Used Spinning Lathe for sale (6,089)

Condition: good (used), Make: Keilinghaus Type: PLS 1500 HY Specifications Metric US Standard Max. blank / workpiece over bed 3000 Max. blank / workpiece in the gap 5000 Ø Centre height over bed 1500 mm Distance between centers 2600 mm Maximum sheet thickness 15 mm Stroke X-Axis 1000 mm Stroke Y-Axis 2800 mm Speedrange 240 Rpm Power 75 kW Spindle taper head stock DIN 55027 - Size 15 DIN / Camlock Iiodpfskvnnksx Abmjf Stroke pinole quill 1200 mm Dimensions (Estimate) Length 10000 mm Width 8000 mm Height 4500 mm Weight 60000 kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Working diameter Ø 2400mm Iodpfxsucdh Te Abmsif Max sheet thickness: 9,5 mm

Year of construction: 2002, condition: excellent (used), More information on request Iiedoghg H Ejpfx Abmof

Condition: used, Year of construction: 1990, Technical details: number of spindles: 8 Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AFH130 with CNC Yob: 1990 eight-spindle automatic lathe 8 main spindles Chucker AFH130 for complete machining means front- and back side Control Siemens Sinumerik 840DI Iiodpezubyrsfx Abmjf complete revising and new configuration of this machine in year 2010. loading arm, for loading and disloading Workpiece turn around station in pos. 4 position 4 with workpiece length control CNC compound slide in pos. 5 coolant pump with magnet candle filter delivered tooling: could be different like pictures option: Ergomat TBF42 for cutting off for half finnishing with FMB-Turbo Visiting under production condition is possible Please, contact us for getting more information and pictures on mail(at) or *

Year of construction: 2008, condition: ready for operation (used), Main spindle: max. bar capacity: 65mm, draw tube bore: 75mm, collet holder diameter: 160mm, centering chuck diameter: 175mm, spindle nose: 140mm, max. speed: 5000/min, nominal torque (S1): 150Nm, nominal power (S1): 22kW. Counter spindle: draw tube bore: 45mm, centering chuck diameter: 175mm, spindle nose: 140mm, max. speed: 5000/min, nominal torque (S1): 100Nm, nominal power (S1): 16.8kW. W2 axis counter spindle: travel: 690mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. X1 axis: travel: 165mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. Z1 axis: travel: 220mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. X2 axis: travel: 165mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. Z2 axis: travel: 150mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. X3 axis: travel: 165mm, max. speed: 40m/min, max. acceleration: 10m/s², nominal thrust (S1): 2400N. Z3 axis: travel: 678mm, max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. Y3 axis: travel: 80mm (+50/-30), max. speed: 30m/min, max. acceleration: 5m/s², nominal thrust (S1): 5000N. Workpiece unloading (UA-WA): max. unloading weight: 4daN, max. unloading diameter: 70mm. Total number of tool stations: 12, tool holder diameter: 30mm, driven positions: 12, max. speed of driven tools: 4000/min, nominal torque (S1-n = 0/min): 17Nm, nominal power (S1-n = 4000/min): 2.9kW, control: Siemens 840D, operator panel: ErgoLine, screen: color TFT 19 inch, number of spindles (C-axes): 2, number of axes: 10, number of channels: 4. Operating hours: 70,035h power on, 48,657h in production, machine operates with cutting oil. With documentation and Bar Loader FMB Turbo 8-80 XT 3200. An on-site inspection is possible. Iodpfx Aeyln Ekebmoif

Year of construction: 2003, condition: ready for operation (used), A CNC twin-spindle lathe Gildemeister with a Y-axis is available. Bar capacity: 32mm, tool stations: 2x12, speed main and sub-spindle: 8000rpm, control: Siemens Sinumerik 840D Powerline, operating hours: 39426h, spindle hours: 25529h. Including coolant system, tools and short bar loader 1500mm Iemca Vip 80E. Documentation available. On-site inspection is possible. Expected to be available starting end of April 2026. Ijdpfoygw Svex Abmjif

