Used Klingelnberg - Oerlikon Measuring Machine for sale (67,668)

Condition: good (used), Year of construction: 2006, voltage 110 - 230 V frequency 50 - 60 Hz Power connection 0,5 kVA weight 150 kg dimensions of the machine ca. 1,0 x 0,8 x 1,75 m Stick blade profile control unit - Control via PC control with Windows XP operating system - Digital drive amplifiers, linear motors and measuring systems - Fully automatic position determination of the cutting edges and axis position of the stick blade Gksdpfx Aioymfz Sjxsa - Measurement of almost all single-part and continuous processes required for spiral bevel gears and hypoid gears - Machine concept designed for the shortest set-up and changeover lines and maximum measuring accuracy - Combination probe for measuring tip and surface measurement - Integrated drawer for accessories - Keyboard integrated in flat drawer - Operating elements and PC protected against unauthorized access with lockable cabinet element

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the Godpew N S E Aofx Aixeka the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: used, Year of construction: 2007, max. wheel diameter 400 mm workpiece dia. 36-300/400 mm axis distance 135-290 mm spindle turning speed - stepless 3000 1/min dist. between centers 100-550 mm Gjdpfxey D T Sus Aixoka Control Siemens 840D weight of the machine ca. 4000 kg dimensions of the machine ca. 2000x3055x2788 mm Test method: - Single flank rolling test - Double flank rolling test - Structure-borne noise test - Heli testing in two-flank contact. Features: - Use of up to 6 test slides - Highest testing accuracy and repeatability - Machine table with workpiece drive - Swiveling pneumatic unit - Spray oil lubrication (type: Vogel) - Oil mist extraction (type: Elbaron)

Year of construction: 2002, condition: used, z-travel 200 mm Clamping diameter of the cutter heads max. 550 mm Max. permissible cutter head weight 150 kg Mounting plate diameter for cutter heads 360 mm Mounting cone for cutter heads Nominal diameter 500 mm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m Cutter Head Set-Up- and -Measuring Machine In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in dry milling, high gear cutting quality and a long service life can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in Gjdpfjy A S U Sox Aixjka plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: used, Year of construction: 2006, voltage 110 - 230 V frequency range 50 - 60 Hz Power connection 0,5 kVA Dimensions (HxWxD) 1000 x 800 x 1750 mm weight 150 kg Measuring machine for bar knives. Equipment/accessories: -Measuring tools -Clamping devices -Computer -Monitor -Printer -Cabin Gkjdpfx Aoyhq T Asixoa -Technical documentation

Condition: used, Year of construction: 2007, max. wheel diameter 500 mm Hypoid adjustment ±70 mm axial cross angle 90 ° Distance Y- 150 - 350 mm Distance Z-axis 120 - 340 mm turning speed range - stepless 0 - 5000 U/min Gedpfoukitxsx Aixska max. torque on the spindle 57 Nm Cone 99,2 mm Pull-in force Tool clamping 23000 N Braking torque max. 93 Nm total connected load 20 kVA total power requirement 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 2,35 x 2,24 x 2,5 m

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, wheel diameter: 400 mm, overall weight: 4,000 kg, distance between centers: 550 mm, spindle speed (max.): 3,000 rpm, controller model: Siemens 840 D, TECHNICAL DETAILS Max. wheel diameter: 400 mm Workpiece diameter: 36–400 mm Centre distance: 135–290 mm Max. spindle speeds (infinitely variable): 3,000 rpm Centre width: 100–550 mm Gsdpfx Aieywg Hxjxeka MACHINE DETAILS Control: CNC Siemens 840 D Dimensions & Weight Space requirement: approx. 2,000 x 3,055 x 2,788 mm Machine weight: approx. 4,000 kg EQUIPMENT Single-flank rolling test Double-flank rolling test Structure-borne noise testing Helical contact testing (double-flank contact) Use of up to 6 test carriages Highest test accuracy and repeatability Machine table with workpiece drive Swivelling pneumatic unit Spray lubrication (Type: Vogel) Oil mist extraction (Type: Elbaron)

