Used Kohler Coil Line for sale (11,453)

Condition: used, Year of construction: 1990, functionality: fully functional, machine/vehicle number: 90387, overall weight: 1,500 kg, Kohler KRM 18.180/19 Precision Strip Straightening Machine with Double Decoiler Kohler Richttechnik precision roller straightening machine with a double decoiler, built in West Germany in 1990. The line is designed for straightening narrow steel strip, such as bandsaw blade material, and runs from left to right at up to 60 m/min. Strip speed is controlled automatically by a light curtain (loop control), so the decoiler and straightener stay synchronised. The straightener has 19 rolls of 18 mm diameter. Both roll stands are adjusted by motor, and a Kohler digital measuring unit with a keypad allows exact, repeatable roll positioning. The operator panel includes decoiler forward, reverse and stop, a speed potentiometer, key switches to open and close the straightening rolls, oil level control, motor temperature monitoring, and setup and automatic modes. TECHNICAL SPECIFICATIONS Prodpfx Aoz E Smhomxob Manufacturer: Kohler Richttechnik Model: KRM 18.180/19 Serial number: 90388 Year of manufacture: 1990 Strip width: 180 mm (please verify; 120 mm per manual) Straightening rolls: 19 pcs, Ø 18 mm Max. straightenable cross-section: 250 mm² Working direction: left to right Strip speed: 0–60 m/min, stepless Speed control: light curtain (loop control) Measuring system: digital, Kohler display with keypad Roll stand adjustment: motorised (2× SEW R302 DT71 D8/2, 0.06/0.25 kW) Entry guide: manual side adjustment Quick-change device: manual Main drive: Lenze GFQT 80-24, 4.2 kW at 3000 rpm Oil pump: AEG AM56 KY4, 0.06 kW Connected load: 6 kW Power supply: 380 V / 50 Hz Decoiler: double Documentation: original manual available Made in West Germany Condition: Complete and available for inspection under power. On stock more stamping eqipment from brands: Bruderer, bihler, mabu, Schaal, Soprem, Noxon, Huras...

Condition: used, Year of construction: 2003, Item No.: Lg 35626 Coil handling system KOHLER 30.400/9 - 2000.2H used Year of manufacture: 2003 Machine No.: 70330 Working direction: from left to right Loading side: rear Consisting of: Double unwinding reel 2000.2H Load capacity: max. 2,000 kg/side Coil width: 85 to 400 mm (when using a pressure arm) Spreading range: 360 – 420 mm Outer diameter: max. 1,800 mm Spreading: hydraulic/sliding wedge system + Automatic retension Drive: 2 x hydraulic motor + auxiliary drive for coil feeding and rewinding Braking: spring-loaded/disc brake Coil diameter-dependent control Lateral displacement: motorized Displacement distance: approx. 200 mm Base frame: frame construction Swiveling: motorized 180°, locking pneumatic, actuated wedge Counter bearing: manually attachable with quick-release fastener, open construction Coil loading: by means of rope or strap Pjdpfozpbazox Amxjrb Spreading: The spreading is carried out hydraulically via a sliding wedge system. The reel is additionally equipped with an automatic retension system, so that the clamping pressure is maintained for several days. Counter bearing: The counter bearing is designed as a ring strut construction and can be attached manually. Two effective quick-release levers ensure a secure hold. The lightweight construction made of square tube profile in an open design has a total weight of approximately 15 kg with an outer diameter of 1600 mm. Automatic brake control/coil diameter dependent A diameter-dependent brake control is achieved via a proportional valve. During the acceleration and deceleration phase, the braking effect is automatically adjusted via a correspondingly controlled proportional pressure control valve. This control technology guarantees smooth coil unwinding. Base frame with motorized lateral displacement of the reel 2 x pressure roller, swiveling: The pressure roller is used to feed the coil into the straightening machine. It also prevents the coil from jumping when the coil strapping is released. The swiveling of the roller, which is coated with plastic, is carried out hydraulically. The contact pressure can be adjusted continuously. The drive of the roller is carried out via a hydraulic motor. Coil straightening machine 30.400/9 Passage width: max. 400 mm Number of straightening rollers: 9 pcs. Straightening roller diameter: 30 mm Straightening roller material thickness: 0.4 – 3.0 mm Roller stand adjustment: motorized (2-point) The complete straightening roller bearing is mounted on a slide plate at the top and bottom and can be manually moved in and out. Measuring device: digital Measuring display: metric Setting accuracy: 0.01 mm Straightening roller bearing: needle bearing Bearing sealing: shaft seals Straightening roller hardness: HRc 60 Straightening roller surface roughness: 0.001 mm and better Straightening roller drive: individual drive Gearbox: distribution gearbox Lubrication: grease lubrication of the straightening roller bearing Oil circulation lubrication of the cardan shafts Drive: three-phase motor with frequency control Speed: 0 - 40 m/min Number of coil feed rollers: 2 Coil feed roller diameter: 120 mm Coil feed roller adjustment: pneumatic Drive coil feed: both rollers from the straightening machine gearbox Surface coil feed rollers: like straightening rollers

