis Pulse Generator Coolant System w/Twin Filters Magnetic Chip Separator Honing Tool Set up for Last Job is Still in Machine Internal Diameter of Honing Tool on Machine is 14" Work Light Power Door Auto Dress 5-Part Program Instruction Book for 16M Control Instruction Book for Set-Up and Operation Specifications: Maximum Outer Diameter: 250 (350) Minimum Outer Diameter: 30 Maximum Overall Length: 400mm Maximum Tooth Width: 45mm Module: 1.0-3.0 Cross Feed Device(Z Axis): 430mm Max. Travel Honing Wheel Cutting Feed Device(X Axis): 370 Max. Travel Honing Wheel Swing Device(C Axis): Njdpfxerualpo Agrjwl Swing Angle: +30 Degress Honing Wheel Rotation Drive Device(A Axis): Honing Wheel Spindle Speed R/Min: 500 Honing Wheel Outer Dia.: 300 (400) Maximum Honing Wheel Width: 50mm Crowning Device (Y Axis): Maximum Rocking Angle: 1.6 Degrees Motor Types: Z-Axis Drive Motor: 1.8Kw X-Axis Drive Motor: 1.8Kw Y-Axis Drive Motor: 0.7Kw C-Axis Drive Motor: 1.8Kw A-Axis Drive Motor: 2.2/3.7Kw Maximum Distance Between Centers: 600mm Center Height: 1,100mm Floor Space: 2,170W X 2,800D X 2,100H Mass Of Machine: 4,500Kg

Condition: good (used), Year of construction: 1987, functionality: fully functional, overall weight: 1,900 kg, total length: 1,690 mm, total width: 1,260 mm, total height: 815 mm, gear ratio: 200, torque: 65,000 Nm, shaft diameter: 200 mm, 2 units of 4-stage industrial gearboxes used in winch applications. Manufacturer: Asug Penig, GDR Type: TGL 34611/10A8-450x200 Year of manufacture: 1987 Maximum torque: 65000 Nm Gear ratio: 200:1 Actual gear ratio: 200.364 Power: n1 950 rpm = 33 kW n1 710 rpm = 24.6 kW Dimensions: Nwodpfx Agezw H Hijrsl Shaft d1: Ø 45 mm x 110 mm Shaft d2: Ø 200 mm x 350 mm Shaft height h1: 400 mm Length: 1690 mm Width without shafts: 560 mm Width with 2x shafts: 1260 mm Height: 815 mm Weight without oil: 1900 kg (For design A8, the weight increases to approximately 2000 kg) Oil capacity: 68 kg The TGL 34611 series of gearboxes for conveyor systems and hoisting equipment includes three- and four-stage gearboxes with hardened gears. The shafts are mounted in roller bearings. Splash lubrication is used. Spur gears and shafts are positively connected by means of keyways. The external dimensions of the housing for a given size are the same for both the three- and four-stage versions. In the four-stage version, the drive shaft is located below the plane of the components. The housing is made of cast iron. The gearboxes can be operated in both directions of rotation.