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, grinding wheel diameter: 200 mm, workpiece length (max.): 200 mm, TECHNICAL DETAILS Grinding wheel diameter: 100–200 mm Maximum workpiece length: 200 mm MACHINE DETAILS Control: Siemens 840D or equivalent CNC axes: 3–5 axes Drive power: 5–10 kW Coolant tank: 100–200 litres EQUIPMENT Coolant filtration system Universal applicability for different tool types and geometries High flexibility through CNC programming and adaptable clamping devices Gsdpfx Aoya Dy Hsixska Process reliability thanks to integrated cooling and filtration system Easy maintenance due to modular design and central supply units

Condition: like new (used), Year of construction: 2013, functionality: fully functional, machine/vehicle number: 1393, arm reach: 2,500 mm, No minimum price – guaranteed sale to the highest bidder! Includes notebook and PCdemis 2016 software! Godszrd R Uepfx Aixoka TECHNICAL DETAILS FP2 Mobility Pack: included Measuring software: PCdemis (2016) Notebook: DELL M 6800 with a 17-inch screen and Windows 10 Tripod: Brunson heavy-duty rolling tripod, type 230 FIX Measuring range: 2,500 mm Accuracy class: 5 Number of axes: 6 Target single-point deviation: 0.020 mm Target volumetric accuracy: ±0.029 mm Arm weight: 8 kg Probe set: Probe with ruby ball 3mm, 6mm and with steel ball 15mm EQUIPMENT - Carbon fiber double-tube construction enables separation of stability and measurement - AbsoluteArm series can start measuring directly without referencing - Probing system with automatic probe recognition - Mounting plate with magnet - FP2 Mobility Pack - Transport case - Magnetic tripod - Test bar L = 700 mm - Test sphere D = 25 mm - Power supply with connecting cable - USB cable measuring arm - notebook - Dust cover - New pressure cylinder installed - Relabeling of the measuring arm before calibration 2023 - ISO 10360 acceptance with certificate 2023 is included Shipping conditions - Ex works, without additional packaging (measuring arm in case and notebook in protective cover) and Brunson rolling tripod – i.e. 3 parts - If the buyer arranges collection via a shipping company, the seller recommends special packaging (approx. 160 x 70 x 70 cm cardboard box on a pallet, with bubble wrap inside) and a Euro pallet (Brunson rolling tripod) at a price of €250, secured with strapping to the pallet.

Condition: used, Year of construction: 2017, functionality: fully functional, Operating voltage: 230 V Frequency: 50 Hz Rated current: 10 A Connection power: 1400 W Measuring software: ARCO CAD Includes EROWA PRESOFT For defining tool zero points Measurement of geometric features without a CAD model Graphical representation of the measured elements Import of CAD models in IGES format Measurement of geometric features Measurement of freeform surfaces Measurement of form and position tolerances Evaluation of the measured elements and comparison with target values Creation of test reports (tabular and graphical) Travel ranges: X-axis: 650 mm Gedjzud Thspfx Aixska Y-axis: 700 mm Z-axis: 500 mm The machine is CNC-controlled Dimensions of the granite plate: 1330 x 819 mm Resolution: 0.0005 Measurement uncertainty within the measuring volume = 0.0025 mm + L/300 Max. permissible workpiece weight: approx. 650 kg Includes the equipment shown in the photos.

Condition: repair required (used), Renishaw InVia Raman Microscope Spectrometer DEVICE NEEDS TO BE RECONDITIONED PRIOR TO COMMISSIONING. Complete with MSC20 Encoded Stage Controller RL532C50 HPNIR Laser Source A-9803-0625 CCD 1. The device doesn't come with a software license or computer. We are selling the device as it is. Gsdpfx Aisym Dt Hexoka 2. There is a HPNIR785 Renishaw Laser Source installed on the device. Unfortunately we are a surplus seller and do not possess the expertise to test and run this machine for diagnostics. Our intentions are to sell the device for parts and leave a buyer recondition to their required standards. Device is missing some parts to make fully operational. Device is missing Renishaw Ramen Filters as seen in images. Device also is missing original Renishaw Key to open access panel.