Condition: used, Year of construction: 1988, Ref. No.: Lg 35526 KOHLER Strip Processing Line 18.260/19 - 1000.2H used Year of manufacture: 1988 Direction of operation: left to right Loading side: front Comprising: Double decoiler 1000.2H Load capacity: max. 1,000 kg per side Strip width: max. 260 mm Mandrel expansion range: 460 – 520 mm Outer diameter: max. approx. 1,200 mm Straightening Machine 18.26019 Passage width: max. 260 mm Number of straightening rollers: 19 pcs Roller diameter: 18 mm Straightenable material thickness: 0.3 – 1.5 mm Drive power: approx. 7 kW Speed: 0 – 40 m/min Roller adjustment: motorized (2-point) Psdpoyb A Swjfx Amxjrb Used, as-is, ex stock, immediately available. Overhaul available on request. Delivery time by arrangement. Further data to follow or upon request. All information is based on manufacturer’s data and is non-binding for us – Subject to prior sale and errors excepted.

Condition: used, Coil Handler and Straightening Machine EBU Strip Processing Line Straightening Machine EBU, Type RE 7.50-320 Year of Manufacture 2004 Strip Nominal Width 320 mm Psdpfjz Ek Scex Amxorb Strip Width max. 320 mm Strip Thickness max. 3 mm Strip Cross-Section max. 1000 mm2 Power Supply 400 Volts, 50 Hz Unwinding Coil Handler EBU, Type BSH 3/320 Manufacturer 10838, Year of Manufacture 2004 Coil Weight max. 2500 kg Coil Width 320 mm Power Supply 400 Volts, 50 Hz - Central expansion - Drive via geared brake motor - 3 starting arms

Condition: repair required (used), Sheet Metal Processing Unit, Decoiler, Straightener, Guillotine Shear, Reinhardt Maschinenbau GmbH Ras 228.60 Used Machine Manufacturer: Reinhardt Maschinenbau GmbH Podpfsvkbrqsx Amxjrb Model: Ras 28.60 Maximum Sheet Width: 1500 mm Maximum Sheet Thickness: 1.5 mm Total Weight: 9350 kg Features: Decoiler Measuring Unit Sheet Straightener Guillotine Shear Electrical Data: Voltage: 400 V Power: 12 kW Frequency: 50 Hz Current: 35 A Note: The control panel display is not functioning.

Condition: good (used), Year of construction: 2019, functionality: fully functional, EMAE-85/600 Servo feeding and straightening line with LARA D-3000/1600-MH decoiler: Hydraulic coil loading table for Lara D-3000/1600MH decoiler Max. width: 600mm Predjvmmucopfx Amxsb Max-Min thickness: 0.8 – 4mm Positioning accuracy: +/-0.05mm Max. Diameter: 1600mm Max. Weight: 3000kg Connection to press CamPositioner_HBPS DieTronic coil lubricator width 500 mm Renewed safety logic and mesh fences 8/2020 CE approved