Year of construction: 2015, condition: ready for operation (used), A CNC double-spindle lathe Traub overhauled in 2025 is available. Turning length: 450mm, spindle clearance: 65mm, speed: 4000rpm, main spindle/counter spindle power: 18.5kW/11kW, tool positions: 10, driven tools: 10, hydraulic capacity: 150l, hydraulic pressure: 60bar, connected load: 39kW. Rapid traverse X1/X2: 15m/min, feed force: 5000N, feed path: 140mm. Rapid traverse Z1/Z2: 30m/min, feed force: 8000N, feed path: 450mm. Rapid traverse Y1: 6m/min, feed force: 8000N, feed path: +/-35mm. Machine dimensions X/Y/Z: approx. 4150mm/2000mm/1800mm, weight: approx. 4750kg, control: Traub System TX 8F, operating hours: 12938h. Including chip conveyor and bar loader LNS Quick Load. Documentation available. On-site inspection is possible. Iiedpfxsv Scrbo Abmef

Condition: ready for operation (used), Year of construction: 2010, Max. workpiece diameter: 25mm, max. workpiece length: 100mm, max. bar diameter: 25mm, max. stroke X/Z: 42mm/50mm, rapid traverse: 40m/min, number of spindles: 6, speed: 12000rpm, control: Siemens 840D Powerline. Iedpfx Abotqfq Ujmoif

Year of construction: 2023, condition: ready for operation (used), Turning length: 705mm, turning diameter: 230mm, travel X1/X2: 165mm/195mm, travel Y: 100mm, travel Z1/Z2: 700mm/702mm, bar passage: 51mm, speed: 6000rpm, tool positions: 2x12. Machine dimensions X/Y/Z: approx. 5100mm/2200mm/2500mm, weight: approx. 8400kg, control: Fanuc 31i-B, operating hours: 1565h, spindle hours: 506h. Includes transformer, chip conveyor, filter system, and cooling unit. The cabin door window is broken. Documentation available. An on-site inspection is possible. Ijdpfxsxaphns Abmoif

Year of construction: 2023, condition: ready for operation (used), Turning length: 705mm, turning diameter: 230mm, travel X1/X2: 165mm/195mm, travel Z1/Z2: 700mm/720mm, bar passage: 51mm, speed: 6000rpm, tool positions: 2x12. Machine dimensions X/Y/Z: approx. 5100mm/2200mm/2500mm, weight: approx. 8200kg, control: Fanuc 31i-B, operating hours: 1407h, spindle hours: 343h. Includes transformer and chip conveyor. Documentation available. An on-site inspection is possible. Iodpfexaphujx Abmsif

Year of construction: 1992, condition: ready for operation (used), Turrets: 2, tool stations: 12, tool holder: VDI 40, max. turning diameter: 320mm, max. swing diameter: 390mm, spindle bore: 61mm, speed: 5000rpm, spindle power: 15kW, travel X/Z: 230mm/430mm, machine dimensions X/Y/Z: 3900mm/2000mm/2900mm, weight: approx. 8600kg. Including robot. Documentation available. On-site inspection is possible. Iiodeyhgpajpfx Abmof

Condition: ready for operation (used), Year of construction: 1997, A Mori-Say 6/32M multi-spindle curve lathe is available. Number of spindles: 6, max. spindle speed: 3750 rpm, max. bar diameter: 40mm. Dimensions X/Y/Z: approx. 6200mm/1600mm/2050mm, weight: approx. 9500kg. Iedotqfq Rjpfx Abmjif

Year of construction: 1977, condition: ready for operation (used), Two Schütte six-spindle turning machines including one Iemca bar feeder are available. 1) Schütte SF 42, year of manufacture: 1977, number of spindles: 6, max. bar capacity: 42mm, max. longitudinal slide stroke: 125mm, speed: 2240rpm, machine dimensions X/Y/Z: approx. 6500mm/1400mm/2200mm, weight: approx. 10000kg. Including pick-off spindle, cams, collets, chip conveyor, oil mist extraction system and Iemca PRA40/33/P bar feeder. 2) Schütte SF 51 DNT, year of manufacture: 1987, max. bar capacity: 51mm, number of spindles: 6, max. turning length: 102mm, max. drilling depth: 102mm, spindle circle diameter: 340mm. Including pick-off spindle, CNC cross slide in position 4, cams, collets, auxiliary coolant pump and chip conveyor. Documentation available. An on-site inspection is possible. Iiodjzbuuwjpfx Abmsf

Year of construction: 1992, condition: ready for operation (used), Number of spindles: 6, max. bar capacity: 42mm, max. machining diameter: 42mm, speed: 5000rpm, machining slides: 4, number of slides front/rear: 4/2. Machine dimensions X/Y/Z: approx. 7200mm/1700mm/2300mm, weight: approx. 10000kg. The machine has an electrical problem as a result of which the control does not start up. Documentation available. On site inspection is possible. Iisdpfjx Tum Sox Abmsf

