Used Scm Drilling Machine for sale (65,869)

Year of construction: 1995, condition: good (used), 3 drilling heads with 21 spindles each Hedpfx Ajih H Epedzjr 1 horizontal 21 spindles 2 vertical 21 spindles pneumatic clamps

Year of construction: 1994, condition: excellent (used), 29 spindles maximum width of the element 168mm left / right spindles Hedpsiclfbjfx Adzor 32mm spindle spacing electric adjustment of the angle of the aggregate 4 pneumatic clamps pneumatic extension of the drilling head power supply 380V

Condition: excellent (used), Multi-spindle drilling machine SCM Type FM 29/S Hedpfx Adsvxtfrezjr 29 spindles Distance 32 mm Table 1200 x 780 mm Max drilling depth for vertical drilling 100 mm/ horizontal 60 mm Spindle speed 3800/min

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Hedpfewuz Ekox Adzer Maximum edge height: 60 mm Total number of drilling spindles: 16 Total number of tool changer positions: 16

Condition: used, Year of construction: 1965, bore capacity in steel (diameter) 40 mm total power requirement 4 kW Hedpfev S Iqcjx Adzer

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Hodjrtrx Repfx Adzsr Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Year of construction: 2012, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: BCOR12150, BIESSE BREMA EKO 902 CNC and vertical dowel insertion machine for reduced cycle times Equipment Features - Clamping grippers measure the thickness to adjust drilling depth - Laser-based measuring system for detecting the front and rear panel edges - Length tolerance compensation correcting the workpiece length in X - 5-position tool changer - Drilling head with individually retractable spindles and grooving saw - Diameter: 120 mm - Gluing and dowel insertion units mounted on Y and Z axes Options - 4.5 kW electrospindle; 18,000 rpm Hodpfew Nytnsx Adzsr - Special drilling unit for hinges Technical Data - Panel length: 160 - 3200 mm - Panel width: 35 - 900 mm - Panel thickness: 8 - 80 mm - X/Y/Z axis speed: 100 / 60 / 30 m/min - X axis travel: 3200 mm - Y axis travel: 900 mm - Main spindle power: 4.5 kW - Number of controlled axes: 3 axes - Number of drilling spindles: 20 - Number of tool positions: 5

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: - Drilling capacity in steel ST 60: 28 mm - Drilling diameter in steel ST 60: 32 mm - Drill spindle mount: MK 3 - Right/left rotation - Drill spindle stroke: 150 mm - Drill spindle speeds, stepless: 80 - 1170 rpm - 2 feed rates: 0.1 / 0.2 mm/rev - Overhang: 290 mm - Max. distance table - drill spindle: 780 mm - Table with 2 T-slots: 480 x 400 mm - Height adjustable via rack and pinion with hand crank - Drive: 400 V / 0.9 / 1.3 kW - Space requirement, approx.: W 600 x H 2100 x D 900 mm - Weight, approx.: 420 kg - Includes: Hodpedkx Anjfx Adzer - Coolant system - Quick-change drill chuck 1-13 - Lighting

Condition: new, functionality: fully functional, travel distance X-axis: 565 mm, travel distance Y-axis: 210 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 50 rpm, total height: 1,120 mm, total length: 710 mm, total width: 890 mm, type of input current: DC, overall weight: 240 kg, table length: 840 mm, table width: 210 mm, power: 1.5 kW (2.04 HP), distance table to spindle center: 360 mm, WMD30LV - 230V / 1Ph Drilling capacity in steel ----- 32 mm Milling capacity in steel ----- 20 mm Face milling ----- 76 mm Motor ----- brushless 1.5 kW Spindle speed, stepless 50 - 3000 rpm Spindle travel ----- 70 mm Spindle mount ----- ISO 30 Work table ----- 840 x 210 mm Cross travel ----- 220 mm Longitudinal travel ----- 565 mm T-slots ----- 3x14 mm Overhang ----- 240 mm Distance spindle - table ----- 470 mm Weight ----- 230 KG STANDARD ACCESSORIES * Drill chuck incl. drill shank * Digital depth stop * Digital spindle display Hodpjga T Agsfx Adzer * Fine adjustment * Left / Right switch * Milling head, left / right, rotatable 90 degrees * Toolbox OPTIONS * 3-axis digital readout * Base cabinet * Automatic longitudinal feed * Milling vice * ISO30 collet chuck & 12 collets in case * Milling set