Condition: not inspected (used), Mitutoyo Quick Vision Apex QV-X404P1L-C CNC Image Measurement System Manufacturer: Mitutoyo Corporation Model: Quick Vision Apex Type: QV-X404P1L-C Code No.: 363-131EU Year of Manufacture: 2007 Machine Type: CNC Image Processing Measurement System Measuring Range: approx. 400 × 400 × 250 mm For sale is a used Mitutoyo Quick Vision Apex CNC Image Processing Measurement System for non-contact dimensional measurement and inspection tasks. The system is offered including the existing PC workstation, two monitors, Mitutoyo control unit, installed QVPAK measurement software, documentation, and other accessories as shown in the pictures. The existing PC system and QVPAK software start. However, the complete machine and measurement function could not be fully tested. Technical Data: Manufacturer: Mitutoyo Corporation Model: Quick Vision Apex Type: QV-X404P1L-C Code No.: 363-131EU Year of Manufacture: 2007 Country of Manufacture: Japan Measuring Range X / Y / Z: approx. 400 × 400 × 250 mm Measurement Principle: non-contact optical image measurement Control: CNC Measurement Software: Mitutoyo QVPAK Software: QVPAK (R): Version 7.502.0010 QVGEO: Version 7.502.0010 Statistics: Version 7.502.0010 Dimensions: Machine and transport dimensions have not been verified and are therefore not provided as binding information. Equipment: Mitutoyo Quick Vision Apex measurement system PC workstation Fujitsu Siemens CELSIUS PC system 2 Fujitsu monitors Keyboard and mouse Mitutoyo control unit / joystick with emergency stop Installed QVPAK measurement software Mitutoyo MCOSMOS / MiCAT data carriers GEOPAK documentation QVPAK documentation Other Mitutoyo operating manuals and documents Clamping plate / workpiece holder Connecting cables and accessories as shown in the pictures Transport Data: Transport by forwarding agent is possible. Exact transport dimensions and transport weight must be agreed upon before collection or shipment. Condition: Used condition with age- and usage-related signs of wear. Visible damage is present on the machine housing, see pictures. The PC system and the existing QVPAK software start. However, the complete machine and measurement function could not be fully tested from a software perspective. Due to the age of the existing PC system, suitable drivers could no longer be provided or installed for individual hardware components. Therefore, complete communication between the measurement system, PC hardware, and measurement software could not be verified. The machine is explicitly offered as untested or for re-commissioning by qualified personnel. Scope of Supply: Mitutoyo Quick Vision Apex QV-X404P1L-C including PC workstation, two monitors, control unit, existing software, documentation, and accessories as shown in the pictures. Gkedpfx Asztyabjixja The machine is available for short-term delivery. Inspection possible by arrangement. The scope of supply is as shown in the pictures. Subject to changes, errors, and prior sale.

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, measuring range X-axis: 300 mm, measuring range Y-axis: 250 mm, measuring range Z-axis: 150 mm, Keyence XM-T2000 coordinate measuring system from 2021, in excellent and fully functional condition. Keyence XMM-1600 controller included. Gedex H T H Dopfx Aixska Additional accessories: Keyence case, dongle, user manual, and certificates. Measuring range: 300 mm × 250 mm × 150 mm Smallest display unit: Distance: 1 μm, Angle: 0.0001 degrees Measuring accuracy: Repeatability: ±3 μm, Measurement deviation: ±8 μm Maximum load capacity: 25 kg #8406

Condition: good (used), Year of construction: 2015, functionality: fully functional, Hexagon Metrology Optiv Classic 432 coordinate measuring machine in good, fully functional condition. Measuring range (single sensor): 400x300x200mm Dimensions: 1232x910x1663mm Weight: approx. 800kg Maximum workpiece weight: glass plate approx. 30kg Accuracy: MPEE = 2.9 + L/100 [μm] No additional software included. A PC is provided, but it is unknown to what extent the PC-DMIS 2020 R1 software can still be used. Gedpsx H T Emofx Aixeka