Year of construction: 2018, condition: ready for operation (used), A high-precision Takisawa CNC lathe with double spindles is available. Spindle power: 2x 7.5kW, speed: 5000rpm, spindle nose: F-80, tool holder: 2x 5 places, max. turning diameter: 50mm, max. turning length: 50mm, max. workpiece weight: 2x 0.5kg. Machine dimensions X/Y/Z: approx. 2600mm/2550mm/2150mm, weight: approx. 4300kg, control: 2x Fanuc Oi-TF, operating hours: 11179h. Including hinged belt conveyor to the rear, automatic central lubrication, machine cladding with coolant pump, portal loader type D, Raku Raku loader, turning station, automatic loading and unloading door per spindle and storage chute for test part. Documentation available. On-site inspection is possible. Iiodpsu Dm Izjfx Abmof

Condition: used, TECHNICAL DETAILS - Number of spindles : 8 - Number of counter-spindles : 1 - Hirth teeth - Number of cross slides : 8 - Max. production : 50 [parts/min] SPINDLES * Max. bar diameter : 21 [mm] * Spindle speeds : 620-6000 [rpm] COUNTER-SPINDLE - Mechanical counter-spindle POWER SUPPLY - Supply voltage : 380 [V] WEIGHT & DIMENSIONS - Machine floor space : 4700x1200 [mm] - Machine height : 2250 [mm] - Machine weight : 5850 [kg] EQUIPMENT - CNC : Fanuc Power mate Iijdpfx Abswdahiomjf - Oscillating stop - Coolant tank - Bar loader : PRA 40/33F - Bar holder and stand

Condition: used, TECHNICAL DETAILS - number of spindles : 6 independent - bar clearance : 32 [mm] - maxi spindle speed : 6 300 [rpm] - machine equipped with 32 numerical axes - slide unity 1.1 : X and Z axes controlled by CNC - slide unity 1.2 : fixed X axis, Z axis controlled by CNC Iedpfxouhaxlj Abmjif - slide unity 2.1 : fixed X axis, Z axis controlled by CNC - slide unity 2.2 : X and Z axes controlled by CNC - slide unity 3.1 : X and Z axes controlled by CNC - slide unity 3.2 : fixed X axis, Z axis controlled by CNC - slide unity 4.1 : X and Z axes controlled by CNC - slide unity 4.2 : fixed X axis, Z axis controlled by CNC - slide unity 5.1 : fixed X axis, Z axis controlled by CNC - slide unity 5.2 : X and Z axes controlled by CNC - slide unity 6.1 : X and Z axes controlled by CNC - slide unity 6.2 : X and Z axes controlled by CNC - counter-spindle position 6.1 EQUIPMENT - INDEX C200-4 control (Siemens SINUMERIK 840D) - Simple NCU - IEMCA SIR MS32/33/P bar loader - Coolant tank with HP pump - KNOLL chips conveyor - Parts catcher with conveyor in position 6 - Cross drilling device in position 3.1 et 4.1

Condition: used, TECHNICAL DETAILS - maxi diameter : 26 [mm] - maxi feeding length : 125 [mm] - spindle speed : 366 – 5020 [rpm] - number of spindles : 6 - central block stroke with cone : 85 [mm] with hydraulic : 200 [mm] Iisdpsuhanajfx Abmef - cross stroke with cone : 36 [mm] with hydraulic : 56 [mm] - dimensions : 5 728 x 1 080 x 1 816 [mm] - weight : 5 200 [kg] EQUIPMENT - sub-spindle - foot and drum

Condition: used, TECHNICAL DETAILS - Number of spindles : 9 - Bar capacity : 26 [mm] MAIN SPINDLES 1 TO 6 - Nominal torque : 18.5 [Nm] - Max. spindle speed : 7000 [rpm] - Stroke X : 70 [mm] - Stroke Z : 125 [mm] MAIN SPINDLES 8 AND 9 - Nominal torque : 15 [Nm] - Max. spindle speed : 10000 [rpm] - Stroke X : 110 [mm] - Travel Z : 125 [mm] COUNTER SPINDLE 7 - Nominal torque : 15 [Nm] - Max. spindle speed : 10000 [rpm] - Stroke Z : 300 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Installed power : 109 [A] DIMENSIONS - Floor dimensions : 9.100 x 1.805 [mm] - Machine height : 2,800 [mm] - Machine weight : 18.500 [kg] MACHINE HOURS Iodpfxjuhaq Ie Abmjif - operating hours : 82000 [h] EQUIPMENT - CNC Siemens Sinumerik 840D - Chips conveyor - Bar loader : SIR 36/33 F - Coolant tank : KNOLL VRF 450/2600 * with high pressure pump * with paper filtration * capacity : 2600 [l]