Year of construction: 2017, condition: excellent (used), functionality: fully functional, machine/vehicle number: 004/2017, The line (multi-purpose automatic machine) is designed for the automatic straightening and cutting of uncoiled flat and metal strip and coil into sheets of various dimensions, with a simultaneous stacking system. The machine was manufactured in Poland in 2017. Main technical and operational parameters of the line: 1. Overall external dimensions of the entire line: total length – 1230 cm, maximum height – 180/260 cm, maximum width – 320 cm, 2. Length/width/height: Prodpsz Eafxjfx Amxsb receiving table – 400 cm, 130 cm, 87 cm; feeding table – 400 cm, 150 cm, 87 cm. 3. Power supply: electrical 3 x 400V/50Hz 4. Flat sheet parameters – thickness 0.5 mm – 2.0 mm / width – max 1500 mm, perforated sheet parameters – thickness up to 3 mm, width – max 1500 mm. 5. Uncoiling, straightening, and cutting speed – automatically controlled. 6. Max. Load – 5000 kg (5T) [spindle carriage]. Machine construction: 1. Rail carriage, 2. Coil unwinder – for strip and coil, 3. Straightener with adjustable straightening gap, 4. Guillotine shears – for transverse cutting of the strip into sheets, 5. Stacker (trap) for preliminary collection of sheet metal, 6. Wheel-and-spindle carriage for packaging sheet metal, 7. Control cabinet – integrated electrical and electronic systems for power supply, programming, and control. 8. Adjustable control panel with a visual touch screen. 9. Safety devices – guards, emergency stop switches, wire circuit with limit switch, distinctive colors. The construction of the machines that make up the line is based on a monolithic, compact frame and table structure made of steel profiles, angles, closed profiles, flat bars, bracing, and sheet metal cladding. The components are joined by longitudinal, butt, and lap welding, as well as by detachable bolted connections. The machine has been used very little (a few dozen operating hours) due to a change in production plans. It is in perfect condition. The stated price is the net price.

Condition: excellent (used), Year of construction: 2016, operating hours: 9,001,700 h, functionality: fully functional, machine/vehicle number: N/A, PACE MEAT BONING LINE FOR BUTCHERY OPERATION. DOUBLE SIDED PACE BUTCHERY CONVEYOR LINE EXTENDING TO A TRIMMING AND PACKING LINE APPROX LENGTH 28m. SPACE FOR 16 BUTCHERS 8 PER SIDE WITH CENTRAL BONE REMOVAL CONVEYOR . SPACE FOR BANDSAW AND DERINDER MACHINES WITHIN THE PROCESS. VARIABLE SPEED CONVEYOR TO DICTATE PACE SPEED OF LINE . Prjdoy Uk A Sopfx Amxsb

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, Storti Nailing Line GSI/150-AL2 – pallet line The Storti GSI/150-AL2 pallet nailing line is designed for efficient pallet production. This robust industrial machine is suitable for automated pallet assembly, offering reliable performance and increased production capacity. Prodjzgayujpfx Amxjb Holtec Variocut VC-SHKA-HPI – cut-to-length saw / optimization line This industrial machine is designed for precise and efficient wood cutting. It is suitable for woodworking operations requiring reliable performance, high output, and accurate material cutting.

Condition: new, Year of construction: 2025, functionality: fully functional, coil outer diameter: 1,500 mm, coil inner diameter: 508 mm, product height (max.): 200 mm, feed length X-axis: 1,520 mm, feed length Y-axis: 3,020 mm, feed length Z-axis: 80 mm, warranty duration: 24 months, total height: 2,380 mm, total length: 8,900 mm, total width: 2,300 mm, load capacity: 1,300 kg, input frequency: 50 Hz, input voltage: 380 V, overall weight: 180 kg, repeat accuracy: 0.02 mm, workpiece weight (max.): 15,000 kg, Equipment: cooling unit, GS-J Series has various workbench sizes such as 3015, 4015, 4020, 6015 to meet different processing needs Suitable for batch processing of thin plates with high flatness requirements of 0.6-3.0mm Uncoiling machine parameters: Maximum weight of coil (kg): 15000 Coil width (mm): 200～1524 Coil outer diameter (mm): Φ800～Φ1500 Coil inner diameter (mm): Φ508mm~Φ610mm (cast iron pad) Coil thickness: (mm) 0.6-2.0mm (stainless steel) ≤1524mm 0.8-3.0mm (carbon steel) ≤1524mm Psdpfxev Awguo Amxerb Feeding length (mm): 0～ Maximum stroke of equipment Unwinding speed (m/min): 0～15 Moving speed (mm/s): 0-8 Lifting speed (mm/s): 3.0 Lifting stroke (mm) : 350 Leveling flatness (mm/㎡): ≤±3 Fixed feeding line height (mm) : 870 Sizing accuracy (mm/m) : Length direction ≤±0.2 Diagonal direction : ≤±0.8 Revolutionize Your Coil Processing with One Machine, Five Functions! Uncoiling, leveling, feeding, cutting, and blanking – all in one seamless automated system for maximum efficiency. Smart, Flexible & Versatile - Effortlessly cuts special-shaped workpieces, adapting to diverse production needs - Optional touchscreen control with top-tier international cutting systems - High-quality drag chain cables – durable, bend-resistant, and interference-free