Condition: used, Year of construction: 2011, length 300 mm Gksdpewmwwasfx Aixsa centre height ca. 30 mm diameter 0,5 - 52 mm weight of the machine ca. 0,103 t dimensions of the machine ca. H 0,84 x L 1,00 x P 0,435 m Serviced and calibrated by Studenroth on 24.07.2024 Length and diameter measuring device: Equipment/accessories: -Software -monitor and computer -Technical documentation

Condition: used, Year of construction: 2009, functionality: unexamined, machine/vehicle number: 1-1028-09, measuring range X-axis: 400 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 200 mm, workpiece weight (max.): 30 kg, total height: 1,663 mm, total width: 910 mm, total length: 1,232 mm, overall weight: 30 kg, Equipment: documentation/manual, We are offering this used Mahr / Hexagon Optiv Performance MS 442 coordinate measuring machine, year of manufacture 2009. The machine was factory overhauled in 2023, purchased by us, and has seen minimal use since then. Gsdpoyf N Iyofx Aixeka Serial number: 1-1028-09 Measuring range: 400x400x200mm Dimensions: 910x1232x1663 Weight: 940kg Maximum workpiece weight on the glass plate: 30kg Includes camera with 2-stage zoom Includes measuring laser Includes LED ring light Accuracy: Length measurement deviation: according to VDI/VDE 2617-6.1 MPEE1: 1.4µm+L/200mm MPEE2: 1.5µm+L/150mm Includes 19" CNC real-time controller based on Windows 10 (32-bit) upgrade kit Includes Renishaw PI200 probe interface Includes Renishaw TP200 probe body Includes Renishaw probe holder Includes various probes & heads Includes OptiChek3D software If you have any questions or need further information, please feel free to send us a message.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Faro Gage Plus measuring arm with 6 axes Measuring arm length: 4 ft (approx. 1.2 m) Accuracy: 5 + 8L/1000µm Includes measuring table, accessories, and matching transport case Gsdpfjztylkox Aixska Includes operating instructions and manuals.

Condition: used, Year of construction: 1992, x-travel 1400 mm y-travel 1200 mm z-travel 1000 mm Control ZM Gkodpfeftfczjx Aixea total power requirement 0,5 kW weight of the machine ca. 2 t dimensions of the machine ca. 2 x 1,5 x 2 m

Condition: ready for operation (used), Year of construction: 2020, functionality: fully functional, type of input current: AC, input voltage: 230 V, Equipment: documentation/manual, Keyence XM-C1000 Portable Coordinate Measuring Machine / Measurement System Manufacturer: Keyence Model: XM-C1000 Condition: Used, fully functional Gsdpfx Asztzm Noixjka For sale is a used Keyence XM-C1000 measurement system for precise 3D coordinate measurement of components and assemblies. The system enables fast and reproducible measurements without complex programming and is ideal for quality assurance, incoming goods inspection, first article inspection, and production monitoring. The XM-C1000 impresses with its ease of use, high measurement accuracy, and flexible application possibilities. Measurements of distances, diameters, positions, angles, and geometric tolerances can be performed and documented efficiently. Technical features: Portable optical coordinate measuring system Precise 3D measurements Intuitive user interface Fast inspection processes Automatic measurement reports Ideal for production and quality assurance Condition: Used Fully functional Good optical condition Normal signs of wear and tear Inspection and functional testing possible by appointment Scope of delivery: Keyence XM-C1000 measurement system Existing accessories as shown in the picture Documentation

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, measuring range X-axis: 500 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 400 mm, Equipment: type plate available, Mitutoyo coordinate measuring machine, type Crysta Apex S544 Multi-sensor cabling (analog scanning) Temperature compensation for all axes Measuring range, X-axis = 500mm Measuring range, Y-axis = 400mm Measuring range, Z-axis = 400mm Measurement uncertainty = 1.7 + 3L/1000 (µm) Mitutoyo controller UC200H Renishaw probe head PH6M Renishaw sensor SP25M Renishaw module SM25-1 Measuring software MCosmos-1 v.4.x PC system WIN10 and 27" monitor (new) Reference sphere / calibration sphere (new) Gksdpfx Ajzhumfsixoa Hardware & software upgrades available upon request Delivery & other services available upon request