Condition: ready for operation (used), Year of construction: 2002, Professional, heavy-duty version by HANG (German quality) in neat, complete condition. Highly suitable for binderies, printing shops, and print departments. ⸻ Specifications • Brand / Model: HANG 107-30 electronic • Serial number: 102553 • Year of manufacture: 2002 • Number of drilling heads: 4 pieces, individually adjustable • Electronic control, automatic drilling cycle • Power connection: 400V – 50Hz – 6A • CE certification present • Cast iron frame, extremely robust construction • Manual and automatic operation • Adjustable stops with fine adjustment • Machine is mounted on swivel casters (easily movable) ⸻ Condition • Removed from production in working order • Drill spindles and guides run smoothly • No damages, normal signs of use • Immediately ready for operation • Complete, as shown in the photos ⸻ Description The HANG 107-30 is one of the most robust paper drilling machines on the market. Heavier-duty and more professional version than the standard models, thanks to the sturdy drilling heads, automatic drilling cycle, and reliable electronic control system. Perfect for calendar production, book blocks, brochures, index tabs, and more. ⸻ Price 👉 € 3,250 net (0% VAT export possible) Hsdpfox A Izljx Adzsr

Condition: used, Year of construction: 2005, functionality: fully functional, empty load weight: 1,300 kg, Horizontal drilling/pushing rig, complete with numerous extension rods. Hsdpfx Aozp Sa Eedzsr Bohrtec PZ 120/80. Year of manufacture: 2005. Weight: 1300 kg. Pushing force: 1200 kN. Pulling force: 800 kN. Length: 325 cm. Width: 60 cm. 46 x extension rod, 100 cm long, 22 cm diameter. 72 x extension rod, 100 cm long, 6 cm diameter. Crate with couplings and various accessories. See photos. Price net + 21% VAT or net for export. Calling or sending a WhatsApp message is the fastest way to contact us. We speak Dutch. We speak German. We speak English.

Condition: ready for operation (used), Year of construction: 1975, arm 1200MM stroke head on bench 1400MM universal head Hedsvm Akgspfx Adzor portable radial

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 8,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 20 m/min, feed rate Y-axis: 20 m/min, feed rate Z-axis: 10 m/min, workpiece weight (max.): 20,000 kg, Travel X-axis – Longitudinal column: 8,000 mm Y-axis – Vertical: 2,500 mm Z-axis – Ram extension: 1,000 mm W-axis – Spindle extension: 800 mm Headstock Spindle diameter: 150 mm Revolutions: 2,500 rpm Power: 40 kW Ram section: 460x520 mm Rapid traverse X and Y axes: 20 m/min Hjdpfozqlgzsx Adzer Z-axis: 10 m/min MG 20 rotary table Table dimensions: 1,600x2,000 mm Longitudinal movement, travel: 1,500 mm Maximum centered load capacity: 20 tons Accessories Automatic indexing headstock 1ºx1º (Power 37 kW) Heidenhain measuring scales on all axes Operator platform Chip conveyor Floor plates (2 units)