Condition: used, Year of construction: 1987, Uncoiler manufactured by DREHER, type 2380 F-FPS. Press force approximately --- tons. Year of manufacture 1994. Summary provided – a full technical translation will follow if required for this lot. Psdpfx Amjzynmvoxsrb

Condition: ready for operation (used), Year of construction: 2006, material width 650 mm Pedpfx Aozu A Scomxsrb coil weight 15 t material thickness 16 mm The year of construction is estimated, the system is as good as new

Condition: used, Year of construction: 2023, Used for the production of refrigerator door panels. Line Specifications: Manufacturer: MAS AUTOMAZIONI SRL Year of manufacture: 2023 Electrical supply: 400 V (±10%), 50 Hz Compressed air: 4.5-6 bar, dew point +5°C Cycle time: 10 seconds Changeover time: Automatic Line dimensions: 38.1 m (L) × 9.6 m (W) × 4.4 m (H) Sheet dimensions: Prsdpfx Aezummqomxsb Length: 400-2200 mm (±1 mm) Width: 650-900 mm (±1 mm) Thickness: 0.35-0.55 mm (±0.04 mm) The metal sheet forming line consists of: Sheet loading with measuring laser sensors. Punching and bending station with 2 sets of bending blades for different shapes. 2 available spaces for additional bending or forming stations. 2nd punching stations. Total number of pieces produced to date: 89,963. 2 scrap conveyors. Siemens S7 control system.

Condition: used, Year of construction: 1993, Uncoiler manufactured by ARKU, type AH 2000/M. Press force approximately --- tons. Year of manufacture 1993. Structured summary – a full technical translation will follow if required for this lot. Prsdpfx Amozym Ewjxjb

Condition: used, Year of construction: 2012, functionality: fully functional, For sale is a high-performance DIMECO LINAPUNCH MC-F CNC coil punching system for the automated processing of strip material directly from the coil. This system is particularly suitable for the economical production of perforated sheets, mounting plates, fastening rails, ventilation components, and customer-specific punched parts in medium to large quantities. Direct processing from the coil significantly reduces material consumption, setup times, and per-piece costs. The LINAPUNCH technology combines the flexibility of a CNC punching machine with the productivity of a continuous coil line. The system operates with standardized thick-turret tools and enables highly productive manufacturing processes. Technical data: Manufacturer: DIMECO Type: LINAPUNCH MC-F Machine type: CNC coil punching system / punching line Control: CNC, Siemens Simostar 370 Coil processing: Coil inner diameter: 508/610 mm Coil outer diameter max.: 1700 mm Coil weight max.: 6000 kg Strip width min./max.: 170 to 525 mm Material thickness: 0.4 to 3 mm Product length max.: 6000 mm Feed length programmable Servo-controlled NC strip feed Automatic strip guidance Punching technology: Punching force: approx. 20 t Multi-axis punching system (X/Y axis) Programmable punching stroke Auto-index function Multi-index function Tool holder for standard thick-turret tools Number of punches: 26 pieces Number of punching heads: 1 piece Number of revolving tool stations: 2 Predpfx Aezmv Dvemxsb Consisting of: Coil unwinder Leveling unit NC feed LINAPUNCH MC-F punching head Shear Ink marking unit Drop table stacker 2 lifting tables Control panel with CNC control Safety enclosure Application areas: Electrical industry Switchgear construction Ventilation and air conditioning technology Metalworking Profile and component manufacturing Series production from coil material EXW, assistance can be provided with dismantling and loading.