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, measuring range X-axis: 500 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 400 mm, Equipment: type plate available, Mitutoyo coordinate measuring machine, type Crysta Apex C544 Temperature compensation for all axes Measuring range, X-axis = 500mm Measuring range, Y-axis = 400mm Gkodpfx Aiezt Tg Uexsa Measuring range, Z-axis = 400mm Measurement uncertainty = 1.9 + 3L/1000 (µm) Mitutoyo controller UC200 Mitutoyo joystick box, type M Renishaw probe head PH6M Renishaw probe head PH10M (optional) Renishaw sensor TP200 Renishaw TP200 measuring modules (6x) Renishaw SCR200 probe rack Measuring software MCosmos-1 v.4.x PC system WIN10 and 27" monitor (new) Reference sphere / calibration sphere (new) Delivery: On request Installation: On request Calibration: On request Training: On request Software upgrade: On request Software options: On request Measuring room design: On request On-site consultation: On request Rental: Possible Leasing / hire purchase: Possible

Condition: reconditioned (used), Year of construction: 2026, operating hours: 12 h, functionality: fully functional, measuring range X-axis: 400 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 200 mm, warranty duration: 12 months, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 200 mm, feed length X-axis: 400 mm, feed length Y-axis: 400 mm, feed length Z-axis: 200 mm, year of last overhaul: 2025, Equipment: documentation/manual, lighting, type plate available, Mahr Multiscope 442 Multisensor Measuring System equipped with camera, laser, Renishaw probing system, and Hexagon Vision 3D software (upgrade to Windows 11 and OptiCheck3D 2025 possible) Complete maintenance history available Godpfxsxufk Ue Aixska Factory-refurbished premium multisensor measuring center with warranty and guarantee, rebuilt in 2025. Delivery via factory service or forwarding agent, worldwide. Online or optional on-site demonstrations with customer parts, application-specific consultation by accredited Profitech metrology laboratories during project planning. Comprehensive service: – Delivery, installation, commissioning, accuracy verification to standard, certification, and extensive acceptance documentation. Individual training and education programs also available as online courses. Rental, hire-purchase, or financing available directly through Profitech without a financial institution. Measuring system can be individually configured to customer requirements. Measuring range for all sensors: 400x400x200 mm Dimensions: 800x1000x2000 mm Weight: approx. 800 kg Maximum load (glass plate): 30 kg Accuracies: U1=1.9 + L/200; U2=2.4 + L/150; U3=2.9 + L/100 (L = measuring length in mm) Max. traverse speed: 250 mm/s Including camera Including rotary table Including laser Including LED ring light Including new frame grabber Including dual-monitor operation Including CNC control and PC Including Hexagon Vision3D software

Condition: ready for operation (used), Year of construction: 2013, A 3D CNC coordinate measuring machine in need of repair is offered for sale. Max. measuring range X/Y/Z: 400mm/400mm/300mm, measuring principle: hybrid (optical/tactile), optical system: CCD camera with motorized zoom optics, focusing method: contrast autofocus, max. accuracy: 1.5µm (MPE), guideways: mechanical precision guideways, base structure: granite construction, control: CNC in all 3 axes, software: WinWerth®. The Z-axis no longer moves. An on-site inspection is possible. Godpfx Ajztrbdsixjka

Condition: used, Three Dimension Coordinate Measuring Machine MITUTOYO Crysta-Apex S574 Gedpfx Aioy Ufkkexoka

Year of construction: 2019, condition: excellent (used), Image-guided 3D coordinate measuring machine Manufacturer: Keyence Type: XM-1200 series Year of manufacture: 2019 Control system: Keyence Technical data: ----- • Camera chip: 4 MP CMOS Gsdpfx Aisih R Uxoxska • Measuring range: 600 x 300 x 200 mm • Smallest display unit: 1 µm • Smallest angle: 0.0001° • Repeatability (locked): ±3 µm • Maximum table load: 25 kg • Display: 15" TFT • Weight: 40 kg Accessories: ----- • Manuals • As-delivered condition (Datasheet attached)