Condition: like new (used), Year of construction: 2013, functionality: fully functional, COLLECTIVE LISTING - 3 FICEP EXCALIBUR CNC BEAM DRILLING LINES Three refurbished CNC single-spindle beam drilling lines from the Ficep Excalibur series: two Excalibur 12 (1201 DE, year 2013) and one Excalibur 6 (601 DE, year approx. 2011). Together they form a graduated profile-processing line (up to 1,200 mm and up to 610 mm). EACH MACHINE AVAILABLE INDIVIDUALLY OR AS A PACKAGE. CONDITION & REFURBISHMENT (all three lines) All three machines have been refurbished and inspected by a certified technician, ready for operation. - The exact scope of reconditioning varies per machine and is disclosed individually upon serious interest. - Viewing possible by arrangement (machines reconditioned - no demonstration under power). === MACHINES 1 + 2: FICEP EXCALIBUR 12 / 1201 DE / YEAR 2013 === Two identical lines, serial numbers 33900 and 34062. CNC single-spindle beam drilling line based on the moving-column principle. The moving drill head with direct drive performs drilling, countersinking, tapping, milling and scribing in a single pass. - Profile cross-section: max. 1,200 x 800 mm, min. 50 x 50 mm | length up to 12 m | CE Hsdpfx Ajv Iamzjdzsr - Profile shapes: I-beams, channels, angles, flat bar, square/rectangular hollow sections - Drill head: 1, direct drive, 19 kW | 180-4,000 rpm | max. drilling diameter 28 mm - Drilling feed: ball screw, servo-driven | CNC axes: 5 - X-axis: travel 0-15,000 mm, 35 m/min | Y-axis: 12 m/min | rack and pinion - Tool changer: 6-position automatic (ATC), HSK A80 - Clamping: hydraulic double-acting | Profile detection: laser, non-contact - Coolant internal (through spindle) and external - Control: Ficep Pegaso CNC (PC/CNC/PLC integrated), remote diagnostics via network - Interfaces: DSTV, DXF, XML (Tekla) | Table: 15 m long, approx. 3,300 mm wide Scope of delivery per line: drilling unit 19 kW | support table with guide rail 15 m | 6-position ATC (HSK A80) | Pegaso CNC | radio remote control | coolant system. === MACHINE 3: FICEP EXCALIBUR 6 / 601 DE / YEAR APPROX. 2011 === Serial number 32754. More compact line with moving drill cabin, workpiece stationary on the clamping frame. - Profile cross-section: max. 610 x 610 mm, min. 30 x 30 mm | I-beam web height up to 610 mm - Max. machining length: 12,000 mm | X-axis traverse 0-12,000 mm, rack and pinion - Profile shapes: I-beams, angles, UPN channels, flat bar, square/rectangular tube - Drilling spindle: 1, 7.5 kW | max. drilling diameter 22 mm | manual change (quick-change chuck) - Operations: drilling, countersinking, tapping (with suitable tooling) - Clamping: double-acting automatic (top/bottom), min. 30 x 30 mm - Control: Mitrol CNC (Ficep Group) Scope of delivery: beam drilling line 601 DE | Mitrol CNC | traverse frame 12,000 mm | length measuring/positioning system X-axis (configuration confirmed during inspection) | automatic clamping system | quick-change chuck. Machine weights, rated voltage and footprint per line follow on request. LOGISTICS & LOCATION Location: Ulft (Netherlands), directly at the German border. Dismantling, transport, installation and commissioning by ASM by arrangement - individually calculated upon request. ABOUT ASM Arendsen Steel Machinery (ASM): specialist for refurbished Ficep structural-steel machinery. Further machines on request. CONTACT / INQUIRY Price on request - individually or as a package | Viewing by arrangement. Sale exclusively to commercial customers (B2B).

Condition: good (used), Year of construction: 2006, feed length X-axis: 1,650 mm, feed length Y-axis: 1,000 mm, Max. drill Ø steel: 5 - 40mm X - Travel: 1650mm Y - Travel: 1000mm W - Travel: 500mm Table size L x W / or ø:1200 x 1500mm Spindle taper: SK40Mk Speeds / ranges: 4200Rpm Length: 6500mm Hodpfswyup Tsx Adzjr Width: 3800mm Height: 3400mm Weight: 6500kg

Condition: used, bore capacity in steel (diameter) 15 mm throat 215 mm turning speeds 200 - 3600 U/min 350 x 300 mm total power requirement 1,0 kW / Volt tool taper MK 2 weight of the machine ca. 320 Kg dimensions 0,8 x 0,6 x 1,9 mm Hedpfxszpzb Sj Adzjr Bench drill - Base unit with drawers