Condition: used, Year of construction: 1985, Decoiler Decoiler with arm: 1,5 ton Material width: 350 mm Coil exterior diameter: 1.200 mm Expansion range: 370 - 430 mm Speed: 0 - 20 m / min Leveller / Straightener Material width : 250 mm Number of levelling rolls: 9 pcs. Diameter of the levelling rolls: 30 mm Material thickness: 0,5 - 6 mm Cross section: 1.200 mm Feeding speed: 20 m / min Required power: 18 kW Prjdpfxjxdl Nis Amxob Standard configuration - Pneumatic clamp roller- Manual disc brake

Condition: used, Unwinding and rewinding reel for coil material, HMS type BA 1.5-06/80 Machine No. Year of manufacture 1991 Coil weight max. 8000 kg Pjdpfx Ajhx R Etjmxorb Coil outer diameter max. 1600 mm (with loading carriage) Coil outer diameter max. 2000 mm (without loading carriage) Diameter of the coil running disk Ø 1700 mm Coil inner diameter, spreading range 460-520 mm Coil width, nominal width max. 630 mm Width of the spreading jaws 750 mm Height of the reel crown above the base plate 1500 mm - Drive of the reel crown via hydraulic motor with gearbox and gear - Pneumatic trailing brake on the reel crown TWINFLEX - Hydraulic operating brake - Hydraulic stop brake - Hydraulic spreading of the reel crown, centrally via wedge slide system - Hydraulic pressure arm with hydraulically driven double rocker roller - Coil loading carriage with 12 ton lifting capacity and 300 mm stroke - Reel on above-ground travel frame with motorized lateral travel drive - Hydraulic unit located nearby (also used for other functions on a conveyor system) - Without electrical control cabinet (or, there is an electrical control cabinet that supplied the entire conveyor system) Transport dimensions L x W x H 3500 x 1900 x 2500 mm Own weight approx. 5 tons Good condition - not electrically operational.

Condition: used, Strip Straightening Machine for Coil Material WANZKE Type RG 400-7 Coil Processing Line REF No.: 1349-6 Year of manufacture: 1983 Nominal strip width: 400 mm Roll width: 408 mm Strip thickness: max. 2 mm Strip cross-section: max. 600 mm² Roll width, straightening rollers: 408 mm Number of straightening rollers (top): 3 (non-driven) Number of straightening rollers (bottom): 4 (driven) Straightening roller diameter: 50 mm Feed rollers: 2 pcs, Ø 50 mm (lower roller driven) Feed roller width (top): 390 mm Feed roller width (bottom): 408 mm Strip speed: approx. 5 - 45 m/min Predpfsxw Rcujx Amxob Motor power: 1.1 kW Power supply: 230 Volt, 50 Hz - Infinitely variable straightening speed via DC motor with DC controller - Drive via geared motor with chain drive - Loop control with speed regulation with 2 speed stages - Upper roller frame adjustable via 4 handwheels - 4 dial gauges for fine adjustment - Mechanical opening of the upper rollers via eccentric lever - Adjustable lateral strip guide at the infeed side - 2 roller baskets for strip guidance - Electrical diagram available Space required by straightener with control unit (L x W x H): 1200 x 800 x 1600 mm Weight: 620 kg Good condition

Condition: used, Year of construction: 2011, Decoiler Coil weight: 4,5 ton Material width max.: 520 mm Coil exterior diameter: 1600 mm Expansion range: 460 - 530 mm Leveller / Straightener Material width : 20 - 400 mm Number of levelling rolls: 7 pcs. Diameter of the levelling rolls: 60 mm Number of pull out rolls: 4 pcs. Diameter of the pull out rolls: 60 mm Material thickness: 0,4 - 3,5 mm Feeding speed: 2 - 10 m / min Roll feeder Material width max.: 310 mm Material thickness: 3,0 mm Material thickness at max. width: 2,8 mm Material thickness at max. cross section: 850 sq mm Number of feeding rolls: 2 pcs. Diameter of feeder rolls : 80 mm Feeding speed: 104 m / min Required power: 1,5 kW Standard configuration Prodpfx Aouqfa Iomxob Coil loading unitStroke 500 mm Load capacity 5000 kg Material width max. 500 mm

Condition: used, Slitting line SECO 60″ x 0.375″ x 50,000Lb (A3791) is perfect solution for longitudinal coil metal cutting into strips with maximum metal thickness 0.375” and maximum coil width 60” Cold Rolled and Hot Rolled Steel 18-60” Strip Width 2 Speed Gear Box 200-500 FPM Thickness: .032″-.375” Complete Line with the Following Components: L-Type Entry Coil Car 40,000# Max Coil Weight Uncoiler: Coil ID: 23-30.50” Coil OD: 72” Maximum Coil Weight: 40,000# Maximum Sliding Base Hydraulic Expansion Pjdpfx Aotiy Ntjmxjrb Peeler and Hold Down Roll 5 Roll Coil Breaker Entry Adjustable Edge Guides Entry Crop Shear Slitting Head: 10” Arbors 40 HP Motor Drive 2 Scrap Winders Recoiler: Coil OD: 72” Max Coil ID: 24” 150HP DC Motor 3 Arm Exit Turnstile 40,000# per Arm Motorized Turn Complete Line with Knives, Rubbers, and Spacers Controls, Hydraulics, and Electrics