Condition: used, TECHNICAL DETAILS - bar clearance : 5-20 [mm] - maxi part length (without counter operation) : 100 [mm] - maxi part length (with counter operation) : 80 [mm] - spindle rotation speed : 5 000 [rpm] - spindles maxi power : 15 [kW] - drilling/tapping maxi power : 3.7 [kW] - number of numerical axes : 23 - number of cross slides : 8 - counter operation slide : 1 - end units : 7 - number of sub-spindle : 1 - sub-spindle motor power : 1.1 [kW] - dimensions : 5880 x 1400 x 1950 [mm] - weight : 7 200 [kg] Ijdjuhaq Uspfx Abmoif EQUIPMENT - TORNOS PNC DECO control - HIRTH teeth drum locking - high pressure pump - chips conveyor - turning tools-holders - IEMCA PRA 40/33F bar feeder - number of hours 31600

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Max. bar diameter : 32 [mm] - Spindle speed : 6300 [rpm] - slide unity 1.1 : X and Z axes controlled by CNC - slide unity 1.2 : X and Z axes controlled by CNC - slide unity 2.1 : X and Z axes controlled by CNC - slide unity 2.2 : X and Z axes controlled by CNC - slide unity 3.1 : X and Z axes controlled by CNC - slide unity 3.2 : X and Z axes controlled by CNC Iijdpfx Abjuhatpjmjf - slide unity 4.1 : X and Z axes controlled by CNC - slide unity 4.2 : X and Z axes controlled by CNC - slide unity 5.1 : X and Z axes controlled by CNC - slide unity 5.2 : X and Z axes controlled by CNC - slide unity 6.1 : X and Z axes controlled by CNC - slide unity 6.2 : X and Z axes controlled by CNC - synchronous unit, spindle position 6.1 EQUIPMENT - CN SIEMENS 840D - Counter spindle - Polygonal milling device : 5.1 carriage unit - Bar loader : IEMCA SIR MS32/33 P - coolant tank KNOLL * with high-pressure pump - chip conveyor KNOLL - Cooling unit - Parts catcher - Ejection of workpiece - Fire extinguisher : KRAFT UND BAUER * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer

Condition: used, Multispindle lathe SCHÜTTE AG 20 Iijdpfx Ajzhcqrjbmef

Condition: used, Cnc multispindle lathe INDEX MS 32C Iisdezpznlepfx Abmjf

Condition: used, TECHNICAL DETAILS - Number of axes : 17 - Max. bar diameter : 25.4 [mm] - Spindle speeds : 5000 [rpm] - Spindle power : 18 [kW] Ijdpfx Abewuu Rgemoif WEIGHT & DIMENSIONS - Machine floor space : 3500 X 1600 [mm] - Machine height : 1950 [mm] - Machine weight : 8500 [kg] MACHINE HOURS - Number of hours under power : 33026 [h] EQUIPMENT - CNC : TORNOS TB DECO - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Cooling unit - Bar loader : TORNOS Robobar MSF 522

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Crosses slides, in position : 1,2,4,5 - Max. travel of transverse slides : 28 [mm] - Max. travel of crossed slides : 45 [mm] - Max. travel of front spindles : 63 [mm] Iiedpfx Abjwvvrbomof SPINDLES - Max. bar diameter : 16 [mm] - Spindle speeds : 400 - 6000 [rpm] - Spindle power : 15 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 43 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.800 x 1.100 [mm] - Machine height : 2.300 [mm] - Machine weight : 4200 [kg] EQUIPMENT - Double mechanical cut and return slide, in position : 6 - Rotary front spindles, in position : 1,2,3,5 - Parts catcher - Parts conveying strip - Bar waste chute - Chips conveyor - Coolant tank - Bar loader : Iemca PRA 40/31/P - Bar holder and stand - Bar holder housing