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, Drilling / Milling Machine KNUTH MARK SUPER SV Year of construction: 2021 Travel X: 560 mm Travel Y: 190 mm Travel Z: 400 mm Spindle: CM4 Spindle exit: 120 mm Spindle speed: from 75 to 2500 RPM Table size: 800 x 240 mm Tilting head Scale 3 axes Electronic speed variator Automatic head up/down Automatic X axe travel Hjdpfx Aszqtc Rsdzjr Manual Y axe travel Supplied with many accessories: Boring heads, clamps holders, etc (see photos) Voltage: 380 V Length: 1400 mm Depth: 1200 mm Height: 2000 mm Weight: approx 500 KG

Condition: excellent (used), Cup band forming machine with press-in device Pneumatic clamps Foot pedal, stop rail and stand Some drills included Hsdpfet Tbutox Adzsr

Condition: ready for operation (used), spindle mount: MK 4, rotational speed (max.): 3,500 rpm, rotational speed (min.): 130 rpm, throat depth: 300 mm, Alzmetall AB 35 / S Drill press, column drill Pinole travel: 180mm Overhang: 300mm Spindle: MK 4 Hjdpozqy I Tefx Adzsr Drill chuck: 3-16mm Variable speed: 130 - 3500 rpm Feed rate: 0.1 - 0.2 - 0.3 mm/rev Threading device Coolant unit Vise You are welcome to visit us for an inspection. We will gladly arrange cost-effective shipping for you! You will receive a proper invoice. For foreign customers, a net invoice can also be issued. A valid VAT identification number is required. Subject to prior sale. Visit our shop and view our other offers. The company names and trademarks mentioned are the property of their respective owners and are used only for identification and description of the products. Deviations from technical data and errors in the description of the item may occur and are subject to change.

Condition: ready for operation (used), functionality: fully functional, Brierley Universal Automatic Drill Grinder Hsdpfx Adezlhlpjzor Model: ZB 32 Capacity: 2.5-32mm With Cams

Condition: ready for operation (used), functionality: fully functional, total width: 355 mm, total length: 381 mm, total height: 1,270 mm, grinding wheel diameter: 203 mm, Dormer Automatic Drill Grinder Hsdpjzlg Szjfx Adzjr Model: 108

Condition: good (used), machine/vehicle number: 10403, Standart Machine 4-head Hjdpfx Aezqr Sdsdzor

Condition: good (used), Year of construction: 1990, Unit with side support table External dimensions of drilling machine: Hedpozqfv Nsfx Adzor Height: 1700 mm Width: 700 mm Depth: 1500 mm Weight: approx. 320 kg External dimensions of the side table: Height: 1100 mm Width: 2600 mm Depth: 1410 mm Condition: good, second-hand

Condition: good (used), operating hours: 200 h, functionality: fully functional, machine/vehicle number: H05107, Bench drill press Knuth SSB 50nSuper MK 4 WORK AREA Drilling capacity 50 mm Threading capacity, steel M 30 Table clamping surface 580 mm x 460 mm Quill stroke 200 mm Manual table travel 515 mm Motorized table travel 405 mm Table swivel range (max.) ± 50° Column diameter 180 mm Distance from spindle nose to table surface 575 mm Distance from spindle nose to base 1165 mm Overhang 360 mm MAIN SPINDLE Speed range 50 rpm - 2000 rpm Spindle taper 4 MK FEED Hedpezqt U Hefx Adzer Quill feeds 0.08; 0.12; 0.17; 0.24; 0.35; 0.50 mm/rev

Condition: like new (used), Year of construction: 2011, machine/vehicle number: MA10110002, functionality: fully functional, SPECIFICATION Drilling capacity in mild steel 18mm Motor 0.45kW 415 volt Spindle 2MT Drive Belt, stepped pulleys Spindle speeds rpm 50Hz 400-700-1200-2100-3600 Spindle travel 75mm Hedpfxszmuntj Adzjr Throat depth 185mm Column diameter 70mm Table -working surface 250 x 164mm Table – slots width & centres 13 x 125mm Base – overall 240 x 360mm Max. distance chuck to table 330mm Overall height 865mm Overall width 280mm Overall depth 600mm Approx. Nett weight 77Kg Machine equipped with Chuck guard Table adjustment by rack Drill chuck