Condition: excellent (used), Year of construction: 2015, operating hours: 5,100 h, Power: 4,000 kN Bolster area: 3,000 x 1,400 mm (W x D) Clamping surface table: 2.950 x 1.500mm Clamping surface ram: 2,950 x 1,240 mm Daylight: 600 mm (stroke down and adjustment on top) Frequency: 5 - 100 rpm, infinitely variable Stroke: 20 - 200 mm, automatically adjustable Ram adjustment: 150 mm (motorized) Design: - With servo technology, speed of ram adjustable, possible to pendle - Table - clamping plates divided and manually adjustable - 8-fold sliding guide - motorized oil - central lubrication - automatic ram adjustment - pneumatic ram weight compensation - electromotive stroke adjustment - control Siemens + Fanuc - visualization Siemens Panel PC in mobile desk - tool safety device 8-fold - tool data memory - 2-channel press force measurement - Hydraulic overload protection - T-slots in table and ram - Longitudinal groove for tool centering in ram - Anti vibration machine feet - opening in the table Equipped with a complete decoiling line make Lorenz Decoiler Prjdpopvlf Ssfx Amxjb Load capacity: 80kN strip width: 20 - 820 mm Inner diameter: 470 - 520 mm Coil - outer diameter 1.800 mm Straightening machine strip width: max. 820 mm Strip thickness: 0,5 - 4,0 mm Straightenable cross section: 1.600mm² Number of rolls: 9 pcs, Ø 65 mm + 2 pcs feeding rolls Speed: 0 - 30 m/min Electronic roll feed Strip width: max. 820 mm Strip thickness: 0.5 - max. 6.0 mm Cross section: max. 2.400 mm² Number of rollers: 2 pcs. Ø 120 mm

Condition: good (used), Year of construction: 2003, functionality: fully functional, SOPREM Precision Coil Feeding Line (Decoiler + Straightener) — 2003. Complete matched feeding line for thin precision strip, ready to pair with a small high-speed stamping press. Decoiler — Type H1000.1000ZV. Max coil weight: 1000 kg. Coil Ø: 1000 mm outer / 375–520 mm inner. Reel speed: 2–20 rpm, 1.5 kW drive. Straightener — Type BR 19 . 160 . 12 . U . Strip capacity: up to 0.5 mm thick × 160 mm wide. Hydraulically driven precision straightening unit. Both units built 2003 · 400 V / 50 Hz · synchronized line with E-stop interlink to downstream press · Made in Switzerland. Technical Specifications Decoiler / Coil Reel (Haspel) H1000 / 1000ZV / 10M / LK.LF / N1 / G Prodszav H Sspfx Amxeb Serial No. (nameplate): 110103 Max coil weight: 1000 kg Coil outer Ø: max 1000 mm Coil inner Ø: 375–520 mm Reel speed: 2–20 rpm Motor: KSMV 90L (4), 1.5 kW, 1400 rpm Gearbox: RMI 110 FL LCB, ratio i = 70 Slip clutch: set to 400 Nm Strip sensing: floor contact plate (loop control) Precision Band Straightener (Richtwerk) BR19.160.12.U Function: straightens coil curvature before the press Max strip thickness: 0.5 mm Max strip width: 160 mm Drive: hydraulically driven precision straightening unit Electrical Supply 400 VAC, 50 Hz, 3-phase + neutral + earth Rating: 25 A pre-fuse

Condition: used, 72”x 0.5” x 60,000Lb Braner Turret Type Loop Slitting Line Podpfx Aorn Sqhemxjrb Braner Turret Type Loop Slitting Line is used for coil metal cross cutting with maximum width 72”, maximum 0,5” metal thcikness and 60,000Lb coil capacity Make: Braner Year New: 1996 Material Thickness: .060″ – .500″ Material Width: 12″ – 72″ Coil Weight: 60,000Lb Line Speed: 120 – 250 feet per minute Coil ID: 20″ – 24″ Coil OD: 75″ Slitting Cap: .500″ / 4 cuts – .125″ / 40 cuts Entry L-Type Coil Car Hydraulic Lift & Traverse Self Contained Hydraulics Control Panel Mandrel Uncoiler Powered Hold – Down Roll Outboard Bearing Support Hydraulic Feed-Up Drive Water Cooled Brake Hydraulic Peeling Table Driven Entry Pinch Rolls Adjustable Edge Guides Entry Mechanical Crop Shear Two Turret Type Slitting Heads Arbor Diameter: 12″ Powered Arbor Adjustment Powered Head Rotation Motor: 100HP DC Drive Lots of Knives & Tooling Two (2) Scrap Winders Powered Open / Close Heavy Duty Design Looping Pit Cross Over Table Drag Board Tension Stand Material Feeding Table Recoiler Hydraulic Drum Powered Push Off Hydraulic Over-Arm Separator Outboard Bearing Support 300HP DC Motor Drive Exit L-Type Coil Car Hydraulic Lift & Traverse Self Contained Hydraulics Upgraded Siemens Digital Drives, Electrics, Controls, Knives & Tooling

Year of construction: 1993, condition: used, material width 350 mm coil weight 2x 1 t material thickness 3 mm coil internal dia. 480-530 mm coil outside dia. 1400 mm Podpfxjlp U Rco Amxsrb

Condition: used, Coil line – Uncoiler and Leveler Pjdpfjif Sg Sjx Amxjrb Year of construction: 1991 Coil width: 50 to 450 mm Sheet thickness with inactive leveler: 6 mm Sheet thickness with active leveler: 2 mm - Very good condition and comprehensive operating instructions Space requirement of the entire system L x W: approx. 7000 x 3000 mm Weight of the entire system: approx. 11 tons Good condition Leveler HMS Type RS 47-04/1, Machine No. Coil width, nominal width: 400 mm Coil width, maximum passage width: max. 455 mm Coil thickness at 400 mm width: max. 1.5 mm (for steel) Coil thickness at 400 mm width: max. 2 mm (for copper) Speed: max. 40 m/min Number of leveling rolls: 7 pieces Leveling roll diameter: Ø 40 mm Number of tension rolls: 2 pieces Tension roll diameter: Ø 80 mm Infeed height, passage height: 1500 mm - Leveling rolls hardened, ground, and hard chrome-plated, with central support - Tension rolls hardened, ground, and hard chrome-plated, with hydraulic gap adjustment - Manual adjustment of the leveling rolls - Infeed guide with hydraulically extendable tongue and hydraulically adjustable idler roller - Adjustable lateral coil guide - All leveling rolls driven via distributor gearboxes with universal joints - Both tension rolls driven via gearboxes with universal joints - Frequency-controlled drive via geared motors - Leveler opening stroke 250 mm for cleaning the system or for processing thicker material, stroke movement via trapezoidal spindle - Ultrasonic loop control Transport dimensions L x W x H: 3600 x 2200 x 2200 mm Weight: approx. 4 tons Uncoiler HMS Type BA 1.5-06/80, Machine No. Coil weight: max. 8000 kg Coil outer diameter: max. 1600 mm (with loading table) Coil outer diameter: max. 2000 mm (without loading table) Diameter of the coil inlet disc: Ø 1700 mm Coil inner diameter, spreading range: 460-520 mm Coil width, nominal width: max. 630 mm Width of the spreading jaws: 750 mm Height of the uncoiler arbor above the base plate: 1500 mm - Drive of the uncoiler arbor via hydraulic motor and gear - Pneumatic retarder brake on the uncoiler arbor TWINFLEX - Hydraulic spreading of the uncoiler arbor, centrally via wedge slide system - Hydraulic pressure arm with hydraulically driven double rocker roller - Coil loading table with 12 tons lifting capacity and 300 mm stroke - Uncoiler in an above-floor running frame with motorized transverse travel drive Transport dimensions L x W x H: 3500 x 1900 x 2500 mm Weight: approx. 5 tons Central hydraulic unit, separate Tank capacity: 350 liters Drive power: 18.5 kW - Drive motor with 2 pumps REXROTH (tandem pump) - Oil cooler as an air heat exchanger with fan motor Transport dimensions L x W x H: 1600 x 850 x 1450 mm Weight: approx. 800 kg Electrical cabinet, separate - All cable connections are made via Harting connectors Transport dimensions L x W x H: 2800 x 500 x 2250 mm Weight: approx. 800 kg
